Prorack K450 User manual

K450
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 1 x 8 x 8 x 4
x 4 x 4 x 1 x 4
Revision No: 12L 1

Fitting Kit K450
MAX kgs (lbs)
W/P WHD
Toyota
4 Runner, 5dr SUV 96-02 US 75 kgs (165 lbs) 75 kgs (165 lbs)
4 Runner, 5dr SUV 96-03 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
4 Runner, 5dr SUV 96-03 CN 75 kgs (165 lbs) 75 kgs (165 lbs)
Suzuki
APV, 5dr MPV 07-+ NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
APV, 5dr MPV 07-+ AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Volkswagen
Caravelle T5, 5dr MPV 03-Dec 15 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
Caravelle T5, 5dr MPV 03-Dec 15 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 03-Dec 15 ZA 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 03-Dec 15 ZA 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 03-Dec 15 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 03-Dec 15 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 04-Dec 15 AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 04-Dec 15 AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 04-Dec 15 NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T5, 5dr MPV 04-Dec 15 NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T6 LWB, 5dr MPV 15-+ EU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T6 LWB, 5dr MPV 15-+ ZA 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T6 LWB, 5dr MPV Dec 15-+ AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Multivan T6 LWB, 5dr MPV Dec 15-+ NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
Touareg, 5dr SUV 02-09 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
Touareg, 5dr SUV 03-+ AU 75 kgs (165 lbs) 75 kgs (165 lbs)
Touareg, 5dr SUV 03-+ NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
Touareg, 5dr SUV 03-07 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Touareg, 5dr SUV 03-09 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
Porsche
Cayenne, 5dr SUV 02-10 NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
Cayenne, 5dr SUV 02-10 AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Cayenne, 5dr SUV 02-10 US 75 kgs (165 lbs) 100 kgs (220 lbs)
Cayenne, 5dr SUV 02-10 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
Cayenne, 5dr SUV 02-10 ZA 75 kgs (165 lbs) 100 kgs (220 lbs)
Land Rover
Discovery 3, 5dr SUV Nov 04-09 NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
Discovery 3, 5dr SUV Nov 04-09 AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Discovery 4, 5dr SUV 09-Mar 17 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
2

Fitting Kit K450
Discovery 4, 5dr SUV 09-Mar 17 ZA 75 kgs (165 lbs) 100 kgs (220 lbs)
Discovery 4, 5dr SUV 09-Mar 17 NZ 75 kgs (165 lbs) 100 kgs (220 lbs)
Discovery 4, 5dr SUV 09-Mar 17 AU 75 kgs (165 lbs) 100 kgs (220 lbs)
Discovery 4, 5dr SUV 10-16 CN 75 kgs (165 lbs) 100 kgs (220 lbs)
Discovery, 5dr SUV 04-09 EU 75 kgs (165 lbs) 100 kgs (220 lbs)
LR3, 5dr SUV 04-09 US 75 kgs (165 lbs) 100 kgs (220 lbs)
LR4, 5dr SUV 09-+ US 75 kgs (165 lbs) 100 kgs (220 lbs)
GMC
Envoy, 5dr SUV 02-09 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Ford
Escape, 5dr SUV 01-07 EU 44 kgs (97 lbs) 44 kgs (97 lbs)
Escape, 5dr SUV Feb 01-08 AU 44 kgs (97 lbs) 44 kgs (97 lbs)
Escape, 5dr SUV Mar 01-08 NZ 44 kgs (97 lbs) 44 kgs (97 lbs)
Expedition, 5dr SUV 03-06 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Expedition, 5dr SUV 97-02 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Explorer, 3dr SUV 95-00 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Explorer, 5dr SUV 95-00 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Explorer, 5dr SUV 95-01 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
Explorer, 5dr SUV 95-01 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
Explorer, 5dr SUV 95-01 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
Explorer, 5dr SUV 95-01 CN 75 kgs (165 lbs) 75 kgs (165 lbs)
Maverick, 5dr SUV 01-07 EU 44 kgs (97 lbs) 44 kgs (97 lbs)
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ NZ 25 kgs (55 lbs) 25 kgs (55 lbs)
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ AU 25 kgs (55 lbs) 25 kgs (55 lbs)
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ ZA 25 kgs (55 lbs) 25 kgs (55 lbs)
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ EU 25 kgs (55 lbs) 25 kgs (55 lbs)
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ CN 25 kgs (55 lbs) 25 kgs (55 lbs)
LDV
G10, 4dr Van 15-+ AU 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 4dr Van 15-+ CN 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 4dr Van 15-+ EU 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 4dr Van 15-+ NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 5dr MPV 15-+ AU 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 5dr MPV 15-+ CN 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 5dr MPV 15-+ EU 75 kgs (165 lbs) 75 kgs (165 lbs)
G10, 5dr MPV 15-+ NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
Daihatsu
Terios, 5dr SUV 97-05 EU 75 kgs (165 lbs) 90 kgs (198 lbs)
Terios, 5dr SUV 98-03 ZA 75 kgs (165 lbs) 90 kgs (198 lbs)
Terios, 5dr SUV Jul 97-Mar 03 AU 75 kgs (165 lbs) 90 kgs (198 lbs)
Nissan
Terrano II, 5dr SUV 96-04 EU 75 kgs (165 lbs) 80 kgs (176 lbs)
Terrano Regulus, 5dr SUV 96-03 NZ 75 kgs (165 lbs) 80 kgs (176 lbs)
Terrano Regulus, 5dr SUV 96-03 AU 75 kgs (165 lbs) 80 kgs (176 lbs)
Chrysler
Town and Country, 5dr MPV 01-07 US 75 kgs (165 lbs) 75 kgs (165 lbs)
Chevrolet
Trailblazer, 5dr SUV 02-09 US 75 kgs (165 lbs) 75 kgs (165 lbs)
3

