PROEL NEOS PX Series User manual

USER MANUAL
NEOS215PX
passive subwoofer
KEY FEATURES
• Premium transducer
• 2000 W program power handling
• Double DemodulaƟng Rings (DDR) for lower distorƟon
• Improved heat dissipaƟon
• Weather protected cone and plates for outdoor usage
• Plywood cabinets with die-cast handles, pole holder and four rugged 80mm wheels for an easy transport.
INTRODUCTION
NEOS PX series represents the highest expression of PROEL GROUP Research & Development applied in loudspeaker systems. A natural evoluƟon
of the NEOS Series, it incorporates the latest technologies developed by PROEL in advanced sound reinforcement systems able to provide premium
sound, maximum performance and up-to-date features.
The NEOS PX are designed for the use both as high-performance mobile systems for live applicaƟons and for advanced fixed installaƟons.
The NEOS PX are able to provide an excepƟonal sound definiƟon together with very high dynamics and low distorƟon in an ultra-compact
package.
TECHNICAL SPECIFICATION
AcousƟcal Frequency Response Diagram
System type Sub-woofer, vented
Low frequency driver 2 x 15’’ woofer - 3” VC
Frequency response from 40 Hz
Coverage omnidirecƟonal
Max SPL 134 dB
Electrical
Nominal Impedance 8 + 8 ohm
Power Handling ConƟnuous 1000 W
Power Handling Peak 2000 W
SensiƟvity 101 dBspl @ 1W / 1m
Suggested Crossover Frequency 80 Hz - 160 Hz
Connectors IN - LINK: Speakon® (NL4MP)
Mechanical
ConstrucƟon 15 and 18 mm birch plywood
Finish AnƟ-scratch black paint
Pole holder 1 top - 1 side
Dimensions (W x H x D) 590 x 760 x 850 mm
Weight 62.5 kg (137.7 lbs)
10k5k2k1k500200100502020 20kHz
110.0
dBSPL
100.0
90.0
80.0
70.0
60.0

MECHANICAL DRAWING
75.7 cm
29.8"
58.5 cm
23.0"
84.5 cm
33.3"
M10 Flying Point
M10 Flying Point
M10 Flying Point
Pole Holder
Pole Holder
OPTIONAL ACCESSORIES
ASO25 2 in 4 out analog loudspeaker processor for speaker suspending:
PC240 2 in 4 out digital loudspeaker processor AC169A M10 black shoulder eyebolt
PC260 2 in 6 out digital loudspeaker processor AC171 L = 75 cm / 30 inch AircraŌcable sling
KP210BK Sub-Speaker pole AC172 L = 1.5 m / 4.9 ŌAircraŌcable sling
NL4FX Neutrik Speakon® PLUG AC173 Screw pin anchor shackle
see www.proel.com for detailed descripƟon and other available accessories.
SPARE PARTS
NL4MP Neutrik Speakon® panel socket
AC102GS 80 mm Caster
98NEOS15SW8 15’’ woofer - 3” VC

REAR PANEL
INPUT - External amplifier power input. The connecƟons depend by the configuraƟon seƫngs accordingly the following table:
INPUT
SINGLE SPEAKER SUB DUAL SPEAKER SUB
1+ / 1- INPUT 1+ / 1- INPUT 1ST WOOFER
2+ / 2- INTERNALLY N.C. 2+ / 2- INPUT 2ND WOOFER
LINK - Power output for connecƟng the unit to another speaker. The INPUT and LINK connectors are in parallel to each other.
PRODUCT LABEL - In this label are wriƩen the most important data informaƟon about the passive loudspeaker, model, impedance, maximum
applicable conƟnuous power, serial number.
The NEOS215PX doesn’t contain a built-in crossover filter so the two loudspeaker are directly connected to the amplifier outputs. For this reason,
an external crossover is required in order to filter properly the sub-woofer and to combine it with top units.
The crossover can be either analog or digital, however we recommend the PROEL ASO25 as analog processor or the PROEL PC240/260 as digital
processor.
In the following table PROEL suggest the PROCESSOR parameters for PC240/260; these parameters could be used to set also other equipment
obtaining similar acousƟc result.
Filter High Pass Filter Low Pass Filter Parametric EQ
Frequency 35 Hz from 80 to 160Hz 40 Hz
Type BuƩerworth 24 dB/oct. BuƩerworth 18 dB/oct. Q = 1.3 / OCT. = 1.1
Gain - - +2 dB

LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaƟon of this product for a period of two years from the original date of purchase. If any defects are found
in the materials or workmanship or if the product fails to funcƟon properly during the applicable warranty period, the owner should inform about these defects the
dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripƟon. This warranty does not extend to damage resulƟng from
improper installaƟon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is sƟll
valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any “direct damage” or “indirect damage” caused by product defecƟveness.
• This unit package has been submiƩed to ISTA 1A integrity tests. We suggest you control the unit condiƟons immediately aŌer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecƟon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noƟfied to forwarder. Each complaint for package tampered with should be done within eight days from product
receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaƟon or posiƟon does not interfere with its proper venƟlaƟon and heaƟng dissipaƟon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operaƟng instrucƟons or as marked on the product. Connect the
apparatus to a power supply using only power cord included making always sure it is in good condiƟons.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecƟon.
– Make sure that power supply mains line has a proper earth connecƟon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when leŌunused for a long period of Ɵme.
CE CONFORMITY
Proel products comply with direcƟve 2004/108/EC (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcƟve 2006/95/CE (LVD), as stated in EN
60065 standard.
