O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
1
OPERATING MANUAL
888-742-3404 www.promolife.com/support
FOR O3ELITE SINGLE, MINI AND DUAL MODELS
For video tutorials please visit:
www.promolife.com/videos

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
2
Table of Contents
Quick start guide......................................................................................................3
Things to know about ozone ..................................................................................3
About the O3Elite.....................................................................................................3
The Ozone Cell .........................................................................................................4
Ozone Check Valve ..................................................................................................4
Wall Mounts..............................................................................................................4
Operating conditions...............................................................................................5
Operating environment ..........................................................................................5
Safety.........................................................................................................................5
Power requirements................................................................................................5
Attaching the tubing ................................................................................................6
How to operate ........................................................................................................6
Settings......................................................................................................................7
Turning on the oxygen source ...............................................................................7
How to turn on the O3Elite.....................................................................................9
The proper way to turn off the ozone generator.................................................9
Warranty ...................................................................................................................9
Disclaimers ...............................................................................................................9
O3Elite Single Output Chart................................................................................. 10
O3Elite Dual Output Chart................................................................................... 11
O3Elite Mini Output Chart ................................................................................... 12
Notes ...................................................................................................................... 12
CE Certifi cate of Conformity ................................................................................ 12
Ozone Defi nitions
1 Gamma = 1ug (microgram)/ml = 1g/L = 1g/m3
1LPM=1000 cc/min = 1000 ml/min
Total volume in ml = fl ow (cc/min) x time (min)
Total Ozone = Total Volume (ml) x Ozone Concentration (ug/ml)
Contact Us
If you have any questions, contact Promolife at:
888-742-3404 or 479-442-3404 | [email protected]
or visit www.promolife.com/support other options.
For video tutorials please visit:
www.promolife.com/videos

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
3
Quick start guide for operation
• Turn on oxygen source fi rst (30 seconds for tanks, fi ve minutes for concentrators)
• Turn on ozone generator to desired setting
• When done, turn off the ozone generator
• Wait 30 seconds and turn off the oxygen source
Things to know about ozone
• Heat degrades the strength of ozone
• Humidity degrades the strength of ozone
Both factors affect ozone output. You should use your ozone generator at room temperature
and not put it in direct sunlight. Always use clean oxygen, either from an O2 concentrator or
an O2 tank while using the ozone generator. Never use ambient air, as dust and humidity
may enter the ozone generator and compromise the unit. Ambient air use will void the
warranty.
Ozone strength will always be greater when using a high-quality oxygen source, as ozone
output directly relates to the concentration of oxygen entering the ozone generator.
An oxygen concentrator uses a compressor to separate and purify the oxygen and operates
at 90% - 95% pure oxygen. An oxygen tank uses oxygen that was created by cooling
oxygen to a liquid and separating out all the impurities, resulting in 99% pure oxygen.
Another factor in ozone output is oxygen fl ow speed. The slower the oxygen fl ow, the
stronger the ozone output. This is because ozone generators rely on contact time with
oxygen. The longer the oxygen can stay in contact with the ozone generator, the stronger
the ozone output will be.
About the O3Elite Ozone Generator Series
The O3Elite is a dual or single cell ozone generator designed for performance and effi ciency.
All models are made in the United States, including the ceramic stainless ozone cells. It
comes in a thick aluminum case with 316 grade stainless steel Luer lock fi ttings. These
allow the user to securely connect tubing to the ozone generator, eliminating any chance of
the tubing becoming loose or falling off.

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
4
Wall mount holes have been added to the Dual and Single to allow the user to place the
ozonator on a fl at surface or attach it to the wall.
The Ozone Cell
The O3Elite utilizes pulse modulated ceramic stainless cells, which produce stable ozone
concentration levels and virtually no heat. This results in a stronger, more effi cient ozone
production with maximum output and minimum high voltage input. No cooling fan is required
which keeps the ozone generator cleaner and increases the life of the machine. The cells
produce very little noise which is a result of effi cient ozone production. The lower the noise,
the more effi cient the ozone generation.
Wall mounts
The O3Elite Mini is designed to sit on a table. The O3Elite Dual and Single come standard
with wall mount holes located on the bottom of the ozone generator, and can therefore be
used on a table or hanging from the wall. All dials and tube connections are located in easy
to see and accessible locations. Mounting screws are not provided.
Operating conditions
The generator is designed to run with a pure oxygen source. This eliminates any
contaminates from being produced that may enter or harm the ozone generator. Do not
exceed 50 psi when using an oxygen tank. Using psi greater than 50 will result in a voided
warranty.
Operating Environment
It is important to set up equipment in an area that is free of airborne moisture and particles.
Set up in an area that is free of airborne moisture and particles. Dust particles and
condensation pose a challenge to the consistent operation of all ozone generators. Make
sure the ozone generator stays clean and dry.
Safety
Please read the following safety guidelines thoroughly before attempting to operate or
install your equipment.
• As with all electric devices, this equipment should never come in contact with water.

