ProMinent Hydro/ 4 User manual

Metering pump
Hydro/ 4, HA4a
Assembly and operating instructions
Target group: trained, qualified personnel, unless otherwise required.
in compliance with API 675
EN
Original operating instructions (2006/42/EC)999824 BA HY 021 05/21 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

Read the following supplementary information in its entirety! Should you
already know this information, you will benefit more from referring to the
operating instructions.
The following are highlighted separately in the document:
nEnumerated lists
Operating guidelines
ðOutcome of the operating guidelines
- see (reference)
Information
This provides important information relating to the cor‐
rect operation of the unit or is intended to make your
work easier.
Safety Information
Safety information is identified by pictograms - see Safety Chapter.
Refer to the precise designation of suppliers' components in the "Technical
Data" chapter for ease of finding the relevant information.
These operating instructions conform to current EU regulations applicable
at the time of publication.
Please state identity code and serial number, which you can find on the
nameplate when you contact us or order spare parts. This enables the unit
type and material versions to be clearly identified.
The nameplate stuck on the cover page is identical to the pump supplied
so that there is a clear link between the operating instructions and the
pump.
Supplementary information
Fig. 1: Please read!
Information in supplier instructions
Validity
State the identity code and serial number
EX pumps only
Supplemental directives
2

Table of contents
1Functional description...................................................................... 5
1.1 Overview of equipment / control elements.............................. 7
1.2 Identity code.......................................................................... 10
1.2.1 Nameplate data.................................................................. 10
1.2.2 ATEX nameplate data........................................................ 10
1.2.3 HA4a identity code............................................................. 11
1.2.4 Explanation of the ATEX label........................................... 13
2 Safety chapter............................................................................... 14
2.1 Labelling of Warning Information.......................................... 14
2.2 User qualification................................................................... 15
2.3 Warning symbols denoting different types of danger............ 16
2.4 Intended use......................................................................... 16
2.5 Misuse................................................................................... 16
2.6 Safety information................................................................. 17
2.7 Emissions.............................................................................. 18
3 Storage, transport and unpacking................................................. 19
3.1 Ambient conditions................................................................ 19
4 Assembly....................................................................................... 21
4.1 Motor number........................................................................ 21
4.2 Space requirement................................................................ 23
4.3 Liquid end alignment............................................................. 23
4.4 Fastening.............................................................................. 24
5 Installation..................................................................................... 25
5.1 Installation, hydraulic............................................................. 25
5.1.1 Basic installation notes....................................................... 27
5.2 Installation, electrical............................................................. 28
6 Start up and operation................................................................... 31
6.1 Bleeding the liquid end.......................................................... 32
6.2 Calibrate the stroke control drive (optional).......................... 32
7 Maintenance.................................................................................. 33
7.1 Inspection.............................................................................. 33
7.2 Maintenance work................................................................. 34
7.3 Changing the hydraulic oil..................................................... 34
7.4 Replacing the diaphragm...................................................... 36
7.5 Using shaped composite seals............................................. 39
7.6 Replacing the safety relief valve........................................... 39
7.7 Repairing the diaphragm monitoring sensor......................... 40
7.8 Calibrating the dosing rate.................................................... 41
8 Troubleshooting............................................................................. 44
9Decommissioning and disposal..................................................... 46
9.1 Decommissioning.................................................................. 46
9.2 Disposal................................................................................ 47
10 Technical data............................................................................... 48
10.1 Reproducibility..................................................................... 48
10.2 Particle size......................................................................... 48
10.3 Viscosity.............................................................................. 48
10.4 Performance data................................................................ 49
10.5 Weight................................................................................. 50
10.6 Wetted materials................................................................. 51
10.7 Ambient conditions.............................................................. 51
10.7.1 Temperatures................................................................... 51
10.7.2 Air humidity...................................................................... 52
Table of contents
3

