PRESTIGIO VISCONTE 130
TECHNICAL SERVICE
MANUAL

1.1. Hardware Specifications…………………………………………………… 3
1.2. Software Specifications………..……………………………….…………... 13
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
2

1. Overview
Intel Centrino platform notebook with Intel Dothan CPU up to 2.13GHz, 2.5 inch HDD,
Multimedia, LAN, Modem, IEEE1394, USB2.0,CARD Reader and PCMCIA. The fellow is a
summary of major components: Main Chip:
CPU 0.09u Dothan Processor 1.73GHz-2.13GHz CPU with 2MB L2 Cache / 0.09u Celeron M 1.3GHz~1.6GHzwith
1MB L2 Cache(478P M-FCPGA)
CPU Core Power Semtech SC451
System 3V/5V Power Semtech SC1404
Core Logic: Intel 915GM + ICH6-M Chipset
Memory SO-DIMM 200pin DDR333 128MB/256MB/512MB/1GB DDR DRAM support
Clock Generator ICS954127
Graphic Engine Intel 915GM Build-in
Card Bus O2 OZ601 Single Slot, 32bit Cardbus Controller
Card Reader GL817E
Sound Codec :Realtek ALC655 (AC＇97 Audio Codec Component Specification Rev.2.1).
Audio Amp.: TI TPA6011A4 for L/R Channel Audio (1Watt x 2)
IEEE1394 Ti TSB43AB22A(OHCI-1.1)
Keyboard Controller ITE 8510EX
LAN MAC + PHY: RealTek RTL8100CL Single Chip Solution
HDD Marvell 88SA8040 SATA to PATA interface
BIOS 4Mbit
Storage Devices: 2.5＂x9.5mm High Hard Disk Drive
ATA 100 Spec Support
CD/DVD ROM CD-RW/DVD Combo and Dual DVD (Options)
USB External USB Storage device.
Legacy Support
Multimedia:
Two Build-in Dynamic Loud Speaker
1.5 watt x 4 ohm x 2 (Speaker) (4:3)
Two Audio Jacks Support ( Line Out x1, Microphone In x1)
Volume Control by Function key
Sound
Line Out Jack support
TECHNICAL SERVICE MANUALPrestigio Visconte 130
3

Communication / IO port:
RJ11 Standard AC97 MDC interface with Scatter, Gather and Burst capability
Wake on Ring on APM or ACPI mode through AC97 link
RJ45 LAN On board
USB2.0 Three USB2.0 connectors support.
IEEE1394 One IEEE 1394 Connector support
PCMCIA One Type II PCMCIA Slot
Card Reader One 3 in 1 memory card Slot, supports MMC / SD / MS memory card
CRT Standard 15Pin D-Sub Type CRT Connector
TV-OUT S-Video Connector support
Power:
AC Adapter 65W (19V)
Battery module Smart battery with Dummy Charger architecture
Battery : 3S2P/3S3P with 2200 mAH Li-ion Cell Battery
Compliance:
PCI 2.2
PC99 compliant
ACPI compliant
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
4

1.2 Functions Specification
1.2.1 Device Specification
Category Specification Note
CPU Vendor: INTEL
Dothan (.09u) Celeron M (.09u) Processor 478pin 478P M-FCPGA Package
•Processor core/bus speeds: 1.73GHz-2..13GHz.
•On die L2 cache –1M/2M Bytes
•Fully compatible with previous Intel microprocessors
−Support for MMX technology
−Support for Streaming SIMD Extensions 2 (SSE2)
•Power Management Features Intel Enhanced Intel SpeedStep technology
•FSB: Dothan 533MHz/ Celeron M 400MHz
Core Logic Vendor: INTEL
North Bridge: 915GM, South Bridge: ICH6-M
•Direct Media Interface (DMI)
- Chip-to-chip interface between GMCH and ICH6-M
- 2 GB/s point-to-point DMI to ICH6-M(1 GB/s each direction)
- 100 MHz reference clock (shared with PCI Express Graphics Attach)
•PCI to Host Bridge
−Support Intel Processor FSB at 533MHz
−AGTL+ Bus Driver Technology
•DRAM Controller
−Support 4 bank of 2.6V DDR SDRAM
−DDR 333 support (64-bit without ECC)
•PCI I/F (PCI 2.2 Compliant)
•System Interrupts
- Supports both 8259 and Pentium M processor FSB interrupt delivery mechanisms
•Integrated Graphic Support
•No External AGP Bus Support
•Integrate IDE controller
−HDD support “Ultra DMA/33, 66, 100
−CDROM support “Ultra DMA/33
•System Peripheral Support
−DMA Controller:
Two 8237A controller
8/16 bit DMA data transfer
Distributed DMA Support
−Interrupt Controller:
Two 8259A Compatible interrupt controllers
Level or edge triggered programmable
Serial Interrupt
−System Timer based on 8254 compatible programmable 16bit counters
−Real Time Clock with 256 Bytes Battery-backed RAM
−LPC-bus support for keyboard controller and super I/O
•USB controller 8 Ports
•AC＇97 Audio and modem CODEC Interface Support
•SMBus controller
TECHNICAL SERVICE MANUALPrestigio Visconte 130
5

