Primera’s AP-Series Label Applicators are the perfect semi-automatic labeling solution for cylindrical
containers as well as many tapered containers, including bottles, cans, jars and tubes.
Set-up and operation is fast and easy. Just:
1. Set the guides
2. Place your container in the machine
3. Press the footswitch and your label is applied
The built-in spring-loaded pressure arm makes sure
labels are applied firmly and without wrinkles.
With an AP-Series Label Applicator you’ll apply labels
faster and more accurately – helping to speed up your
production and sell more of your products!
AP-Series Label Applicators
www.primeralabel.eu

Apply Labels Fast and Accurately
With an AP-Series Label Applicator you’ll be able to apply labels at
speeds of up to 1200 per hour. Labels are perfectly applied without
wrinkles, giving your finished products a highly professional look.
AP-Series Label Applicators are an ideal accessory to Primera’s LX-
or CX-Series label printers. The applicators can also apply roll-fed,
pressure-sensitive labels produced by most other flexographic, offset
and digital presses.
Container Width: 1" to 9.4" (25.4mm to 238mm)
Container Diameter: 15mm to 170mm (0.6" to 6.7")
Container Shape: Cylindrical and many tapered
Supply roll diameter: Up to 203mm (8" )
Media liner width: 25.4mm to 213mm (1" to 8.375")
Supply roll core: 51.8mm to 76.2mm (2" to 3" I.D.)
Electrical rating: 12VDC, 5.0A
Power requirements: 100-240VAC, 50/60 Hz, 60 watts
Agency certifications: UL, UL-C, CE, FCC Class A
Weight: 7.26 kg (16 lbs.)
Dimensions: 340mmW x 226mmH x 328mmD
(13.4"W x 8.9"H x 12.9"D)
Specifications
AP-Series Label Applicators are the perfect accessory to
Primera’s LX400eand LX810eColor Label Printers
Features
»Quick set-up and easy operation
»Accurately applies labels to the front (AP360e) or front and back
(AP362e) with variable spacing
»Fast – labels are applied at 5.3” (135mm) per second –
up to 1200 containers per hour
»Compact size – fits on most desks and countertops
»Professionally designed – one of the only semi-automatic label
applicators available with UL, CSA and FCC safety and emissions
certifications
»Industrial strength – built with heavy-duty sheet metal and steel
for long life
AP360e is the base model. It quickly and efficiently
applies single labels at a time.
AP362e is an advanced model. It can apply one or
two different labels to a single container. A built-in
LED counter and memory for up to nine front-to-back
label offsets is also included.
Two Models Available