10.7.3 Installation height............................................................. 52
10.8 Housing degree of protection.............................................. 52
10.9 Motor data........................................................................... 53
10.10 Diaphragm monitoring sensor........................................... 54
10.11 HA4 safety relief valve...................................................... 56
10.12 Filling volumes.................................................................. 56
10.13 Sound pressure level of HA4 / HP4.................................. 57
10.14 Supplementary information with modified designs............ 57
11 Dimensional drawing, example...................................................... 58
12 Earthing drawing............................................................................ 61
13 Ordering information...................................................................... 62
13.1 Exploded view..................................................................... 62
13.2 General............................................................................... 62
14 List of other applicable documents................................................ 63
15 EU, EC Declarations of Conformity / Incorporation for HA4.......... 64
15.1 EC Declaration of Conformity for HA4 Machines................ 64
15.2 EU Declaration of Incorporation for HA4 Machines............ 65
15.3 EC Declaration of Conformity for machines without HA4
motor................................................................................... 66
15.4 EC Declaration of Conformity for ATEX HA4 Machines...... 67
15.5 EC Declaration of Incorporation for ATEX HA4a
Machines............................................................................. 68
15.6 EC Declaration of Conformity for ATEX HA4 machines
without motor....................................................................... 69
16 UK Declarations of Conformity or Incorporation for HA2............... 70
16.1 UK Declaration of Conformity for HA4................................ 70
16.2 UK Declaration of Incorporation for HA4............................. 71
16.3 UK Declaration of Conformity for machines without motor
HA4..................................................................................... 72
16.4 UK Declaration of Conformity for ATEX HA4...................... 73
16.5 UK Declaration of Incorporation ATEX HA4a...................... 74
16.6 UK Declaration of Conformity for ATEX machines without
motor HA4........................................................................... 75
17 Index.............................................................................................. 76
Table of contents
4

1 Functional description
The Hydro HA4a product range represents motor-driven metering pumps
with hydraulically operated multi-layer diaphragm (6).
The motor moves the hydraulic piston (4) to the front by means of a worm
gear and cam (1). The hydraulic piston is connected positively to the cam
by a bracket (7) so that the discharge stroke as well as the suction stroke
are performed by the force of the motor (so-called “Full Motion Drive”). The
forward motion pushes the hydraulic piston (4) into the hydraulic end and
builds up the pressure in the hydraulic oil in the hydraulic end. The
hydraulic oil then pushes the multi-layer diaphragm (6) into the dosing
head.
The hollow bored hydraulic piston (4) has several spill ports to adjust the
stroke volume. The adjustable control sleeve (3) seals these spill ports at
each discharge stroke. The control sleeve seals the spill ports sooner or
later depending on the position of the control sleeve (3). While the control
spill ports are free, hydraulic oil can escape from the hydraulic end into the
power end housing during a discharge stroke. The multi-layer diaphragm
in the dosing head is then not deflected. If the spill ports are sealed, the
hydraulic piston (4) can then build up pressure in the hydraulic oil in the
hydraulic end. The multi-layer diaphragm (6) is pressed into the dosing
head. However, the multi-layer diaphragm is deflected to a lesser degree
as hydraulic oil can escape from the hydraulic end (into the power end
housing). The suction stroke causes the hydraulic oil to flow from the
power end housing through the spill ports and back into the hydraulic end.
Both power ends work in push-pull mode with pumps with add-on power
end.
The pump has a permanent safety relief valve (5) installed in the hydraulic
part. The safety relief valve provides protection for the pump power end
and the multi-layer diaphragm if the feed pressure becomes too high. If the
pressure side of the liquid end is blocked, the safety relief valve (5) opens
at a pre-set pressure and allows hydraulic oil to flow into the power end
housing.
1 2 3 4 5 6
P_HY_0082_SW
7
Fig. 2: Cross-section through the pump
1 Cam
2 Stroke adjustment dial
3 Control sleeve
4 Hydraulic piston
5 Safety relief valve / Automatic vent valve
6 Multi-layer diaphragm
7 Bracket
Power end
Functional description
5

