ProLights EclPanel TWCMini2X1 User manual

USER MANUAL
REV.01-01/22 English version
EclPanel TWCMini2X1
115W Tunable White and colourful LED soft
light with pixels and lighting effects

Thank you for choosing PROLIGHTS
Please note that every PROLIGHTS product has been designed in Italy to meet quality and performance requirements
for professionals and designed and manufactured for the use and application as shown in this document.
Any other use, if not expressly indicated, could compromise the good condition/operation of the product and/or be
a source of danger.
This product is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively
applicable national accident prevention rules and regulations.
Features, specications and appearance are subject to change without notice. Music & Lights S.r.l. and all afliated
companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other
loss occasioned by the use of, inability to use or reliance on the information contained in this document.
Product user manual can be downloaded from the website www.prolights.it , or can be inquired to the ofcial
PROLIGHTS distributors of your territory (https://www.prolights.it/sales_network.html).
Scanning the below QR Code, you will access the download area of the product page, where you can nd a broad
set of always updated technical documentation: specications, user manual, technical drawings, photometrics,
personalities, xture rmware updates.
The PROLIGHTS Logo, PROLIGHTS names and all other trademark in this document pertaining to PROLIGHTS services
or PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its afliates, and subsidiaries.
PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc -
04026 - Minturno (LT) ITALY.
Visit the download area
of the product page

PROLIGHTS - Ecl Panel TWCM2X1 01
INDEX
SAFETY INFORMATION 02
1 - PACKAGING 05
PACKAGE CONTENT..................................................................................................... 05
OPTIONAL ACCESSORIES............................................................................................. 05
2 - TECHNICAL DRAWING 06
3 - INSTALLATION 07
MOUNTING.................................................................................................................... 07
4 - CONNECTION TO THE MAINS SUPPLY 08
5 - START UP 08
CONNECT AND DISCONNECT POWER FROM THE PRODUCT.................................. 08
6 - PRODUCT OVERVIEW 09
7 - DMX CONNECTION 10
CONNECTION OF THE CONTROL SIGNAL: DMX LINE .............................................. 10
INSTRUCTIONS FOR A RELIABLE DMX CONNECTION ............................................... 10
CONNECTION DAISY CHAIN........................................................................................ 10
CONNECTION OF THE DMX LINE................................................................................ 10
CONSTRUCTION OF THE DMX TERMINATION ........................................................... 11
DMX ADDRESSING ........................................................................................................ 11
ETHERNET OPERATION ................................................................................................ 11
ETHERNET TO DMX OPERATIONS ............................................................................... 11
OPERATION AS A WIRELESS TRANSMITTER................................................................ 12
IN TO WDMX ................................................................................................................. 12
OPERATION AS A WIRELESS RECEIVER........................................................................ 12
WDMX TO DMX (RX)...................................................................................................... 13
8 - CONTROL PANEL 14
DISPLAY AND BUTTONS LAYOUT................................................................................. 14
ROTATORY KNOB LAYOUT ........................................................................................... 14
9 - MENU STRUCTURE 15
10 - SHORTCUT 19
11 - DIMMER CURVES 19
12 - RDM FUNCTIONS 21
13 - DMX CHARTS 22
14 - ACCESSORIES INSTALLATION 43
POLE OPERATED YOKE (CODE ECLPANELM2X1POYO - OPTIONAL) ........................ 43
EGG CRATES (CODES EPTWCM2X1EC30, EPTWCM2X1EC60, EPTWCM2X1EC2C -
OPTIONAL)..................................................................................................................... 44
DIFFUSION FILTERS (CODES EPTWCM2X1FILTINT, EPTWCM2X1FILTERHD,
EPTWCM2X1FILTERMD, EPTWCM2X1FILTERLD - OPTIONAL) .................................... 45
BARN DOOR (CODE EPTWCM2X1BD - OPTIONAL) .................................................... 46
CENTER MOUNT BRACKET (CODE EPTWCBRKM - OPTIONAL)................................. 47
BALL HEAD JOINT (CODE EPTWCBHEAD - OPTIONAL) ............................................. 48
15 - MAINTENANCE 49
MAINTENANCE AND CLEANING THE PRODUCT........................................................ 49
REPLACING THE FUSE................................................................................................... 49
VISUAL CHECK OF PRODUCT HOUSING ..................................................................... 49
TROUBLESHOOTING..................................................................................................... 50

