probst SPEEDY VS-140/200 User manual

5270.0011/5270.0012/5270.0013/5270.0014
V3
GB
Operating Instructions
Translation of original operating instructions
Vacuum Hand Laying Device
SPEEDY VS-140/200; VS-140/200-XL; VS-140/200-110; VS-140/200-XL-110

Contents
2 / 25
5270.0011/5270.0012/5270.0013/5270.0014
V3
GB
Contents
1EC-Declaration of Conformity ............................................................................................................................... 4
2General.................................................................................................................................................................... 5
2.1 Authorized use................................................................................................................................................ 5
3Safety...................................................................................................................................................................... 8
3.1 Instructions for the Owner ............................................................................................................................8
3.2 Instructions for the Installation, Maintenance and Operating Personnel...................................................8
3.3 Hazard Alert Symbols .....................................................................................................................................8
3.4 Installation Site Requirements.......................................................................................................................8
3.5 Emissions.........................................................................................................................................................8
3.6 Special Hazards...............................................................................................................................................8
3.7 Workplaces .....................................................................................................................................................9
3.8 Instructions for the Operator ........................................................................................................................9
3.9 Equipment for Personal Protection ...............................................................................................................9
3.10 Behaviour in Emergencies..............................................................................................................................9
3.11 Checking the Safety Devices ..........................................................................................................................9
3.12 Checking the vacuum gauge ..........................................................................................................................9
3.13 Cleaning the air filter ......................................................................................................................................9
3.14 Safety Marking.............................................................................................................................................. 10
4Technical Data ........................................................................................................................................................11
4.1 Dimensioned Drawing ................................................................................................................................... 11
4.2 Basic device , variants....................................................................................................................................12
4.3 Basic device, specifications ...........................................................................................................................12
4.4 Quick-change suction plate (optional) .........................................................................................................12
4.5 Retrofit kit counterholders (optional).........................................................................................................12
4.5.1 Suitable suction plate without retrofit kit counterholder (VS-GH-SPS).................................................13
4.5.2 Suitable suction plate with retrofit kit counterholders ( (VS-GH-SPS)...................................................13
5Description ............................................................................................................................................................14
5.1 Components of the Lifting Device ................................................................................................................14
5.2 Controls..........................................................................................................................................................14
5.2.1 Push switch ...............................................................................................................................................14
5.2.2 Operating lever .........................................................................................................................................14
5.2.3 Vacuum generator ....................................................................................................................................14
5.2.4 Suction pads..............................................................................................................................................14
6Installation............................................................................................................................................................. 15
6.1 Preparing for use ...........................................................................................................................................15
6.2 Switching off at the end of the day ............................................................................................................. 16
6.3 Mounting of a quick-change suction plate (optional) .................................................................................17
6.4 Mounting and dismounting of the suction plate with counterholders .....................................................17
6.4.1 Mount the counterholder to the suction plate egenhalter an Saugplatte montieren..........................17
6.5 Dismounting of the siuction plate with counterholders (optional) ............................................................17
6.6 Mounting of the suction plate with counterholder .................................................................................... 18
7Operating...............................................................................................................................................................19
7.1 Safety Instructions........................................................................................................................................ 19
7.2 Lifting, Transporting and Lowering Loads .................................................................................................. 20
7.2.1 Lifting Loads............................................................................................................................................. 20

EC-Declaration of Conformity
3 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
7.2.2 Transporting Loads.................................................................................................................................. 20
7.2.3 Lowering Loads........................................................................................................................................ 20
7.3 Handle height adjustment............................................................................................................................ 20
7.4 Lifting eye with safety chain .........................................................................................................................21
7.5 Handle extension...........................................................................................................................................21
8Troubleshooting .................................................................................................................................................. 22
9Maintenance......................................................................................................................................................... 23
9.1 General .......................................................................................................................................................... 23
9.2 Maintenance Plan ......................................................................................................................................... 23
9.3 Suction Pads / Seals ...................................................................................................................................... 23
9.4 Leak Test ....................................................................................................................................................... 24
9.5 Safety procedures ........................................................................................................................................ 24
9.6 Hints to the type plate.................................................................................................................................. 25
9.7 Hints to the renting/leasing of PROBST devices ......................................................................................... 25