•System Power Management
•Integrated 10/100MB LAN MAC
System Memory Two Slot Standard 200-pin DDR SO-DIMM support
•Size: 128/256/512/1024 MB
•Type: DDR SDRAM 2.6V
•Frequency: PC2700 ( DDR333 )
•CL=2/2.5
•Operating ambient temperature: 0oC ~ 70oC
•SPD Function Support
IEEE1394 •T1 TSB43AB22A (OHCI-1.1 support)
Clock Generator ICS954127
•Vendor: ICS
•Generate System clock for CPU, DDR, PCI, USB and 14.318MHz.
•Provide Spread Spectrum function
BIOS ROM 4Mb Flash EEPROM
•Vendor: AMIC
•Including system and VGABIOS
•Support shadow system BIOS
•Support shadow VGABIOS
VGA Controller Integrated Graphics
•Core Frequency of 200 MHz
•3D Setup and Render Engine
•High Quality Texture Engine
•3D Graphics Rasterization Enhancements
•2D Graphics
•Video Overlay
USB2.0 ICH6-M built in
•Compliant with Universal Serial Bus Specification Revision 2.0
•Compliant with EnhancedHost Controller Interface Specification Revision 0.95
•Compliant with Universal Host Controller Interface Specification Revision 1.1
•PCI multi-function device consists of two UHCI Host Controllers for
full/low-speed signaling and one EHCI Host Controller core for high-speed signaling
•4 downstream facing ports in the root hub with integrated physical layer
transceivers shared by UHCI and EHCI Host Controllers
•Supports PCI-Bus Power Management Interface Specification release 1.1
•Legacy support for all downstream facing ports
Card Bus TI PCI1410
•Vendor: TI
•PCI master device
•PC/Card Bus Type II X1 (Don’t support Type III device)
•Supports 3.3V/ 5V PC Card 16 cards and 3.3V Cardbus Card
Card Reader GL817E
•Vendor: Genesys Logic
•Supports MMC / SD / MS memory card
Sound Realtek ALC655
•Vendor: Realtek
•AC-97 codec
•Wavetable synthesizer support
•Integrate AC’97 Audio Codec 18bits (AC’97 2.1 compliance)
•Sound Blaster compatibility.
•Operating ambient temperature: 0oC ~ 85oC
Audio Amplifier : TPA6011A
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
6

•Vendor: TI
•Provide Bridge-Tied Load or Single Ended Modes
KB Controller ITE 8510EX
•Vendor: ITE
•Internal KB controller
•Support PS/2 devices( Touch Pad)
•Support GPIO functions
•Two SMBus controller
•CPU temperature senser
•DAC support ( battery charge control )
•ADC support ( Inverter brightness control )
•X-BUS support ( BIOS )
•FAN speed control
LAN REALTEK RTL8100CL built-in Mac & PHY
•Plug & Play compatible
•32bit PCI BUS master with DMAcontroller for low CPU and BUS utilization
•IEEE802.3 & 802.3u standard compatible
•Single 25MHz clock for 10 & 100 Mbps operation
TECHNICAL SERVICE MANUALPrestigio Visconte 130
7