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
5
• The equipment must be operated using a properly grounded electrical circuit that is
protected by either a fuse or circuit breaker.
• Promolife, Inc. assumes no liability for damages or injuries incurred by misuse of
this product.
• Use a power conditioner if line voltage fl uctuates outside of specifi ed range.
Power requirements
The O3Elite offers a standard AC to DC wall transformer which can be used with voltages
ranging from 100 to 240 volts. This gives the O3Elite the ability to be used internationally
without a step-down transformer; however, please note that a plug adapter will likely be
necessary for international use (included with international orders).
• Voltage 12 VDC
• Power: Mini and Single [800ma]; Dual [800ma with one cell or 1600ma with both]
Attaching the tubing to the O3Elite
The ozone generator has female Luer Lock
connectors while the tubing has male Luer Lock
connectors. These connectors are designed to
work together. Attach the male Luer lock with
tubing attached directly to the female Luer lock
and turn clockwise. This will lock the tubing in place for quick, easy use. To disconnect the
tubing turn the male Luer lock counter clockwise.
Ozone check valve
Promolife provides an ozone check valve with each ozone generator. The ozone check
valve should always be used when water is being used, as it can help prevent backfl ow
issues. Using the ozone generator with water or oil and without the ozone check valve will
void the warranty. On new units the check valve comes already attached to your silicone
tubing.
Note: We recommend replacing check valves every six months. If the check valve comes
in contact with oil, replace it immediately.
MALE

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
6
To install a new check valve, blow into the check valve to
determine which side the air comes out. That side should
be attached to the ozone tubing that connects to your ozone
accessories. The side where air does not come out should
be attached to the ozone tubing that is connected to your
ozone generator.
How to Operate
Before turning on the ozone generator make sure all the tubing is connected. The O3Elite
Dual has two ozone cells which are controlled individually with each dial. The dial on the left
hand side operates cell one; the dial on the right hand side operates cell two. Each dial has
fi ve different settings which allow you to customize your ozone output. The O3Elite Single
has one dial with eight different settings to customize the output. Many ozone outputs are
available by combining the dial setting with your oxygen setting. The Mini has no dial; the
output is controlled by oxygen output.
On the top of each Dual and Single there are two markings: Oxygen In & Ozone Out. The
Mini has an Oxygen In on the back and an Ozone Out on the front. This is where you will
connect your tubing.
Connect the clear plastic tubing to your oxygen source. Attach the other end with the luer
lock to the Oxygen In connection of the ozone generator. Next attach the opaque/hazy
silicone tubing with the luer lock to the Ozone Out connection of the ozone generator.
O3ELITE DUAL O3ELITE SINGLE

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
7
The other end of the ozone tubing can now be connected to your chosen application.
Turning on your oxygen source
It is important to turn your oxygen source on before the ozone generator.
For tanks, turn on the fl ow for at least 30 seconds.
For an oxygen concentrator, run the concentrator for fi ve minutes before turning on your
ozone generator, as it can take several minutes for the concentrator to reach its maximum
purity level. Turning on the ozone generator before high purity oxygen is fl owing can lead to
nitrous oxides in your ozone. DO NOT use the humidifi er that came with your concentrator.
Hook your tubing directly to the concentrator’s output fi tting.
See the diagram on the next page for more.
How to turn on the O3Elite
Now you are ready to turn on the ozone generator. The dial(s) on the generator should be
in the off position.
On the Dual model there are fi ve settings on each dial, with one being the lowest and fi ve
being the highest.
With 870 Tank and Syringe With 540 Tank and Cup With 540 Tank and Bag
O3Elite Mini Examples

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
8
Oxygen Source Options
If using an oxygen
concentrator, attach your
clear tubing to the output
fi tting on the unit. If using
a fl owmeter, see the
instructions included with the
fl owmeter. If using a tank,
attach clear tubing to the
output fi tting on the low fl ow
regulator.
Attach the end
of your tubing
with the Luer lock
adapters to the
appropriate
connection on the
O3Elite.
Ozone Application
Sauna, Bag, Humidifi er, Water Bubbler, Oil Bubbler, Ozone Destruct System, etc.
Example attachment between
O3Elite Dual and Ozone
Humidifi er