EC-Declaration of Conformity
4 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
1
EC-Declaration of Conformity
Description:
Type:
Order number:
Vacuum Hand Laying Device
SPEEDY VS
-140/200; VS-140/200-XL; VS-140/200-110; VS-140/200-XL-110
5270.0011/5270.0012/5270.
0013/5270.0014
Manufacturer:
Probst GmbH
Gottlieb
-Daimler-Straße 6
71729 Erdmannhausen, Germany
info@probst
-handling.de
www.probst
-handling.de
Complies with the following provisions applying to it
EC
-machinery directive 2006/42/EC
Based on the following harmonized standards (in excerpts):
DIN EN ISO 12100
Safety of machinery
- General principles for design - Risk assessment and risk reduction (ISO 12100:2010)
DIN EN ISO 13857
Safety of machinery
- safety distances to prevent hazard zones being reached by upper and lower limbs (ISO 13857:2008)
DIN EN 1012
-1 / DIN EN 1012-2
Compressors and vacuum
pumps; Safety requirements part 1 and 2.
DIN EN
60204-1 (IEC 60204-1)
Safety of machinery, electrical equipment of industrial machines.
Part 1: General requirements.
2014/35/EU
(Low voltage standard)
2014/30/EU
(Electromagnetic compatibility)
Authorized person for EC
-documentation:
Name: J.
Holderied
Address: Probst GmbH; Gottlieb
-Daimler-Straße 6; 71729 Erdmannhausen, Germany
Signature, information to the subscriber:
Erdmannhausen,
09.10.2017..........................................................................
(M. Probst, Managing director)

General
5 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
2
General
2.1
Authorized use
The “Vacuum Hand Laying Device
SPEEDY VS-140”is designed for lifting and moving stone and concrete slabs.
Operation requires two pers
ons.
The maximum lifting capacity must not be exceeded.
The l” Vacuum Hand Laying Device” may be used only in vertical position.
Transport of persons and animals with the load or the “Vacuum Hand Laying Device” itself is forbidden!
Unauthorised modificatio
n of the lifting device is forbidden for safety reasons!
The operating, maintenance and service instructions in this manual must be observed.
Retrofit parts
-The use of the „Vacuum Hand Laying Device SPEEDY VS-140“at a lifting equipment (e.g. excavator) is
only allowed with the installed retrofit part „Lifting eye with safety chain – VS-XL-EH“.
-When laying large stone slabs up to 1,2 m (47 “) the extended handles „VS-XL-HG“ should be used (in
manual operation by 2 people, and in one-man operation with a lifting equipment), so that the feet are
outside of the danger zone.
-The quick-change suction plate (VS-SWV-SPS-50-30 / 25) is on the one hand a suction plate, as well as a
quick-change adapter. Either to carry small stones weighing up to 50 kg or to be able to quickly switch
between other Speedy suction pads.
-Retrofit kit (VS-GH-SPS) for quick changing of existing Speedy suction plates (this is only possible in
conjunction with the Speedy-mounted quick-change suction plate VS-SWV-SPS-50-30 / 25).
VS
-200-EH (4271.0143)
Lifting eye with safety chain
Maximum working load: 200 kg
VS
-140-XL-HG (4271.0089)
long handles for stone slabs up to 1,2 m width
Maximum working load: 140 kg
VS
-GH-SPS (4271.0127)
Retrofit kit (counterholders) for Speedy suction plates

General
6 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
VS
-SWV-SPS-50-30/25 (4271.0126)
Quick
-change suction plate
The device is only designed for the use specified in this documentation.
Every other use is not authorized and is forbidden!
All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration
of conformity, and additional local health and safety regulations have to be observed.
Prior to every operation the user
must ensure that:
The equipment is suited to the intended operation, the functioning and the working condition of the
equipment is examined, and the load is suitable to be handled.
Any doubts about ins
tructions should be raised with the manufacturer prior to use.
ATTENTIO
N: The use of this device is only permitted in proximity to the ground.
NOT ALLOWED ACTIVITIES:
Unauthorized alterations
of the device and the use of any self-made additional equipment could cause
danger and are therefore
forbidden!
Never exceed the
carrying capacity and the nominal width/nominal size of the device.
All unauthorized transportatio
ns with the device are not allowed:
Transportation of people and animals.
Transportation of other loads and materials than described in this manual.
Never suspend any goods with ropes, chains or similar at the device.