1.2.2 I/O Port
Category Specification Note
CRT Port 1 Port (Standard D-Sub 9 Pin connector)
IEEE1394 1 Port (OHCI-1.1 support)
USB 3 Port: Base connector, 1.1/2.0 Compliant
Line Out 1 Jacks (Stereo Mini Pin Jack)
Mic In 1 Jack (Mono Mini Pin Jack)
Modem 1 Port (RJ-11)
LAN 1 Port (RJ-45)
Card Bus Slot Type II X 1 Supports 3.3V/ 5V PC Card 16 cards and 3.3V Cardbus Card
Card Reader Slot 1 Port supports MMC / SD / MS / MS-Pro memory card
Point Device Internal Touch Pad – PS/2 mouse I/F
•Vendor: Synaptics
•Model:
•2 buttons support Right/Left
INT/KB •Sumrex/ Chicony
Mini-PCI Wireless LAN
•Optional
TV-Out 1 Port TV-Out ( S-Video)
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
8

1.2.3 Power Supply
Battery Battery Pack general spec.
•Gas Gauge: BQ2060
•Operating ambient temperature: 0oC ~ 60oC
•Charge temperature: 0oC ~ 60oC
•Self discharge rate: Fully charged battery will be at least 80% of full charge
when stored at 25o C, 85% RH for a period of one month
•Protection: Over charge protection
Over and under voltage protection
Over current protection
Thermal protection
•Pack Vendor: SMP/Foxlink/GLW
•Capacity: 2200mAH Li-ion battery
•Cell Vendor: 3S2P-> 3.7V Samsung/LG, 3.6V Panasonic
3S3P-> 3.7V Samsung/LG, 3.6V Panasonic
•Size: 18650
•Pack Configure: 3S2P / 3S3P
•Pack Capacity: 3S2P-> 4400mAH, 10.8/11.1V, 43.2/48.8W
3S3P-> 6600mAH, 10.8/11.1V, 43.2/48.8W
Charge Strategy
Dummy Charger Battery architecture
•Charger: ITE8510EX
•Charge Current: System off Max. 2.0A.
System on Max. 0.7A
•Charging terminate: Charging current lower than 200mA
Battery voltage up to 16.8V.(SMBUS)
Battery temperature over 50 degree C (SMBUS)
Charging time over 6 hrs
AC Adapter Vendor :Li-Shin, Liteon, Hipro
Input: AC 100~ 240V, 50/60Hz
Output: 19V, 3.42A, 65W
RTC Battery Real-time clock/calendar with a coin type battery back up.
Vendor: KTS BBBCR2032B
Voltage: 3V
Capacity: 220mAh
RTC Power Plane Power Consumption: 5uA/ 3V
Estimated RTC Battery Life: 2 years
Output Tolerance Max load Test spec
5.0V +/- 5% 4.5A 5.5A
3.3V +/- 5% 4.5A 5.5A
12V +/- 5% 0.2A 0.2A
2.6V +/- 5% 4.5A 5.0A
1.8V +/- 3% 1.5A 2.0A
1.5V +/- 3% 4.0A 5.0A
DC/DC
Converter
1.05V +/- 3% 4.0A 5.0A
TECHNICAL SERVICE MANUALPrestigio Visconte 130
9

