PROAIM CINEMA Series User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Mitchell Vibraon Isolator for Gimbals (VB-MTCL-00)
Ass e mb l y M a n u a l
Mitchell Plate
Middle Base Plate
Rods
Vibraon
Isolator
Base Plate Allen Key

2
 Aach Mitchell Vibraon Isolator with plate
of your setup and ghten to secure it
properly.
 Then loosen the bolts of Mitchell plate and
insert Castle Ring into it. Connect any Gimbal
Mount with Castle Ring as shown in the
image.
Mitchell Isolator Setup
Isolator Base Plate Setup
NOTE: The isolator plate can be xed both Over
Slung and Under Slung, as per your
requirement.
 Loosen bolts on Mitchell Plate with help of
allen key and remove the plate. Your
equipment will look as shown in image.
 Turn Isolator upside-down & loosen the bolts
to remove Isolator with Base Plate.
 Now loosen 4 corner bolts of Middle Base
Plate and remove Rods as shown in image.
NOTE: You can also aach only Vibraon Isolator Plate by removing the Mitchell Plate.

3
 Then aach Middle Base Plate with Ronin
Plate (Not Included). Insert the bolts and
ghten them with help of allen key.
 Now aach this Middle Base Plate with
Isolator Plate and ghten the bolts
accurately with allen key, as shown in image.
 Finally, you can mount Base Plate with
L-plate of your Isolator Arm (Not Included)
and mount your Gimbal.
 Loosen the bolts from top and boom of
Vibraon Isolator.
 Then remove bolts and one wire set from
Vibraon Isolator plate.
Single Spring Set Setup
NOTE: Vibraon Isolator can also be customized with Single Spring conguraon for using with
lightweight setups from 15-30kg / 33-66lb.

4
YOUR PROAIM MITCHELL VIBRATION ISOLATOR FOR GIMBALS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
 Now adjust other wire set in center of the
Vibraon Isolator and ghten all allen bolts
to secure spring set appropriately