General
7 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
The load (stone slabs) which is to be sucked and
transported, must have sufficient inherent stability,
otherwise there is risk of breakage when lifting!
Stone slabs must not be bend when lifting -
especially take
care with thin and large-sized stone slabs!
Generally, the load (stones slab) is only to be sucked in the
middle, otherwise the load hangs diagonally under the
device and the load could break - especially when lifting
large stone slabs with a small suction plate.
Standard suction plates are not suitable for the transport of
glass plates!
Only
suction plates of the manufacturer PROBST shall be used!!!
·Some suction plates which can be mounted to the device will reduce its carrying capacity.
The maximum load is indicated on each suction plate.
·Use only suction plates which are approved for this device!
Do not exceed
the maximum carrying capacity of the suction plates!
Danger: Load
(stone slabs) will fall down!

Safety
8 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
3 Safety
3.1
Instructions for the
Owner
The lifting devices
SPEEDY VS series are manufactured according to current technical
standards and are safe. Nevertheless, t
hey will present hazards
if they are not operated by qualified or at least trained staff,
if they are used contrary to the approved applications.
This may result in
injuries to or death of operators and other persons,
damage to lifting device and other valuable goods.
3.2
Instructions for the
Installation,
Maintenance and
Operating Personnel
The device must be installed and maintained by qualified personnel, mechanics and
electricians.
Each person in your company involved in the installation, commissioning
, operation,
maintenance or repair of the device
must have read and understood these operating instructions
and especially the chapter "Safety" herein.
Your company must ensure by internal measures
that the operators of the lifting device are properly trained,
that they have read and understood the operating instructions,
that the operating instructions are available to them at all times.
The responsibilities for the tasks carried out with the device must be clearly defined
and observed. Ambiguity regarding
responsibilities must not exist.
3.3 Hazard Alert Symbols
Danger
Attention
Prohibition
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will
result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or
damage to property can result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe
injury, or damage to property will result.
3.4
Installation Site
Requirements
The lifting device may not be operated in rooms which contain explosive atmospheres.
The ambient temperature of 40 °C must not be exceeded.
Ensure by internal instructions and checks that the installation site is always kept
clean and
tidy.
3.5
Emissions
The equivalent continuous sound pressure level of the device is
approx. 80 dB(A).
3.6
Special Hazards
Danger
Since the load is held by a vacuum, it will fall off as soon as this vacuum is lost.
This can happen if the vacuum generator
fails.
If the vacuum generator fails, lower the load immediately if this is possible.
If this is not possible, immediately leave the dangerous area near the load.
The device generates a very strong suction which can draw in hair and clothing. Do not
look
into the suction opening when the device is switched on. Parts of body can be
sucked in.