1.2.4 Power-On Source
No Note
1. System Power Button *System power on control
*Push this button 4 sec will happen H/W power shut down
This item works both when system is at on and off state
Besides RTC and AUX power plane, all power plane will turn
off until the releasing of the power button
1.2.5 Power Plane
No Name Level System off System on Standby STD W/OAC & BAT
1. VCC3_AUX 3.3V ON ON ON ON OFF
2. VCC5_AUX 5V ON ON ON ON OFF
3. 12V_AUX 12V ON ON ON ON OFF
4. VCC3_SUS 3.3V OFF ON ON OFF OFF
5. VCC3 3.3V OFF ON ON OFF OFF
6. VCC5 5V OFF ON ON OFF OFF
7. VCC2.6 2.6V OFF ON ON OFF OFF
8. VCC1.8 1.8V OFF ON ON OFF OFF
9. VCC1.5 1.5V OFF ON ON OFF OFF
10. VCC1.05 1.05V OFF ON ON OFF OFF
11. 12V 12V OFF ON ON OFF OFF
12. RTCVCC 2.0~3.3V ON ON ON ON ON
13. VCCP 1.05V OFF ON OFF OFF OFF
14. VCC_CORE 1.484V OFF ON OFF OFF OFF
1.2.6 Connector
No Connector Location Pin No
1. DC_IN CON CON1 6
2. SW Board FFC CON CON2 32
3. INT K/B CON CON3 24
4. TOUCHPAD FFC CON CON5 6
5 AUDIO FFC CON CON6 40
6 Battery CON CON9 10
7 CPU FAN CON CON10 3
8. DVD-ROM CON CON11 50
9. LCD CON CON12 30
10. INVERTER CON CON13 10
11. LAN Wire CON CON14 10
12. IO Wire CON CON16 18
13. MODEM BOARD FFC CON CON17 8
14 INT MIC CON (Option) CON18 2
15. PADA HDD CON CON19 44
16. BLUETOOTH WIRE CON (Option) CON20 5
17 MINI PCI CON CON21 124
18. DDR SO-DIMM CON30 200
19. DDR SO-DIMM CON31 200
20. SATA HDD CON (Option) CON32 22
21. CARD BUS FFC CON CON100 32
22. CARD BUS FFC CON CON101 32
23. SUB BAT CON CON102 2
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
10

24. DC_IN JACK SCN1 5 In Switch Board
25 DC_IN CON SCN2 6 In Switch Board
26. SWITCH BOARD FFC CON SCN3 32 In Switch Board
27 CRT CON SCN4 15 In Switch Board
28 TP/MB FFC CON TCN1 6 In TouchPad Board
29 TP FFC CON TCN2 12 In TouchPad Board
30 LED CON LCN1 14 In LED Board
31 MODEM WIRE CON MCN1 2 In Modem Board
32 MODEB FFC CON MCN2 8 In Modem Board
33 USB CON MCN5 4 In Modem Board
34 RJ11 JACK MCN10 2 In Modem Board
35 LINE OUT JACK CN2 6 In Audio Board
36 MIC JACK CN3 6 In Audio Board
37 Cardreader CON CN4 26 In Audio Board
38 MDC CON CN7 12 In Audio Board
39 USB CON CN8 4 In Audio Board
40 LED CON CN9 14 In Audio Board
41 AUDIO FFC CON CN10 40 In Audio Board
42 SPEAKER CON CN11 4 In Audio Board
43 S-VIDEO ICN1 4 In IO Board
44 LAN JACK ICN3 8 In IO Board
45 IO WIRE CON ICN4 18 In IO Board
46 LAN WIRE CON ICN5 10 In IO Board
47 1394 CON ICN6 4 In IO Board
48 USB CON ICN10 4 In IO Board
49 PCMCIA SOCKET PCN3 68 In PCMCIA Board
50 CARD BUS FFC CON PCN100 32 In PCMCIA Board
51 CARD BUS FFC CON PCN101 32 In PCMCIA Board
1.2.7 Cable
No Cable
1. DC_IN cable M/B to Switch BOARD
2. SWITCH Board FFC M/B to Switch BOARD
3. IO cable M/B to IO BOARD
4. Lan cable M/B to IO BOARD
5 LCD cable M/B to LCD
6 INV cable M/B to Invertor
7 MODEM FFC M/B to Modem BOARD
8 TOUCHPAD FFC M/B to TOUCHPAD BOARD
9 CARD BUS FFC x 2 M/B to PCMCIA BOARD
10 AUDIO Board FFC M/B to AUDIO BOARD
11 MDC cable MDC to Modem BOARD
TECHNICAL SERVICE MANUALPrestigio Visconte 130
11

1.2.8 LED
POWER ON/OFF Blue light always on when system is in Power On.
POWER/Charging Status Orange light flash shown when battery is being charged
Green light is shown when battery is not charging and Battery capacity is Full.
Red light flash when battery is low warning
RF_ON Blue light always on when WIRELESS Card RF activated
SUSPEND Status Green light flash when system is during suspend
Green light always on when system is in silent mode
HDD/ODD LED ON when HDD/ODD activated
Num lock LED ON when activated. Num Lock OFF at default
Caps lock LED ON when activated. Caps Lock should be OFF at boot up
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
12

