Prilux Arisa TOP4 User manual

1/8 agosto 2021
ÑE
Arisa
TOP4
[GRÁFICOS: Unidades en mm/ GRAPHICS: Units in mm/GRAPHIQUES: Unités en mm/GRÁFICOS: Unidades em mm]
Especicaciones/ Specications
Aislamiento eléctrico/
Electrical isolation
CI
Índice de estanqueidad/
Sealing rating IP66
Protección contra impactos/
Impact resistance IK09
Nº LED/
LED Number 12/16/32LED
Peso/
Weight 8kg
Altura Máx. de instalación/
Sealing rating 20m
Máx. sup. proyectada al aire/
Maximum surface wind exposed
0,185m2
Manual instrucciones
Instruction manual
478
468
590
2/8
PRECAUCIONES:
• Mantenga el producto fuera del alcance de los niños.
• No sumerja este producto en agua ni lo manipule con las manos mojadas.
• No golpee el producto.
• No instale el producto donde haya fuentes de calor o concentraciones
de humedad.
• No manipule el producto mientras se encuentre en funcionamiento y
déjelo enfriar antes de tocarlo con las manos.
• El producto no debe ser cubierto por material aislante térmico en ningún
caso.
• Mantenga una distancia mínima de 1m con la supercie u objeto a
iluminar.
• Si el producto se encuentra dañado sustitúyalo inmediatamente por uno
nuevo.
• Desconecte la corriente antes de instalar el producto.
• Este producto contiene componentes sensibles a la electricidad estática y
una descarga sobre ella podría destruir o dañar sus componentes.
• Antes de proceder a cualquier manipulación o mantenimiento hay que
asegurarse de que el aparato esté completamente desconectado del
suministro eléctrico.
• La reposición o mantenimiento de cualquier componente deberá hacerse
con idénticos elementos recomendados y suministrados por el propio
fabricante. De no ser así, cualquier incidencia en una instalación que
no se haya realizado de acuerdo con esta hoja de instrucciones será
responsabilidad del instalador.
• La fuente de luz de esta luminaria debe reemplazarse unicamente por el
fabricante, su servicio técnico o persona cualicada equivalente.
• La luminaria debe colocarse de forma que no se espera una mirada
prolongada a la luminaria a una distancia más cercana a 1m.
PRECAUTIONS:
• Keep the product out of the reach of children.
• Do not immerse this product in water or handle it with wet hands.
• Do not hit the product.
• Do not install the product where there are heat sources or moisture
concentrations.
• Do not handle the product while it is in operation and allow it to cool before
touching it with your hands.
• The product must not be covered with thermal insulation material under
any circumstances.
• Maintain a minimum distance of 1m from the surface or object to be
illuminated.
• If the product is damaged, replace it immediately with a new one.
• Disconnect power before installing the product.
• This product contains components sensitive to static electricity and a
discharge to it could destroy or damage its components.
• Before carrying out any work or maintenance, make sure that the device is
completely disconnected from the power supply.
• The replacement or maintenance of any component must be carried
out with the same elements recommended and supplied by the
manufacturer himself. If this is not the case, any incident on an installation
that has not been carried out in accordance with this instruction sheet is
the responsibility of the installer.
• The light source of this luminaire must be replaced only by the manufacturer,
its technical service or equivalent qualied person.
• The luminaire must be positioned so that a prolonged look is not expected
at the luminaire at a distance closer to 1m.
AVISO
ANTES DE COMENZAR LA INSTALACIÓN DE ÉSTE PRODUCTO,
POR FAVOR, LEA ATENTAMENTE LAS INSTRUCCIONES Y
GUÁRDELAS EN UN SITIO SEGURO.
LA INSTALACIÓN DEBE REALIZARLA PERSONAL
CUALIFICADO.
LA INADECUADA MANIPULACIÓN DE LOS COMPONENTES
O DE LA PROPIA LUMINARIA PODRÍA DAÑAR EL CORRECTO
FUNCIONAMIENTO DE ESTE PRODUCTO, QUEDANDO ANULADA
LA GARANTÍA DEL FABRICANTE.
