ProMinent Portamess 911 Conductivity User manual

Portamess 911 Conductivity
Operating manual
A3425
Version TA-193.202-PMD01 130701
Software version: 1.x
EN
Target group: instructed personnelPart number 999609 Version: BA DT 068 09/21 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

General non-discriminatory approach In order to make it easier to read, this docu‐
ment uses the male form in grammatical struc‐
tures but with an implied neutral sense. The
document is always aimed equally at women,
men and gender-neutral persons. We kindly
ask readers for their understanding in this sim‐
plification of the text.
Supplementary information
Please read the supplementary information in its entirety.
Information
This provides important information relating to the correct operation of the unit or is intended
to make your work easier.
Warning information
Warning information includes detailed descriptions of the hazardous situation, see
Ä Chapter 2.1
‘Labelling of Warning Information’ on page 6 .
The following symbols are used to highlight instructions, links, lists, results and other elements in
this document:
Tab. 1: More symbols
Symbol Description
Action, step by step.
⇨Outcome of an action.
Links to elements or sections of these instructions or other applicable docu‐
ments.
nList without set order.
[Button] Display element (e.g. indicators).
Operating element (e.g. button, switch).
Supplemental directives
2

Symbol Description
‘Display/GUI’ Screen elements (e.g. buttons, assignment of function keys).
CODE Presentation of software elements and/or texts.
Supplemental directives
3

Table of contents
1 The Portamess 911 Conductivity............................................................................................ 5
1.1 Scope of delivery............................................................................................................ 5
1.2 Brief description of the unit............................................................................................. 5
2 Safety...................................................................................................................................... 6
2.1 Labelling of Warning Information.................................................................................... 6
2.2 User qualification............................................................................................................ 8
2.3 General safety information............................................................................................. 9
3 Operation.............................................................................................................................. 10
3.1 Construction of the unit................................................................................................ 10
3.2 Display.......................................................................................................................... 11
3.3 Keypad......................................................................................................................... 12
4 Connection and start up........................................................................................................ 13
4.1 Sensor connector......................................................................................................... 13
4.2 Connector assignment................................................................................................. 14
5 Configuration......................................................................................................................... 15
6Calibration............................................................................................................................. 16
6.1 Calibration by direct input of the cell constants (AutCAL OFF).................................... 16
6.2 Calibration with 0.1 or 0.01 molar KCl solution (AutCAL On)....................................... 17
6.3 Calibration with any calibration solution (AutCAL ON)................................................. 17
7 Measurements...................................................................................................................... 18
8 Troubleshooting and maintenance........................................................................................ 20
8.1 Error messages............................................................................................................ 20
8.2 Battery replacement..................................................................................................... 22
8.3 Cleaning the unit.......................................................................................................... 22
9 Appendix............................................................................................................................... 23
10 Technical data....................................................................................................................... 24
11 Disposal of used parts........................................................................................................... 26
12 Technical terminology........................................................................................................... 27
13 Index..................................................................................................................................... 28
Table of contents
4

1 The Portamess 911 Conductivity
A3426
Fig. 1: The Portamess 911 Conductivity
1.1 Scope of delivery
Please check the completeness of the delivery
once you have unpacked it. The scope of
delivery of the unit includes the following parts:
nPortamess 911 Conductivity (ready-to-use)
nSupport strap
nSensor LF 204
nOperating instructions
nField case
1.2 Brief description of the unit
The Portamess 911 Conductivity measures
conductivity, salinity, TDS and temperature in
the industrial, environmental, food and waste
water sectors.
The unit complies with the requirements of the
EMC Act and the NAMUR NE 21 recommenda‐
tions.
The unit’s degree of protection is IP 66
according to DIN EN 0470 Part 1.
Temperature compensation is provided auto‐
matically with a Pt 1000 temperature sensor, an
NTC 30 kΩ (automatic detection when switched
on) or by manual temperature specification.
Calibration can be done by direct input of the
cell constants, by calibration with calibration
solutions KCl 0.01 mol/l or 0.1 mol/l or with any
other calibration solution.
Uninterrupted operation of the unit for approx.
1000 hours is possible with 3 mignon batteries.
To save battery life, the unit automatically
switches off after 1 hours if it is not operated.
The Portamess 911 Conductivity
5

