Primera LX810e User manual

Primera Technology is one of the world’s leading
manufacturers of specialty printers. We’ve built well over
a million inkjet, thermal transfer and dot matrix printers
throughout our history. So, you can be confident that
your new Color Label Printer from Primera will give you
years of reliable performance. Best of all, the LX810e
delivers truly professional results at an affordable price!
NiceLabel and Z-Color are trademarks and Primera is a registered trademark of Primera Technology, Inc. Windows is a registered trademark of Microsoft Corporation. All other trademarks are the property of
their respective companies. Specifications are subject to change without notice. All data and company names used in sample prints are fictitious. © 2009, Primera Technology, Inc. Patents pending. 090130
Technical Specifications
Print Method: Inkjet
Print Resolutions: 4800 x 1200 dpi, 2400 x 1200 dpi, 600 x 600 dpi
Print Speeds: Approximately 51 mm per second for black
Approximately 38 mm per second for color + black
Approximately 245 mm per second feed rate
Ink Cartridges: Color (CMY)
Black Dye-Based (Kd)
Black Pigment-Based (Kp)
Colors: 16.7 million
Color Matching: Z-Color™ Color Matching Software
Max. Print Width: 210 mm
Media Width: 40 mm to 215 mm
Media Types: Roll-fed pressure-sensitive labels, roll-fed tags
Media Sensing: Moveable see-through sensor for die-cut labels;
Reflective for labels and tags with black stripe;
Continuous label stock; Preprinted label stock.
Supply Roll: 152 mm max. diameter on 76 mm core
Ink Level Warning: Calculates actual number of prints remaining
based upon ink usage of graphics being printed
(patent-pending)
Indicator Lights: Power, Pause, Ink
Controls: Pause, Feed, Unload
Operating Systems: Windows XP/2000/Vista or Mac OS X, 10.2 or higher
Data Interface: USB 2.0; External Control Port
Recommended Minimum System:
For PC: Pentium® IV computer or better, 512MB RAM,
5GB free hard drive space, USB 2.0 (recommended)
For Mac: 700 Mhz G4 or higher with 512MB RAM,
5GB free hard drive space, USB 2.0 (recommended)
Label Design NiceLabel SE Primera Edition included.
Software: Can also be used with most other popular
label design software programs.
Electrical Rating: 12VDC, 5 A
Power Requirements: 100-240VAC, 50/60 Hz, 60 watts
Certifications: UL, UL-C, CE, FCC Class B
Weight: 13.2 kg
Dimensions: 432 mmW x 231 mmH x 394 mmD
Need to Make Smaller Labels?
The LX400e offers all of the same great features of our
LX810e but prints smaller labels with a maximum width
of 108 mm.
Specialty Applications
The LX400e is also ideal for producing full-color tickets
and tags, retail coupons, patient wristbands
and much more. The optional, field-
installable Media Cutter attaches to
the front of the printer and slides
down and out of the way when
not needed. A fan-fold media slot
for tags and tickets is located on
the rear panel of the printer.
Price/Performance Leader
Mainzer Strasse 131
D - 65187 Wiesbaden (Germany)
Fon: +49 (0) 611 - 92777-0
Fax: +49 (0) 611 - 92777-50
www.primeralabel.eu
www.primera-europe.eu
E-mail: [email protected]
Primera20090130 Reorder Nr.: MKT74252BEN
www.primeralabel.eu

..................................... ................................... ..................................... ..................................... ............................... ............................... ...............................
$0
$1,200
$1,000
$800
$600
$400
$200
COST COMPARISON
TOTAL COST (Ink and Label)
LX810 Flexo Press
LABEL QUANTITY
250 500 1,000 2,500 5,000 10,000 15,000
250 500 1,000 2,500 5,000 10,000 15,000
LX810e
Print Short-Run Color
Labels On-Demand!
The LX810e Color Label Printer utilizes the
latest in high-resolution inkjet technology to
print brilliant full-color product labels right
in your office or production facility. With
spectacular 4800 dpi print resolution and
high throughput speeds, the LX810e is
simply the best industrial-grade color inkjet
label printer ever made!
Your labels can include full-color photos,
illustrations, graphics, text and bar codes.
Print them when and where you need them –
in quantities you can really use! Best of all,
depending upon the quantity you print, the
price per label will be significantly less than
labels printed on flexo or offset.
With the LX810e there are…
• No minimum order requirements • No obsolete label inventory
• No plate and die charges • No long lead times
For more information, visit us at www.primeralabel.eu
Professional-Quality Results
There’s no need to settle for low-resolution color
labels on your products. LX810e’s incredible 4800 dpi
printing delivers results that far exceed virtually any
other on-demand print method available today.
Six built-in print resolutions let you select the
combination of print quality and speed that fits
your application best. No matter which you choose,
your labels are bright, colorful and professional.
Creating labels takes just minutes on your Windows®
XP/2000/Vista™ PC or Mac® OS X V10.2 or higher.
You can mix any combination of text, graphics,
photos, illustrations and even bar codes. Easy to
use NiceLabel™ SE Design Software is included for
your basic label design needs. You can also use
most other graphic software programs, such as
Adobe® Photoshop® and Illustrator®, giving you
maximum flexibility and creativity in your designs.
Get Up and Running Quickly
From initial set-up to full operation, the LX810e is easy
to use. Plus, everything you need to start printing
labels is included in the box.
Each LX810e ships with NiceLabel
SE design software, sample roll of
high-gloss labels, color and black
ink cartridges and a USB cable.
You’ll be printing full-color labels
within minutes of taking the printer out
of its shipping box.
A Wide Variety of Substrates –
Including Water-Resistant Labels!
The LX810e prints onto many different label and tag
materials, including inkjet-coated high-gloss, semigloss
and matte labels. Labels printed on high-gloss
material are highly scratch and smudge resistant and
virtually waterproof. This is a perfect solution for
primary or box labels that can be exposed to water,
rain and snow.
Maximum label width can be as wide as 21.5 cm.
Maximum label length is 61 cm.
Many Applications
The LX810e produces gorgeous, professional-quality
labels for all your short-run, specialty products.
It is also perfect for a host of other uses such as:
• Full-color box-end labels with all the required
bar codes
• Test marketing
• Contract manufacturing
• Private label goods
• Promotional labels
• And much more!