PROLIGHTS - Ecl Panel TWCM2X102
SAFETY INFORMATION
WARNING!
• Please read carefully the instruction reported in this section before installing, power-
ing, operating or servicing the product and observe the indications also for its future
handling.
This unit is not for household and residential use, only professional applications.
Connection to mains supply
• The Connection to the mains supply must be carried out by a qualied electrical
installer.
• Use only AC supplies 100-240V 50-60 Hz, the xture must be electrically connected
to ground (earth).
• Select the cable cross section in according with the maximum current draw of the
product and the possible number of products connected at the same power line.
• The AC mains power distribution circuit must be equipped with magnetic+residual
current circuit breaker protection.
• Do not connect it to a dimmer system; doing so may damage the product.
Protection and Warning against electrical shock
• Do not remove any cover from the product, always disconnect the product from AC
power before servicing.
• Ensure that the xture is electrically connected to ground (earth). And use only a
source of AC power that complies with local building and electrical codes and has
both overload and ground-fault (earth-fault) protection.
• Before using the xture, check that all power distribution equipment and cables are
in perfect condition and rated for the current requirements of all connected devices.
• Isolate the xture from power immediately if the power plug or any seal, cover, ca-
ble, or other components are damaged, defective, deformed or showing signs of
overheating.
• Do not reapply power until repairs have been completed.
• Refer any service operation not described in this manual to PROLIGHTS Service team
or an authorized PROLIGHTS service center.
Installation
• Make sure that all visible parts of the product are in good visible condition before its
use or installation.
• Make sure the point of anchorage is stable before positioning the projector.
• When suspending the xture above ground level, secure it against failure of primary
attachments by attaching a safety cable that is approved as a safety attachment for
the weight of the xture to the attachment point on the main frame of the product. ln
case the safety cable, enter in action, it needs to be replaced with a new one.
• Install the product only in well ventilated places.
• For non temporary installations, ensure that the xture is securely fastened to a load-
bearing surface with suitable corrosionresistant hardware.
• For a temporary installation with clamps, ensure that the quarter-turn fastener and/or
screws are turned fully, and secured with a suitable safety cable.
0,5 m Minimum distance of illuminated objects
• The projector needs to be positioned so that the objects hit by the beam of light are
at least 0.5 meters (1.64 ft) from the lens of the projector.

PROLIGHTS - Ecl Panel TWCM2X1 03
T 45°
C
a
Max operating ambient temperature (Ta)
• Do not operate the xture if the ambient temperature (Ta) exceeds 45 °C (113 °F).
T
-10°
C
a
Minimum operating ambient temperature (Ta)
• Do not operate the xture if the ambient temperature (Ta) is below -10 °C (-14 °F).
Protection from burns and re
• The exterior of the xture becomes hot during use. Avoid contact by persons and
materials.
• Ensure that there is free and unobstructed airow around the xture.
• Keep ammable materials well away from the xture
• Do not expose the front glass to sunlight or any other strong light source from any an-
gle. Lenses can focus the sun’s rays inside the xture, creating a potential re hazard.
• Do not attempt to bypass thermostatic switches or fuses.
Indoor use
• This product is designed for indoor and dry environments.
• Do not use in wet location and do not expose the xture to rain or moisture.
• Never use the xture in places subject to vibrations or bumps.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Excessive dust, smoke uid, and particle build up degrades performance, causes
overheating and will damage the xture.
• Damages caused by inadequate cleaning or maintenance are not covered by the
product warranty.
T
90°
C
c
Temperature of the external surface
• The surface of the xture can reach up to 90 °C (194 °F) during operation. Avoid
contact with people and materials.
Maintenance
• Warning! Disconnect the xture from AC mains power and allow to cool for at least
10 minutes before handling.
• Only technicians who are authorized by PROLIGHTS or Authorised service partners
are permitted to open the xture.
• Users may carry out external cleaning, following the warnings and instructions pro-
vided, but any service operation not described in this manual must be referred to a
qualied service technician.
• Important! Excessive dust, smoke uid, and particle build up degrades performance,
causes overheating and will damage the xture. Damages caused by inadequate
cleaning or maintenance is not covered by the product warranty.
Photobiological safety
• This device emits potentially dangerous optical radiation and is identied in the cat-
egory of Risk Group 1 according to EN 62471.
Do not stare at the operating light source
• Do not look directly at the LED source during operation. It can be harmful to the eyes
and skin.
• During Installation, operation and maintenance, be prepared for the xture to light
and move suddenly when connected to power.
Disposal
• This product is supplied in compliance with European Directive 2012/19/EU – Waste
Electrical and Electronic Equipment (WEEE). To preserve the environment please dis-
pose/ recycle this product at the end of its life according to the local regulation.

PROLIGHTS - Ecl Panel TWCM2X104
The products to which this manual refers comply with:
• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD).
• 2014/30/EU - Electromagnetic Compatibility (EMC).
• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS).
• 2014/53/EU - Radio Equipment Directive (RED).
The products to which this manual refers comply with:
• UL 1573 + CSA C22.2 No. 166 - Stage and Studio Luminaires and Connector Strips.
• UL 1012 + CSA C22.2 No. 107.1 - Standard for power units other than class 2.
FCC Compliance:
• This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
Other approvals
• The product meets the safety requirements of the certification procedures of the
market in which it is placed and sold.

