Probasics Three-in-One Commode User manual
Three-in-One
Commode
Silla inodoro tres en uno/
Chaise d’aisance trois-en-un
www.healthcaredme.com
FEATURES
• Can functionas a free-standing commode, a
toilet safety frame (with backrest removed), or as
a raised toilet seat with arms
• Features deeper elongated seat depth for less
mess and to allow more room for cleaning
• Durable steel-welded frameis attractive, strong
and easy-to-clean
• Tool-free assembly, includes plastic snap on seat
with lid
• Seat height readily adjusts in one-inch increments
• Plastic arms provide added comfort
• Comescompletewith commode bucket with
handle, cover and splashguard
• HCPCSCode:E0163*
SPECIFICATIONS
Width between arms: 17.5"
Outside Width: 24"
Seat Dimensions: 13.5"W x 16.5"D
Seat Opening: 8"W x 10"D
Adjustable Seat Height: 15.5" – 23.5"
Color: Gray
Weight Capacity: 300 lb
Carton Dimensions: 25.5" x 25.5" x 25"
Shipping Weight: 57 lb
Warranty: Limited lifetime on frame
One year on parts
Three-in-One
Steel Commode
The ProBasics Three-in-One Steel Commode
has three versatile functions; it can beused as
a toilet safety frame, a commode, and a raised
toilet seat. It features a removable back and
comes complete with commode bucket, splash
guard and lid. The versatile design includes
an elongated deeper seat, armrests for added
comfort, angled legs for stability andnon-
marring rubber tips.
Item # Description UPC UOM
sc/4838170760518taeSdetagnolEhtiwedommoCenO-ni-eerhTscisaBorPC13SB
2
WEIGHT CAPACITY :
350 lb/158 kg (BS31C shown above)
450 lb/204 kg (BSB31C)
Capacidad de peso / Capacité de poids
English Español Français
1Lid Tapa Couvercle
2Backrest support Soporte de
respaldo
Dossier
3Seat Asiento Siège
4Frame Estructura Châssis
5Leg tip Puntas de la pata Embouts
6Commode pail
with splash guard
and lid (BS31C)
Commode Pail only
(BSB31C)
Cubo de silla
inodoro con
protector para
salpicaduras y
tapa (BS31C) Solo
cubo de inodoro
(BSB31C)
Seau de chaise
d’aisance avec
pare-éclaboussures
et couvercle
(BS31C) Seau de
chaise seulement
(BSB31C)
7Height adjustable
legs
Patas de altura
regulable
Pattes à hauteur
réglable
8Back frame rail Riel trasero de la
estructura
Rail de châssis arrière
9Armrest Apoyabrazos Accoudoirs
THREE-IN-ONE
COMMODE DIAGRAM
Silla inodoro tres en uno/Chaise d’aisance trois-en-un
1
3
4
5
2
3
Remove the three-in-one commode components from all
packaging including tape, cardboard and plastic. Check
all parts for damage before use. If any parts are missing or
damaged, DO NOT attempt to use the commode. If you
do not understand the manual, contact your dealer for a
complete explanation of the instructions, cautions and
warnings. Otherwise injury may result.
NOTE: DO NOT use excessive force when installing any parts.
SETUP INSTRUCTIONS
1. Remove frame, seat, lid, pail, cover and splash shield from
carton. Allow the seat and lid to reach room temperature
if exposed to cold. This will help prevent the seat and
lid clamps from cracking while being assembled onto
commode back frame rail.
2. Align the toilet seat clamps onto the back-frame rail (both
clamps should sit outside the pail brackets). Push down on
3. Repeat the same process for the lid, ensuring the lid clamps
line up outside of the seat clamps.
4. Lift the seat and lid to rest against the backrest.
5. Place the commode pail between the pail brackets on the
Remove the bucket lid before use.
ADJUST COMMODE HEIGHT
1. Depress the height adjustment button and slide the lower
leg upward or downward until the height adjustment
button is fully engaged in the desired hole.
2. Repeat for other three leg attachments.
CAUTION: Ensure that all four commode legs are adjusted to
the same height, and that all height adjustment buttons
protrude fully through adjustment holes before use.
ASSEMBLY INSTRUCTIONS
Congratulations on purchasing a quality ProBasics ®Three-
in-One Commode. Our commodes have a versatile design
that can be used as a bedside commode, raised toilet seat or
toilet safety frame. Please be sure to read these instructions
and warnings thoroughly and follow the instructions of your
your safety.
DO NOT ATTEMPT TO ADJUST OR OPERATE
THIS COMMODE WITHOUT READING ALL
INSTRUCTIONS CAREFULLY.
4
TO USE COMMODE OVER TOILET
(AS A RAISED TOILET SEAT OR TOILET SAFETY FRAME)
1. Set commode to desired height (see “Adjust Commode
Height” section).
2. Position splash guard in place onto pail supports.
3. Remove back support by simply unscrewing the wing nut
assembly on either side.
4. Lift toilet bowl seat and place commode over toilet with
splash shield positioned over the center of the toilet bowl.
5. Lower the commode seat onto the frame before use.
6. Clean seat and splash shield with disinfectant after
each use.
TO USE AS A BEDSIDE COMMODE
1. Set commode to desired height (see “Adjust Commode
Height” section).
2. Push commode pail onto pail supports. Ensure that pail is
properly positioned below commode opening. Commode
is now ready for use.
3.
lid over commode pail to contain odors.
4. Remove pail and lid simultaneously to empty pail. Clean
seat and pail with disinfectant after each use.
CAUTION: It is NOT recommended to remove the backrest
support when using as a bedside commode. Serious injury
may result.
1. Use a mild soap and water solution, rinse thoroughly
with clean water, then dry with a soft cloth. Ensure that
commode is well rinsed and dried before using.
2. Never use organic solvents, abrasive cleaners or scouring
pads on any part of commode.
3.
WEEKLY to ensure that the commode is stable and safe
to use.
MAINTENANCE
WARNINGS
DO NOT ATTEMPT TO ADJUST OR OPERATE
THE COMMODE WITHOUT READING ALL
INSTRUCTIONS CAREFULLY.
• Maximum weight capacity: 350 lb/158 kg (BS31C),
450 lb/136kg (BSB31C).
• DO NOT use this device if it is not securely installed.
• This product should not be used without instruction from a
healthcare professional.
• The toilet seat must be in down position before use. Failure
to do so may result in injury.
• Ensure the height adjusting snap buttons fully protrude
through the same respective hole of each leg extension. This
will ensure the leg extensions are locked in position and an
even height is achieved.
• NEVER stand on the commode seat or frame.
•
at all times.
• Users with limited physical strength should be supervised or
assisted while using commode.
•
are dry before use.
• Use the armrest for assistance only. DO NOT use the
armrests to support full body weight.
• Weight should be evenly distributed when using the
commode. DO NOT lean or reach for objects while on the
commode.
• Inspect all parts for shipping damage before assembly.
If there is shipping damage — DO NOT USE . Contact
dealer/carrier for further instructions.
• Users with limited physical capabilities should be supervised
or assisted in commode areas even when using support rails.
• Consult a healthcare professional for advice and instructions
• Healthcare DME assumes no responsibility for any
damage or injury caused by improper installation, assembly
or use of this product.
USE CAUTION. FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS
FURTHER INCREASES RISK OF SERIOUS INJURY. USE AT YOUR OWN RISK AND WITH
APPROPRIATE AND SERIOUS ATTENTION TO SAFE OPERATION.