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
9
On the Single model there are eight settings on the dial with one being lowest and eight
being the highest. When a cell is turned on the appropriate light will also turn on.
The O3Elite Mini has a single power button that lights up when on.
To adjust your settings to produce the ozone output you want, see the relevant ozone output
chart on the following pages.
The proper way to turn off your ozone generator
After you are done using the O3Elite, turn the ozone generator off fi rst. Wait at least 30
seconds and then turn off your oxygen source. This will allow the ozone cells and tubing to
fl ush out, increasing the life span of all of the parts. Unhook all tubing when not in use.
Warranty
Promolife offeres a lifetime warranty on the O3Elite ozone generator to be free from
defects in parts and workmanship under conditions of normal use. Warranty is void if the
unit has been tampered with, the cover is removed, water or any other liquid material or
dirt or extensive dust is found in the unit. Promolife, Inc. will perform repairs or replace
equipment, at their discretion. The warranty shall be null, void, and non binding upon
Promolife if Promolife determines the cause of malfunction to be misuse. Promolife is not
liable to the purchaser or other users for loss of use of the generator or for other special,
indirect, incidental or consequential damages. Promolife is not liable for any special,
indirect, incidental or consequential damages that result from the misuse or malfunction of
the ozone generator and/or any of its components.
Free Calibration Service
If for any reason you feel as if your ozone generator is not operating properly, please contact
Promolife to fi nd out about our free calibration warranty.
Disclaimer: This unit is for recreational and experimental use only.

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
10
O2
LPM 12345678
1245678910
3/4 3 5 7 9 11 13 15 17
1/2 4 7 9 11 14 16 17 19
1/4 9 14 18 22 25 29 31 33
1/8 18 29 33 41 44 46 50 52
1/16 30 37 42 48 54 56 58 63
1/32 36 42 44 51 57 62 66 70
Ozone Generator Dial Setting
How to use this chart: Determine how many gammas of ozone you want to produce. Find that number in the chart. Set your oxygen to the LPM setting on the left and your O3Elite dial to the setting above. Example: To produce18 gamma, you can use 1/4 LPM of oxygen and turn your ozone dial to 3. To produce 50 gamma, you could use 1/8 LPM of oxygen and turn your ozone dial to 7. Note: Gamma = ug/ml
O3Elite Single Output Chart

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
11
O3Elite Dual Output Chart
O2
LPM 1 2 3 4 5 5,1 5,2 5,3 5,4 5,5
11 3 5 7 8 11 13 15 17 18
3/4 2 4 7 9 10 14 16 18 20 21
1/2 4 8 11 13 15 19 22 26 30 33
1/4 7 13 18 23 26 32 37 42 47 53
1/8 12 24 33 40 45 51 60 68 70 75
1/16 21 40 49 55 59 73 81 85 90 95
1/32 30 52 65 71 78 88 95 101 106 110
Dial One Only Both Dials
How to use this chart: Determine how many gammas of ozone you want to produce. Find that number in the chart. Set your oxygen to the LPM setting on the left and your O3Elite dial to the setting above. Example: To produce 26 gamma, you can use 1/4 LPM of oxygen and turn dial 1 to 5. To produce 70 gamma, you could use 1/8 LPM of oxygen and turn dial 1 to 5 and dial 2 to 4. Note: Gamma = ug/ml

O3Elite Operating Manual
Promolife, Inc. 888-742-3404 www.promolife.com
12
Notes
Serial # __________________________________________________________
Date Purchased ______________________________________________
O3Elite Mini Output Chart
OXYGEN
FLOW RATE
OZONE
OUTPUT
1 LPM 7
3/4 LPM 9
1/2 LPM 13
1/4 LPM 25
1/8 LPM 38
1/16 LPM 52
1/32 LPM 65
Low
Medium
High
To use, determine the
amount of ozone you
want to produce under
Ozone Output. Set your
oxygen source to the
LPM setting specifi ed
under Oxygen Flow.
Once oxygen is running
at the specifi ed LPM,
turn on the O3Elite Mini
to achieve your desired
output.
Certifi cate and Declaration of Conformity
Promolife, Inc. 1220 S Happy Hollow Rd, Fayetteville, AR 72701. 1-479-442-3404. [email protected]
Promolife, Inc declares under their sole responsibility that their O3Elite Mini, O3Elite Single, and O3Elite Dual
comply with the Essential Requirements of the following EU Directives: Low Voltage Directive 2014/35/EU,
EMC Directive 2014/30/EU, and RoHS 2 Directive 2011/65/EU, and further conform with the following EU
Harmonized Standards: EN 60335-1:2012+A13:2017, EN 1278:2010, EN 61000-6-3:2007+A1:2011, and EN
61000-6-1:2007.
Dated: 19 April 2022
Position of Signatory: Operations Manager Name of Signatory: Tobias Segal Signed below on behalf of Promolife Inc.
Ozone Packages Manual
If you have a complete ozone package, you can download our manual using the
QR code at right, or visit www.promolife.com/promolife-guides/