2 Safety
2.1 Labelling of Warning Infor‐
mation
Introduction
These operating instructions provide informa‐
tion on the technical data and functions of the
product. These operating instructions provide
detailed warning information and are provided
as clear step-by-step instructions.
The warning information and notes are categor‐
ised according to the following scheme. A
number of different symbols are used to denote
different situations. The symbols shown here
serve only as examples.
DANGER!
Nature and source of the danger
Consequence: Fatal or very serious
injuries.
Measure to be taken to avoid this
danger.
Description of hazard
–Denotes an immediate threatening
danger. If the situation is disre‐
garded, it will result in fatal or very
serious injuries.
WARNING!
Nature and source of the danger
Possible consequence: Fatal or very
serious injuries.
Measure to be taken to avoid this
danger.
– Denotes a possibly hazardous sit‐
uation. If the situation is disre‐
garded, it could result in fatal or
very serious injuries.
CAUTION!
Nature and source of the danger
Possible consequence: Slight or minor
injuries. Material damage.
Measure to be taken to avoid this
danger.
– Denotes a possibly hazardous sit‐
uation. If the situation is disre‐
garded, it could result in slight or
minor injuries. May also be used
as a warning about material
damage.
Safety
6

NOTICE!
Nature and source of the danger
Damage to the product or its surround‐
ings.
Measure to be taken to avoid this
danger.
– Denotes a possibly damaging sit‐
uation. If the situation is disre‐
garded, the product or an object in
its vicinity could be damaged.
Type of information
Hints on use and additional information.
Source of the information. Additional
measures.
– Denotes hints on use and other
useful information. It does not indi‐
cate a hazardous or damaging sit‐
uation.
Safety
7

2.2 User qualification
WARNING!
Danger of injury with inadequately qualified personnel
The operator of the system / equipment is responsible for ensuring that the qualifications are
fulfilled.
If inadequately qualified personnel work on the unit or loiter in the hazard zone of the unit,
this could result in dangers that could cause serious injuries and material damage.
– All work on the unit should therefore only be conducted by qualified personnel.
–Unqualified personnel should be kept away from the hazard zone.
The pertinent accident prevention regulations, as well as all other generally acknowledged
safety regulations, must be adhered to.
Training Definition
Instructed personnel An instructed person is deemed to be a person who has been
instructed and, if required, trained in the tasks assigned to him and pos‐
sible dangers that could result from improper behaviour, as well as
having been instructed in the required protective equipment and protec‐
tive measures.
Trained user A trained user is a person who fulfils the requirements made of an
instructed person and who has also received additional training specific
to the system from the manufacturer or another authorised distribution
partner.
Trained, qualified per‐
sonnel
A trained, qualified employee is deemed to be a person who is able to
assess the tasks assigned to him and recognize possible hazards
based on his training, knowledge and experience, as well as knowledge
of pertinent regulations. A trained, qualified employee must be able to
perform the tasks assigned to him independently with the assistance of
drawing documentation and parts lists. The assessment of a person's
technical training can also be based on several years of work in the rel‐
evant field.
Safety
8

Training Definition
Electrical technician An electrical technician is able to complete work on electrical systems
and recognise and avoid possible dangers independently based on his
technical training and experience as well as knowledge of pertinent
standards and regulations. An electrical technician must be able to per‐
form the tasks assigned to him independently with the assistance of
drawing documentation, parts lists, terminal and circuit diagrams. The
electrical technician must be specifically trained for the working environ‐
ment in which the electrical technician is employed and be conversant
with the relevant standards and regulations.
Service The Service department refers to service technicians, who have
received proven training and have been authorised by the manufacturer
to work on the system.
2.3 General safety information
WARNING!
Unauthorised access!
Possible consequence: Fatal or very
serious injuries
– Measure: Ensure that there can be
no unauthorised access to the unit
–Only trained personnel may fit,
install, service and operate this
sensor
CAUTION!
Functional limitations
Possible consequence: Slight or minor
injuries. Material damage
– Check the sensor regularly for dirt
and contamination
–Observe all applicable national
regulations relating to mainte‐
nance, service and calibration
intervals
Safety
9