P_HY_0008_SW
Fig. 3: Cross-section through the liquid end
The heart of the liquid end is a PTFE multi-layer diaphragm (1). The PTFE
multi-layer diaphragm hermetically seals the delivery chamber of the
dosing head and causes displacement in the dosing head at each pump
stroke. The suction valve (6) and the discharge valve (3) provide the feed
in conjunction with the movement of the diaphragm. The diaphragm (1) is
tightly stretched between the dosing head (4) and a diaphragm mounting
plate (2).
The multi-layer diaphragm prevents feed chemical from mixing with
hydraulic oil in the event of a diaphragm rupture.
As the diaphragm is hydraulically actuated - it is not attached to the piston
- it always works in balance with the pressure and is therefore well suited
to high feed pressures. The reliable return to the starting position after a
stroke is guaranteed by an in-built diaphragm return spring (7).
The diaphragm (1) is designed as standard as a multi-layer diaphragm.
The diaphragm anchor (5) and a film of liquid join the sandwiched dia‐
phragm layers.
Liquid end
Functional description
6

1
2
P_HY_0009_SW
Fig. 4: View of the dismantled dosing head with cross-section
The diaphragm monitor monitors the multi-layer diaphragm for leaks and
faults. The middle diaphragm layer of the multi-layer diaphragm has slots.
The slots are connected by a channel in the dosing head (1) to the dia‐
phragm monitoring sensor (2). As soon as one of the outer diaphragm
layers ruptures, feed chemical or hydraulic oil will reach the diaphragm
monitoring sensor. The diaphragm monitoring sensor generates a signal.
1.1 Overview of equipment / control elements
A A B B B C C C
21
2
21
1
43
56P_HY_0080_SW
43
5 56 7
Fig. 5: Hydro HA, Simplex (vertical) and Simplex double head
A Power end
B Hydraulic end
C Liquid end
1 Stroke adjustment dial
2 Safety relief valve + bleed valve
3 Oil inspection window
4 Gearbox vent stopper
5 Oil drain stopper
6 Oil drainage plug
7 Diaphragm monitor
Every power end includes all these components – apart from the motor.
Diaphragm monitor
Functional description
7

P_HY_0083_SW
40481023
A B C
4
3
56
24 1
3
1
Fig. 6: Hydro HA, Duplex; a) View from left, b) View from right, c) Overall view
Functional description
8

P_HY_0084_SW
40481076
A B C
21 4
3
56
34
Fig. 7: Hydro HA, Triplex; a) View from left, b) View from right, c) Overall view
A Power end
B Hydraulic end
C Liquid end
1 Stroke adjustment dial
2 Safety relief valve + bleed valve
3 Oil inspection window
4 Gearbox vent stopper
5 Oil drain stopper
6 Oil drainage plug
7 Diaphragm monitor
Every power end includes all these components – apart from the motor.
P_HY_0006_SW
1
4
5
3
2
Fig. 8: Liquid end
1 Discharge valve
2 Diaphragm mounting plate
3 Diaphragm monitor
4 Dosing head
5 Suction valve
Functional description
9