Fitting Kit K450
Great Wall
X200, 5dr SUV Nov 09-+ NZ 50 kgs (110 lbs) 50 kgs (110 lbs)
X200, 5dr SUV Oct 09-+ AU 50 kgs (110 lbs) 50 kgs (110 lbs)
X240, 5dr SUV Nov 09-+ NZ 50 kgs (110 lbs) 50 kgs (110 lbs)
X240, 5dr SUV Oct 09-+ AU 50 kgs (110 lbs) 50 kgs (110 lbs)
4

Fitting Kit K450
X
A B C 1 2 3
4 Runner, 5dr SUV 96-02 (US) 200mm 900mm - 735mm 735mm -
7 7/8ths" 35 7/16ths" - 28 15/16ths" 28 15/16ths" -
4 Runner, 5dr SUV 96-03 (EU) 200mm 900mm - 735mm 735mm -
7 7/8ths" 35 7/16ths" - 28 15/16ths" 28 15/16ths" -
4 Runner, 5dr SUV 96-03 (CN) 200mm 900mm - 735mm 735mm -
7 7/8ths" 35 7/16ths" - 28 15/16ths" 28 15/16ths" -
APV, 5dr MPV 07-+ (NZ) 200mm 500mm - 650mm 650mm -
7 7/8ths" 19 11/16ths" - 25 9/16ths" 25 9/16ths" -
APV, 5dr MPV 07-+ (AU) 200mm 500mm - 650mm 650mm -
7 7/8ths" 19 11/16ths" - 25 9/16ths" 25 9/16ths" -
Caravelle T5, 5dr MPV 03-Dec 15 (EU) 300mm 1000mm - 1082mm 1082mm -
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" -
Caravelle T5, 5dr MPV 03-Dec 15 (EU) 300mm 1000mm - 1082mm 1082mm 1082mm
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" 42 5/8ths"
Cayenne, 5dr SUV 02-10 (NZ) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Cayenne, 5dr SUV 02-10 (AU) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Cayenne, 5dr SUV 02-10 (US) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Cayenne, 5dr SUV 02-10 (EU) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Cayenne, 5dr SUV 02-10 (ZA) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Discovery 3, 5dr SUV Nov 04-09 (NZ) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Discovery 3, 5dr SUV Nov 04-09 (AU) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Discovery 4, 5dr SUV 09-Mar 17 (EU) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
5

