I N S T R U C T I O N M A N U A L
MP4 PLAYER
MP-3134-2G
DEAR CUSTOMER
In order to achieve the best performance of your product, please read this instruction manual carefully
before using, and keep it for future reference.
If you need extra support, please write to inf[email protected]

P-1
CAUTION
RISK OF ELECTRIC
SHOCK, DO NOT
OPEN
Caution: To reduce the risk of electric shock do not open
this device, there are not serviceable parts for customers.
Please refer any maintenance or repair to qualified
personnel.
This sign means the existence of dangerous voltage at
the inside of the unit, which states a risk of electric shock.
This sign means that there are important instructions of
operation and handling in the manual that comes with
this
device.
PREMIER CUSTOMER SERVICE
Venezuela: 0800 – ELECTRIC (353-2874)
Colombia: 01-900-331-PEJC (7352)
Panama: 300-5185
Website www.premiermundo.com
E-mail: [e-mail]
NOTE
This unit may be submitted to changes in specifications, characteristics and/or operation without prior
notice to the user, in order to continue improving and developing its technology.

P-2
Catalogue
Declaration………………………………………………………………………………..………………………3
Unique Features………………………………………………………………………………….………………3
Locating the controls ………………………………………………………………………….……………...…4
Appearance & keys…………………………………………………………………………….……………… 4
LCD Window …………………………………………………………………………………...……………… 4
Electricity quantity display………………………………………………………………………………….. …4
Basic Operation…………………………………………………………………………………………………..4
Entering Menu System…………………………………………………………………………………………. 4
Browsing……………………………………………………………………………………………………..……4
Entering Different Modes…………………………………………………………………………………… …4
Volume Control……………………………………………………………………………………….…….…… 5
Turn On/off……………………………………………………………………………………………….……… 5
Play & Stop…………………………………………………………………………………………………….… 5
Record/Pause…………………………………………………………………………………………….………5
Keys Operation…………………………………………………………………………………………….…… 5
Keys function definition………………………………………………………………………………….………5
Keys operation definition………………………………………………………………………………...………5
Play Music………………………………………………………………………………….……………..………5
Basic Operation………………………………………………………………………………………………… 6
EQUALIZER MODEL …………………………………………………………………………………..………6
The lyric Display (with Microphone function) in step…………………………………………………………6
Play movie ……………..………………………………………………………………………………..……… 6
Record Voice ………………………………………………………………………………………….……… 7
Record voice in “recording mode” ……………………………………………………………………..…… 7
Play Recorded files………………………………………………………………………………………………8
How to use FM………………………………………………………………………………………………….. 8
Browse of JPEG………………………………………………………………………………………………… 8
Playing images status……………………………………………………………………………………...…... 8
System setting…………………………………………………………………………………………………… 9
Parameters introduction………………………………………………………………………………………… 9
Detailed applying directions………………………………………………………………………………….… 10
Recording time set………………………………………………………………………………………….……10
LCD set……………………………………………………………………………………………………………10
Language selection………………………………………………………………………………………………10
Power off set………………………………………………………………………………………………..…… 10
Interface selection………………………………………………………………………………………….……10
Replay mode set…………………………………………………………………………………………………10
Online mode………………………………………………………………………………………………..…… 10
Memory info. ……………………………………………………………………………………………….…… 10
F/W version……………………………………………………………………………………………………… 10
F/W upgrade……………………………………………………………………………………………..……… 10
Electronic Book………………………………………………………………………………………….……… 11
Games…………………………………………………………………………………………………………… 11
TEL-BOOK……………………………………………………………………………………………………… 12
USB disk……………………………………………………………………………………………..……………12
Player Upgrade………………………………………………………………………………………………….. 13

P-3
Choose different directories……………………………………………………………………………………14
Deleting files……………………………………………………………………………………..………………15
Playing Mode……………………………………………………………………………………….……………16
Tempo Rate………………………………………………………………………………………………………16
Replay Mode……………………………………………………………………………………….……………16
A-B………………………………………………………………………………………..……………16
Follow reading…………………………………………………………………………………………16
Replaying times…………………………………………………………………..……………………16
Replay Gap………………………………………………………...……………..……………………16
Strong Recommendation………………………………………………………………………………………..16
Private space Function……………………………………………………………….…………….…17
Follow accessory…………………………………………………………………………………………….…...17
Trouble shooting…………………………………………………………………………..……………… ……..18
Specification………………………………………… ……………………………………………………………19
PREFACE
The MP4 player is a new generation of digital portable device, supporting multiple music formats
including MP3, WMA, AMV and WAV, etc. Its perfect sound quality, great reliability and exquisite
appearance make it a masterpiece. Devoutly hope to bring you great enjoyment in this digital age
.
Declaration
Thank you for your purchase.
Please read this manual carefully before using your new player.
Contents in this manual may change possibly for better service.
We have the right to make changes to this manual because of performance and function without notice.
If the real settings are not corresponding to the directions in this manual, please visit our website for
detailed information of the newest
version.
Unique Features
●AMV film function
●Browsing JPEG BMP GIF function
●Exquisite Appearance
Unique appearance designed as a gold brick and comfortable for handling
●Multi-Code Player
Supporting MP3, WMA, AMV, and WAV formats
Firmware Upgrade
Download the newest upgrade software to realize the function expansion of this player.
●FM Stereo Radio Function
You may easily listen to FM stations and set your favorite stations by using Auto Preset or Manual
Preset. The player can save 40 (20 for each Band) local stations at different frequency.
●Drive Free U Disk
You may manage your files directly through “Portable Disk” in “My Computer” on Winows2000 Operating
System or above without driver.
●“Private Space” Disk Mode
The flash memory can be divided into two parts by using the accessory tools and one is encrypted to
hide the contents saved inaccessible by others. Keep Your Secret!

