ProMinent DULCOMETER D1C A D Series User manual

Please enter the identity code of your device here.
Operating Instructions
DULCOMETER®D1C
Part 2: Adjustment and Operation,
Measured Variable Redox/ORP
ProMinent®
D1C2-001-D
Part No. 987850 ProMinent Dosiertechnik GmbH ·69123 Heidelberg ·Germany BA DM 183 10/10 EN
Please completely read through operating instructions! ·Do not discard!
The operator shall be liable for any damage caused
by installation or operating errors!
D1C A ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___
START
STOP
DULCOMETER
750
mV
Redox/ORP
Type WType D
750
mV
START
STOP
DULCOMETER
Redox/ORP
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr1

2
1 Device Identification / Identity Code
D1C A
Please enter the identity code of your device here!
D1C A DULCOMETER®Controller Series D1C / Version A
Type of mounting
DControl panel installation 96 x 96 mm
WWall mounting
Operating voltage
0230 V 50/60 Hz
1115 V 50/60 Hz
2200 V 50/60 Hz (only with type of mounting D)
3100 V 50/60 Hz (only with type of mounting D)
424 V AC/DC
Measured variable
RRedox/ORP (-1000...+1000 mV)
Connection of measured variable
1Terminal, standard signal 0/4-20 mA
2SN6 connector
5Terminal mV
Correction variable
0None
Feed forward control
0None
1via standard signal 0/4-20 mA
2via frequency 0-500 Hz
3via frequency 0-10 Hz
Control input
0None
1Pause
Signal output
0None
1standard signal 0/4-20 mA measured value
2standard signal 0/4-20 mA control variable
42standard signal outputs 0/4-20 mA, freely programmable
Power control
GAlarm and 2 limit value/timer relays
MAlarm and 2 solenoid valve relays
RAlarm relay and servomotor with feedback
Pump control
0None
2Two pumps
Control characteristics
0None
1Proportional control
2PID control
Log output
0None
Language
DGerman
EEnglish
FFrench
IItalian
NDutch
SSpanish
PPolish
ASwedish
BPortuguese
UHungarian
JJapanese
GCzech
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr2

3
2General User Information
Page
1Device Identification / Identity Code ....................................................................................................... 2
2General User Information ......................................................................................................................... 3
3Device Overview / Controls ..................................................................................................................... 4
4Functional Description ............................................................................................................................. 5
5Display Symbols ...................................................................................................................................... 6
6Operation ................................................................................................................................................. 7
7Restricted Operating Menu ..................................................................................................................... 8
Layout .............................................................................................................................................. 8
Description ...................................................................................................................................... 9
8Complete Operating Menu .................................................................................................................... 12
Overview ........................................................................................................................................ 12
Description .................................................................................................................................... 13
9Fault / Remarks / Troubleshooting ........................................................................................................ 24
General User Information
These operating instructions describe the technical data and function of the series DULCOMETER®D1C
controller, provide detailed safety information and are divided into clear steps.
IMPORTANT
•Please observe the parts of these operating instructions applicable to your particular
version! This is indicated in the Section “Device Identification / Identity Code”.
•Correct measuring and dosing is only possible in the case of impeccable operation of the
probe. The probe has to be calibrated / checked regularly!
NOTE
A form “Documentation of controller settings type D1C” is available under
www.prominent.com/documentation_D1C for the purpose of documenting the controller
settings.
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr3

4
UP button
To increase a displayed numerical value
and to change variables (flashing
display)
BRANCH BACK button
Back to permanent display or to start
of relevant setting menu.
DOWN button
To decrease a displayed numerical
value and to change variables (flashing
display).
CHANGE button
To change over within a menu level
and to change from one variable to
another within a menu point.
START/STOP button
Start/stop of control and metering
function.
ENTER button
To accept, confirm or save a displayed
value or status. For alarm acknow-
ledgement.
3Device Overview / Controls
D1C2-002-GB
STOP
START
®
STOP
START
Graphic
display
"Start/stop"
Button
"Enter"
Button
"Up"
Button
"Change"
Button
"Down"
Button
"Branch back"
Button
Display field
Measured variable
Redox/ORP
Redox/ORP
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr4

