PROAIM P-GDTR-01 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Gladiator Ergonomic Body Support Camera Rig (P-GDTR-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Assembly Manua l
Removable
Non-Skid Pad
Washable Pads
Wider Back Support
Accessory Loops
Quick height
Adjustment
Knobs

2
Gladiator Rig Setup
 Reghten the screws using an Allen key to
secure the shoulder pad posion.
 To adjust the shoulder pad posion, loosen
the top front & back screws using an Allen
key and adjust the shoulder pad as required.
Note: You can move the screws up and down
by loosening them. Moving the screw up helps
you extend the shoulder post upwards. Lower-
ing the screw lowers the shoulder pad.
 Detach the chest buckle and wear the
gladiator jacket on your right shoulder. Then,
reaach the waist buckle.
Note: The gladiator jacket comes assembled
on the right side. If you want to wear it on the
le side according to your requirement, its
steps are given separately.
 Buckle up the chest strap as shown in the
image.
Note: You can adjust the chest strap as per
your comfort.
 Adjust the height as required and reghten
the knobs properly. Then detach the waist
buckle.
Note: The jacket quickly adjusts to t dierent
body types and changes on the y to keep you
comfortable take-aer-take.
 Loosen both the front and back height ad-
justment knobs on the jacket.

3
Gladiator Rig Le shoulder Setup
 Loosen and take o both the height
adjustment knobs.
Note: If you don't interchange the shoulder
support plate of the gladiator rig and wear it on
the le shoulder, the gladiator jacket will not
adjust on your body, and the pad will go to the
back wrong side.
The steps to mount the pad correctly are given
below.
 Loosen all bolts on the front and back sides
of the jacket using an Allen key.
 You can adjust the boom plate of the
jacket anywhere on the rear-strut.
 Aach the middle plate and ghten the
knobs back securely.
 Remove the jacket's middle plate and shi it
along with the pad from one side to the
other.
Interchanging Shoulder Support from Right to Le
Rear strut
re-mountable
for dierent
body types
Shiing the Middle Plate & Pad

4
Note: Proaim Gladiator Rig prevents spinal
compression allowing you to comfortably
operate shoulder-mounted conguraons
without aecng the camera's movement or
balance. 100% of the weight is transferred from
your shoulders and back to your hips, bypass-
ing your spine.
It supports heavy-duty loads, such as
fully-accessorized ARRI, Red or Black Magic
Cameras.
 Buckle up and adjust the chest and the waist
straps as per your comfort.
 Shi the boom plate of the jacket from one
side to the other and ghten all the bolts us-
ing an Allen key, as shown in the image.
Note: Follow the same process on the other
side of the jacket.
YOUR PROAIM GLADIATOR BODY SUPPORT CAMERA RIG
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)

5
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