1.2 Identity code
1.2.1 Nameplate data
Ser.no.
p rtd
p max
P_HY_0089_SW
p test
DBV
Type
987654321
008 bar
010 bar
008 bar
012 bar
Year of construction
Q rtd
Q max
Fluid T.
Stroke rate
2021
380 l/h
407 l/h
40 °C
136 rpm
HydroP HA4AV063136AS100S000PS10DE
ProMinent GmbH, Im Schuhmachergewann 5 - 11
69123 Heidelberg, Germany
Fig. 9: Nameplate data (example), explanation
Type Identity code - see above
p rtd Maximum pressure, as ordered
p max Maximum pressure
p test Maximum pressure in the test
DBV Opening pressure of pressure relief valve
Q rtd Maximum dosing rate, as ordered
Q max Maximum dosing rate
Temp. Ambient temperature, range
Stroke rate Stroke rate, maximum, in strokes per minute
1.2.2 ATEX nameplate data
Ser.no.
p rtd
p max
P_HY_0090_SW
p test
DBV
Type
20211234
008 bar
010 bar
008 bar
012 bar
Year of construction
Q rtd
Q max
Fluid T.
Stroke rate
2021
380 l/h
407 l/h
40 °C
136 rpm
HydroP HA4AV063136AS1000L00PS11DE0
ProMinent GmbH, Im Schuhmachergewann 5 - 11
69123 Heidelberg, Germany
_ _ _ _ _ _ _ _ _ _
Fig. 10: ATEX nameplate data (example)
Type Identity code - see above
p rtd Maximum pressure, as ordered
p max Maximum pressure
p test Maximum pressure in the test
DBV Opening pressure of pressure relief valve
Q rtd Maximum dosing rate, as ordered
Q max Maximum dosing rate
Temp. Ambient temperature, range
Stroke rate Stroke rate, maximum, in strokes per minute
ATEX specification - refer to the nameplate on your pump, the corre‐
sponding EU Declaration of Conformity for ATEX Machinery and
Ä Chapter 1.2.4 ‘Explanation of the ATEX label’ on page 13 .
Functional description
10

1.2.3 HA4a identity code
HA4a Hydro/ 4, version a, in compliance with API 675
Drive type
V Simplex (vertical) S U Duplex
D Simplex double head D T Triplex
M modified
Piston
040 Piston Ø 40 mm 063 piston Ø 63 mm
052 Piston Ø 52 mm 080 piston Ø 80 mm
M00 modified 094 piston Ø 94 mm
Stroke rate
071 71 strokes / min, 50 Hz 086 086 strokes / min, 60 Hz
103 103 strokes / min, 50 Hz 124 124 strokes / min, 60 Hz
136 136 strokes / min, 50 Hz 164 164 strokes / min, 60 Hz
188 188 strokes / min, 50 Hz 225 225 strokes / min, 60 Hz
214 214 strokes / min, 50 Hz M00 modified
Pressure stage
Z 7 bar D 25 bar
A 10 bar E 40 bar
B 16 bar M modified
Material of dosing head / seals
S1 Stainless steel / PTFE (standard) T1 PTFE + 25 % carbon / PTFE
H1 Hastelloy® C / PTFE V1 PVC / PTFE
P1 PVDF / PTFE Y1 PP / PTFE
M0 modified
Valve design
0 no valve spring (standard)
1 with valve spring
M modified
Diaphragm monitor
0 standard (electrical) B without - with electrical overpressure
display
1 none C Visual display with electrical overpres‐
sure display
2 visual display (red - green) M modified
A Standard with electrical
overpressure display
Hydraulic connector
0 Standard threaded connector (in line with the technical data)
E DIN flange M modified
F ANSI flange
Electrical connection
Functional description
11

HA4a Hydro/ 4, version a, in compliance with API 675
S 3-phase 230 V/400 V 50/60 Hz,
T 3-phase, 230 V/400 V 50/60 Hz, with PTC
K 3-phase, 230 V/400 V, 50 Hz, (Exe) T3
R 3-phase, 230 V/400 V, 50 Hz, (Exde) T4
P 3-phase, 265 V/460 V, 60 Hz, (Exe) T3
Q 3-phase, 265 V/460 V, 60 Hz, (Exde) T4
R Variable speed stroke control motor, 3-phase, 230/400 V
V Variable speed motor with integrated frequency converter
W Controllable motor with integral ATEX frequency converter
1 no motor, with motor flange 200/90
2 no motor, with motor flange 250/100
3 no motor, with NEMA motor flange
4 no motor, with motor flange 200/90 ATEX
5 no motor, with motor flange 250/100 ATEX
6 no motor, with NEMA ATEX motor flange
M modified
Stroke length adjustment
0 Stroke length adjustment, standard
A Stroke control motor 0...20 mA, 230 V, 50/60 Hz
B Stroke control motor 4...20 mA, 230 V, 50/60 Hz
C Stroke control motor 0...20 mA, 115 V, 60 Hz
D Stroke control motor 4...20 mA, 115 V, 60 Hz
M modified
Temperature (ambient / feed chemical)
0 -20 °C … +40 °C / -20 °C…+90 °C (SS;HC) +50 °C
(PTFE) +65 °C (PVDF)
1 -10 °C … +50 °C / -20 °C…+90 °C (SS;HC) +50 °C
(PTFE) +65 °C (PVDF)
2 -25 °C … +40 °C / -25 °C…+90 °C (SS;HC) +50 °C
(PTFE) +65 °C (PVDF)
M modified
Paintwork
0P C3 - Standard textured paint - RAL 2003
1P C3 - Standard smooth paint - RAL 2003
2P C4 - Outdoor - RAL 2003
3P C5 - Offshore - RAL 2003
M0 modified
Tests
S1 Standard performance test
A1 API test complete
... on request
Functional description
12