Fitting Kit K450
Discovery 4, 5dr SUV 09-Mar 17 (ZA) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Discovery 4, 5dr SUV 09-Mar 17 (NZ) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Discovery 4, 5dr SUV 09-Mar 17 (AU) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Discovery 4, 5dr SUV 10-16 (CN) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Discovery, 5dr SUV 04-09 (EU) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Envoy, 5dr SUV 02-09 (US) 100mm 1660mm - 814mm 814mm -
3 15/16ths" 65 3/8ths" - 32 1/16ths" 32 1/16ths" -
Escape, 5dr SUV 01-07 (EU) - - - 772mm 772mm -
- - - 30 3/8ths" 30 3/8ths" -
Escape, 5dr SUV Feb 01-08 (AU) - - - 772mm 772mm -
- - - 30 3/8ths" 30 3/8ths" -
Escape, 5dr SUV Mar 01-08 (NZ) - - - 772mm 772mm -
- - - 30 3/8ths" 30 3/8ths" -
Expedition, 5dr SUV 03-06 (US) - - - 845mm 845mm -
- - - 33 1/4ths" 33 1/4ths" -
Expedition, 5dr SUV 97-02 (US) 40mm 1720mm - 853mm 853mm -
1 9/16ths" 67 3/4ths" - 33 9/16ths" 33 9/16ths" -
Explorer, 3dr SUV 95-00 (US) 150mm 1260mm - 798mm 798mm -
5 15/16ths" 49 5/8ths" - 31 7/16ths" 31 7/16ths" -
Explorer, 5dr SUV 95-00 (US) 120mm 1540mm - 798mm 798mm -
4 3/4ths" 60 5/8ths" - 31 7/16ths" 31 7/16ths" -
Explorer, 5dr SUV 95-01 (NZ) 120mm 1540mm - 798mm 798mm -
4 3/4ths" 60 5/8ths" - 31 7/16ths" 31 7/16ths" -
Explorer, 5dr SUV 95-01 (AU) 120mm 1540mm - 798mm 798mm -
4 3/4ths" 60 5/8ths" - 31 7/16ths" 31 7/16ths" -
Explorer, 5dr SUV 95-01 (EU) 120mm 1540mm - 798mm 798mm -
4 3/4ths" 60 5/8ths" - 31 7/16ths" 31 7/16ths" -
Explorer, 5dr SUV 95-01 (CN) 120mm 1540mm - 798mm 798mm -
4 3/4ths" 60 5/8ths" - 31 7/16ths" 31 7/16ths" -
G10, 4dr Van 15-+ (AU) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 4dr Van 15-+ (CN) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 4dr Van 15-+ (EU) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 4dr Van 15-+ (NZ) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 5dr MPV 15-+ (AU) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 5dr MPV 15-+ (CN) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 5dr MPV 15-+ (EU) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
G10, 5dr MPV 15-+ (NZ) 170mm 970mm - 1022mm 1010mm -
6 11/16ths" 38 3/16ths" - 40 1/4ths" 39 3/4ths" -
LR3, 5dr SUV 04-09 (US) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
LR4, 5dr SUV 09-+ (US) 220mm 1640mm - 935mm 875mm -
8 11/16ths" 64 9/16ths" - 36 13/16ths" 34 7/16ths" -
Maverick, 5dr SUV 01-07 (EU) - - - 772mm 772mm -
- - - 30 3/8ths" 30 3/8ths" -
Multivan T5, 5dr MPV 03-Dec 15 (ZA) 300mm 1000mm - 1082mm 1082mm -
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" -
Multivan T5, 5dr MPV 03-Dec 15 (ZA) 300mm 1000mm - 1082mm 1082mm 1082mm
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" 42 5/8ths"
Multivan T5, 5dr MPV 03-Dec 15 (EU) 300mm 1000mm - 1082mm 1082mm -
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" -
Multivan T5, 5dr MPV 03-Dec 15 (EU) 300mm 1000mm - 1082mm 1082mm 1082mm
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" 42 5/8ths"
Multivan T5, 5dr MPV 04-Dec 15 (AU) 300mm 1000mm - 1082mm 1082mm -
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" -
Multivan T5, 5dr MPV 04-Dec 15 (AU) 300mm 1000mm - 1082mm 1082mm 1082mm
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" 42 5/8ths"
Multivan T5, 5dr MPV 04-Dec 15 (NZ) 300mm 1000mm - 1082mm 1082mm -
6