Safety
9 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
3.7
Workplaces
The device is operated always by two persons. The workplace of the operators is in
front of the control handles.
Stand so that you can constantly observe
the vacuum gauge.
3.8
Instructions for the
Operator
As an operator of the lifting device, you must be trained before you start to use the
device. You must have read and understood the operating instructions and especially
the chapter "Safety".
Ensure that only authorised persons use the device. You are responsible for others in
the operating range of the equipment.
Local safety requirements are fully applicable. The safety instructions in this document
complement these local regulations and do not supersede t
hem.
3.9
Equipment for
Personal Protection
When operating the device always wear:
safety shoes (with steel toecaps),
tough gloves.
3.10
Behaviour in
Emergencies
Danger
An emergency situation exists when
power suddenly fails (device switches off),
the vacuum pressure drops in the red danger zone on the scale of the vacuum
gauge.
Lower the load immediately if possible. If this is not possible, immediately leave the
dangerous area near the load, since it will be dropped from the device.
3.11
Checking the Safety
Devices
The lifting device is equipped with following safety device:
vacuum gauge with red danger zone
Check this device at the beginning of each shift (when operating in shifts) or once a
week (when operating continually).
3.12 Checking the vacuum
gauge
Switch
on the lifting device.
Place the lifting device on a flat floor and apply vacuum.
When the vacuum has built up, the pointer of the vacuum gauge must reach a vacuum
of at least
-0,2 bar.
3.13
Cleaning the air filter
Inspect the air filter at least once per week
and clean it (by blowing out the dirt) as
necessary.
Attention
If the air filter is dirty, the manometer will show a higher value than is actually available
at the suction plates.
The air filter must therefore be inspected and cleaned regularly in o
rder to maintain
the operational safety of the device.
Correct any faults before using the device.
If faults occur during operation, switch the device off and correct the faults before
continuing work with the
device.

Safety
10 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
3.14 Safety Marking
WARNING SIGN
Symbol
Meaning
Order
-No.:
It is not allowed to be under hanging loads.
Danger to life!
2904.0210
2904.0209
2904.0204
30 mm
50 mm
80 mm
Do not lift any components off
-centre.
2904.0383
(
102x52 mm)
WARNING SIGN
Symbol
Meaning
Order
-No.:
Size:
Danger of squeezing the hands.
2904.0221
2904.0220
2904.0107
30 mm
50 mm
80 mm
REGULATORY SIGN
Each operator must have read and understood the operating
instructions (and all safety instructions).
2904.0665
2904.0666
30 mm
50 mm

Technical Data
11 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
4 Technical Data
4.1 Dimensioned Drawing
Pos
Description
Pos
Description
1
Operator handles
6
Cover of the device
2
Upper part of the device with blower motor
7
Operating lever
3
Suction plate
8
Push switch
4
Ventilating flap
9
Vacuum gauge
5
Lower part of the
device

Technical Data
12 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
4.2
Basic device , variants
VS
-140/200 (230 V)
5270.0011
VS
-140/200-XL (230 V)
5270.0012
VS
-140/200-110 (110 V)
5270.0013
VS
-140/200-XL-110 (110 V)
5270.0014
4.3
Basic device, specifications
Blower motor, power
1500 W
Blower motor, power /
Frequenzy
57200011 und 57200012
57200013 und 57200014
230 V / 50 Hz
110 V / 50/60 Hz
Temperature range
0°C bis 40 °C
Carrying capacity / working load limit (WLL) (at
-200 mbar low
pressure)
Depends on the size of the suction plate
Dead weight
18
–23 kg, Depends on variant or equipment
Device dimensions
390 x 290 mm
4.4
Quick-change suction plate (optional)
Type:
Order.
-Nr.:
VS
-SWV-SPS-50-30/25
4271.0126
Description
: with the quick-
change suction plate (42710126) can quickly be changed from one suction plate to the other (see
the following list). It can also be used as a suction plate with a carrying capacity / working load limit (WLL) of 50 kg.
4.5
Retrofit kit counterholders (optional)
Type:
Order.
-Nr.:
VS
-GH-SPS
4271.0127

Technical Data
13 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
4.5.1
Suitable suction plate without retrofit kit counterholder (VS-GH-SPS)
Type
Lenght (mm)
Width (mm)
Carrying capacity / working
load limit (WLL) (kg)
Order
-Nr.
VS
-SPS-50-30/25
300
250
50
*
4271.0134
VS
-SPS-80-40/30
400
300
80
*
4271.0135
VS
-SPS-100-50/30
500
300
100
*
4271.0136
VS
-SPS-140-70/30
700
300
140
*
4271.0137
VS
-SPS-200-
85/34
850
340
200
*
4271.0133
4.5.2
Suitable suction plate with retrofit kit counterholders ( (VS-GH-SPS)
Type
Lenght (mm)
Width (mm)
Carrying capacity / working
load limit (WLL) (kg)
Order
.-Nr.
VS
-GH-SPS-50-30/25
300
250
50
*
4271.0128
VS
-GH-SPS-80-40/30
400
300
80
*
4271.0129
VS
-GH-SPS-100-50/30
500
300
100
*
4271.0130
VS
-GH-SPS-140-70/30
700
300
140
*
4271.0131
VS
-GH-SPS-200-85/34
850
340
200
*
4271.0132
Replacement seals
**:
(easily attachable to suction plates
- without glueing)
Type
Order
.-Nr.
VS(
-GH)-SPS-50-30/25
4271.0032
VS(
-GH)-SPS-80-40/30
4271.0029
VS(
-GH)-SPS-100-50/30
4271.0031
VS(
-GH)-SPS-140-70/30
4271.0030
VS(
-GH)-SPS-200-85/34
4271.0140
*Value at -200 mbar low pressure
** inkl. Spannband