3 Operation
3.1 Construction of the unit
nUser qualification: instructed user
Ä Chapter 2.2 ‘User qualification’ on page 8
12
345
meas cal
on/off
Portamess
A2588
Fig. 2: Construction of the unit
1 Sensor connector
2 Reference electrode
3 Temperature sensor connector
4 not assigned
5 Sensor quiver
Operation
10

3.2 Display
1
14
13
11
10
9
8
7
654
3
2
12
A2589
Fig. 3: Display
1 Wait, sensor set-up time
2 Measured value symbol
3 Temperature detection with Pt 1000/NTC
4 Manual temperature detection
5 Main display
6 Secondary display
7 Error message
8 Zero point/gradient
9 Sensoface
10 Battery depleted
11 Flush sensor
12 Stir buffer solution
13 Sensor set-up time
14 Press Cal key
Operation
11

3.3 Keypad
Key Function
‘ON/OFF’ Use the ‘ON/OFF’ key to switch the unit on or off. Once the unit has been
switched on, it automatically performs a self-test and checks which tempera‐
ture sensor is connected.
Note: You can also use
‘meas’ to switch on the unit. However, this only per‐
forms a short test and does not detect the temperature sensor. The unit
assumes the last temperature sensor detected.
‘meas’ ‘meas’ takes you from any function back to measuring mode.
In measuring mode, ‘meas’ displays the following parameters:
nCond measuring mode: Temperature compensation
ntdS measuring mode: TDS factor
‘cal’ ‘cal’ starts calibration.
⇩⇧ ⇩ and ⇧ let you select and change the parameters and select a mode.
‘cal’ + ‘ON/OFF’ When the unit is switched off, press ‘cal’ + ‘ON/OFF’ to activate configura‐
tion mode.
When pressing 2 keys in parallel, make sure that the key shown on the left
is pressed first.
Operation
12

4 Connection and start up
nUser qualification: instructed user
Ä Chapter 2.2 ‘User qualification’
on page 8
4.1 Sensor connector
You can connect the following sensors to the
unit. LF 204 4-pin sensor with integrated NTC
30 kΩ temperature sensor.
Connection and start up
13

4.2 Connector assignment
Socket Connector
1 Sensor
2 and 3 Separate temperature sensor
4 not assigned
The unit works with the temperature set manually if you have not connected a temperature sensor.
[man] appears in the display.
Set up the cell constant and temperature compensation before initial commissioning. The cell con‐
stant is printed on the sensor head or specified in the sensor’s technical data
The calibration and configuration data are permanently saved both when the unit is switched off and
when the batteries are removed (battery change).
The ‘ON/OFF’ key is used to switch to measuring mode. When the unit is switched on, it detects the
temperature sensor connected and performs a self-test:
nSimultaneous appearance of all display segments, measured value symbols etc.
nDisplay of the unit type 911.
nDisplay of the software version.
Note: The temperature sensor is only detected during switching-on using
‘ON/OFF’ .
Note: You can also use ‘meas’ to switch on the unit. However, this only performs a short test and
does not detect the temperature sensor. The unit assumes the last temperature sensor detected.
Connection and start up
14

5 Configuration
nUser qualification: instructed user
Ä Chapter 2.2 ‘User qualification’
on page 8
You can change the following basic settings of
the unit in the configuration:
nCond (conductivity), SAL (salinity) or tdS
(Total Dissolved Solids or evaporation res‐
idue)
nCalibration by input of the cell constants
(AutCal Off) or calibration with a calibration
solution (AutCal On)
nTemperature display °C or °F
To activate configuration, with the unit switched
off, press
‘CAL’ and then press ‘ON/OFF’ .
‘ConF’ : The menu items of the configuration
menu are processed one after the other.
Pressing ⇧ and ⇩ lets you change the settings
of the respective menu item.
‘CAL’ takes you to the next menu item, saving
the settings displayed.
‘meas’ lets you exit the configuration menu at
any time. The value last displayed and possibly
changed is not saved.
Use Function to select the measuring function
[Cond] (conductivity), SAL (salinity) or tdS
(Total Dissolved Solids or evaporation residue).
Automatic or manual calibration
Select whether you wish to adjust cells by
direct input of cell constants or by calibration
with a calibration solution and automatic drift
control. Factory default setting: Direct input of
the cell constant (AutCAL OFF)
AutCAL OFF
Direct input of the cell constants (AutCAL OFF)
from 0.010 cm–1 ... 199.9 cm–1. Factory default
setting 0.475 cm–1.
AutCAL ON
Automatic calibration (AutCAL On) with 0.1
molar KCl solution, 0.01 molar KCl solution or
input of the temperature-correct conductivity of
another known calibration solution.
Temperature display °C temp
The temperature can be displayed in either °C
or °F. Factory default setting: °C.
Configuration
15