2. Software Specifications
2.1 Product Specification
Process
or Intel
▓TDP 27W
▓Dothan CPU
Pentium M, Operating to 2.13 GHz, 533 MHz FSB, 2MB L2 cache
Celeron M, Operating to 1.60 GHz, 400 MHz FSB, 1MB L2 cache
Memory DDR
▓DDR1 333
▓DDR RAM socket * 2
▓System RAM up to 1GB total
**1GB memory is depends on module’s availability and customer’s
request.
▓Host Interface:
Supports a FSB frequency of 400 and 533 MHz of Dothan series CPUs
▓System Memory Interface:
Supports DDR1 memory interface
Supports DDR1 333 SO-DIMM module
Core
Logic
Intel 915GM
(Alviso)
+ ICH6-M
▓DMI Interface:
Chip-to-chip interface between GMCH and ICH6-M
VGA Integrated ▓Supports DX9
KBC/EB
C
IT8510EX
▓ACPI 2.0b compliant
▓16-bit RISC core, with 2 Mbytes address space, and running at up to
20MHz
PCMCIA
card OZ601 ▓PCMCIA card support
IEEE
1394a TSB43AB22A ▓Support IEEE 1394a with Open HCI Compliance
▓PCI V2.2 MAC/BIU supports
S-Video Intel 915GM
Integrate ▓Display on a PAL or NTSC TV
▓Support for Macrovision 7.1 copy protection standard-a fully
programmable timing capability
LAN
Controll
er
RTL8100CL ▓Supports 10 and 100 Mb/Sec
Modem ▓Standard AC97 MDC interface with Scatter, Gather and Burst apability
▓Wake on Ring on ACPI mode through AC97 link
▓Supports ITU v.92/v.90
Wireless
LAN Intel 2200BG MSI 6833A &
▓Mini-PCI interface
▓IEEE802.11b/g standard compliant
Keyboar
d ▓86Keys K/B
Pointing
Device Synaptics TM15P-UZ378 ▓PS/2 Touch Pad with 2 buttons and page down/ page up
LCD 13” TMD
LTD133EX2A ▓13.3 " WXGA (16:9) resolution 1280 x 800
HDD Hitachi/WD ▓2.5" 9.5mm IDE HDD with PATA support
Optical
Device Lite-On/QSI/HLDS ▓Combo, DVD Dual
▓GBAS support
Card
reader GL817E ▓Support 3 in 1 card reader SD/MMC/MS memory card
▓USB 2.0 compliant
▓Support boot function
TECHNICAL SERVICE MANUALPrestigio Visconte 130
13

Battery
Pack Samsung ▓Li-ion Smart Battery with BQ-2060 Gas Gauge IC
▓6 cells, 11.1V/4400mA (3S2P), 3.7V/ 2200mAH/ Cell, Samsung
▓Battery life (TBD)
AC-Adap
ter Lite-On (2-pin) ▓50/60Hz 65Watts 19V
I/O Port ▓1 x DC-in jack (2-pin)
▓1 x S-Video output port (4-pin)
▓1 x IEEE 1394a port
▓2 x Phone jacks for microphone input / audio output:
a). External microphone jack 1/8”
b). External earphone jack 1/8”
▓1 x RJ45 LAN
▓1 x RJ11 modem connector
▓1 x PCMCIA
▓3 x USB 2.0 ports
▓1 x CRT port
▓1 x MMC/MS/SD memory card slot
System
Status
Indicato
r
▓Num Lock: Green
▓Caps Lock: Green
▓ODD, HDD R/W: Green
▓RF-ON (Wireless LAN): Blue
▓Power On, Suspend: Blue / Blue flash
▓Battery status Charging/ Low: Green/ Orange / Orange flash
▓Power Cinema/ Silent Mode: Green
Quick
Launch
Button
▓Multiple function button for PCM On/Off and Silent mode
▓WLAN On/Off button
Power
Cinema
under
Linux
▓On / Off
▓Support DVD player, MP3 player, CD player, USB storage devices reader, View photo
Speaker ▓Build-in 2 speakers
▓Speaker : 1.5W and 4 ohm
Power
Button ▓On/ Off: Programmable Power Buttons
▓1 Sec. -> Suspend, 4 Sec. -> Power Off
▓Post 1 Sec. to power off
O.S. ▓Supports Windows XP
BIOS ▓Supports PnP, APM 1.2 & ACPI 2.0
▓Support external USB flash memory card boot up.
Power
Manage
ment
Uniwill “Smart Power II” Power Management (TBD)
▓Proprietary Technology of battery life and system performance Extension
The technology is including Long battery life mode, Silent mode
Long battery life mode: Battery life extension
Silent mode: Noise frequency under 25dB and Maximum battery life
Physical
Outline ▓Dimension: LxWxH: 316mmX224mmX31.9~34.4(w/battery) (TBD)
▓Weight: 4.5lb (TBD)
EMI ▓FCC, VCCI, CE
RF ▓FCC, R&TTE, CSA
Telecom ▓CTR21, CSA
Safety ▓UL, cUL, CB, TUV, JATE, BSMI
Accesso
ry
(Option
al)
Port replicator
Uniwill PR8800 ▓CRT upstream port
▓VGA display swappable support
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
14