Description
14 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
5 Description
5.1 Components of the Lifting Device
Parts with safety functions appear in bold type
Pos
Description
Pos
Description
1
Operator handles
6
Cover of the device
2
Upper part of the device with blower motor
7
Operating lever
3
Suction pad
8
Push switch
4
Ventilating flap
9
Vacuum gauge
5
Lower part of the device
5.2
Controls
5.2.1
Push switch
The push switch is used for
switching the unit on and off.
5.2.2
Operating lever
Attention
The operating lever is used for releasing the load by opening the venting valve.
This lever may be actuated only when the load is resting on a solid surface.
When the lever is actuated, the
vacuum is released immediately and the unit can be
lifted off the workpiece.
5.2.3
Vacuum generator
The vacuum is generated by an electrically driven blower.
5.2.4
Suction pads
Danger
The suction pads are designed to lift various items. Only items with
smooth, air-tight
surfaces are suitable for vacuum lifting.
To generate vacuum, the suction pad must be in contact with and attached to the
load.
The suction pad must always be positioned in the centre of the workpiece in order to
ensure even distribution
of the load. If the suction pad is positioned off-centre, the
workpiece may suddenly drop from the unit during lifting and lowering operations,
since the load is then one
-sided.

Installation
15 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
6 Installation
6.1
Preparing for use
Attention
Move the operator handles (1) to the
working position
as follows: remove the spring
clips (2) from the pins, pull out the pins, move the handles to the desired position (Pos.
1), insert the pins and secure them with the spring clips.
Danger
Connect electric power to the lifting device. Before connecting, check that the local
voltage and frequency agree with the values shown on the rating plate. If this is not
the case, do not connect the power.
The locally provided power cable (3)
must
be capable of carrying the rated current of
the lifting device.
Secure the cable
(3) to the operator handle (1) with the aid of the Velcro strip (4)
provided for this purpose, to secure the plug
-and-
socket connection against accidental
releasing (e.g. st
ep on the cable: losing of the load).
Transport position
Working position

Installation
16 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
6.2
Switching off at the
end of the day
Before switching off the device with the push switch, allow it to run for at least 30
seconds with the venting valve open
This loosens and removes any dirt which may have been deposited on the vacuum
blower.
For
transport, swing the operator handles (1) down as follows:
remove the spring clips (2) from the pins, pull out the pins, move the handles to the
transport position (
Pos. 2), insert the pins and secure them with the spring clips.
This lifts the suction pad from the ground, protecting it from damage during transport.
Transport position

Installation
17 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
6.3
Mounting of a quick-change suction plate (optional)
The assembly of a quick-change
suction plate is the
same as the assembly of a normal suction plate:
If a suction plate has already been installed on the unit,
dismount it before.
Attach the quick
-change suction plate to the SPEEDY
using the four screws (see marking in the figure)
6.4
Mounting and dismounting of the suction plate with counterholders
Mounting and dismounting
the suction plates only when the device is switched off!
6.4.1
Mount the counterholder to the suction plate egenhalter an Saugplatte montieren
In order to be able to
mount suction plates to the quick-change suction plate, they must be equipped with
counterholders.
If the suction plate is not fitted with counterholders, the retrofit kit (4271.0127) can be exchanged with the
counterholders.
The template and assembly ins
tructions are included in the operating instructions.
6.5
Dismounting of the siuction plate with counterholders (optional)
Fold up the safety clip (1).
1
Counterholders VS-GH-SPS