6 Calibration
nUser qualification: instructed user Ä Chapter 2.2 ‘User qualification’ on page 8
Calibration adapts the Portamess 911 Conductivity to the cell constant of the sensor. In general, it is
enough to enter the cell constants specified by the manufacturer of the sensor into the unit.
Tab. 2: General calibration information
Parameter Explanation
Calibration solu‐
tions
Solutions for the calibration of conductivity measuring units are unbuffered
systems. Their conductivity values are not stable and are affected by low
contamination or dilution, e.g. drops of water adhering to the sensor.
Clean sensor Ensure that the sensor is clean before calibration. Use distilled water to
rinse out any residue. After this, we recommend drying the sensor and
rinsing it with the intended calibration solution.
Cell constant The cell constant is determined by the size and geometric arrangement of
the sensor. The cell constant is the core size of conductivity sensors. The
cell constant is virtually immutable. Clean sensor surfaces without insulating
coatings are a prerequisite for this. Regular calibration is therefore not gen‐
erally necessary
4-pin sensors With 4-pin sensors, the principle of separate current/voltage electrodes
means that the partial contamination of the sensor does not lead to meas‐
uring errors in practice. By contrast, sensors fully contaminated with insu‐
lating coatings cause the measurement to fail.
Sensor LF 204 The cell constant is given with a tolerance of 1.5 % for the conductivity
sensor LF 204. In calibration mode (AutCAL OFF), this cell constant is
entered into the Portamess 911 Conductivity and saved. Further calibration
with calibration solutions is not required.
6.1 Calibration by direct input of
the cell constants (AutCAL
OFF)
1. INFORMATION: Sensor LF 204: C =
0.475 cm-1
Use
[CAL] to access calibration. The cell
constant determined and/or set during
the last calibration is displayed. ‘meas’
lets you exit calibration again.
Calibration
16

2. Use ⇧ and ⇩ to adjust the cell constant
of the sensor used. Confirm with CAL.
ðThe unit then switches back to
measuring mode.
6.2 Calibration with 0.1 or 0.01
molar KCl solution (AutCAL
On)
It is essential that contamination of the calibra‐
tion solutions is avoided.
1. Use
‘CAL’ to access calibration. The
cell constant determined and/or set
during the last calibration is displayed.
‘meas’ lets you exit calibration again.
2. Select the calibration solution used
(CALSoL). A 0.1 and a 0.01 molar KCI
solution are available. Confirm the
appropriate solution with
‘CAL’ .
3. Immerse the clean and dry sensor in the
calibration solution.
4. Press
‘CAL’ to start calibration. Use
‘meas’ to interrupt calibration if you do
not wish to calibrate.
5. The temperature is displayed in the
lower line during calibration. Automatic
drift control checks the stability of the
conductivity and temperature. The hour‐
glass symbol flashes.
6. If the measured values are stable, the
correct tabular temperature value of the
KCI solution is displayed. The conduc‐
tivity measured value flashes.
7. Confirm with
‘CAL’ .
ðThe cell constant detected is dis‐
played for several seconds. The
unit then switches back to meas‐
uring mode.
6.3 Calibration with any calibra‐
tion solution (AutCAL ON)
It is essential that contamination of the calibra‐
tion solutions is avoided.
1. Use
‘CAL’ to access calibration. The
cell constant determined and/or set
during the last calibration is displayed.
‘meas’ lets you exit calibration again.
2. Select the calibration solution used
(CALSoL). A 0.1 and a 0.01 molar KCI
solution are available. Confirm the
appropriate solution with
‘CAL’ .
3. Immerse the clean and dry sensor in the
calibration solution.
4. Press
‘CAL’ to start calibration. Use
‘meas’ to interrupt calibration if you do
not wish to calibrate.
5. The temperature is displayed in the
lower line during calibration. Automatic
drift control checks the stability of the
conductivity and temperature. The hour‐
glass symbol flashes.
6. If the measured values are stable, the
correct tabular temperature value of the
KCI solution is displayed. The conduc‐
tivity measured value flashes.
7. Read off the conductivity value from the
table for your calibration solution aligned
to the measuring temperature displayed.
Use ⇧ and ⇩ to enter the correct tem‐
perature-based conductivity value in the
unit.
Confirm with ‘CAL’ .
ðThe cell constant detected is dis‐
played for several seconds. The
unit then switches back to meas‐
uring mode.
Calibration
17