P-4
●Record/ Replay
The player supports recording through built-in microphone and saves as WAV and MP3 formats.
Meanwhile it supports real digital A-B replay or comparison replay.
●7 Presets EQ
Normal, Rock, Pop, Classic, Soft, Jazz and DBB
●Multiple Repeat Mode
Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random, Intro.
●Power Off
You may set Sleep Timer or Off Time mode in your own convenience.
●GUI (Graphic User Interface) Menu
Vivid animation menu with corresponding characters make it easy to operate.
1. Locating the Controls
appearance & Keys
LCD Window
●Electricity quantity display
When the electricity quantity is 3.7V, the display shows .
With the time up, the display of the electricity quantity will reduce. When the battery is almost used up, the battery mode will
change into blank . You should recharge the battery in time.
▼. When power run out, turn on the power switch before recharging, or the player may not be recharged.
▼. When recharging the player, you need to turn off the charger power, it is normal that the player still works in USB mode, if
you want to exit from USB mode, cut off the connection between the player and charger.
▼. Power off when the player is not working.
2. Basic Operation
Entering Menu System
Pressing MENU button may enter the different menu system, including main menu (long press of MENU key at Stop mode),
submenu at Play mode (press to enter) and submenu at stop mode (press to enter).
Browsing
○Choose and browse music files from Menu
○Fast forward or fast backward when playing music
Entering Different Modes
You may enter different modes from the main menu.
Main menu: (long press MENU button)

P-5
●Volume Control
Press VOL, then press:
“PREV”: turn up the volume.
“NEXT”: turn down the volume.
●Turn On/Off
Long press, “Play” to turn on or turn off (Check whether the player is Power on)
●Play& Stop; Exit from submenu
In the music model press the” play” key for a short time to play the music, and press it again to stop the music playing.
●Record /pause (short press), Stop recording (long press)
As for the recording mode, press “play” to pause, long press “play” to stop recording.
3. Keys Operation
●Keystroke operation definition
1.On “OK”:boot-strap/play/stop
2. “MENU” chooses option. Come into menu.
3. ”ON/ OFF”: power switch
4.”VOL”: Press VOL, then press: “ PREV”: turn up the volume. “ NEXT”: turn down the volume.
5. “NEXT”: Next item, Swiftness addition.
6. “PRE”: PREV item, Swiftness reduces
7."USB”: USB connector plugs.
8. Earphone standard jack
●Keystroke action definition
Keystroke action comprise short press 、 long press 、 press 、 single press four genus handle means. Back except in particular
explain 、 all belong to short press.
Short press: press once Keystroke. At once become effective.
Long press: press once Keystroke. Excess 1.2 second doesn’t leave go off just go into effect and that just once.
Single: press once keystroke. As far as leave go of time moment just go into effect.
Press: Press once keystroke until leave goes of process. Events will take into effect according to the times of some frequency,
for example: “Fast forward or Fast backward”.

P-6
4. Play Music
●Basic Operation
Connect the earphones
Long press “PLAY” to turn on, Short press” MENU” to Enter “Music Mode”,
Press button “Play” to play music.
To select music:
PRE: to select previous music
Next: to select next music
To adjust the volume: press VOL
And then press “NEXT”: turn up the volume.
press“PRE”: turn down the volume.
5. When the player charge by USB , if you want to play music, you need to turn the power switch on.
●EQUALIZER Mode
Playing music status
Press MENU button for a shot time to enter Play Submenu
Push Next switch to select Equalizer menu
Press MENU button to enter EQUALIZER selection Menu.
Different EQ, the menus as following:
Push Next button to switch, and press MENU button to confirm selection.
●The lyric Display in step
This player supports “*.LRC” lyric files, and lyrics may be displayed synchronously while playing music.
How to use lyric files?
Save the lyric file with the same name as that of the corresponding music file.
e.g.: Music file name: IDO-SHIYE.mp3
Lyric file name: IDO-SHIYE.Irc
How to know whether the lyrics exist?
1.Find out matching lyric file:
2. Long press MENU to enter the Lyric Interface.
3. Browse lyrics manually.
4. Short press MENU to come back the music mode.
5. Play Movie
●Basic Operation
Connect the earphones
Long press “PLAY” to turn on, Short press” MENU” to Enter “Movie Mode”,
Press button “Play” to play Movie.