Installation
18 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
Press the closing
brackets (2) downwards -
the clamping bracket
is released from the counterholder.
Repeat steps 1 and 2 on the other side of the device. The suction
plate is now detached.
Remove the suction plate.
6.6
Mounting of the suction plate with counterholder
Place the device on the suction plate in the center.
Hook the U
-bolt of the closing bracket (2) into the
counterholder (3).
Pull up the closing bracket (2).
Fold down the safety clip (1).
Repeat this procedure on the other
side of the device -
(suction
plate is now mounted on the device).
2
2
3

Operating
19 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
7 Operating
7.1
Safety Instructions
The ground or floor in the working area should by clean and dry or rough enough
to ensure that the operating personnel cannot slip.
The device is
intended only for manual transport of paving stones or slabs. Never
suspend it from a crane or mechanical shovel, etc.
Local safety requirements are fully applicable. The following safety instructions
supplement the local regulations and do not supersede t
hem:
Wear safety shoes, gloves and ear protection.
Never exceed the maximum lifting capacity of the device.
Do not stand below the load. Always keep clear of the load.
Never carry people or animals with the load or the lifting device itself!
Operate only when you can view the entire working area. Look out for other
persons in the working area. Never manoeuvre loads above people.
Do not release the handles while a load is attached.
Do not pull loads to the side or drag them along with the lifting device.
If the load has become jammed, do not attempt to tear it free with the lifting
device.
In the case of a fault in the vacuum generator, lower the load immediately if
possible. Immediately leave the danger area near the load.
Pick up and lift only appropriate loads (check for stability and porosity).
Always keep an eye on the vacuum gauge. Never lift loads when the vacuum is
below –
200 mbar. If the pointer of the pressure gauge moves into the red danger
zone, lower the load immediately.
Place workpieces only on
clear, level surfaces, since they may otherwise slide away
when released.
Release the load only when it has been fully lowered to the ground. Do not reach
under the load when lowering it, since serious injuries may result!
Always distribute load evenly on the suction surfaces.
Ensure that the vacuum generator cannot be switched off while transporting
loads.
Check all suction hoses and clamps for proper installation and tighten the clamps if
necessary.
If you set down the unit with the motor running, take care not to place it on an
airtight surface, since this will block the flow of cooling air. Instead, place the unit
on a support (such as a block of wood).
Always switch off the unit if you do not intend to use it again within two minutes

Operating
20 / 25
5270.0011/5
270.0012/5270.0013/5270.0014 V3
GB
7.2
Lifting, Tran
sporting
and Lowering Loads
The following operating steps must be checked by a qualified mechanic prior to use of
the device by the operating personnel. Correct any faults before the device is used.
7.2.1
Lifting Loads
Switch the blower on.
Position the lifting device directly above the load. Do not pull to the sides.
Distribute load evenly.
Lower the lifting device onto the load.
The suction pad grips the load.
Watch the pressure gauge. As soon as a vacuum pressure of -
200 mbar has been
reached (pointer
of the vacuum gauge is in the green range) you can lift the load.
Never attempt to lift the load with a lower vacuum since it will be dropped.
When lifting items from a stack, ensure that only one piece is actually lifted.
The duty cycle (lifting/venting) should not exceed 2/3 to 1/3.
Maximum lifting period 30 seconds, followed by 15 seconds with inlet free.
7.2.2
Transporting Loads
Avoid jerky movement of the load.
The operator who actuates the operating lever must always inform the second
operator clearly and
unambiguously of his intended actions.
7.2.3
Lowering Loads
Lower the load to a safe and clear, level surface so the load cannot slip or tip over.
Pull the operating lever to release the load.
7.3
Handle height
adjustment
The operator handles can be adjusted for operators of differing heights. This may be
done only when the device is resting on the ground.
Remove the spring clips, move the pins to the desired position and secure the pins
again with the spring clips.
