PRESTIGIO NOBILE 158W
ENG
Prestigio Nobile 158W
Quick Start Guide
This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key
componentsare.Ifyouarenotthatcomfortablewiththistypeofdevice,thenpleaserefertothefollowingpages,which
give an overview of the system.
Itisstillbesttoreviewthesesteps,beforetakinganyaction.Ifthereisanythingyouarenotsureabout,thenpleaserefer
totheappropriatechapterbeforecontinuing.
Unlessyouneedtoinstall anoperatingsystem, yourcomputershould bereadyto workrightout ofthebox. Beforeyoubegin
pleasefollowthesafetyinstructions.
1.Removeall packing materials.
2.Securelyattachanyperipheralsyouwanttousewiththecomputer(e.g.keyboardandmouse)totheirports.
3.Attach the ACadapterto theDC-injack on the rightofthecomputer,thenplug the ACpower cordintoan outlet,and
connect the AC power cord to the AC adapter.
4.Raisethelid/LCDtoacomfortable viewing angle.
5.Pressthe powerbuttonto turn“On”.
System Map
Yourcomputerhasalotofbuilt-infeatures.Most of these areenabledbyyour operating system.Further explanations of
thevarioussubsystemsarecoveredinthechapterorpagesindicated.
Getting to Know Your Computer
Thefollowing graphicswillhelp youtobecome familiarwiththe basicfunctions, and tolearn thelocationof thevariousports
andcomponentsof yourcomputer.
Top View

2PRESTIGIO NOBILE 158W
ENG
ToopentheLCD display:
1.Placethecomputerona stable surface.
2. Move the LCD latches (1) in the direction of the arrows to release the top cover (the left latch will lock in position and
isclearlymarked with locked and unlocked icons).
3. Lift the top cover to reveal the LCD panel and keyboard.
4.AdjusttheLCDpaneltoacomfortableviewingangle.
5.The LED indicators (2) show the power and battery status of the computer,and give notification of e-mail received.
Top View with LCD Panel Open
1. Optional Built-In PC Camera
2. LCD
3. LED Power & Communication Indicators
4. Speakers
5. Close Cover Switch
6. LED Status Indicators
7. Power Button
8.Keyboard
9.Built-In Microphone
10.TouchPadand Buttons
11. Hot-Key Buttons
PC Camera
Ifyou have purchased the optional PCCamera,make sure you install the softwareapplication.The Module ON/OFF Button
willenable/disablethe PC Camera.

3
PRESTIGIO NOBILE 158W
ENG
LCD Panel
ThecomputercomeswithawidescreenTFT (Thin FilmTransistor),Liquid Crystal Displayscreen.
LED Power & Communication Indicators
Theseindicatorsdisplaythe systempowerstatus,andbattery statusof the computer.Thethirdindicatormay be configured
togive a visual confirmation when e-mail is received in thedefault e-mail program.
Stereo Speakers
Thebuilt-in speakers provide rich, stereosound.
Close Cover Switch
Thisswitchacts as a sensor to tellwhentheLCD Panel is closed. When this LCDcoversensoris activated the default setting
of your operating system’s power scheme sends the computerinto a power saving state.
LED Status Indicators
Thesedisplay the system’soperational status.
Power Button
Pressthis button toturn your computer on or off.Thisbutton mayalso be used as a suspend/resume key,once configured
assuchinthepowermanagementcontrolpanelof your operating system.
Keyboard
Thecomputerhas a“WinKey”keyboardincluding anumerickeypad.Ithasthe samefeaturesas a full-sizeddesktopkeyboard
andcaneasilybereplaced with a different language keyboard should you desire.
Microphone
Recordon your computer with thebuilt-inmicrophone.
TouchPad & Buttons
Thepointing device featuresa sensitive glidepadfor precisemovements.It functions thesameway asatwo-button mouse.
TherightTouchPadbutton is the same as the right mouse button;the leftTouchPadbutton is the same as the left mouse
button.Thecentralbuttonmay be used to scroll up and down, or may be configured to perform a variety of functions.
Hot-Key Buttons
Thethree hot-keys allowyouinstantaccess to yourdefaultInternet browser anddefaulte-mail program, and totoggleon/
offthemodules(WirelessLAN/Bluetooth/PCCameramodules).