P-7
To select Movie:
PRE: to select previous Movie
Next: to select next Movie
When the movie pause to adjust the volume
To adjust the volume: press VOL
And then press “NEXT”: turn up the volume.
press“PRE”: turn down the volume.
6. When the player charge by USB, if you want to play music, you need to turn the power switch on.
6. Record Voice
Make sure that the battery is not in the status of “low battery”.
The player may save 99 recording files under each directory.
●Start recording in Record Mode
Enter main menu.
Push Next switch to select recording mode.
Press Menu button for a short time to enter Record mode.
Press Play button to start recording.
▼. The recorded file is saved in the current folder set in “Recording Stop submenu/ /Local Folder”.
▼. If “Overflow” is displayed on the LCD, the player’s memory is full. Please delete other files to make some space available.
▼. If “over record” is displayed on the LCD, the current directory has already had 99 recording files. Please switch to another
directory.
▼.Only “play ” button is effective during the recording time.
Select Recording Type
1. On the status of Stop Recording
2. Press MENU key for a short time to enter the Record Submenu.
3. Push Next key for a short time to select REC Type option
4. Press MENU to enter this option
5. Push Next to select desired recording type
6. Press MENU to confirm the type selected
7. Press Play to start recording
Recording Type:

P-8
7. Play Recorded Files
Enter main menu.
Push Next to select “Voice mode”.
Press MENU to enter Voice mode interface.
Press Play to start playing.
Select recorded files:
PRE: to select the previous recorded file
Next: to select the next recorded file
Control the volume
press VOL
And then press “NEXT”: turn up the volume.
press“PRE”: turn down the volume.
8. How to use FM
1. Enter main menu.
2. Push Next switch to select FM Mode.
3. Press MENU button to enter FM mode
4. Manual search: Push PRE/Next button and the player forward or backward single step 100KHZ to manual search station ；
5.Auto search: Push on PRE / Next button for about 2 seconds, and the player scans forward or backward per 100 KHz, and
stops at the scanned station. If you want to stop scanning, push PRE / Next switch to stop.
6.Save manual scanned stations.
Press MENU for a short time to enter FM submenu., Press MENU again to save the sation.
7.Choose stations saved previously.
If there are more than one station, you can listen to the station by pressing “Play” in a backward sequence.
8.Record radio files function
when you are listen to FM Radio, you can record those programs you prefer. Press MENU for a short time, enter FM
submenu ”choose fine recording or long time recording ”, then you can save them into recording files.
9.Volume control
press VOL
And then press “NEXT”: turn up the volume.
press“PRE”: turn down the volume.
▼.US Band and Japan Band can save maximum 20 stations respectively.
▼.Delete stations: please refer to “delete files in the next section.
9. Browse of JPEG
JPEG interface file selection choose file”05.jpg” as following:
If no files, the directory is empty.
Press the “play” button and browse JPEG
Press the “Next/PRE” button to selects the next/PRE file.

P-9
Press the “MENU” button, enter the stop submenu.
1. Local folder 2.play set 3.delete 4.delete all 5.exit
Play set: manual play and auto play
The Auto turning page time is set for 2-10 seconds, other buttons are ineffective.
Enter the browsing picture:
Press the “Next/PRE” button to play the next/PRE picture
Press the” play” button back to the document choice status.
Long press the “MENU” button to enter pervious menu
10. System Setting
System parameters can be set here and every option varies according to firmware upgrading.
Enter main menu, push Next button to select System setting icon, and then press MENU button to enter System Setting
submenu interface is as follows:
Parameters Introduction
Display
style Style one Style two
（ System
time ）
Set the time and date when recorded files are
saved
(REC type) Voice record WAV Music record Mp3 Music
record
（ LCD
set ） Set the LCD light
（ Languag
e ） Set different languages displayed
（ Power
off ）
Set a fixed time after which the player may turn
power off automatically
(Replay
mode ） Set working status on Replay Mode
（ Online
Mode ）
An option specially designed for “Private Space”
function
（ Memory
info. ）
Show memory capacity and percentage that has
been used
（ F/W
version ） Show firmware version
（ F/W
upgrade ） Special for firmware upgrading
（ Exit ） Exit from current interface
