Prestigio NOBILE 156 User manual

1
PRESTIGIO NOBILE 156
ENG
Prestigio Nobile 156 - User’s guide
Preface
Thisnotebookcomputerincorporatesthelatestmobiletechnologiesinaslimandportablepackage.Thismanualshould
answermostofthequestionsyouhaveabouttheday-to-dayoperationofyournotebookcomputer.You should also take
advantageoftheonline help files that are availablewithalmostalloftheprograms shipped with yourcomputer.
We hope you enjoy your notebook computer.With proper care,your computer will provide you with years of productive
service.
Connecting the computer
Connectingthecomputerisaseasyas1-2-3.
1.Insertthebatteryatanangle(1);pressgentlyonthebattery
(2)untilitclicksintoplace. Then slidethebattery lock tothelock
position(3).
Note: When using a battery pack for the first time, fully
recharge the battery, then disconnect the adapter to use up
the battery before recharging again. Perform this action
twiceto condition the battery pack.
2. Connect one end of the AC adapter to the DC-in port on the
computer’s rear panel (1);connect the power cord to the AC
adapter (2) and the other end to a properly grounded power
outlet(3).
3.Press the display cover release latch (1) and open the display
(2)toacomfortableviewingangle. Press the power switch (3)
to turn on the power.The POST (power-on self-test) routine
executesand Windowsbegins loading.

2PRESTIGIO NOBILE 156
ENG
Front view
# Item Description
1 Display cover latch Press to unlatch the display cover.
2 Optical drive Accepts a CD or DVD
3 LED indicator Lights up when the optical is active
4 Eject button Press to eject the drive tray
5 Emergency eject hole Insert a pin to eject the drive tray when power is off
Top view
# Item Icon Description
1 Display screen Also called LCD (liquid-crystal display),displays computer output.
2 Status indicators LEDs (light-emitting diodes) that turn on and offto show the status
of the computer and its functions and components
3 Power button Turns on the computer power

3
PRESTIGIO NOBILE 156
ENG
# Item Icon Description
4 Launch keys Buttons for launching frequently-used programs
5 Touchpad Touch-sensitive pointing device which functions like
a computer mouse
6 Microphone Inputs sounds and voices into your computer
7 Click buttons The left and right buttons function like the left and right mouse
(left, right, and center) buttons
8 Palm rest Comfortable support area for your hands when you use the computer
9 Keyboard Inputs data into your computer
Left view
# Item Icon Description
1 Volume control Adjusts the volume.
2 Memory Stick/Secure Digital Accepts a Memory Stick, Secure Digital (SD) or MultiMediaCard (MMC)
card slot (option) memory card.
3 PC Card slot Accepts one Type II 16-bit PC Card or 32-bit CardBus PC Card
4 PC Card eject button Ejects the PC Card from its slot
5 Infrared port (option) Interfaces with infrared devices (e.g.,infrared printer, IR-aware
computer).
Right view
# Item Icon Description
1 Security keylock Connects to a Kensington-compatible computer security lock.

4PRESTIGIO NOBILE 156
ENG
Rear view
# Item Icon Description
1 DC-in jack Connects to an AC adapter.
2 S-video out port Connects to a television or display device with S-video input
3 External monitor port Connects to a display monitor (up to 2048x1536 resolution).
4 Parallel port Connects to a parallel device (e.g., parallel printer).
5 Modem jack Connects a phone line (only for models with an internal fax/data
modem).
6 Network jack Connects to an Ethernet-based network.
7 IEEE 1394 port Connects to a IEEE 1394-compatible (4-pin) device
(e.g., digital video camera).
8 USB ports Connect to USB devices (e.g., USB digital camera
9 Line-in jack Accepts audio line-in devices (e.g., audio CD player, stereo walkman).
10 S/PDIF line-out jack Connects to audio line-out devices (e.g., speakers, headphones);
supports S/PDIF connections.
Bottom view

5
PRESTIGIO NOBILE 156
ENG
# Item Icon Description
1 Memory compartment Houses the computer’s main memory
2 Hard disk bay Houses the computer’s hard disk
3 Battery bay Houses the computer’s battery pack
4 Battery release latch Unlatches the battery to remove it
5 Battery lock Locks/unlocks the battery pack
Indicators
Thecomputerhasseveneasy-to-readstatusindicators(LEDs)underthedisplayscreen.
ThePower andStandby indicatorsarevisible evenwhen youclosethe displaycover soyoucan seethestatus ofthe computer
whilethecoverisclosed.
# Item Icon Description
1 Wireless communication Lights when the wireless LAN (optional) capabilities are enabled.
2 Power Lights when the computer is on. Blinks when a battery-low condition
occurs.
3 Standby Blinks when computer enters Hibernation mode
4 Media activity Lights when the hard disk, or CD or DVD drive is active
5 Battery charge Lights when the battery is being charged