*** The content is subjected to change without notice.
Function Key define :
F1 TBD(Nothing to do)
F2 into COMS
Fn + F3 Screen on/off(backlight on/off)
Fn + F4 Hibernation
Fn + F5 Switch to CRT
Fn + F6 Brightness down
Fn + F7 Brightness up
Fn + F8 Volume down
Fn + F9 Volume up
Fn + F10 Silent(it mean "if end users press Fn+F10 = mute on" , press Fn+F10 again = mute
off.)
2.2 Preface
The software engineering specification is a deployment from product marketing specification. It should outline major
tasks to be implemented in a specific model. For any model which has been defined from product marketing division, there
should have a product marketing specification comes out.
The purpose of this specification is to be an implementation guideline for engineers who are responsible for the model. It
intends to avoid ambiguity about function definitions so as to allow engineers to shorten their implementation period.
The specification covers all the bundled software components which including BIOS, Micro-Controller, device drivers
and applications. The target Operating Systems will be Windows XP. The device drivers and applications are options based on
per-customer’s requirements. The engineers should make sure that these drivers and application could run without any
difficulties on the target PC2001 model.
The readers of this specification are assumed to have enough experiences and knowledge to understand whatever in the
context. The specification will not intend to explain any detail of specific topic.
TECHNICAL SERVICE MANUALPrestigio Visconte 130
15

2.3 Summary of BIOS Specification
Feature Description
Basic Bios Features POST(Power On Self Test)
Quiet Boot (optional show OEM Boot Logo)
Multi-Boot
APM 1.2 Compliance
Support ACPI 1.0b Spec.
Support PCI 2.1 Spec.
Support WindowsXP
Support SMBIOS 2.3 Spec.
CPU Auto detect the CPU type and speed
DRAM Auto detection and sizing up to 1GB
Cache Auto detection and sizing, and always enabled
Hard Disk Support PATA IDE detection
Support LBA mode for large capacity HDD > 8GB
Support Ultra DMA 33/66/100
Support Fast PIO mode 4
Multi-Boot Support boot from HDD, CDROM/DVD-ROM, LAN, USB removable devices
Crisis Disk Support Flash BIOS from BIOS Boot Block
Plug and Play Support PnP runtime service and Conflict-Detection-Resolve during POST
Support SMBIOS2.3
Auto routing PnP device I/O, Memory, IRQ and DMA
SupportACPI 2.0 Device Management
Keyboard Controller WHQL Keyboard Logo compliance
Support hot plug/swap external PS/2 mouse and keyboard
Support Fn hot-key
Power Management SupportACPI 1.0b power management
Support system S3, S4 state
Support CPU C0, C1 ,C2, C3state
Support Uniwill Smart Power control by EC
Instant On Support Instant On button to boot to Linux with DVD/MP3/Photo Player function
Core Logic INTEL915GM + ICH6M
2.4 SYSTEM
2.4.1 System Memory
The System consists of DDRI memory on 64-bit bus and the size options are 128/256/512MB on each DIMM slot. The
BIOS will automatically detect the amount of memory during POST.
2.4.2 VGA
The VGAchip is Intel 915GM Build in VGA
There’re some limitations like below:
1. Display not allow switching while playing DVD/VCD
2. TV display cannot full fill screen at XP dosprompt full screen mode
2.4.3 Audio
The audio controller is integrated in south bridge and through the AC97 data line to external CODEC to reduce the noise
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
16

