PROAIM Fusion User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
3 x Junior Pin
Adapters
2 x End Feet
Fusion Video/Film Camera Dolly Slider with Track Ends (DL-FUSN-01)
4 x Adjustable Leveling Legs
2 x Safety Wheels
Camera Dolly with
100mm bowl
Mitchell Base
Support Bracket
150mm Bowl 3 x T-Type Allen Key
(Size : 3mm, 4mm, 5 x 16”)
75mm Conversion Ring
4 x Elasc
Stoppers

2
 Insert the adjustable leveling legs into the
end feet adapter and ghten the knob to
secure it.
 Loosen the knobs of the end feet & insert the
track rails (Not Included) into it, and then
ghten the knobs ghtly to secure it.
 Mount the camera Dolly on the track
(Not Included), as shown.
NOTE: Always mount dolly on rigid tracks.
Aaching the Track
Aaching the Levelling Legs Setup
Assembling the Dolly Setup

3
 Remove the side knobs of the Dolly and
aach the safety wheels on either side.
Secure them by ghtening the knobs.
 Now aach the elasc stoppers on both the
rails to prevent the Dolly from geng
dislocated. These can also be used as wheel
brakes.
 By default, a standard 100mm bowl
receptacle is axed to the Dolly.
NOTE: Fusion Dolly accommodates 4 Camera
Mounng Heads. 75mm Bowl / 100mm Bowl /
150mm Bowl / Mitchell Base.
 You can also mount a 150mm conversion ring
to use 100mm bowl head.
 You can mount a 75mm conversion ring to
use 75mm bowl head.
 Loosen the side knobs of the Dolly in order to
lt the camera plaorm that can incline up to
52°. Adjust and lock it to your desired angle
by locking the knobs.

4
 Remove the 100mm bowl receptacle from the
plaorm & aach the Mitchell plate on it.
Tighten the assembly with the help of
provided tools.
 Now you can mount your camera setup as
desired.
 Now, remove the hook from the junior pin
adapter, and insert it into the support
bracket, as shown in the image.
 Then loosen the knob of the junior pin
adapter and mount the track system
(Not Included) on a stand (Not Included) via
the adapter. Tighten the knob to secure it.
 Remove the hook from the junior pin adapter
and insert it into the end feet.
 Tighten the assembly by twisng the adapter.
Aaching the Supports

5
 Place this support bracket below the track
(Not Included) system, and then mount your
camera setup, as shown in the image.
 Aach the 100mm bowl receptacle to the
boom of the Dolly and ghten it with the
help of the Allen key.
 You can mount your camera in an underslung
orientaon.
To Use Dolly As Underslung

6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR PROAIM FUSION VIDEO/FILM CAMERA DOLLY SLIDER WITH TRACK ENDS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