4PRESTIGIO NOBILE 158W
ENG
Front View
1. LCD Latches
2. Mini-IEEE 1394 port
3. 4-in-1 Card Reader
4. S/PDIF Out Port
5.Microphone-In Jack
6. Headphone-Out Jack
7. Hot-Key Buttons
Mini-IEEE 1394 Port
Thisallowshigh-speed connection to various peripheraldevices,e.g.external disk drives and digital cameras.
4-in-1 Card Reader
Thecard reader allows you to use some of the latest digital storage cards (SD/MS/MS PRO/MMC).Pushthe card into the
slotand it will appear as a remov-able device.
S/PDIF Out Port
ThisS/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect yourDVD-capable PC to a Dolby AC-3
compatiblereceiverfor“5.1”or‘dts’surroundsound.
Microphone-In Jack
Recordonyour computer with an external microphone.
Headphone-Out Jack
Headphonesor speakers may be connected throughthisjack.
Note: Set your system’s volume to a reduced level before connecting to this jack.
Hot-Key Buttons
Thethree hot-keys allow youinstantaccess to yourdefaultInternetbrowser and defaulte-mailprogram, and to togglethe
poweron/offtothe Wireless LAN/Bluetooth/PC Camera modules.
Module ON/OFF Button
You canuse thisbuttontotogglethe powerON/OFFforthe optionalIntelPRO/Wireless 2100(802.11b)OR 2200BG(802.11b/
g)MiniPCIWLAN module,the optional Bluetooth module and theoptionalPCCamera module.To enable the modulesyou
willneed to installthedrivers/software forthem.Make sure thewirelessmodules are OFFwhenyou areusingthe computer
aboardaircraft.

5
PRESTIGIO NOBILE 158W
ENG
Left Side View
1.Vent
2. External Monitor (VGA) Port
3. S-Video Out Port
4. RJ-11 Phone Jack
5. RJ-45 LAN Jack
6. 2 * USB 2.0 Ports
7. Infrared Transceiver
8. PC Card Slot
9. PC Card Eject Button
Vent
Thisenablesairflow to prevent the computer from overheating.
External Monitor (VGA) Port
Connect an external VGA monitor to this port to allow dual video or simultaneous display on the LCD and external VGA
monitor.
S-Video-Out Port
Connectyourtelevision toyourcomputer and view DVDs,VCDsor anything else yourcomputer can display.Youwill need
anS-Videocabletomaketheconnection.Enable this port from the video driver controls.
RJ-11 Phone Jack
Thisportconnects tothe built-inmodem.Youmayplugthe telephonelinedirectlyintothisRJ-11 telephoneconnection.Note:
Broadband(e.g.ADSL)modems usually connect to the LAN port.
RJ-45 LAN Jack
ThisportsupportsLAN(Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
2 * USB 2.0/1.1 Ports
TheseUSB2.0 compatible ports (USB 2.0isfullyUSB 1.1 compliant) are for low-speedperipheralssuchas keyboards, mice
orscanners, and forhighspeedperipherals such asexternalHDDs, digital videocamerasor high-speed scannersetc.Devices
canbe plugged into thecomputer,and unplugged fromthe computer,without theneedtoturnthe system off (ifthepower
ratingofyour USB device is 500mA or above, make sure you use the power supply which comeswiththe device).
PC Card Slot
The3.3V/5V slot may be usedforaType-II PC Card(PC Cards werealso previouslyreferredto as PCMCIA)andfullysupports
Cardbus.

6PRESTIGIO NOBILE 158W
ENG
Right Side View
1. USB 2.0/1.1 Port
2. Serial Port
3. Optical Device Bay
4. DC-In Jack
USB 2.0/1.1 Port
TheseUSB2.0 compatible ports (USB 2.0isfullyUSB 1.1 compliant) are for low-speedperipheralssuchas keyboards, mice
orscanners, and forhighspeedperipherals such asexternalHDDs, digital videocamerasor high-speed scannersetc.Devices
canbe plugged into thecomputer,and unplugged fromthe computer,without theneedtoturnthe system off (ifthepower
ratingofyour USB device is 500mA or above, make sure you use the power supply which comeswiththe device).
Serial Port
Connecta serial type mouse to this port.
Optical Device Bay
Theoptical device bay will contain a 5.25" (12.7mm height) CD/DVD typedevice.The actual device will depend on your
purchaseoption.
DC-In Jack
PlugthesuppliedACadapterintothisjack topoweryour computer.
Rear View
1. Security Lock Slot
Security Lock Slot
To preventpossible theft,aKensington-type lock can beattachedtothis slot.Lockscanbe purchasedat any computerstore.