5
4Functional Description
NOTE
Please refer to the description of the complete operating menu in Section 8 for a detailed
description of the individual characteristics of the DULCOMETER
®
D1C controller!
4.1 Operating Menu
The D1C controller permits settings to be made in two different menus. All values are preset and can be
changed in the complete operating menu.
The controller is delivered with a restricted operating menu so that the D1C controller can be used
effectively in many applications from the very onset. If adaptations prove to be necessary, all relevant
parameters can then be accessed by switching over to the complete operating menu (see “General
Settings”).
4.2 Access Code
Access to the setting menu can be prevented by setting up an access code. The D1C controller is supplied
with the access code 5000 which permits free access to the setting menu. The calibration menu remains
freely accessible even if access to the setting menu is blocked by the code.
4.3 Control
The D1C can operate as a proportional controller or as a PID controller - depending on the device version
(see identity code) and the setting.
The controlled variable is recalculated once a second. Control procedures which require rapid correction of
setpoint deviations (less than approx. 30 seconds) cannot be processed with this controller. The cycle
times must be taken into consideration when activating solenoid valves (pulse length) in the same way as
their running times when activating servomotors (3-point).
Via the control input pause, the control function (selection of controlled variable) can be switched off. The
calculation of the controlled variable starts again after cessation of "pause".
4.4 Feed Forward Control
The D1C controller can process a signal of a feed forward control. Depending on the device version (see
identity code) and the setting, this signal can be obtained in any form of a 0–20 mA or 4–20 mA signal or as
a digital contact signal with the maximum frequencies 10 Hz or 500 Hz.
This signal can be used, for example, for flow-proportional metering (multiplicative effect) or feed forward-
dependent basic load metering (additive effect). The result of control variable calculation from the
proportional or PID control is multiplied by or added to the feed forward signal. A multiplicative feed forward
variable at the level of the set rated value carries over the calculated controlled variable unchanged into the
control variable:
Control variable = Feed forward variable/rated value x calculated controlled variable
During start-up, the zero point has to be checked. The feed forward control is not designed for switching off
permanently the actuating variable (signal ≈0).
An additive feed forward variable at the level of the rated value results in maximum control variable:
Control variable (max. 100 %) = (Feed forward variable/rated value x
max. control variable) + calculated controlled variable
4.5 Error Messages
Error messages and information are indicated on the bottom line in the permanent display 1. Errors to be
acknowledged (acknowledgement switches off the alarm relay) are indicated by the " ". Errors/notes
which still apply after acknowledgement are indicated alternately. During correction variable processing
(temperature for correction of pH-value), the value is indicated in the same line as the error/note. Faults
which are rectified of their own accord due to changed operating situations are removed from the
permanent display without the need for acknowledgement.
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr5

6
The display of the DULCOMETER®D1C controller uses the following symbols:
Description Comment Symbol
Limit value transgression Symbol
Relay 1, upper left
Symbol
Relay 1, lower left
Symbol
Relay 2, upper right
Symbol
Relay 2, lower right
Metering pump 1 (oxidant) Symbol
Control off left
Symbol
Control on left
Metering pump 2 (reducing agent) Symbol
Control off right
Symbol
Control on right
Solenoid valve 1 (oxidant) Symbol
Control off left
Symbol
Control on left
Solenoid valve 2 (reducing agent) Symbol
Control off right
Symbol
Control on right
Servomotor
Control, open relay
Control, close relay
Without control
Thickness of bar
Position feedback increases from left to right
during opening
Stop button pressed
Manual metering
Fault
5Display Symbols
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr6