caused by PCB’s layout. According to the H/W architecture , the BIOS will recognize it as a PCI device and initialize it in PCI
bus initialization. The PCI legacy audio mode is not to be supported.
2.4.4 Modem
The system can use all of the modem that is AC97’ compliance and the MDC form factor. During POST, the BIOS will
detect the existence the MDC and set proper registers in south bridge
2.4.5 PCMCIA
The OZ 601T supports a variety of features . PCcard , CardBus
2.4.6 Card Reader
Card Reader via USB bus, support SD Card , MMC, Memory Stick, Memory Stick Pro
2.4.7 LED Indicator
Indicator Function Description
Power/Suspend LED The LED will turn blink green when system is suspend
Charge LED The LED will always off when without Battery
The LED will turn on green when Battery Full Charged
The LED will turn on orange when Battery Charging
The LED will turn on red when Battery Low warning
Wireless LED 1. Setup menu can define RF enable or disable
2. Load default = RF enable , The LED will turn on blue
3. Without WALN card = always disable
4. Into suspend = RF disable
5. Before Power off & Suspend need keep RF status for setting next power on & resume .
Silent LED The LED will turn on when system entry silent mode
Num Lock LED The LED will turn on when Num Lock function is activated
Cap Lock LED The LED will turn on when Cap Lock function is activated
HDD/CDROM LED The LED will turn on when the hard disk or CDROM is activated or accessed
Power on the system will turn on Cap, ,Num lock LED about 1~2 seconds then turn off them.
.
2.4.8 PCI Device
All the PCI devices will occupy the system resources, such as I/O, Memory and IRQ, especially the IRQ assignment is
relative to H/W and system arrangement. The following will list all PCI devices:
PCI DeviceIDSEL Bus# Device# Func# INT Pin Device Name
PAD20 1 3 0 B OZ601 PCMCIA
PAD26 1 10 0 A TI TSB43AB22A IEEE-1394
PAD28 1 12 0 A LAN RTL8100CL
PAD19 1 7 0 A, B MINI PCI DEVICES
2.4.9 SMBus Devices
The SMBus is a two-wire interface through which the system can communicate with power-related chips. The BIOS
should initialize the SMBus devices during POST.
TECHNICAL SERVICE MANUALPrestigio Visconte 130
17

SMBus Device Host/Slave Address
ADM1032 (Temperature) Slave 4Ch
Battery Slave 16h
ICS954127 (Clock Generater) Slave D2h
SO-DIMM SPD Slave A0h, A2h
AT24C02 (IEEE-1394 EEPROM) Slave
93C46 (LAN EEPROM) Slave
2.4.10 GPIO PinAssignment
The following will list the core chip GPIO definition and function:
General Purpose Inputs
Pin Name Function Name Type Signal Description
GPI8 RUN_SCI# Input 10Kohm pull high
GPIO31 LCDSEL0# Input Select LCD type
GPIO30 LCDSEL2# Input Select LCD type
GPIO29 LCDSEL1# Input Select LCD type
2.5 Keyboard Controller
The system uses the ITE IT8510E as the keyboard controller and ACPI embedded controller. Following will summarize all
the features of keyboard firmware.
zUniwill Smart Power support
zInternal Keyboard and Auxiliary Device Support and Internal Pointing Device Support.
zInternal Keyboard Scan Code Controller Support and Internal Numeric Keypad Support.
zSimultaneous Operation of External Devices
zSimultaneous Operation of External Keyboards
zSimultaneous Operation of External Auxiliary
zDevice Hot Pluggability
zEmbedded Controller IT8510E 176-Pin LQFP package
zLPC System Interface
zACPI Embedded Controller Power Management Event Control.
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
18