PROLIGHTS - Ecl Panel TWCM2X1 05
1 - PACKAGING
PACKAGE CONTENT
• 1x ECLPANELTWCM2X1;
• 1x 1,5 meters power cable (BARE END - NEUTRIK POWERCON TRUE1 IP65);
• 1x ECLFRSPG: spigot for PROLIGHTS Fresnel series;
• User manual.
OPTIONAL ACCESSORIES
• WSBBR512G6: blackBox R-512 G6 receiver 512Ch, 2.45GHz,DMX&RDM,Bluetooth,G3,G4,G4S,G5,CRMX;
• WSBBF1G5: blackBox F-1 G5 transmitter, 2,45GHz & 5.2/5,8 GHz, DMX/RDM, 512Ch;
• WSBBF1G6: blackBox F-1 G6 transrec, 512ch, 2.45GHz, DMX&RDM,Bluetooth,G3,G4,G4S, G5, CRMX;
• WSBBR512G5: blackBox R-512 G5 receiver 512Ch, 2.45GHz & 5.8GHz, DMX/RDM optional;
• C6040: aluminum clamp for 28mm spigot, 200kg load, 48-51mm tubes;
• C6002: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt;
• RSR0630A/B: steel security cable for hanging bodies, inox steel shackle, L=60 cm, silver/black;
• 9533FXWL03: ass. 3x2.5mm TH07 cable, SHUKO plug, MENAC3FXW socket, L.3m;
• 9513FXWL03: ass. 3x2.5mm TH07 cable, 16A 3p 230V CEE plug, MENAC3FXW socket, L.3 m;
• 958225L03: 3x2.5mm TH07 Cable, 16A 3p PwCon MXW, 16A 3p PwCon FXW, L. 3m;
• TOUR53415L03BK: dmx cable HC5340. CANC5MXX XLR 5p->CANC5FXX XLR (f) 5p, L.3m;
• FCLPANELM2X14U: ight case for 4 pcs of ECLPANELTWCM2X1;
• EPTWCBRKM: center mount bracket for ECLPANELTWC and ECLPANELTWCJR4X1;
• EPTWCBHEAD: ball head joint for center mount bracket EPTWCBRK series
• ECLPANELM2X1POYO: pole operated aluminium yoke bracket for ECLPANELTWCM2X1;
• EPTWCM2X1FILTINT: front intensied diffusion lter for ECLPANELTWCM2X1;
• EPTWCM2X1FILTERHD: front high diffusion lter (less output) for ECLPANELTWCM2X1;
• EPTWCM2X1FILTERMD: front low diffusion lter (more output) for ECLPANELTWCM2X1;
• EPTWCM2X1FILTERLD: front low diffusion lter (more output) for ECLPANELTWCM2X1;
• EPTWCM2X1EC30: 30 degree egg crate for ECLPANELTWCM2X1;
• EPTWCM2X1EC60: 60 degree egg crate for ECLPANELTWCM2X1;
• EPTWCM2X1EC2C: 2 chamber egg crate for ECLPANELTWCM2X1
• EPTWCM2X1BD: barndoor for ECLPANELTWCM2X1 with 4 directional aps to adjust the light beam;
• EPTWCSBM21: snapBag 2x1 for ECLPANELTWCM2x1 by DoP choice;
• EPTWCSG4SBM2140: 40° SnapGrid for SnapBag, 2x1 for ECLPANELTWCM2x1 by DoP choice;
• EPTWCSGM2140: 40° SnapGrid, 2x1 for ECLPANELTWCM2x1 by DoP choice;
• SWIT500W2KIT: 24/48V 500W battery (>1.2hrs) KIT including 2*PBH260S smart power batt.+st.adapt;
• SPGM10: 28mm spigot for xtures, M10 bolt;
• SPGM12: 28mm spigot for xtures, M12 bolt;
• UPBOX1U: Firmware uploader kit, USB IN, 3pin XLR DMX OUT, USB OUT.

PROLIGHTS - Ecl Panel TWCM2X106
2 - TECHNICAL DRAWING
Fig. 01
Weight: 6 kg - 13.22 lbs
Weight: 8.63 kg - 19.03 lbs

PROLIGHTS - Ecl Panel TWCM2X1 07
Fig. 02
3 - INSTALLATION
MOUNTING
Check that the supporting structure can safely bear the weight of all installed xtures, clamps, cables,
auxiliary equipment, etc. and complies with locally applicable regulations.
When suspending the xture above ground level, secure it against failure of primary attachments by
attaching a safety wire that is approved as a safety attachment for the weight of the xture to an anchor
point on the product main frame.
Do not use removable parts or weak anchors for secondary attachment.
Warning! When clamping the xture to a truss or other structure at any angle, use clamps of half-cou-
pler type. Do not use any type of clamp that does not completely encircle the structure when fastened.
RSR0630A/B
steel security cable
C6002
clamp
RSR0630A/B
steel security cable
C6040
clamp
RSR0630A/B
steel security cable
C6040
clamp
Ø10.5 mm
Ø0.41 in