7
NOTE
Access to the setting menus can be barred with the access code!
The number and scope of setting menus is dependent on the device version!
If the access code is selected correctly in a setting menu, then the following setting menus are
also accessible!
If within a period of 10 minutes no button is pushed, the unit automatically branches back from the
calibrating menu or a setting menu to the permanent display 1.
6Operation
Access code, correct
Parameter
setting
Calibration notes
Permanent
display 1
Permanent
display 2
Calibration
menu
Various
Access code
Setting menus
D1C2-007-GB
The various menus are selected with
the CHANGE button
The menu is started with
the ENTER button
BRANCH BACK to permanent display
or to relevant setting menu
D1C2-008-GB
CHANGE from selection to selection
Change numbers or
settings of selection
Variables flash
ENTER and save setting,
continue to next menu
BRANCH BACK without
saving setting
BRANCH BACK to
start of setting
Text 1
Text 2
Selection 1
Selection 2
Text 1
Text 2
Selection 1
Selection 2
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr7

8
The restricted operating menu permits simple operation of the most important parameters. The following
overview shows the settings which can be selected.
7Restricted Operating Menu / Layout
limit 2 upper
900 mV
D1C2-010-Redox-GB
Permanent display 1
Permanent display 2
only with control
(w = setpoint)
mV
750
check probe
ORP check probe
ORP
probe in buffer
460 mV
check probe
measurement act.
please wait !
460 mV
check probe
ORP
value:
buffer: 460 mV
465 mV
limit 1
100 mV lower
limits
setting ?
Control with dead zone
For normal control
PID control
Proportional control
setpoint
750 mV
setpoint 2 upper ctrl. parameter
Ti =
Td =
xp =
0 s
750 mV
setpoint 1 lower
650 mV
10 %
ctrl. parameter
xp = 10 %
control
settings ?
Only with control
control
positive oxide
regulated value:
negative reduc
manual dosing
control
current regulat.
value: 30 %
control
current regulat.
value: 30 %
control
current regulat.
value: 30 %
15 %
regulated range
general setting
information ident-code: D1CA
Software version
DxRxxxxxxxxxx
D1C-A1 FW-5.00
alarm relay access c.:
=
=
operating menu:
active
5000
english
restricted
mea. val.
fd. fwd.:
reg. val.:
750 mV
w: 750 mV
70 %
59 %
Positive values of setting variable:
Negative values of setting variable:
Oxidant agent
Reducing agent
manual
with dead zone
normal
or
or
Setting in
complete
operating
menu
Number and scope of setting menus
is dependent on the device.
Access to setting menus can
be blocked with access code.
0 s
For manual control
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr8

9
Possible values
Initial value Increment Lower value Upper value Remarks
Buffer values Measured valve 1 mV -2000 mV +2000 mV
185–265 mV 220 mV
425–505 mV 465 mV
Checking the Redox Probe
During calibration, the D1C sets the command outputs to “0”. Exception: if a basic load or a manual control
variable was set, these are maintained during calibration. The standard signal outputs mA (measuring value
or correction value) are frozen. The measured value or the standard buffer value 220 mV or 465 mV is
proposed as the buffer value; this value is adjustable (arrow keys). After everything has been checked, all
error tests which refer to the measured value are restarted.
Restricted Operating Menu / Description
Error message Condition Effect
Measured value high Measured value Return to permanent display:
40 mV > buffer Basic metering load
Measured value low Measured value "
40 mV < buffer
D1C2-011-Redox-GB
Permanent display 1
Permanent display 2
only with control
(w = setpoint)
mea. val.
fd. fwd.:
reg. val.:
750 mV
w: 750 mV
70 %
59 %
Positive values of setting variable:
Negative values of setting variable:
Oxidant agent
Reducing agent
mV
750
D1C2-012-Redox-GB
= automatic timing
check probe
ORP check probe
ORP
probe in buffer
460 mV
check probe
measurement act.
please wait !
460 mV
check probe
ORP
value:
buffer: 460 mV
465 mV
Permanent display 1
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr9