6PRESTIGIO NOBILE 156
ENG
# Item Icon Description
6 Caps lock Lights when Caps Lock is activated
7 Num lock (Fn-F11) Lights when Numeric Lock is activated
Hotkeys
Thecomputeruseshotkeys orkey combinationsto accesscontrolssuch asscreen contrastand brightness,volumeoutput and
theBIOSsetup utility.
Hotkey Function Icon Description
Fn-F1 Hotkey help Displays a list of the hotkeys and their functions
Fn-F2 Sleep Puts the computer in Sleep mode, which can be defined via
the advanced section of the Power Management Properties in the
Windows Control Panel.
Fn-F3 Display toggle Switches display output between the display screen, external monitor
(if connected) and both the display screen and external monitor
Fn-F4 Screen blank Turns the display screen backlight off to save power. Press any key
to return
Fn-F5 Speaker on/off Turns the speakers on and off; mutes the sound
Fn-PgUp Home Functions as the “Home” key
Fn-PgDn End Functions as the “End” key
Fn-–› Brightness up Increases the screen brightness
Fn-‹– Brightness down Decreases the screen brightness

7
PRESTIGIO NOBILE 156
ENG
Activating hotkeys
Whenactivatinghotkeys,pressandholdtheFnkeybeforepressingtheotherkeyinthe hotkey combination.
Keyboard ergonomics
Locatedbelow the keyboard, thewideand curved palm restisergonomically designed to provide youwitha very comfort-
ableplace to rest your hands while you type.
Touchpad
Thebuilt-in touchpad is a pointing device that senses movement on its surface.
Thismeansthecursorrespondsasyoumove your finger on the surface of the touchpad. The central location on the palm
restprovidesoptimumcomfortandsupport.

8PRESTIGIO NOBILE 156
ENG
Touchpad basics
Thefollowing teaches you how to use thetouchpad:
• Move your finger across the touchpad to move the cursor.
• Presstheleft (1)and right(2) buttonslocated onthe edgeof thetouchpad todo selectionand executionfunctions. These
two buttonsaresimilar to the left and right buttons on a mouse.Tapping on the touchpad producessimilar results.
Function Left Button Right Button Tap
Execute Click twice quickly Tap twice (at the same speed
as double-clicking the mouse
button)
Select Click once Tap once
Drag Click and hold, then use Tap twice (at the same speed as
finger to drag the cursor double-clicking the mouse
on the touchpad. button) and hold finger to the
touchpad on the second tap to
drag the cursor
Access context menu Click once
Scroll
Note: Keep your fingers dry and clean when using the touchpad. Also keep the touchpad dry
and clean. The touchpad is sensitive to finger movements. Hence, the lighter the touch, the
better the response.Tapping too hard will not increase the touchpad’s responsiveness.

9
PRESTIGIO NOBILE 156
ENG
Launch keys
Locatedatthe top of the keyboard are five launch keys used to launch frequentlyusedapplications.
# Item Icon Description
1 Wireless communication This button is used to enable or disable the wireless LAN (optional)
function
2 Email The mail button is used to launch the email application
3 Internet browser By default, is used to launch your internet browser
4 P1 This button is user-programmable
5 P2 This button is user-programmable