Fitting Kit K450
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" -
Multivan T5, 5dr MPV 04-Dec 15 (NZ) 300mm 1000mm - 1082mm 1082mm 1082mm
11 13/16ths" 39 3/8ths" - 42 5/8ths" 42 5/8ths" 42 5/8ths"
Multivan T6 LWB, 5dr MPV 15-+ (EU) 300mm 1050mm - 1080mm 1080mm -
11 13/16ths" 41 5/16ths" - 42 1/2ths" 42 1/2ths" -
Multivan T6 LWB, 5dr MPV 15-+ (ZA) 300mm 1050mm - 1080mm 1080mm -
11 13/16ths" 41 5/16ths" - 42 1/2ths" 42 1/2ths" -
Multivan T6 LWB, 5dr MPV Dec 15-+ (AU) 300mm 1050mm - 1080mm 1080mm -
11 13/16ths" 41 5/16ths" - 42 1/2ths" 42 1/2ths" -
Multivan T6 LWB, 5dr MPV Dec 15-+ (NZ) 300mm 1050mm - 1080mm 1080mm -
11 13/16ths" 41 5/16ths" - 42 1/2ths" 42 1/2ths" -
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ (NZ) - - - 1140mm 1140mm -
- - - 44 7/8ths" 44 7/8ths" -
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ (AU) - - - 1140mm 1140mm -
- - - 44 7/8ths" 44 7/8ths" -
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ (ZA) - - - 1140mm 1140mm -
- - - 44 7/8ths" 44 7/8ths" -
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ (EU) - - - 1140mm 1140mm -
- - - 44 7/8ths" 44 7/8ths" -
Ranger Wildtrak (Rear Cargo), 4dr Ute 12-+ (CN) - - - 1140mm 1140mm -
- - - 44 7/8ths" 44 7/8ths" -
Terios, 5dr SUV 97-05 (EU) - - - - - -
- - - - - -
Terios, 5dr SUV 98-03 (ZA) - - - - - -
- - - - - -
Terios, 5dr SUV Jul 97-Mar 03 (AU) - - - - - -
- - - - - -
Terrano II, 5dr SUV 96-04 (EU) - - - 784mm 784mm -
- - - 30 7/8ths" 30 7/8ths" -
Terrano Regulus, 5dr SUV 96-03 (NZ) - - - 784mm 784mm -
- - - 30 7/8ths" 30 7/8ths" -
Terrano Regulus, 5dr SUV 96-03 (AU) - - - 784mm 784mm -
- - - 30 7/8ths" 30 7/8ths" -
Touareg, 5dr SUV 02-09 (EU) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Touareg, 5dr SUV 03-+ (AU) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Touareg, 5dr SUV 03-+ (NZ) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Touareg, 5dr SUV 03-07 (US) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Touareg, 5dr SUV 03-09 (ZA) - - - 770mm 770mm -
- - - 30 5/16ths" 30 5/16ths" -
Town and Country, 5dr MPV 01-07 (US) - - - 866mm 866mm -
- - - 34 1/16ths" 34 1/16ths" -
Trailblazer, 5dr SUV 02-09 (US) - 1320mm - 868mm 868mm -
- 52" - 34 3/16ths" 34 3/16ths" -
X200, 5dr SUV Nov 09-+ (NZ) 200mm 1000mm - 825mm 780mm -
7 7/8ths" 39 3/8ths" - 32 1/2ths" 30 11/16ths" -
X200, 5dr SUV Oct 09-+ (AU) 200mm 1000mm - 825mm 780mm -
7 7/8ths" 39 3/8ths" - 32 1/2ths" 30 11/16ths" -
X240, 5dr SUV Nov 09-+ (NZ) 200mm 1000mm - 825mm 780mm -
7 7/8ths" 39 3/8ths" - 32 1/2ths" 30 11/16ths" -
X240, 5dr SUV Oct 09-+ (AU) 200mm 1000mm - 825mm 780mm -
7 7/8ths" 39 3/8ths" - 32 1/2ths" 30 11/16ths" -
7

Fitting Kit EN
K450
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
●Use keys to remove covers.
8

Fitting Kit EN
K450
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
●Remove plastic clamp block by gripping bar
leg with fingers and push firmly with
thumbs until clamp block drops out behind
leg.
9

Fitting Kit EN
K450
●Remove both pins from each leg. Use
tapered end of spanner located inside left
hand cover to assist.
●Detach foot from leg. Store loose parts in a
safe place.
●Repeat for all legs.
●Assemble foot from kit into leg.
10