PROLIGHTS - Ecl Panel TWCM2X108
5 - START UP
CONNECT AND DISCONNECT POWER FROM THE PRODUCT
To apply and disconnect power to the product:
• Check that the product is installed and secured as indicated in the Safety Informations, and that
personal safety will not be put at risk when the xture lights up.
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz).
• The product is then ready for its operations and can be controlled through the available input sig-
nals on board.
• To disconnect power from the product, disconnect the Mains from the socket.
• In case you wish to run the product through an external battery, then connect the product to an
external battery (24-36V) into the dedicated XLR4p socket; to disconnect power, disconnect the
Battery from the socket.
• In case you wish to run the product through an external PU, then connect the product to an external
PU (48V) into the dedicated XLR3p socket; to disconnect power, disconnect the PU from the socket.
4 - CONNECTION TO THE MAINS SUPPLY
WARNING: For protection from electric shock, the xture must be earthed!
The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts.
If you need to install a power plug on the power cable to allow connection to power outlets, install a
grounding-type (earthed) plug, following the plug manufacturer’s instructions. If you have any doubts
about proper installation, consult a qualied electrician.
T max power consumption is 130W.
Core (EU) Core (US) Connection Plug terminal marking
Brown Black Live L
Blue White Neutral N
Yellow+green Green Earth

PROLIGHTS - Ecl Panel TWCM2X1 09
6 - PRODUCT OVERVIEW
1. BRACKET.
2. USER INTERFACE with display and buttons for access to the control panel functions.
3. HIGHLIGHT button: turns the xture temporary on for focusing without data signal.
4. ROTATORY KNOBS for product stand alone control operations.
5. ANTENNA of Wireless DMX Transceiver internal module.
6. TILT KNOB: for xture tilt adjustment and fastening.
7. DC IN (3-pole XLR): for battery within 48 V range, 1 = V -, 2 = V+, 3 = N/C.
8. BATTERY IN (4-pole XLR): for battery within 24-36 V range, 1 = V -, 2 = N/C, 3 = N/C, 4 = V+.
9. DMX IN (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C.
10. DMX OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C.
11. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (250V,T3.15A, Ø5X20).).
12. POWER IN: for connection to the Mains 100-240V~/50-60Hz.
13. POWER OUT: power output for connection of multiple units in series.
14. ETHERCON CONNECTORS IN / OUT: for Ethernet protocols signal.
Fig. 03
1
2
643
1
5
7 8 9 10 11 12 13 14 14

PROLIGHTS - Ecl Panel TWCM2X110
7 - DMX CONNECTION
CONNECTION OF THE CONTROL SIGNAL: DMX LINE
The product has XLR sockets for DMX input and output.
The default pin-out on both socket is as the following diagram:
INSTRUCTIONS FOR A RELIABLE DMX CONNECTION
Use shielded twisted-pair cable designed for RS-485 devices: standard microphone cable cannot trans-
mit control data reliably over long runs. 24 AWG cable is suitable for runs up to 300 meters (1000 ft).
Heavier gauge cable and/or an amplier is recommended for longer runs.
To split the data link into branches, use splitter-ampliers in the connection line.
Do not overload the link. Up to 32 devices may be connected on a serial link.
CONNECTION DAISY CHAIN
Connect the DMX data output from the DMX source to the product DMX input (male connector XLR)
socket.
Run the data link from the product XLR output (female connector XLR) socket to the DMX input of the
next xture.
Terminate the data link by connecting a 120 Ohm signal termination. If a splitter is used, terminate
each branch of the link.
Install a DMX termination plug on the last xture on the link.
CONNECTION OF THE DMX LINE
DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω im-
pedance and low capacity.
The following diagram shows the connection mode:
Fig. 05 - Example 15 DMX channels conguration
. . . . . . . . . . . .
DMX Address: 33 DMX Address: 78DMX Address: 48 DMX Address: 63
. . . . . . . . . . . .
DMX512 Controller
DMX IN DMX IN DMX IN DMX INDMX OUT DMX OUT DMX OUT DMX OUT
Fig. 04
Pin1 : GND - Shield
Pin2 : - Signal
Pin3 : + Signal
Pin4 : N/C
Pin5 : N/C
DMX - OUTPUT
XLR socket
DMX - INPUT
XLR plug