7 Measurements
Measuring mode
nUser qualification: instructed user
Ä Chapter 2.2 ‘User qualification’
on page 8
‘meas’ moves you from all functions to meas‐
uring mode. In measuring mode, the main dis‐
play shows the measured variable selected in
the configuration, while the lower display shows
the temperature.
The set-up time of the sensor and the
temperature sensor is considerably
shorter if the sensor is first moved in
the buffer solution and then held calmly
to be read off. This then gives you
stable values more quickly.
Conductivity measurement (Cond)
The main display shows the conductivity
measured, while the secondary display
shows the temperature.
Temperature compensation
1. The measuring unit offers various tem‐
perature compensation options.
‘meas’
and ⇧ or ⇩ allow you to select and
adjust temperature compensation:
2. (tc OFF) no temperature compensation
3. (tc nLF) temperature compensation with
a non-linear characteristic curve in
accordance with EN 27888 or DIN
38404.8 for natural water and ultra-pure
water (reference temperature 25 °C).
The secondary display also shows tc.
4. (tc 0.01 ... 9.99 %/°C) temperature com‐
pensation with a linear characteristic
curve and parametrisable temperature
coefficients (reference temperature 25
°C). The secondary display also shows
‘tc’ .
5. INFORMATION: If you have selected
temperature compensation with a linear
characteristic curve, this function can
only be exited or the non-linear function
selected if the temperature coefficient
has been set to 0.00.
Salinity measurement (SAL)
The main display shows the salinity
measured in ‰ (g/kg), while the secon‐
dary display shows the temperature.
Measurements
18

TDS determination (TDS)
1. The main display shows the concentra‐
tion of the dissolved substances that
contribute to the conductivity of the solu‐
tion (TDS comparable with the evapora‐
tion residue) in mg/l, while the secon‐
dary display shows the temperature.
2.
‘meas’ and ⇧ or ⇩ allow you to set the
TDS factor within a range of 0.40 ...
1.00.
INFORMATION The TDS factor
depends on the composition of the
water being analysed and needs to be
determined for each type of water.
Manual temperature specification
The
‘man’ display signals that no tem‐
perature sensor is connected. The unit
works with the temperature value man‐
ually specified. ⇧ and ⇩ allow you to
change the temperature specification in
Cond measuring mode.
Measurements
19

8 Troubleshooting and maintenance
8.1 Error messages
Error Description
Sensor problems An error message appears and the measured value display flashes if
problems occur with a sensor.
‘ERROR 1’ Problem with the sensor.
Possible causes:
Sensor faulty.
Sensor cable disconnected
Incorrect sensor connected
Incorrect cell constant entered
‘ERROR 3’ Problem with the temperature sensor
The temperature measured lies outside the ranges:
Conductivity:–20 °C ... +120 °C
nLF: 0 °C ... +120 °C
Salinity: 0 °C ... +30 °C
TDS: +10 °C ... +40 °C
Possible causes:
Temperature sensor faulty
Short circuit of the temperature sensor
Incorrect temperature sensor connected
When changing the temperature sensor (even with sensors with inte‐
grated temperature sensor), note that the type of temperature sensor
(Pt 1000/NTC 30 kΩ) is only detected when the unit is switched on
using ‘ON/OFF’ .
Calibration error messages
If errors occur during calibration or if the sensor data detected is out‐
side of the valid range, then an error message appears (ERROR 6,
ERROR 11).
Troubleshooting and maintenance
20
