Prime Design DEPLOYPRO LOCK N GO User manual

DEPLOYPRO LOCK N GO
PRIME DESIGN, A SAFE FLEET BRAND ▪ Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118
Toll Free: 1.8.PRIME.RACK ▪ Fax: [phone] ▪ Email: [email protected] ▪ Website: www.primedesign.net

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2020 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608 AND OTHER PATENTS PENDING
2
1
Z-Post Pair w/ Clamps (1X) Slide Assembly (1X)
M8 x 40MM (2X)
PLR-8229 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
CONTENTS OVERVIEW
1—PLR-8229.......................................................... (Qty 1)
DeployPro Lock N Go Ladder Clamp Assembly
2—DPS 8000/8001 (shown for illustrative purposes only)
Ordered separately
* Pre-assembly required. See your DeplyPro
Assembly Instructions for proper setup before
installing the PLR-8229.

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2020 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608 AND OTHER PATENTS PENDING
3
PLR-8229 ASSEMBLY INSTRUCTIONS
2
DEPLOYPRO LOCK N GO LADDER CLAMP
ASSEMBLY SEQUENCE
Slide the Clamp base into the open
position as shown.
1Where applicable, remove your ladder and
straps before installing the Clamp base.
NOTE: Your ladder will be needed in
Steps 4–6 for nal adjustments.
Pull release levers on
both sides to open
NOTE: Ladder, Base/Rotation rack and mounted DPS are shown for
illustrative purposes only. Customer-specic models and setup will vary.

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2020 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608 AND OTHER PATENTS PENDING
4
PLR-8229 ASSEMBLY INSTRUCTIONS
USAM-PLR8229-US01 Rev-B 0619
3
Install Clamp base with the included M8 Hardware
into the DeployPro’s pre-installed Strip Nuts as shown.
Determine desired positioning on the DeployPro,
and torque to 90 in-lbs.
4Position your ladder
back onto the Deploy Pro.
Install the Z-Posts onto the
ends of the Clamp base
as shown below.
6
Using the release levers,
slide the Clamp base
together into the closed
position on the ladder.
6.1
Slide Z-Posts in until they are approximately ¼” from
the sides of the ladder, and torque the Z-Post Clamp
Nuts to 90 in-lbs.
¼” from ladder sides
NOTE: Ladder Straps will no longer be necessary,
and may be discarded.
5Finger-tighten Clamp Nuts only.
Do not trorque until Step 6.1