PROLIGHTS - Ecl Panel TWCM2X1 11
DMX ADDRESSING
In order to start controlling the product via DMX, the rst step is to select a DMX address, also known
as the start channel, this is the rst channel used to receive instructions from a DMX controller. If you
wish to control the product individually, it is necessary to assign a different starting address channel to
each xture.
The number of channels occupied from the product depends on the DMX mode selected, so always
verify the DMX Mode in the MENU before start addressing.
If you assign two xtures the same address, they will be executing the same behaviour. Selecting the
same address to multiple xtures can be useful for diagnostic purposes and symmetrical control.
DMX addressing is limited to make it impossible to set the DMX address so high that you are left with-
out enough control channels for the product.
To set the xture’s DMX address:
1. Press MENU to open the main menu.
2. Reach the addressing menu, then select the DMX ADDRESS settings.
3. Select the address from 1 to 512 using the navigation arrows/buttons and conrm by pressing
ENTER.
4. Press Menu to exit and return to the Home screen.
ETHERNET CONNECTION
The products is provided with two 8-pin RJ-45 sockets for Ethernet input/output for a simple daisy
chain connection to the network.
The product can be controlled with ArtNet/sACN communication protocol.
Use a network cable category 5 (with four “twisted” wire pairs) and standard RJ-45 plugs.
ETHERNET OPERATION
Please refer to the section MENU STRUCTURE contained in this document for detailed informations
about the parameters of setting on the xture (Protocol, Net, Subnet, Universe, Start Channel and IP
Address, Ethernet to DMX No/Yes).
• IP addresses recommended: 002.xxx.xxx.xxx or 010.xxx.xxx.xxx.
• The submask net is xed at 255.0.0.0.
ETHERNET TO DMX OPERATIONS
Please refer to the section MENU STRUCTURE contained in this document for detailed informations
This function allow a product receiving an ethernet signal protocol to re-transmit the incoming signal
onto a wired DMX line through its onboard XLR-out connector.
• An Ethernet protocol (Artnet, sACN or others available) has to be enabled from Ethernet menu
CONSTRUCTION OF THE DMX TERMINATION
The termination is prepared by soldering a 120Ω 1/4 W resistor between pins 2 and 3 of the male XLR
connector, as shown in gure.
Fig. 06
Example:
5 pin XLR connector
4

PROLIGHTS - Ecl Panel TWCM2X112
at rst xture. Please make sure that wireless receiver is switched to OFF if you use Ethernet
comunication.
• Enable the option Ethernet To DMX choosing which xture needs to be retransmitted (Main Fixture
or Pixel Engine) from the Ethernet menu at the rst product (connected to the Ethernet) in the signal
chain, next products have standard DMX setting.
• Connect the Ethernet input of the rst product in the data chain with the network. Connect the
DMX output of this product with the input of the next product until all products are connected to
the DMX chain.
• Caution: At the last product, the DMX chain has to be terminated with a terminator. Solder a 120 Ω resis-
tor between Signal (–) and Signal (+) into a XLR-plug and connect it in the DMX-output of the last product.
OPERATION AS A WIRELESS TRANSMITTER
ECLPANELTWCM2X1 can be used as wireless transmitter to transmit DMX signal to different wireless
receivers. To use ECLPANELTWCM2X1 as wireless transmitter, please follow the procedure below:
1. Push ENTER button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select WIRELESS, then press ENTER to conrm.
3. Push ENTER button on WDMX ON/OFF function and enable it to ON.
4. Select WDMX mode and set it on Transmitter (please note that WDMX mode will be available only
if WDMX ON/OFF is set to ON).
5. Ensure that the receiver units are not connected to any other transmitter. Please refer to "Reset the
receiver" paragraph.
6. Enable TX LINK to ON to link transmitter to receivers (please note that TX LINK will be available only
if WDMX mode is set to Transmitter).
• The transmitter scans for all unlinked receivers for a period of about 5 seconds.
• If the connection fails, check the position of the receiver.
• The wireless icon on the receiver display indicates the received signal strength.
Unlinking the transmitter
Follow the procedure below to unlink the transmitter from all receivers connected with the unit.
1. Push ENTER button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select Wireless, then press ENTER to conrm.
3. Enable TX UNLINK to ON 8 (please note that TX UNLINK will be available only if WDMX mode is
set to Transmitter).
• All connected receivers will be unlinked.
IN TO WDMX
This function enable or disable the transmission throught wireless of the DMX signal from the transmit-
ter side to the receiver.
Any incoming signal (ArtNet, sACN or DMX) is retransmitted throught wireless.
If the ECLPANELTWCM2X1 protocol selected is ArtNet / sACN, the WDMX module will retransmit the
DMX values contained in the ArtNet / sACN signal received by the ECLPANELTWCM2X1.
NOTE: Artnet and sACN have higher priority on DMX if they are connected to transmitter.
NOTE: Do not use IN TO WDMX and ETH TO DMX simultaneously, this will cause data conict on
DMX output signal.
OPERATION AS A WIRELESS RECEIVER
ECLPANELTWCM2X1 can be used as wireless receiver connected to a wireless transmitter.
To use ECLPANELTWCM2X1 as wireless receiver, please follow the procedure below:
1. Push ENTER button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select Wireless, then press ENTER to conrm.
3. Push ENTER button on WDMX ON/OFF function and enable it to ON.
4. Select WDMX mode and set it on Receiver (please note that WDMX mode will be available only if
WDMX ON/OFF is set to ON).
5. Enable RX RESET to ON to reset the receiver (please note that RX RESET will be available only if
WDMX mode is set to Receiver).