QUEDA ANULADA LA GARANTÍA DEL FABRICANTE: SI LA
INSTALACIÓN NO SE REALIZA SEGÚN LO INDICADO EN EL REBT
2002.
ES DE OBLIGADO CUMPLIMIENTO LA APLICACIÓN DE ITC BT09-
4 DEL REBT (INSTALACIÓN DE PROTECTORES DE SOBRETENSIONES
EN LÍNEAS Y LUMINARIAS) PARA INSTALACIONES INDUSTRIALES
Y DE ALUMBRADO PÚBLICO. LA GARANTÍA NO CUBRE DAÑOS
PRODUCIDOS POR SOBRETENSIONES EN LUMINARIAS SIN
PROTECTORES DE SOBRETENSIONES.
RESPETAR LAS PRECAUCIONES
DE MANIPULACIÓN DE LOS
COMPONENTES SENSIBLES A
DESCARGAS ELECTROSTÁTICAS
(LED).
WARNING
BEFORE INSTALLING THIS PRODUCT, PLEASE READ THE
INSTRUCTIONS CAREFULLY AND STORE THEM IN A SAFE PLACE.
THE INSTALLATION SHOULD BE CARRIED OUT BY TRAINED STAFF.
INCORRECT HANDLING OF THE PARTS OR THE LIGHT FIXTURE ITSELF
MAY IMPAIR THE PROPER PERFORMANCE OF THIS PRODUCT. IN
THIS CASE, THE MANUFACTURER GUARANTEE SHALL BE DEEMED
VOID.
THE MANUFACTURER GUARANTEE SHALL BE DEEMED VOID: IF THE
INSTALLATION IS NOT PERFORMED IN ACCORDANCE WITH THE
SPANISH LOW VOLTAGE ELECTROTECHNICAL REGULATION 2002
(REBT 2002).
THE APPLICATION OF IBC BT09-4 OF REBT (INSTALLATION OF
LINE AND LIGHT FIXTURE SURGE PROTECTORS) IS ESSENTIAL
FOR INDUSTRIAL AND PUBLIC LIGHTING INSTALLATIONS. THE
GUARANTEE DOES NOT COVER AGAINST DAMAGES CAUSED
BY SURGES IN LIGHT FIXTURES WITHOUT SURGE PROTECTORS
INSTALLED.
ATTENTION!!!
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES.
3/8
8Nm máx.
X4
X8
8Nm máx.
82
78
100
Ø65
Ø62
90
Ø65
Ø62
90
100
82
78
100
82
78
100
66
62
Ø65
Ø62
90
ACOPLE POSTE 60mm/
POST COUPLING 60mm/
4/8
LADO ACERA
SIDEWALK SIDE
220-240 50-60Hz
Ø60mm max.
X4
8Nm máx.
a/ 60mm.
Vidrio templado 4mm/
4mm tempered glass
5/8
b/ 76mm.
X4
8Nm máx.
220-240 50-60Hz
LADO ACERA
SIDEWALK SIDE
Ø76mm max.
X2
82
78
100
Ø65
Ø62
90
Ø65
Ø62
90
100
82
78
100
82
78
100
66
62
Ø65
Ø62
90
ACOPLE POSTE 76mm/
POST COUPLING 76mm/
Vidrio templado 4mm
Tempered glass 4mm
6/8
Ver esquema de instalación/
See installation diagram
5≤ Ø manguera =≤ 10mm 2.5 Nm Máx
5≤ Ø hose =≤ 10mm 2.5 Nm Máx
7/8
ESQUEMA DE INSTALACIÓN/ INSTALLATION DIAGRAM
ALIMENTACIÓN/
POWER IN
Regulación DALI/
DALI regulation
Doble nivel con línea de mando/
Double level whith control line
Regulación 1-10V/
1-10V regulation
DA DADA DA
Nc Lc
www.grupoprilux.com
8/8