1.2.4 Explanation of the ATEX label
Explanation of the pump’s ATEX labelling in accordance with Directive 2014/34/EU and standards EN ISO 80079-36,
-37
Unit group
II No mines or associated underground systems, which can be endangered by firedamp - Unit for use in other areas
at risk from explosion
Other parameters
3G Ex h (Example)
Explosion group
IIC for explosion group IIC gas - refer to your explosion protection document.
IIB for explosion group IIB gas - refer to your explosion protection document.
Temperature class
T3 for temperature class T3 gas - refer to your explosion protection document.
T4 for temperature class T4 gas - refer to your explosion protection document.
Equipment protection level (EPL)
Gb high EPL
use possible in zones 1 and 2 - refer to your explosion protection document.
Gc normal EPL
use possible in zone 2 - refer to your explosion protection document.
Suffix X
X Special conditions - refer to the Declarations of Conformity and EC-type
examination certificates
Functional description
13

2 Safety chapter
2.1 Labelling of Warning Information
These operating instructions provide information on the technical data and
functions of the product. These operating instructions provide detailed
warning information and are provided as clear step-by-step instructions.
The warning information and notes are categorised according to the fol‐
lowing scheme. A number of different symbols are used to denote different
situations. The symbols shown here serve only as examples.
DANGER!
Nature and source of the danger
Consequence: Fatal or very serious injuries.
Measure to be taken to avoid this danger.
Description of hazard
–Denotes an immediate threatening danger. If the sit‐
uation is disregarded, it will result in fatal or very
serious injuries.
WARNING!
Nature and source of the danger
Possible consequence: Fatal or very serious injuries.
Measure to be taken to avoid this danger.
– Denotes a possibly hazardous situation. If the situa‐
tion is disregarded, it could result in fatal or very
serious injuries.
CAUTION!
Nature and source of the danger
Possible consequence: Slight or minor injuries. Material
damage.
Measure to be taken to avoid this danger.
– Denotes a possibly hazardous situation. If the situa‐
tion is disregarded, it could result in slight or minor
injuries. May also be used as a warning about mate‐
rial damage.
NOTICE!
Nature and source of the danger
Damage to the product or its surroundings.
Measure to be taken to avoid this danger.
– Denotes a possibly damaging situation. If the situa‐
tion is disregarded, the product or an object in its
vicinity could be damaged.
Type of information
Hints on use and additional information.
Source of the information. Additional measures.
– Denotes hints on use and other useful information. It
does not indicate a hazardous or damaging situa‐
tion.
Introduction
Safety chapter
14