10
Restricted Operating Menu / Description
Limits
Possible values
Initial value Increment Lower value Upper value Remarks
Type of limit trans- upper Limit transgression
gression Limit 1: lower lower when exceeding or
Limit 2: upper off* dropping below value
*only with limit relay
Limit value Limit 1: 500 mV 1 mV -2000 mV 2000 mV
Limit 2: 1000 mV 1 mV -2000 mV 2000 mV
Control
limit 1
100 mV lower
limit 2 upper
900 mV
D1C2-014-GB
Access to all setting menus can be blocked with an access code !
limits
setting ?
control
current regulat.
value: 30 %
control
current regulat.
value: 30 %
control
current regulat.
value: 30 %
D1C2-015-Redox-GB
Access to all setting menus can be blocked with an access code !
Only with control
Note: The controlled variable is recalculated every second. Only
suitable for processes with time constants greater than 30 s !
Control with dead zone
For normal control
PID control
Proportional control
Positive values of setting variable:
Negative values of setting variable:
Oxidant agent
Reducing agent
setpoint
750 mV
setpoint 2 upper ctrl. parameter
Ti =
Td =
xp =
0 s
750 mV
setpoint 1 lower
650 mV
10 %
ctrl. parameter
xp = 10 %
control
settings ? control
positive oxide
regulated value:
negative reduc
manual dosing
15 %
regulated range
manual
with dead zone
normal
or
or
Setting in
complete
operating
menu
0 s
For manual control
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr10

11
Restricted Operating Menu / Description
General Settings
Possible values
Initial value Increment Lower value Upper value Remarks
Setpoint 750 mV 1 mV lower limit upper limit 2 setpoints necessary
measuring range measuring range for control with dead zone.
Setpoint 2 > setpoint 1
Control parameter xp 10 % 1 % 1 % 500 % xp referred to measuring range
Control parameter Ti off 1 s 1 s 9999 s Function off = 0 s
Control parameter Td off 1 s 1 s 2500 s Function off = 0 s
Manual metering 0 % 1 % -100 % +100 %
Possible values
Initial value Increment Lower value Upper value Remarks
Alarm relay active active
not active
Access code 5000 1 1 9999
Language as per identity as per identity
code code
Operating menu restricted restricted
complete
D1C2-016-GB
Access to all setting menus can be blocked with an access code !
general setting
information ident-code: D1CA
software version
DxRxxxxxxxxxx
D1C-A1 FW-5.00
alarm relay access c.:
=
=
operating menu:
active
5000
english
restricted
Abbreviations for control variables:
xp=100 %/Kp (inverse proportional coefficient)
Ti=Icontroller integration time [s]
Td=Dcontroller differential time [s]
Access Code
Access to the setting menu can be prevented by setting up an access code. The DULCOMETER®D1C
controller is supplied with the access code 5000 which permits free access to the setting menu. The
calibration menu remains freely accessible even if access to the setting menu is blocked by the code.
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr11

12
8Complete Operating Menu / Overview
All parameters of the controller can be set in the complete operating menu (access see previous page). The
following overview shows the settings which can be selected:
D1C2-017-Redox-GB
Permanent display 1
Permanent display 2
only with control
(w = setpoint)
Only with limit relay,
solenoid valve relay
or servomotor
Only with
servomotor
Only with pumps
meas. value
setting ?
pumps
setting ?
relays
setting ?
limits
setting ?
servomotor
setting ?
Number and scope of setting menus
is dependent on the device.
Access to setting menus can
be blocked with access code.
mea val.
fd. fwd.:
reg. val.:
750 mV
w: 750 mV
70 %
59 %
mV
750
check probe
ORP
Only with control
control
setting ?
feed forward ctrl.
setting ?
Only with 2 standard
signal outputs
Only with standard
signal output
general setting
information
signal output 2
mA setting ?
signal output 1
mA setting ?
Only with feed
forward control
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr12