7
PRESTIGIO NOBILE 158W
ENG
Bottom View
1. Vent/Fan Intake
2. Battery
3. RAM Bay Cover
4. Hard Disk, WLAN & Bluetooth Module Bay Cover
5. CD Device Screw Cover
Vent/Fan Intake
Thisenablesairflow to prevent the computer from overheating.
Hard Disk Drive
The internal hard disk drive is used to store your data.
Wireless LAN (Network) & Bluetooth Modules
Theantenna(e) and other componentsofthe optional Intel PRO/Wireless2100(802.11b) OR 2200BG (802.11b/g)MiniPCI
WLANmodule, andtheoptional Bluetoothmoduleare not externallyvisible (please checkwith your servicerepresentative).
Ifyour configuration includes the module(s), make sure you install the driver for it.
Using The Computer
The Power Sources
Thecomputer can be powered by either an AC adapteror a battery pack.
AC Adapter
Useonly the AC adapter thatcomeswith your computer.The wrongtype of ACadapter will damage the computerandits
components.
1.Attach the AC adapter to the DC-in jack on the right of the computer.
2.Plug the AC power cord into anoutlet,and then connect the AC power cord to the AC adapter.
3.Raisethelid/LCDtoacomfortable viewing angle.
4.Pressthe powerbuttonto turn“On”.

8PRESTIGIO NOBILE 158W
ENG
LED Indicators
Thereare two sets of LED indicators(LEDPower& Communication Indicators and LEDStatusIndicators)on your computer
that will display helpful information about thecurrentstatus of thecomputer.TheLED Power & Communication Indicators
are also visible when the topof your computer is closed.
LED Status Indicators
Icon Color Description
Green Hard Disk/CD Device activity
Green The Module(s) (WLAN, PC Camera, Bluetooth) is/are On
Green Number Lock is activated
Green Caps Lock is activated
Green Scroll Lock is activated (to activate press Fn & ScrLk)
LED Power & Communication Indicators
Icon Color Description
Orange DC power is plugged in
Green The computer is on
Blinking Green The computer is in standby mode
Orange The battery is being charged
Green The battery is fully charged
Blinking Orange The battery has reached critically low power status
Blinking Green New mail has arrived
Hot-Key Buttons
These keys access the Internet and e-mail, and enable you to toggle power on/off to the optional module(s) (WLAN/
Bluetooth/PCCamera) with one quick button press.Make sureyouinstalltheHot-Keydriver.
My Computer Hot-Key
The Hot-Key at the bottom left of the keyboard gives you quick one button access to the My Computer folder on your
computer.

9
PRESTIGIO NOBILE 158W
ENG
Programming the Hot-Keys
Hot-Key Function
Activate the default Internet browser
Activate the default e-mail program
Toggle power on/off to the optional module(s) - (Wireless LAN/Bluetooth/PC
Camera modules)
Function Keys and Numeric Keypad
Function Keys
On the bottom-left of the keyboard is the Fn key or Function key.The Fn key allows you to change operational features
instantly.Tousethefunctions press and hold the Fn key,then presstheappropriate function key (F5 - F12 etc.)locatedon
yourkeyboard.
Keys Description
Fn Function Key
Fn + Esc Sleep/Resume Toggle
Fn + F5 Mute Toggle
Fn + F6 Display Toggle
Fn + F9 Decrease LCD Brightness
Fn + F10 Increase LCD Brightness
Fn + F11 Decrease Audio Volume
Fn + F12 Increase Audio Volume
Fn + Scr Lk Scroll Lock Toggle
Fn + Num Lock Toggles Padlock Mode if Number Lock is enabled