2.2 User qualification
WARNING!
Danger of injury with inadequately qualified personnel
The operator of the system / equipment is responsible
for ensuring that the qualifications are fulfilled.
If inadequately qualified personnel work on the unit or
loiter in the hazard zone of the unit, this could result in
dangers that could cause serious injuries and material
damage.
– All work on the unit should therefore only be con‐
ducted by qualified personnel.
–Unqualified personnel should be kept away from the
hazard zone.
The pertinent accident prevention regulations, as well as
all other generally acknowledged safety regulations,
must be adhered to.
Training Definition
Instructed personnel An instructed person is deemed to be a person who has been instructed and, if
required, trained in the tasks assigned to him and possible dangers that could result
from improper behaviour, as well as having been instructed in the required protective
equipment and protective measures.
Trained user A trained user is a person who fulfils the requirements made of an instructed person
and who has also received additional training specific to the system from the manufac‐
turer or another authorised distribution partner.
Trained, qualified personnel A trained, qualified employee is deemed to be a person who is able to assess the tasks
assigned to him and recognize possible hazards based on his training, knowledge and
experience, as well as knowledge of pertinent regulations. A trained, qualified
employee must be able to perform the tasks assigned to him independently with the
assistance of drawing documentation and parts lists. The assessment of a person's
technical training can also be based on several years of work in the relevant field.
Electrical technician An electrical technician is able to complete work on electrical systems and recognise
and avoid possible dangers independently based on his technical training and experi‐
ence as well as knowledge of pertinent standards and regulations. An electrical techni‐
cian must be able to perform the tasks assigned to him independently with the assis‐
tance of drawing documentation, parts lists, terminal and circuit diagrams. The
electrical technician must be specifically trained for the working environment in which
the electrical technician is employed and be conversant with the relevant standards
and regulations.
Service The Service department refers to service technicians, who have received proven
training and have been authorised by the manufacturer to work on the system.
Safety chapter
15

2.3 Warning symbols denoting different types of danger
The following warning symbols are used in these operating instructions to
denote different types of danger:
Warning symbol Type of danger
Warning of a dangerous area.
Warning of hazardous electrical voltage.
Warning of hot surfaces.
2.4 Intended use
nOnly use the pump to meter liquid, sediment-free feed chemicals.
nOnly start up the pump once it has been correctly installed and started
up in accordance with the technical data and specifications contained
in the operating instructions.
nObserve the general limitations with regard to viscosity limits, chem‐
ical resistance and density - see also the ProMinent Resistance List
(in the Product Catalogue or at www.prominent.com)!
nOnly suitable pumps can be used in areas at risk of explosion.
nThe pump is not intended for operation in private areas.
nOnly allow appropriate personnel to operate the pump, see
Ä Chapter
2.2 ‘User qualification’ on page 15 .
nYou have a responsibility to observe the information contained in the
operating instructions for the auxiliary equipment at the different
phases of its respective service life.
2.5 Misuse
nThe pump is not intended for the metering of gaseous media and
solids.
nThe pump is not intended for the metering of explosive substances
and explosive mixtures.
nThe pump is not intended for unprotected use outdoors.
Warning symbols denoting different types
of danger
Safety chapter
16

2.6 Safety information
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious injuries.
Please ensure when handling hazardous substances
that you have read the latest safety data sheets provided
by the manufacture of the hazardous substance. The
actions required are described in the safety data sheet.
Check the safety data sheet regularly and replace, if
necessary, as the hazard potential of a substance can
be re-evaluated at any time based on new findings.
The system operator is responsible for ensuring that
these safety data sheets are available and that they are
kept up to date, as well as for producing an associated
hazard assessment for the workstations affected.
WARNING!
Ignition hazard by exothermic reaction
Certain oils from the intermediate diaphragm chamber
can react exothermically and become hot with certain
feed chemicals.
– Assess the required feed chemical in terms of this
risk.
(Project-specific oil replacement is possible.)
CAUTION!
Refer to the documentation for the bought-in parts.
CAUTION!
Warning of feed chemical spraying around
Feed chemical may spray out of the hydraulic compo‐
nents if they are tampered with or opened due to pres‐
sure in the liquid end and adjacent parts of the system.
– Disconnect the pump from the mains power supply
and ensure that it cannot be switched on again by
unauthorised persons.
–Ensure that the system is at atmospheric pressure
before commencing any work on hydraulic parts of
the system.
CAUTION!
Warning of feed chemical spraying around
An unsuitable feed chemical can damage the parts of
the pump that come into contact with the chemical.
– Take into account the resistance of the wetted mate‐
rials and the ProMinent Resistance List when
selecting the feed chemical - see the ProMinent
Product Catalogue or visit ProMinent.
Safety information
Safety chapter
17