PROLIGHTS - Ecl Panel TWCM2X1 13
6. On the transmitter, enable TX LINK to ON to link transmitter to the receivers.
7. If the connection is successful and DMX input is available the display the display on the receiver unit
will shows the DMX address. If DMX signal is not available, the display will shows "No signal" but
keeps the transmitter linked.
8. If the connection fails, check the position of the receiver.
9. The wireless icon on the receiver display indicates the received signal strength.
Reset the receiver
Follow the procedure below to reset the receiver.
1. Push MENU button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select Wireless, then press ENTER to conrm.
3. Enable RX RESET to ON.
• The wireless icon on the receiver display indicates the received signal strength.
WDMX TO DMX (RX)
This function enable or disable the retransmission of the wireless DMX signal received throught the
DMX port on the receiver side.

PROLIGHTS - Ecl Panel TWCM2X114
Fig. 07
8 - CONTROL PANEL
The product has a display and buttons for access to the control panel functions.
MODE ROTARY KNOB 1 ROTARY KNOB 2 ROTARY KNOB 3
EFFECTS Dimmer (0 ÷255) Effect Speed (1 ÷100)
CCT Dimmer (0 ÷255) +/- Green (-25/+25) Control temperature
(CCT): 2800K ÷10000K
HSI Dimmer (0 ÷255) Colors (0 ÷255) Saturation (SAT): 0 ÷255
DISPLAY AND BUTTONS LAYOUT
• The product has a display and buttons for access to the control panel functions.
• HIGHLIGHT: Press and hold for three seconds to temporary turn ON the product at Full ON for user
focusing operations.
• MENU: Used to access the menu tree or to return a previous menu window.
• UP: Browse upwards through the menu list and increases the numeric value displayed.
• DOWN: Browse downwards through the menu list and decreases the numeric value displayed.
• ENTER: Used to conrm the current menu or conrm the current function value or option within a
menu.
ROTATORY KNOB LAYOUT
The product is equipped with rotatory knobs for manual control of the product, those are enabled only
in Stand Alone mode and they enable access to control certain attributes according to the selected
STAND ALONE mode as indicated below.

MENU
1CONNECT DMX Address DMX
WDMX
ArtNet
sACN
1 - 512
DMX Mode Theater 1CH
2CH
Amber Shift On
Color
Temperature
2800K
3200K
3500K
4000K
4500K
5000K
5600K
6000K
6500K
7000K
7500K
8000K
8500K
9000K
9500K
10000K
Hue (-025÷025)
Hue=0
Manual
Color
Red (000÷255)
Green (000÷255)
Blue (000÷255)
White (000÷255)
4CH
5CH1
5CH2
6CH
10CH
15CH
17CH
21CH
Tour 4CH
6CH
10CH
11CH
15CH
Pixel 1
2
Film 1M12CH
2M20CH
3M17CH
4M33CH
5M17CH
6M33CH
XY
2 Pix Direct
Wireless WDMX
ON/OFF
On-Off Enable/Disable the wireless card.
WDMX mode Transmitter
Receiver
Choose whether to set the wireless card as Transmitter
or Receiver.
WDMX mode is unlocked only if WDMX ON / OFF is ON.
TX link On-Off TX link unlock when the unit is set as a transmitter.
TX unlink On-Off Disconnect the transmitter from all receivers.
TX unlink unlocks only if WDMX mode is on transmitter.
RX reset On-Off Total reset of the receiver.
RX reset unlocks only if WDMX mode is receiver.
DMX to
WDMX (TX)
On-Off Enable/Disable the transmission of the dmx from the
transmitter to the receiver via wdmx.
WDMX to
DMX (RX)
On-Off Enable/Disable the retransmission of the DMX from the
receiver to the other units connected by cable to the re-
ceiver itself.
PROLIGHTS - Ecl Panel TWCM2X1 15
9 - MENU STRUCTURE
The following chart describes the MENU tree of the product, the terms shown in BOLD indicate the
default settings for Standard factory reload, the terms shown in Underlined indicate the default set-
tings for Film factory reload.