13
Checking the Redox Probe
During calibration, the D1C sets the command outputs to “0”. Exception: if a basic load or a manual control
variable was set, these are maintained during calibration. The standard signal outputs mA (measuring value
or correction value) are frozen. The measured value or the standard buffer value 220 mV or 465 mV is
proposed as the buffer value; this value is adjustable (arrow keys). After everything has been checked, all
error tests which refer to the measured value are restarted.
Possible values
Initial value Increment Lower value Upper value Identification code expression
Buffer values Measured value 1 mV -2000 mV +2000 mV if measured variables 2 and 5
185–265 mV 220 mV are connected
425–505 mV 465 mV – +1000 mV if measured variable 1 is connected
Complete Operating Menu / Description
D1C2-018-Redox-GB
Permanent display 1
Permanent display 2
only with control
(w = setpoint)
mea. val.
fd. fwd.:
reg. val.:
750 mV
w: 750 mV
70 %
59 %
Positive values of setting variable:
Negative values of setting variable:
Oxidant agent
Reducing agent
mV
750
= automatic timing
check probe
ORP check probe
ORP
probe in buffer
460 mV
check probe
measurement act.
please wait !
460 mV
check probe
ORP
value:
buffer: 460 mV
465 mV
D1C2-019-Redox-GB
Permanent display 1
Error message Condition Effect
Measured value high Measured value Return to permanent display:
40 mV > buffer Basic metering load
Measured value low Measured value Return to permanent display:
40 mV < buffer Basic metering load
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr13

14
Possible values
Initial value Increment Lower value Upper value Remarks
Standard signal input 4 mA 0 mA
lower signal limit 4 mA
Allocated 0–1 V 1 mV -2000 mV +2000 mV
probe voltage
Checkout time off 1 s 1 s 9999 s Constant measurement
signal results in message
and alarm.
Function off = 0 s
Control Time Measuring Value
IMPORTANT
This function may not be activated for applications where it can be assumed that the
measuring value does not change.
This function checks whether the measuring value from the sensor (measuring value input) changes within
the “control time measuring value”. It is assumed that the value does not change for an intact sensor.
If the measuring value does not change during this control time, the DULCOMETER®D1C sets the control
output to “0” and the alarm relay drops out. The LCD display shows e.g. the message “check mV-probe”.
IMPORTANT
When changing the range adjustment, the adjustments in all menus have to be checked!
Complete Operating Menu / Description
Measured Value
D1C2-020-Redox-GB
Access to all setting menus can be blocked with an access code !
Standard signal input mA
meas. value
range adjustment
4 mA
= 0 mV 20 mA = 1000 mV
meas. value
range adjustment
meas. value
checkout time
measured value
off
meas. value
setting ?
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr14

15
Correction Value*
temperature
correction value
setting ?
correction value
automatic
Access to all setting menus can be blocked with an access code !
Pumps
Possible values
Initial value Increment Lower value Upper value Remarks
Max. stroke/minute of 180 1 1 500 off = 0 strokes/min
pumps 1 and 2
D1C2-022-Redox-GB
Access to all setting menus can be blocked with an access code !
Only with pumps for control
pumps
setting ?
dosing pump max.
pump1:
pump2:
control ORP
pump1 oxide
pump2 reduc pulse/minute
180
180
*In the setting menu “correction value” for this equipment enables you to display the temperature or to
maintain an mA signal proprotional to the temperature. No temperature adjustment is made to the
measured variable!
Complete Operating Menu / Description
Relay for power control
D1C2-023-Redox-GB
Access to all setting menus can be blocked with an access code !
Only with limit relay, solenoid valve relay or servomotor
relays
setting ?
solenoid valve 2
reduc
solenoid valve 1
oxide
period
min. time
10 s
1 s period
min. time
10 s
1 s
relay adjustment
relay1:
relay2: SV1
SV2
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr15