WARNING!
Adjusted pressure switches fail
– The switching point of the 42 V pressure switch
must not be changed.
–The ATEX pressure switch must not be reprog‐
rammed.
It could result in overheating of the pump.
WARNING!
The inside of the dosing head needs to be constantly
filled with medium in normal mode, and the start-up and
run-down processes have to be designed in such a way
by the operator so that no explosive mixture is produced
inside the dosing head.
In the event of an electrical accident, disconnect the mains cable from the
mains or press the emergency cut-off switch fitted on the side of the
system!
If feed chemical escapes, also depressurise the hydraulic system around
the pump as necessary. Adhere to the safety data sheet for the feed
chemical.
Basic assumption for assessment of the ignition hazards:
With regard to the ignition hazard assessment, it is assumed that the
inside of the dosing head is constantly filled with medium in normal mode
and also that the start-up and run-down processes are designed in such a
way by the operator that no explosive mixture is produced inside the
dosing head.
Ignition hazard Protective measures to be observed by the customer
Hot surfaces Limitation of the maximum feed chemical temperature to
90 °C
Exothermic reaction, including the self-combustion of dust Feed chemicals, which react exothermically with the oil
from the diaphragm intermediate chamber, have to be
considered in terms of the risk.
Dust deposits and other material Regularly and carefully clean the outside of the pump.
Additional considerations
Damage to the diaphragm with hazardous media
The customer must wire the diaphragm rupture indicator
so that it reliably stops the pump as quickly as possible.
Electrical bought-in parts (motor, actuator and/or control
drive, proximity switch, ...)
Electrical connection by technical personnel.
Refer to the documentation for the bought-in part.
Non-electrical bought-in parts (coupling, ...) Refer to the documentation for the bought-in part.
2.7 Emissions
The sound pressure level is listed in the "Technical data".
Information in the event of an emergency
Summary of relevant ignition hazards and
protective measures put in place for the
Hydro HA4a / in accordance with EN ISO
80079-36
Safety chapter
18

3 Storage, transport and unpacking
User qualification: trained person / qualified personnel
Ä Chapter 2.2 ‘User qualification’ on page 15
WARNING!
Only return the metering pump for repair in a cleaned
state and with a flushed liquid end - refer to the chapter
"Decommissioning"!
Only return metering pumps with a completed Decon‐
tamination Declaration form. The Decontamination Dec‐
laration constitutes an integral part of an inspection /
repair order. A unit can only be inspected or repaired
when a Declaration of Decontamination Form is sub‐
mitted that has been completed correctly and in full by
an authorised and qualified person on behalf of the
pump operator.
The "Decontamination Declaration Form" can be found
at www.prominent.com.
CAUTION!
Use lifting points with suitable lifting means.
Secure the pump to prevent it from falling.
CAUTION!
Danger of environmental and material damage
Oil can escape by improper storage or transportation.
Only transport the unit with the sealing screw , and not
the vent screw, fitted to the oil filler neck.
1. Fit the caps to the valves.
2. Check whether the sealing screw is fitted to the oil filler neck.
3. Position the pump vertically on a pallet and secure it from toppling
over.
4. Cover the pump with a tarpaulin, allowing for rear ventilation.
5. Store the pump in a dry and closed room.
3.1 Ambient conditions
Tab. 1: Pump, complete
Specification Value
Storage and transport temperatures: -25 ... +60 °C
Storage
Storage, transport and unpacking
19

Specification Value
Maximum air humidity*: 95 % relative humidity
*non-condensing (according to DIN IEC 60068-2-30)
Storage, transport and unpacking
20