Fitting Kit EN
K450
●Insert pins through foot into leg.
●Select plastic internal block (from fitting kit)
and insert into foot.
●Repeat for all legs.
●Remove fixed-point cover.
●FITMENT TO FORD RANGER WILDTRAK
ONLY
11

Fitting Kit EN
K450
●Place T-bolt into track by either inserting it
from the top or sliding in from the end.
●Rotate bolt clockwise so it engages in
place in the centre of track.
●Use 4 T-bolts per track
●Repeat for both tracks.
12

Fitting Kit EN
K450
●Place track pad over T-bolt
●Thread the nut over the T-bolt by hand.
●Repeat for all four positions.
●Use the 3mm (1/8") Hex Key to hold the T-
bolt in a stationary position and ensure the
T-bolt has correct engagement.
●Using the 10mm (3/8") spanner supplied,
tighten the nut to 5Nm (3.7 ft lb).
13

Fitting Kit EN
K450
●Place crossbars over mounting assembly
on tracks.
●Tighten the plastic knob.
●Ensure the plastic knob is in the position
shown when fully tightened.
●Repeat for all four positions.
14

Fitting Kit EN
K450
●Tighten adjusting screw to 3 Nm (2.2 ft lb)
hand tight.
●Check crossbar is securely attached to the
vehicle.
●Use keys to fit and lock covers
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
15

Fitting Kit EN
K450
Maintenance
●Clean the car roof and surfaces of the
product that will be in contact with the car
roof.
●Follow the fitting instructions for fitting the
product to your vehicle. Make sure all steps
are carried out in order.
●Set crossbars a minimum distance of
700mm (27 1/2") apart where no other
distance is specified in the fitting
instructions. This is especially important
when carrying long loads.
●Check unit is securely attached whenever
you refit it to the vehicle. If the unit feels
loose, refer to the fitting instructions and
readjust.
●Some glass/panoramic roofs and radio
antennae may not be able to be used when
the product is fitted.
●Do not modify this product.
●Refer to the maximum permitted load
capacity specified in the fitting instructions.
Do not exceed the vehicle manufacturers
roof load rating if it is lower than the
maximum load capacity specified in the
fitting instructions.
●Loads should not overhang the sides of the
product and be evenly distributed with the
lowest possible centre of gravity.
●Long loads should be secured with non-
elastic straps to the front and rear of the
vehicle.
●Objects with pointed ends (e.g. ski poles)
should be carried with the pointed ends to
the rear of the vehicle.
●Remove all loose or removable objects
from the load prior to loading.
●Make sure all loads are securely fastened
with non-elastic straps. Check regularly
during longer journeys.
●A loaded roof rack system can alter the
performance of your vehicle. Be especially
aware of the effects of side winds,
changing of direction, and braking
performance. Avoid rapid acceleration and
deceleration. Drive carefully.
●Note that the total height of the vehicle
increases when upright loads are carried.
●Products should be locked during transport
if they have locks fitted.
16

Fitting Kit EN
K450
●Check and replace worn out or defective
parts.
●Keep the product clean and maintained.
●Never drive into a car wash with the roof
rack system fitted.
●Lubricate locks and adjusting screws at
regular intervals.
●Remove the products from the vehicle
when not in use. Make sure all loose parts
are stored safely.
●Yakima Australia Pty Ltd
17 Hinkler Court
Brendale QLD 4500
AUSTRALIA
www.prorack.com.au
www.prorack.co.nz
17