16
Complete Operating Menu / Description
D1C2-033-Redox-GB
relays
setting ? control timer 1
relay 1
period 1 h
t on: 1 min
control timer 2
relay 2
period 1 h
t on: 1 min
with timer
relay adjustment
relay1: timer
relay2: timer
Possible values
Initial value Increment Lower value Upper value Remarks
Relay adjustment as per
identity code
Relay 1 Solenoid valve 1
Limit value 1* *For “limit value”, the relays
Actuator 1 remain active, even in the
Timer 1 event of a fault.
Servomotor only with servomotor
off
Relay 2 Solenoid valve 2
Limit value 2*
Actuator 2
Timer 2
off
Cycle 10 s 1 s 10 s 9999 s for solenoid valve
min. time 1 s 1 s 1 s Cycle/2 for solenoid valve
Set here the smallest
permitted operating factor
of the connected device.
Period (Cycle) off 1 h 1 h / off 240 h for timer
t on 1 min 1 min 1 min 60 min for timer
NOTE
The limit value relay can be defined in such a way as to respond as an actuator, i.e. if a limit
value relay closes a circuit, it opens when a pause contact is activated and/or for a
subsequent delay period td(if tdis set to > 0 min in “General settings”).
Cycle
Timer relay
off
on
t
ton
IMPORTANT
The timer will be reset if there is a drop in the power supply.
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr16

17
Complete Operating Menu / Description
At the end of the (timer) cycle time, the DULCOMETER®D1C closes the assigned relay for the duration of
“t on” (timer). “Pause” interrupts the timer.
When the clock is shown in the LC display, the timer can be reset to the start of the cycle at precisely this
point using the Enter button.
The % figure in the LC display indicates the progress of the current cycle.
Timer relays may be used, e.g. for shock metering or sensor cleaning.
Cycle
min. time
Solenoid
valve
off
on
t
ton
off
on
t
ton
Cycle
Control
variable: 50 %
ton
Cycle = 0.50
Control
variable: 80 %
ton
Cycle = 0.80
The switching time of the DULCOMETER®D1C (solenoid valve) depends on the actuating variable and the
“min. time” (smallest permitted operating factor of the connected device).
The actuating variable determines the ratio ton/cycle and thus the switching times (see fig. above).
The “min. time” influences the switching times in two situations:
a) theoretical switching time < min. time:
off
on
t
off
on
t
Cycle Cycle Cycle
Cycle Cycle Cycle
min. time
min. time
theoretical
actual
The DULCOMETER®D1C does not switch for a certain number of cycles until the sum of the theoretical
switching times exceeds the “min. time”. Then the DULCOMETER®D1C switches for the duration of this
total time .
b) theoretical switching time > (cycle - min. time) and calculated switching time < cycle
Cycle
min. time
off
on
t
off
on
t
Cycle Cycle
Cycle Cycle Cycle
min. time
theoretical
actual
The DULCOMETER®D1C does not deactivate for a certain number of cycles until the differences between
cycle and theoretical switching time exceed the “min. time”.
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr17

