PROAIM P-STRG-CF User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
CF Carbon Fiber Star Ring for Handheld Gimbal
Camera Stabilizers & Body Support Rigs (P-STRG-CF)
Assembly Manual
2 x L-type Allen key
(Size:- 5mm, 3mm)
Top CF Star Ring
4 x Allen Bolts
(Size: 4 x 16)
4 x Allen Bolts
(Size:-3 x 10)
4 x Allen Bolts
(Size: 3 x 12)
4 x Allen Bolts
(Size: 4 x 20)
1 x T-type Allen key
(Size:-2.5mm)
Boom CF Star Ring Bag Packing
2
FUNCTION
Stands in Upright Posions with
Addion Mounng
keep the setup upright without using a
stand by providing a wide base that does
not fall forward or backward.
Foot Clamps
Index marking to
enable the operator
to eciently ax the
clamps and
quick-release adapter
where they were the
last me they were
shoong.
Scalling
Eortlessly aach to most body
support rigs and Camera can be move
exible and adjust the posions.
Spool Clamps
Quick Release Adapter
Index Marking
Index marking helps to
adjust the posions of
spool clamps and
adapter.
Underslung and over-slung mode using the quick-
release adapter with M3 and M4 threads
Wide compability movi & R2 Quick
release plate with addional accessory
security, control over your 2-axis and
3-axis gimbals with the adapter
3
• Aach the top CF & boom CF Star Ring.
NOTE: The portable and travel-friendly design
can be detached into two pieces to ensure
comfortable carriage to dierent shoong
locaons.
CF Carbon Fiber Star Ring Setup
• All three foot clamps have been removed, as
shown in the image.
• Aer aaching the Star Ring, ghten the allen
bolts it using the 2.5mm Allen key, as shown
in the image.
• The Star Ring has sturdy spool clamps that
easily aach to most body support rigs.
Features: The Spool clamp can be posioned at
the same place where they were the last me
you were shoong using the index markings.
• Remove the aached Foot clamp on the Top
CF Star ring by loosening it.
• Repeat the same process with the other two
foot clamps.
• Aach the foot clamps with the boom CF
Star Ring.
4
• Aer aaching the foot clamps, ghten them
using the provided knobs.
• Aer aaching the spool clamp, insert Allen
bolts in it.
• Repeat the same process with the second
spool clamp.
• Loosen and remove the bolts using the Allen
key.
Feature: The octagonal ring features index
marking to enable the operator to eciently
ax the clamps and quick-release adapter
where they were the last me they were
shoong.
• Detach the spool clamp from the Star Ring.
• Change the spool clamp's direcon by
aaching the clamp's outer poron to the
inside, as shown in the image.
• Now, the direcon of the spool clamps is on
the outside, as shown in the image.
Feature: Its robust spool clamps eortlessly
aach to most body support rigs, such as
Proaim Hawk Body Support, Hawk Lite Body
Support, Gimbal Bird Body Support, and Flycam
Flowline Camera Gimbal Tilt Control Kit.
Feature: It incorporates foot clamps that keep
the setup upright without a stand, providing a
broad base that does not fall forward or
backward as shown in the picture.
Spool Clamps Assembly Inside
5
• To straighten the quick-release adapter on
the Top CF Star Ring, loosen all its bolts using
the Allen key.
• Aer aaching, re-insert the bolts in the
adapter and ghten them using the Allen key.
• Detach the quick-release adapter as shown.
• Aach the quick-release plate from the
boom side of the Top CF Star Ring.
• Aach the quick-release adapter.
• Loosen the knob of the quick-release adapter
and remove it.
Quick Release Adapter Assembly Inside
6
• Insert the bolt in the quick-release plate.
NOTE: It can be used in both underslung and
over-slung mode using quick-release adapters
with M3 and M4 threads, to which the MOVI
quick-release plate and R2 quick-release plate
can be mounted, respecvely.
• To aach the gimbal (Not Included), slide the
quick-release plate onto the Star Ring and
ghten the knob to secure the setup.
• Aer inserng the bolt, aach the plate with
the QR Movi (Not Included).
• Aer the aachment, secure the
quick-release plate using the Allen key.
• Aach the QR Movi with the gimbal
(Not Included) and press the locking lever by
pressing the lever.
• Slide the Camera (Not Included) onto the
quick-release plate of the gimbal.
NOTE: Unlock unmatched stability and control
over your 2-axis and 3-axis gimbals with the
Handheld CF Star Ring,
7
• Aer mounng the Camera (Not Included),
press the locking lever from the boom side
to secure the Camera.
• The Star Ring oers enhanced support and
exibility, allowing gimbal operators to
achieve more stable control over their camera
gimbals to achieve professional-quality shots
consistently.
YOUR PROAIM CF CARBON FIBER STAR RING FOR HANDHELD GIMBAL
CAMERA STABILIZERS & BODY SUPPORT RIGS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