1.
2.
3.
a.
b.
1.
2.
WARRANTY & DISCLAIMER
Yakima Australia Pty Ltd ABN 58 154 440 221
17 Hinkler Court, Brendale QLD 4500
Tel: [phone] (NZ) or 1800 143 548 (AU)
Email: [email protected] or [email protected]
Where the product is supplied to the customer for other than business purposes within the meaning of section 43 of the New
Zealand Consumer Guarantees Act 1993, the provisions of that Act shall apply. It is important that anyone who fits or uses this
product does so in accordance with the manufacturer's instructions.
Where the product is supplied to the customer for business purposes within the meaning of section 43 of the New Zealand
Consumer Guarantees Act 1993, the provisions of that Act and all other representations or terms (including any conditions or
warranty expressed or implied by law, statute or otherwise) not expressly included in this leaflet are hereby expressly excluded
shall have no effect and the clauses (a) and (b) shall apply.
Subject to the Additional Information (Australia), where the product is supplied and purchased in Australia, the following shall
apply:
THE SUPPLIER WARRANTS the product to be free from defects in materials and/or workmanship for a period of three (3) years
from the date of original purchase (the warranty period). Proof of purchase is required. Subject to the limitations and exclusions
set out below, the Supplier hereby agrees to remedy any defects in materials or workmanship becoming apparent during the
warranty period, by replacing or repairing any defective product or component (at its option) free of charge to the purchaser in
respect of replacement parts or labour. Any defective product or component must be notified and where practicable, returned
at the purchaser’s expense to the Supplier immediately upon discovery of the alleged defect and no attempt made on the part of
the purchaser to repair it.
EXCEPTIONS, EXCLUSIONS AND LIMITATIONS TO WARRANTY. The product and/or its components must be fitted/ assembled
and loaded in accordance with the Supplier’s written instructions and any requirements set out in the car’s owner manual. This
warranty does not cover defects, loss or damage resulting from circumstances beyond the Supplier’s control including, but not
limited to misuse, overloading, or failure to assemble and/or fit the product or component in accordance with the Supplier’s
written instructions. Nor does the warranty cover defects, loss or damage resulting from accidents, unlawful use of the vehicle
or defects/inconsistencies in the vehicle on which the product or component is fitted. Liability for direct, indirect, special,
punitive, incidental, exemplary, contractual or consequential damage or loss arising from defects, faulty materials or design
omissions or negligence or workmanship in the product or its components is hereby expressly excluded subject to the following.
Certain Commonwealth legislation, including the Competition and Consumer Act 2010 (Cth), and other State and Territorial
legislation confers upon purchasers rights which cannot be excluded from or be restricted or modified by contract. Any
conditions, guarantees and/or warranties implied by law and incapable of exclusion are deemed to be expressly incorporated
herein. Nothing herein contained is intended nor shall be permitted to be inconsistent with any such conditions, guarantees
and/or warranties. To the extent permitted by legislation all conditions, guarantees and/or warranties such as implied
warranties which are capable of exclusion are hereby expressly excluded and negatived.
ADDITIONAL INFORMATION ( AUSTRALIA )
This information should be read in conjunction with clauses (a) and (b).
IMPORTANT LEGAL NOTICE
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
This warranty does not change or take away your rights under the Australian Consumer Law. Your right to claim under this policy for
the benefits covered is in addition to other rights and remedies you have under the law in relation to the product.
Where you become aware of defects in materials or of workmanship, and wish to make a claim under this warranty you must do the
following for the warranty to be honoured by your Prorack dealer or Yakima Australia Pty Ltd ABN 58 154 440 221 (Yakima):
Make a claim as soon as practicable by contacting the Prorack dealer from whom you purchased the product, who will give you
instructions on how to proceed.
If you are unable to contact the Prorack dealer, or the dealer is not able to remedy the defect, you should contact Yakima as
soon as practicable at:
Call: 0800 4776 722 (NZ) or 1800 143 548 (AU)
Email: [email protected] or [email protected]
Fitting Kit EN
K450
18

3.
4.
Alternately, you can write to Yakima at 17 Hinkler Court, Brendale QLD Australia 4500 in order to make a claim under your
warranty.
Upon contacting Yakima directly, you should explain as fully as possible the defect. A Yakima representative will provide you
with appropriate instructions for returning the product together with a copy of the original purchase invoice or receipt to
Yakima.
The costs and expenses associated with making a claim under your warranty including the costs of complying with those
instructions and of returning the product to Yakima or the Prorack dealer will be borne by you.
Following receipt of the product and purchase invoice or receipt, Yakima or the Prorack dealer must inspect the product to determine
whether the claim falls within the warranty. If:
4.1 the claim falls within the warranty, Yakima will remedy any defects in materials or workmanship becoming apparent during the
warranty period, by replacing or repairing any defective product or component (at its option) free of charge to the purchaser in
respect of replacement parts or labour.
4.2 the claim does not fall within the warranty, Yakima will return the product to you at your expense.
Fitting Kit EN
K450
19