10 PRESTIGIO NOBILE 156
ENG
Important safety instructions
1.Read these instructions carefully.Savethese instructions for future reference.
2.Follow all warnings and instructions markedonthe product.
3.Unplug this productfromthe wall outlet beforecleaning.Do not use liquidcleanersor aerosol cleaners. Useadamp cloth
forcleaning.
4.Donotusethis productnear water.
5.Do notplace this producton an unstablecart, stand, ortable. Theproductmay fall,causingserious damagetothe product.
6.Slots and openings inthecabinet and the back orbottomare provided for ventilation; toensurereliable operation of the
productand toprotect it fromoverheating, theseopeningsmust notbeblocked orcovered. The openingsshould never
beblocked byplacingthe productona bed,sofa,rug, orothersimilar surface. Thisproduct should neverbe placed near
or over a radiator or heat register,or in a built-in installation unless proper ventilation is provided.
7.Thisproduct should be operated from the type of power indicated on themarking label. If you are not sure of the type
ofpoweravailable,consult yourdealeror local powercompany.
8.Donotallowanythingto rest on the power cord. Do not locate this product where persons will walk on the cord.
9.If an extension cord is usedwiththis product, make sure that thetotalampere rating of the equipment pluggedintothe
extensioncord does not exceedtheextension cord ampere rating. Also,makesure that the totalratingof all products
pluggedintothewalloutletdoes not exceed the fuse rating.
10.Neverpushobjects ofany kindinto thisproduct throughcabinetslotsasthey maytouch dangerousvoltage pointsor short
outparts that could result in a fire orelectric shock. Never spill liquid of any kindon the product.
11.Do not attempttoservicethis product yourself,asopening or removingcovers may exposeyouto dangerousvoltage
pointsorotherrisks. Refer all servicing to qualified service personnel.
12.Unplug thisproduct fromthewall outletand referservicingto qualifiedservice personnelunderthe followingconditions:
a.Whenthepowercord or plug is damaged or frayed
b.If liquid has been spilled into theproduct
c.If the product has been exposed to rain or water
d.If the product does not operate normally when theoperatinginstructionsare followed. Adjust only those controls
thatare covered by theoperatinginstructions since improper adjustmentofother controls may resultindamage and
willoftenrequire extensive work by a qualified technician to restore the product to normalcondition.
e.If the product has been dropped or the cabinet hasbeendamaged
f.If the product exhibits a distinct change in performance, indicating a need for service.
13.Replacethe batterywith the same type asthe product’s battery we recommend.Useof another batterymay present
a risk of fire or explosion. Refer battery replacement to a qualified serviceman.
14.Warning!Batteriesmayexplodeif not handled properly.Donot disassemble or disposeofthem in fire.Keep them away
fromchildren and dispose of used batteriespromptly.
15.Use onlythe propertypeof powersupply cordset(provided inyour accessoriesbox)for thisunit. Itshouldbe adetachable
type:UL listed/CSA certified, type SPT-2, rated7A125V minimum, VDE approved or its equivalent.Maximumlength
is 15 feet (4.6 meters).

11
PRESTIGIO NOBILE 156
ENG
Specifications
MICROPROCESSOR
•Intel® Pentium® M Processor
MEMORY
•Memory upgradeable to 1 GB with 2 PC2700(DDR-333) soDIMM sockets
DATA STORAGE
•One high-capacity,9.5mm,Enhanced-IDEharddisk
• One internal DVD or DVD/CD-RW combo drive
• One Memory Stick/Secure Digital (SD) combo slot - option
• External USB floppy drive - option
DISPLAY AND VIDEO
• 14.1-inch or15.0-inch TFT LCD displaying32-bit color depthat 1024x768 XGA resolution
•Simultaneous LCD and CRT display
•Dual display support
• External displaysupport up to 1280x1024resolution, 32-bit colorat 85Hz or 1600x1200resolution, 32-bit color at60Hz
AUDIO
•Built-in speakers and microphone
•Sound Blaster Pro- and Windows Sound System-compatible
•Separate audio ports for line-in/microphone-in and line-out (S/PDIF) devices
KEYBOARD AND POINTING DEVICE
•84-/85-/88-key Windows keyboard
•Touchpad pointing device with4-wayscrollbutton
•Easy launch keys
I/O PORTS
• One type II/I CardBus PC Card slot
•One RJ-11 phone jack (V.92)
•OneRJ-45network jack (Ethernet 10/100)
• One DC-in jack
• One external monitor port (DDC 2.0)
• One parallel port
•Oneaudio line-out jack (S/PDIF) (3.5mm mini-jack)
•Oneaudioline-in jack (3.5mm mini-jack)
• Three USB 2.0 ports
•One IEEE 1394 port (4-pin)
•OneS-video output port
•One FIR wireless communication port (IrDA-compliant)
•OneRJ-45network jack (Ethernet 10/100/1000) - option; replaces Ethernet/Fast Ethernet jack
• One MemoryStick/Secure Digital combo slot - option
•Wireless LAN (mini-PCI) - option

12 PRESTIGIO NOBILE 156
ENG
WEIGHT AND DIMENSIONS
•2.7kg(5.9lbs)for14.1-inchmodel;2.77(6.1lbs)for15.0-inchmodel
• 326 x 270 x 30~32 mm (12.83 x 10.63 x 1.18~1.26 in.)
ENVIRONMENT
•Temperature
•Operating:5°C~35°C
•Non-operating: -10°C ~ 65°C
•Humidity (non-condensing)
•Operating: 20% ~ 80% RH
•Non-operating: 20% ~ 80%RH
SYSTEM
•MicrosoftWindowsXPoperatingsystem
POWER
• Battery pack
•65-WattHourLi-Ion battery pack
•1.5-hour rapidcharge/2.5~4-hourcharge-in-use
• AC adapter
•70-Watt
• Auto sensing 100~240Vac,50~60Hz
OPTIONS
• 256/512 MB PC2700(DDR-333) soDIMM memory modules
•AdditionalAC adapter
• USB floppy drive
• DVD, DVD/CD-RW combo or DVD-Multi drive
• 802.11b,802.11a+802.11bor 802.11g wireless LANmini-PCI module