10 PRESTIGIO NOBILE 158W
ENG
TouchPad and Buttons/Mouse
TheTouchPad is a device for pointing (controlling input positioning) on the computer’s display screen by sensing finger
movement,and downwardpressure.It is an alternative to themouse;however,youcan alsoaddamouse toyourcomputer
throughoneof the USB ports.
TheTouchPadbuttonsfunctionin much the same wayasatwo-buttonmouse.The centralbuttonmay be configured to
functionasyou require.
Configuring the TouchPad and Buttons
Onceyou haveinstalled theTouchPad driversyoucan configurethe functions bydouble-clickingtheTouchPaddrivericonon
thetaskbar.Youmaythenconfigure theTouchPadtapping,buttons,scrolling,pointermotion and sensitivity optionstoyour
preferences.Youwill find further information on this at www.synaptics.com.
Important safety instructions
1.Read these instructions carefully.Savetheseinstructions for future reference.
2.Follow all warnings and instructions markedontheproduct.
3.Unplug this product fromthewall outlet before cleaning.Donot use liquid cleanersoraerosol cleaners. Use adampcloth
forcleaning.
4.Do not use this productnear water.
5.Do notplacethis productonan unstable cart,stand, or table.Theproduct mayfall,causing seriousdamageto theproduct.
6.Slots and openings in thecabinetand the back orbottomareprovided for ventilation; toensurereliableoperation of the
productand toprotectit fromoverheating,these openingsmustnot beblockedor covered.Theopenings shouldnever
beblocked by placingthe product onabed, sofa,rug,or other similarsurface.This productshouldnever beplacednear
or over a radiator or heat register,or in a built-in installation unless proper ventilation is provided.
7.Thisproductshould be operated from the type of power indicated on the marking label. If you are not sure of the type
ofpoweravailable,consultyourdealer or local powercompany.
8.Donotallowanythingtorestonthepowercord.Donotlocatethisproductwhere persons will walk on the cord.
9.If an extension cord is usedwiththis product, make sure that thetotalampere rating of the equipment pluggedintothe
extensioncord does not exceedtheextensioncord ampere rating. Also,makesure that the totalratingofall products
pluggedintothewalloutletdoesnotexceedthefuserating.

11
PRESTIGIO NOBILE 158W
ENG
10.Never pushobjects ofanykind intothis productthroughcabinet slotsas theymaytouch dangerousvoltage pointsorshort
outparts that could result in a fire or electric shock. Never spillliquid of any kind on the product.
11.Do not attemptto servicethis product yourself,as opening or removingcovers may expose youtodangerousvoltage
pointsorotherrisks.Referallservicingtoqualifiedservicepersonnel.
12.Unplug thisproductfrom thewalloutlet andrefer servicing toqualified servicepersonnelunder thefollowingconditions:
a.Whenthepowercordorplugisdamagedorfrayed
b.Ifliquid has been spilled into theproduct
c.Ifthe product has been exposed to rain or water
d.Ifthe product does not operate normally whentheoperatinginstructionsare followed. Adjust only those controls
thatare covered by theoperatinginstructions since improper adjustmentofothercontrols may resultindamageand
willoftenrequireextensive work by a qualified technician to restore the product to normal condition.
e.Ifthe product has been dropped or thecabinethasbeendamaged
f.Iftheproductexhibits a distinct change in performance, indicating a need for service.
13.Replacethe batterywith the same type astheproduct’s battery we recommend.Use of another battery may present
a risk of fire or explosion. Refer battery replacement to a qualified serviceman.
14.Warning!Batteriesmayexplodeifnot handled properly.Do not disassembleordispose of them in fire.Keep themaway
fromchildren and dispose of used batteriespromptly.
15.Use onlytheproper typeof power supplycord set(providedin youraccessoriesbox) forthisunit. Itshould beadetachable
type:UL listed/CSA certified, type SPT-2, rated7A125Vminimum, VDE approved or itsequivalent.Maximumlength
is 15 feet (4.6 meters).
Specification
Feature Specification
Processor Types Intel® Pentium® M Processor (478-pin) (µ0.13) 0.13 Micron Process Technology, 1MB On-die L2
Micro-FCPGA Package Cache & 400MHz Front Side
Bus - 1.3/ 1.4/ 1.5/ 1.6/ 1.7 GHz
(µ0.09) 0.09 Micron Process Technology, 2MB On-Die L2
Cache & 400MHz Front Side
Bus - 1.5A/ 1.60A/ 1.70A/ 1.8 / 2.0 GHz
Core Logic Intel 855PM + ICH4-M
Security Security (Kensington® Type) Lock Slot BIOS Password
Memory Two 200 Pin DDR SODIMM Sockets Supporting 128/256/512/1024 MB DDR RAM Modules
Supporting DDR 266/333 MHz Modules Expandable up to 2GB
BIOS One 512KB Flash ROM Insyde BIOS
LCD 15.4" WXGA / WSXGA+ / WUXGA TFT LCD (16:10 Wide Screen Aspect Ratio)
Display ATI Mobility Radeon 9700 High Performance Chip
Integrated 128-bit 2D/3D Graphics Accelerator
Advanced HW Acceleration for DVD Playback
Fully DirectX® 9 Support
128MB DDR SGRAM External Video Memory
Dual-View Display Monitor
External Display Supporting Resolution up to 1600 * 1200 UXGA
Storage One Changeable 12.7mm (h) Optical Device (CD-ROM/ DVD-ROM/ CD-RW/ DVD-RW /Combo/DVD-Dual etc.)
One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive Supporting LBA Mode
Supports Master Mode IDE, PIO Mode 4 / ATA-33/66/100