Ethernet
Settings
ArtNet set-
tings
IP Address Settings for ArtNet protocol use.
Net
Subnet
Universe
sACN set-
tings
IP Address Settings for sACN protocol use.
Universe
Merge
Mode
Off
HTP
LTP
Ethernet to
WDMX
On-Off Enable / Disable DMX retrasmission from sACN/ArtNet
signal to WDMX (TX mode).
Ethernet to
DMX
On-Off Enable / Disable DMX retrasmission from sACN/ArtNet
signal to DMX out port.
2SETUP Screen Back Light On
10 s
20 s
30 s
Select the timing after that display will switch automati-
cally off when unactive.
Flip Display No-Yes Allows you to rotate the display by 180°.
Key Lock No-Yes Lock the buttons on the control panel by a password.
Press following combinations (password) in order to ac-
cess to the user menu : UP, DOWN, UP, DOWN, ENTER.
Display Value Percentage Choose how to show datas on Stand Alone Modes.
In percentage mode values will be shown as 0-100%.
In Raw Data mode values will be shown as 0-255.
Raw Data
Temperature
Unit
C° - F° Allows you to choose Temperature unit showed in home
screen.
Transfer
Conguration
Without DMX Address To transfer the same menu settings of one fixtures to
all the other in the daisy chain, including or not the
With DMX Address
3ADVANCED Full On
Mode
HB
Studio
HB - High Brightness Mode, delivering the full output on
every primary color
Studio – Calibrated white output at 6000K,when all
primary colors are set to full.
Dimmer
Curve
Linear
S-Curve
Square Law
Inverse Square Law
High Res@Low
Dimmer
Mode
Off
Dimmer 1
Dimmer 2
Dimmer 3
Dimmer Mode denes speed of the dimmer.
Dimmer 1 is fastest, Dimmer 3 is slowest.
Dimmer End Snap Off @ End
Fade Off @ End
Set Dimmer End behaviour.
Snap Off will make xture snap when dimming out to 0.
Fade Off will make xture fade when dimming out to 0.
This selection affects only 004-000 DMX value behaviour.
Color
Calibration
White
Balance
Off Disable the White Calibration at full.
Adjust Red
Green
Blue
White
Manually adjust color calibration.
Calibrated Manufacturer calibration to grant performance and color
consistency.
Led
Frequency
600Hz
1200 Hz
2000 Hz
4000 Hz
6000 Hz
10 kHz
12 kHz
15 kHz
20 kHz
25 kHz
36 kHz
40 kHz
Select PWM frequency.
PROLIGHTS - Ecl Panel TWCM2X116

Fan Mode
(Standard)
Constant Output Auto
On
Off
Silent1
Silent2
Select the product Fan mode for Standard mode.
Constant Output: xture will decrease immediatly light
output. Note: xture will lower light output in case of
Silent1, Silent2 and OFF.
Dynamic Output: xture will have variable light output
in order to keep a safe running temperature.
Dynamic Output
Fan Mode
(Film)
Auto
On
Off
Silent1
Silent2
Quiet1
Quiet2
Turbo
Select the product Fan mode for Film mode.
Quiet1 and Quiet2 start to dim light down only when
xture gets near to the thermal protection treshold.
Fan speeds are costant.
Factory
Reload
Standard No/Yes Reload xture with Standard settings.
Film No/Yes Reload xture with Film settings.
4INFORMA-
TION
Fixture Time 0÷9999 View informations about product operating lifetime.
Disp Version V1.0
Drv Version V1.0
RDM UID 15D0022F**** View the UID of the product (RDM control).
Calibration MASTER/LED View Calibration used.
5 STAND
ALONE
Master/Slave Master
Master No Dmx
Slave
Allow you to link and operating in synk multiple
units without a DMX console. Choose a unit to
perform as the Master. This unit must be the rst
unit in line; Set the successive units to be slave.
Effect
Effect 1
Effect 2
Effect 3
Effect 4
Effect 5
Candle
Cop Car
Cop Car1
Cop Car2
Cop Car3
Fire
Fireworks
Paparazzi
Television
Party
Clouds
Club
Color Chase
Strobe
Lightning
Explosion
Fluorescent
Process
Pulsing
Welding
Parameter list, all effect have dimmer and speed.
Effect 1
Effect 2
Effect 3
Effect 4
Effect 5
Candle: CCT
Cop Car: color (B RB BW BRW BA BRA RA R
A), ash
Cop Car 1
Cop Car 2
Cop Car 3
Fire: CCT (Warm, Neutral, Cold)
Firework: color (Random, W, CW)
Paparazzi: ash type, tint, CCT
Television: CCT (Warm, Neutral, Cold)
Party: saturation
Clouds: offset
Club: color number
Color chase: saturation, offset
Strobe: CCT, tint, x-fade, hue, saturation
Lightning: ash, CCT, tint
Explosion: CCT, tint, x-fade, hue, saturation
Fluorescent: frequency, CCT, tint, x-fade, hue,
saturation
Process: direction, CCT, tint, x-fade, hue,
saturation
Pulsing: pulses, CCT, tint, x-fade, hue, saturation
Welding: minimum dimmer, CCT, tint, x-fade,
hue, saturation, speed
Source
Matching
Dimmer
Categoy
Source
Category and source list:
INCANDESCENT: Tungsten Bulb, Incandescent,
Halogen, Antique Bulb, Warm Antique Bulb,
Christmas Lights, Night Light, Infrared Heat
Lamp, Grow light
FLUORESCENT: CFL Soft White, CFL Bright
White, CFL Cool White, CFL Daylight, Cool
White 1, Cool White 2, Cool White 3, Warm
White, CFL Blacklight
DISCHARGE: HMI, High Pressure Sodium, Low
Pressure Sodium, Mercury Vapor, Metal Halide
Ceramic, Carbon Arc, Xenon
OTHER: Candle, Gas Fire, Sun Direct, Sun Overcast, Sun
Blue Hour, Mobile Phone, Computer
Monitor, Electroluminescence, Blow Torch, Road
Flare, Amber Caution, Green Trafc Light, Yellow
Trafc Light, Red Trafc Light, Blue Glow Stick,
Green Glow Stick, Red Glow Stick, Yellow Glow
Stick, Pink Glow Stick, Violet Glow Stick
PROLIGHTS - Ecl Panel TWCM2X1 17

