Prestigio REVOLT A3 User manual

PRESTIGIO®
REVOLT A3
Wireless charger
User Manual

REVOLT A3
2
©2020 Prestigio | All rights reserved | version 1.0
EN
Contents:
Read Before Using 3
Benefits of Prestigio Revolt A3 Smart Dock 5
Product Bundle 6
Components and Interface Elements 7
Technical Specifications 8
Operation Guide 9
LED Indicators 13
Troubleshooting 14
Safety Guidelines 17
Care Recommendations 18
Transportation and Storage Rules 19
Waste Disposal 20

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
3
EN
Read Before Using
Thank you for choosing the Prestigio Revolt A3 wireless
charger. To ensure that you are using the charger correctly
and safely, please read this manual before you start. Do
not discard the manual, as you may have to refer to it in
the future.
Please note that the design and position of certain
elements may differ from the images and descriptions you
will find below because, as part of its commitment to
continuous improvement, the manufacturer reserves the
right to alter the charger's specifications without prior
notice.
The company will not be held liable for damage caused by
improper use of the charger.
The purpose of this manual is to provide information, and
it does not constitute any overt or covert warranty.
For the latest updates, go to www.prestigio.com.

REVOLT A3
4
©2020 Prestigio | All rights reserved | version 1.0
EN
Benefits of Prestigio Revolt A3 Charger
The Prestigio Revolt A3 wireless charger is designed for
your comfort. Its design and operation principles allow you
to position it as conveniently as possible, so that it won't
get in the way and won't become an eyesore.

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
5
EN
Product Bundle
Prestigio Revolt A3 wireless charger 1 pc.
Power adapter 24V/1A 1 pc.
Charging pad 1 pc.
Quick user guide 1 pc.
Warranty card 1 pc.

REVOLT A3
6
©2020 Prestigio | All rights reserved | version 1.0
EN
Components and Interface Elements
1. DC input for the power adapter
2. LED indicator
3. Ventilation holes

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
7
EN
Technical Specifications
Dimensions
115*115*21 mm (h*w*d)
Power capacity
24V/1A
Wireless charging
interface
5/7.5/10W
Optimal use range
15-35 mm

REVOLT A3
8
©2020 Prestigio | All rights reserved | version 1.0
EN
Operation Guide
1. Choose where you will place the wireless charger.
Attention. Make your choice very carefully. Before
mounting the charger, ensure that the power adapter's
cable length will be sufficient for comfortably plugging it
in.
2. Using double-sided tape, attach the charger to any non-
metal surface.

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
9
EN
Attention. Determine where you want the DC port to be
in advance, then mount the charger with the port's
position in mind.
The surface where you will be mounting the charger must
be between 15 and 35 mm thick. This is the device's active
range.
4. Place the charging pad on the other side of the surface
you chose, ensuring that the pad's center aligns with the
center of the charger. The pad will focus the charger's
emissions on your smartphone.

REVOLT A3
10
©2020 Prestigio | All rights reserved | version 1.0
EN
Attention.While charging, do not place any metal objects
(including paper clips, coins, keys, etc.) or plastic bank
cards between the smartphone and the charging pad. This
may damage your smartphone or its case, the charging
pad, or the object within the charger's active range.

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
11
EN
5. Plug the wireless charger in, using the included power
adapter.
6. Place your smartphone in the center of the charging pad.
Please note that the smartphone must support wireless
charging.

REVOLT A3
12
©2020 Prestigio | All rights reserved | version 1.0
EN
LED Indicators
Red light
The wireless charger is plugged in
and on standby.
Green light
The wireless charger is plugged in
and in use.
The LED
indicator is
blinking red
once every
second
The charger is malfunctioning.
Please consult the Troubleshooting
section.

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
13
EN
Troubleshooting
The charger is not
working. The LED
indicator is dark
- Use only the original power
adapter
- Ensure that the charger has
been plugged in
- Ensure that the socket you
have plugged the adapter into
is receiving power
The LED indicator is
red, but the phone is
not charging
- Ensure that your smartphone
supports wireless charging
- Ensure that the thickness of
the surface that separates the
wireless charger and the
charging pad falls within the 15-
40 mm range.
- Ensure that your smartphone
is properly aligned with the
charging pad

REVOLT A3
14
©2020 Prestigio | All rights reserved | version 1.0
EN
- Try repositioning your
smartphone by moving it a little
in different directions
The LED indicator is
blinking red once
every second
- Use only the original power
adapter
- Ensure that no other objects
were placed between the
charging pad and the
smartphone
- Try repositioning your
smartphone by moving it a little
in different directions
- Unplug the charger and let it
rest at least 30 minutes, then try
again. The device could be
malfunctioning because it is
overheating in a warm room or
because it lacks natural
ventilation.
The problem isn't
solved
If this didn't solve your problem
or if you have additional
questions, please contact

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
15
EN
customer support. The contact
information is provided in the
warranty card.
Safety Guidelines
1. Use the charger only for its intended purpose.
2. Use only the power adapter supplied with the charger
3. Do not disassemble the charger or try to alter its
structure or design. If the device needs maintenance or
repair, take it only to an authorized service center.
4. If you have run into an issue, or if any part of the charger
has been damaged, stop using it immediately, unplug it,
and contact a service center.
5. The charger cannot come into contact with moisture, oil,
chemicals, or any organic fluids. We do not recommend
using the charger in areas with high humidity.

REVOLT A3
16
©2020 Prestigio | All rights reserved | version 1.0
EN
6. Do not use the charger in very dusty places.
7. Keep the charger and its accessories out of the reach of
children.

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
17
EN
Care Recommendations
Clean the charger with a soft, dry cloth or with alcohol-free
wipes for cleaning office equipment.

REVOLT A3
18
©2020 Prestigio | All rights reserved | version 1.0
EN
Transportation and Storage Rules
1. The charger is not intended for use in residential,
business, or industrial zones with a hazard risk.
2. We recommend storing and using the charger in
environments where temperatures range from 0 °C to +40
°C and the relative humidity is 10~80%.
3. Long-term storage is permitted only in the charger's
original packaging in dark, dry, clean, well-ventilated
enclosed spaces.
4. The charger may be shipped by any means of transport
across any distance, but it must be shipped in its original
packaging.

REVOLT A3
©2020 Prestigio | All rights reserved | version 1.0
19
EN
Waste Disposal
Do not dispose of the charger and its accessories with
regular household waste. At the end of their service life,
take them to an electronics recycling facility.

© 2020 Prestigio. All rights reserved. All names and trademarks, as well as logos and other symbols mentioned herein
are the property of their respective owners. Prestigio reserves the right to amend this document without prior notice
to its customers, and it will not be held liable for any negative consequences that may result from technical and/or
typographic errors in this document and/or from using an outdated version of this document.
prestigio.com