18
Possible values
Initial value Increment Lower value Upper value Remarks
Type of limit transgression upper Limit transgression when
Limit 1: lower lower exceeding or dropping below value
Limit 2: upper off* *only with limit relay
Limit value Limit 1: 500 mV 1 mV -2000 mV 2000 mV
Limit 2: 1000 mV 1 mV -2000 mV 2000 mV
Hysteresis limits 10 mV 1 mV 10 mV 2000 mV Effective in direction of cancelling
limit transgression
Checkout time limits off 1 s 1 s 9999 s Results in message and alarm.
off = 0 s:
Function switched off,
no message, no alarm
Control on on
off
Actuating direction active closed active closed Reacts as make contact
limit value 1; active open Reacts as break contact
limit value 2
Switch-on delay ∆t on 0 s 1 s 0 s 9999 s
Switch-off delay ∆t off 0 s 1 s 0 s 9999 s
Complete Operating Menu / Description
Limits
D1C2-024-Redox-GB
relay 2 LV2
- active closed
∆t on 0 s
∆t off 0 s
Access to all setting menus can be blocked with an access code !
limits
setting ?
relay 1 LV 1
- active closed
∆t on 0 s
∆t off 0 s
limit 2 upper
800 mV
limit 1 lower
100 mV
hysteresis
limits: 10 mV
∆t on: off
control: on
If the limit is exceeded for longer than the “Delay time - limit values”, an error message is given which
must be acknowledged, and the alarm relay circuit is broken. If “Control” is also set to “off” the control
process stops.
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr18

19
Servomotor
The operating range is defined by the total resistance range of the feedback potentiometer. The maximum
limit of the range actually used is set by defining the control range.
IMPORTANT
•To ensure correct operation, the activation time of the actuator used should not be less
than 25 seconds for the control range from 0…100 %!
•Activation of the servomotor must be carried out with the same meticulous care as taken
when calibrating a measuring probe.
Complete Operating Menu / Description
Possible value
Initial value Increment Lower value Upper value Remarks
Servomotor Setting Setting
ok
off
Control direction Oxidant Oxidant
Reducing
Control range 100 % 1 % 10 % 100 % in % of operating range
D1C2-025-Redox-GB
Access to all setting menus can be blocked with an access code !
servomotor
setting ?
dosing:
control range:
0 % to
operating range
oxide
100 %
Only with servomotor
servomotor
current position:
servomotor
open ? servomotor
please wait !
open
servomotor
please wait !
close
servomotor
value take over ?
opened !
servomotor
value take over ?
closed !
servomotor
close ?
servomotor
current position:
OK
setting
= automatic timing
NOTE
•If the broad bar is to the far right, the servomotor is fully open.
•The continuous display shows the degree (in %) to which it is open (the greater the percentage,
the more open the servomotor).
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr19

20
Complete Operating Menu / Description
Control
Possible values
Initial value Increment Lower value Upper value Remarks
Control normal normal When controlling with dead zone,
with dead zone the feed forward control is not used
manual for measured values within
the dead zone.
2 setpoints necessary for
Lower limit Upper limit control with dead zone.
Setpoint 750 mV 1 mV measuring range measuring range Setpoint 2 > setpoint 1
Control parameter xp 10 % 1 % 1 % 500 % xp referred to measuring range
Control parameter Ti off 1 s 1 s 9999 s Function off= 0 s
Control parameter Td off 1 s 1 s 2500 s Function off = 0 s
Additive basic load 0 % 1 % -100 % +100 %
Manual metering 0 % 1 % -100 % +100 %
D1C2-026-Redox-GB
10 %
control load:
regulated range
Access to all setting menus can be blocked with an access code !
Only with control
Note: The controlled variable is recalculated every second. Only
suitable for process with time constants greater than 30 s !
Control with dead zone
For normal control
PID control
Proportional control
setpoint
750 mV
setpoint 2 upper ctrl. parameter
Ti =
Td =
xp =
0 s
750 mV
setpoint 1 lower
650 mV
10 %
ctrl. parameter
xp = 10 %
control
settings ? control
positive oxide
regulated value:
negative reduc
manual dosing
control
current regulat.
value: 30 %
15 %
regulated range
Positive values of setting variable:
Negative values of setting variable:
Oxidant agent
Reducing agent
normal
0 s
For manual control
Abbreviations for control variables:
xp: 100 %/Kp (inverse proportional coeffizient)
Ti: Integration time of I-controller [s]
Td: Differential time of D-controller [s]
BA_DM_183_10_10_EN.p65 28.10.2010, 11:44 Uhr20