zSingle Pin Keys Support .
zPS/2 Interface External Port Support support.
zSystem Power On/Off ATX Power Sequence Control.
zSystem BIOS Strap Pin.
zSystem BIOS ROM Flash Protect.
zFAN DAC or speed Control.
zLCD Backlight BrightnessAdjust.
zDirect LEDs Support.
2.5 Power Management
INPUT :
Input voltage range : 9V~17Vdc (Battery) or 18V~21.5Vdc (Adaptor).
Adapter: 20V @ 3.25A,65W constant voltage mode .
Battery: Main Battery: 4 Cells (4S1P) DC 14.8V 2200mA
3 Cells(3S2P) DC 11.1V 2200mA/2000mA
Second Battery: 3 Cells(3S1P) DC 11.1V(Option) 2200mA
2.5.1 General Requirement
The purpose of the Power Management (PM) is trying to reduce the power consumption of the system and extent the
battery life, increase the time without recharging the battery. The Advanced Configuration and Power Interface (ACPI)
specification is the latest and better PM method and will replace the traditionalAPM and PNP functions. ACPI is a kind of
Operating System Directed Power Management (OSPM), that is, the OS will control the system/devices to enter proper
power-saving mode and determine when to do it.
The BIOS shall provide the ACPI table that is written by ASL language, to tell the OS how to setup and control the
system/device configuration and the power-saving mode. So the system H/W, BIOS and drivers must be meet theACPI
specification:
ACPI 1.0b compliant
Intel Geyserville III Technology Support
Supporting processor power state C0, C1 , C2 ,C3
Supporting system state S0, S3, S4 (WinXP) and S5
Support Uniwill Smart Power Function
First of all, the next section will depict the power management state transition, then describe the definition for each
TECHNICAL SERVICE MANUALPrestigio Visconte 130
19

system state.
2.6 Power Management State Transition
2.6.1 Power Management Mode Definitions
Each system (or model) may have different PM model and state definition. For clear, see the following table :
PM Mode Definitions
Full-On The CPU runs in full speed and all the devices are power on. The system can respond to all
applications with maximum performance.
1. The system is in the state S0.
2. The CPU is in the state C0.
3. All the devices are in the state D0.
Geyserville
III CPU will running between diffenent BUS ratio depend on system loading, if power Schemes set to Presentation or Max Battery
Idle This mode is similar to Full-On . The CPU might change into C1 or C2 state depend on the OS, in
order to save CPU power consumption.
1. The system is in the state S0.
2. The CPU is in the state C1 or C2.
3. All the devices are in the state D0.
Suspend The state is more power saving than above, the CPU and most of parts power will be cut off except
DRAM system.
1. The system is in the state S3.
2. The CPU and all of devices are power off except DRAM system.
SOFF/STD The state is the most power saving mode, all of the parts in the system will power off, except the
keyboard controller enter to idle mode continuously to control the battery charging and monitor power
button.
Note: Before enter to S4, the OS will save all of data or registers in HDD.
1. The system is in the state S5 or S4.
2. The CPU and all of devices are power off.
When system is in suspend mode (S3 state ), external keyboard/mouse/touch pad/Lid cannot be the wake up event source.
Only Power button can resume the system.
2.6.2 Uniwill Smart Power Function
The purpose of Smart Power is to save the power consumption during the system is not busy. This function not only save the
power of Battery to extend the Notebook’s battery working time, but also reduce the the temperature of CPU / Chip and keep
system working in a lower temperature to extend the CPU and whole system’s life. Reduce temperature will also keep
Operation System work stable.
2.6.2.1 Instant On Mode: If press Instant On button to power on, CPU FSB 400 ext. clock will keep at
80MHz, CPU FSB 533 ext. clock will keep at 90MHz CPU bus ratio will keep at the minimum.
2.6.2.2 Long Battery Life Mode: Also called Smart Power 1, CPU FSB 400 ext. clock will keep at
100MHz, CPU FSB 533 ext. clock will keep at 133MHz CPU maximum bus ratio will keep at the most
TECHNICAL SERVICE MANUAL Prestigio Visconte 130
20