12 PRESTIGIO NOBILE 158W
ENG
Feature Specification
Audio AC’97 2.2 Compliant Device S/PDIF Digital Output (5.1 CH)
Advanced Wavetable Synthesizer Built-In Microphone
DirectSound™ 3D Accelerator 4 Built-In 1.5W Speakers (25 * 15 mm)
Full-Duplex
Keyboard, Pointing Full Size Winkey Keyboard with Numeric Keypad Built-In TouchPad (Scroll Functionality Included)
Device & Buttons
PCMCIA One Type II PCMCIA 3.3V/5V Socket
Interface & Three USB 2.0/1.1 Ports One 4-in-1 Built-In Card Reader (SD/ MS/MMC)
Communication One Mini IEEE1394 Ports One RJ-11 Jack (Modem) Integrated V.90/56K MDC
One External Monitor (VGA) Port Modem (V.92)
One S-Video Jack for TV Output One RJ-45 Jack (Local Area Network) 1000BASE-T
(Gigabit) LAN On Board 10/100 BASE-T Compatible
One Serial Port IEEE 802.3 & 802.3u Compliant
One InfraredTransceiver (IrDA 1.1/FIR/SIR/ASKIR) DC-In Jack
Infrared Transfer 1cm ~ 1M Operating Intel PRO/Wireless 2100 (802.11b) OR Intel PRO/Wireless
Distance 2200BG (802.11b/g
115.2K bps SIR Mini PCI WLAN Module (Optional)
4M bps FIR USB Video Camera Module (Factory Option)
One Headphone Jack Bluetooth 1.1 + MDC Module (Factory Option)
One Microphone Jack
One S/PDIF Out Port
Indicators LED Indicators (System Activity, Suspend/Power On/AC-In, Battery Charging/Battery Full, Num
Lock, Caps Lock, Scroll Lock, email, WLAN, Bluetooth)
Power Management Supports ACPI 2.0 Supports Resume from Alarm
Supports Hibernate/Standby Modes Supports Resume from Modem Ring
Supports Battery Low Sleep Supports Resume from LAN
Power Universal AC Adapter - AC-In 100~240V, 47~63Hz, DC Output 65W
Easy Changeable Main Battery Smart Lithium-Ion (6 cells)
Buttons email/ browser/ power/ WLAN+ Bluetooth
Environmental Spec Temperature Relative Humidity
Operating: 5°C ~ 35°C Operating: 20% ~ 80%
Non-Operating: -20°C ~ 60°C Non-Operating: 10% ~ 90%
Physical Dimensions 360mm (w) * 273mm (d) * 29.5mm (h) 3.15Kg Max (with battery)
& Weight
Optional CD-RW Drive Module Intel PRO/Wireless 2100 (802.11b)
DVD/CD-RW Combo Drive Module Mini PCI WLAN Module (Optional)
DVD-ROM Drive Module Intel PRO/Wireless 2200BG (802.11b/g) Mini
DVD-RW Drive Module PCI WLAN Module (Optional)
DVD-Dual DriveModule Bluetooth 1.1 + MDC Module (Factory Option)
Software DVD Player USB VIdeo Camera Module (Factory Option)