CCT Dimmer (000÷255) Use the 1st rotary knob to set the Dimmer value
Tint
(-25/+25)
Use the 2nd rotary knob to choose the tint (+/-
green) value.
CCT
(2800K ÷ 10000K)
Use the 3rd rotary knob to select the CCT value.
HSI Dimmer (000÷255) Use the 1st rotary knob to set the DImmer value.
Hue (000÷255) Use the 2nd rotary knob to choose the color point.
Saturation (000÷255) Use the 3rd rotary knob to select the Saturation
of the selected color.
XY Dimmer (000÷255) Use the 1st rotary knob to set the Dimmer value
X (0.00÷0.85) Use the 2nd rotary knob to set the X coordinate value.
Y (0.00÷0.85) Use the 3rd rotary knob to set the Y coordinate value.
Color Macro Dimmer
Macro
Color gel list:
Open, Red, Green, Blue, Cyan, Magenta, Yellow,
Dirty White, Alice Blue, Congo Blue, Dark Steel
Blue, Deep Lavender, Lilac Ting, Daylight Blue,
Flame Red, Bastard Amber, Deep Orange,
Pale Gold, Apricot, Bright Blue, Primary Green,
Special Lavender, Pale Lavender, Deep Golden
Amber, Medium Blue, Bright Pink, Mauve,
Dark Green, Lee Green, Dark Blue, Light Blue,
Steel Blue, Medium Blue-Green, Peacock Blue,
Magenta, Dark Pink, Middle Rose, Light Salmon,
English Rose, Light Rose, Orange, Deep Amber,
Straw, Light Amber, Spring Yellow, Dark Yellow
Green, Just Blue, Sky Blue, Lavender, Light
Lavender, Pink Carnation, Medium Pink, Light
Pink, Sunset Red, Dark Amber, Gold Amber,
Medium Amber, Fire, Surprise Peach, Straw Tint,
Medium Yellow, Lee Minus Green, Pale Gold,
Orange, Deep Straw, Rose Purple, Deep Purple,
Soft Green
Color
Temperature
2800K
3200K
3500K
4000K
4500K
5000K
5600K
6000K
6500K
7000K
7500K
8000K
8500K
9000K
9500K
10000K
Hue
(-025÷025)
Dimmer
(000÷255)
Select a predened White CCT output from the
list.
Fixed Color R
G
B
W
GB
RB
RG
RGB
RW
GW
BW
RGW
RBW
GBW
RGBW
Select of the following predened color combination and
its Dimmer value.
After enabled this mode, the unit will be automatically
assigned as Master.
Manual Color Red
Green
Blue
White
User generated color preset by assigning values
to each primary color attribute.
After enabled this mode, the unit will be automatically
assigned as Master
STANDALONE BEHAVIOUR
Fixture will have two different behaviour between Standard or Film factory reload.
STANDARD
If no Standalone mode selected, after unplugging DMX signal xture will keep last DMX frame.
If a Standalone mode was previously selected, after unplugging DMX signal xture will go into Standalone mode selected.
If xture is booted up without DMX signal plugged in It will go into selected Standalone Mode.
FILM
If no Standalone mode selected, after unplugging DMX signal xture will keep last DMX frame.
If a Standalone mode was previously selected, after unplugging DMX signal xture will keep last DMX frame, as soon as knobs are
touched xture will activate selected standalone.
If xture is booted up without DMX signal plugged in It will stay in Blackout also if a Standalone mode was selected previously, as soon
as knobs are touched xture will activate selected standalone.
PROLIGHTS - Ecl Panel TWCM2X118
