PS Industries EDGEHALT LSGPS-1520 Instruction Manual

1
LSGPS & LSGPSD Series
Rev041823
© 2023 PS Industries®Incorporated. All Rights Reserved.
IMPORTANT! This is an abbreviated manual for installation into a typical guardrail/railing systems. In all cases the
installer and end-user should read the entire O&M and Installation Manual for detailed installation requirements
and operation and maintenance guidelines.
I. Product Information
A. Retain this manual for future reference.
B. To download a copy of the full O&M, scan above QR Code, go to website: https://www.pssafetyaccess.com/o-m/
edgehalt-ladder-safety-gate/; or pssafetyaccess.com to request an O&M download.
C. This product should be used by trained employees only and should not be installed in an area accessible to the
general public.
NOTICE This product is a fall protection product. The effectiveness of the product is directly related to the proper
installation and operation of this product. Failure to properly maintain this product will affect performance.
NOTICE Unauthorized modication of or to the Product voids this Limited Warranty. Authorized modications,
received in writing from PS Industries® Incorporated, as long as the modication is accomplished in strict
accordance with PS Industries’ instructions, does not void warranty. If this product is modied or altered without
manufacturer’s permission, manufacturer is no longer responsible for the product design, engineering, or
performance and owner assumes all responsibility. To request product modications contact PS Industries
Incorporated, 1150 S. 48th Street, Grand Forks, ND 58201, phone [phone], email: 4psinfo@psindustries.
com
II. Safety Precautions
A. Ensure opening is clear of all obstructions through the entire proposed travel of the Ladder Safety Gate during
operation.
B. Comply with all OSHA and ANSI Safety Regulations and/or company safety policies when installing.
IMPORTANT! Due to variances in eld conditions, it is the responsibility of the installer to ensure that the product
is installed to a mounting surface that is capable of supporting all imposed loading from the product. The installer
is responsible for ensuring that the eld congured mounting arrangement is capable of supporting all eld loads
and meets applicable codes and regulations.
CAUTIONCAUTION For products that are approved for use as a means of fall protection, the product only serves as a
means of fall protection when the product is in the closed position.
WARNING Do NOT force components if they do not operate freely.
DANGER Ensure area below installation is blocked off from personnel
during installation.
PN 515968 A
Models:
LSGPS-1520
LSGPS-2030
LSGPSD-2030
LSGPSD-3040
LSGPSD-4060
Website
pssafetyaccess.com
Toll Free Phone
877.446.1519
Quick Start Installation Guide
(Full Installation and O&M Manual online)
Scan for full O&M
Draft #1Draft #1

2LSGPS & LSGPSD Series
Rev041823
© 2023 PS Industries®Incorporated. All Rights Reserved.
Standard Square or Round Installation
NOTICE Alternate mounting congurations detailed in
full O&M available online.
STEP 1. Hang Hinge Plate, align top of railing or 42” to
oor.
a. Match drill holes for Stop Plate into railing.
b. Install Hinge Brackets at 90○to the gate
opening.
Step 1
Illustration I
Step 2
Illustration I
STEP 4. Install Slam-ProofTM Damper Kit.
1. Loosen nut on the hinge bolt; DON’T fully remove
nut.
2. Push hinge bolt up to expose head of hinge bolt.
3. Slide Damper Stud onto bolt head (not nut) and
align pin of Damper Stud into receiving hole in
hinge bracket.
4. Tighten nut of hinge bolt to snug Damper Stud
onto hinge bracket. Over-tightening will prevent
friction-free hinge movement.
5. Slide Damper onto Damper Stud. Pivot gate to
create alignment.
6. Install the O-ring over Damper Stud to secure
Damper in place.
STEP 2. Install Hoop.
CRITICAL End of gate tube must be installed within
”HOOP ADJ. RANGE”.
Step 3
Illustration I
DISTANCE TO
FLOOR: 42”
20ft*lbs
(U-Bolt)
10ft*lbs
10ft*lbs
HOOP ADJ.
RANGE
FINISHED GATE
TOP VIEW
Swing Direction
(On to Platform)
✔
✖
90○
Match Drill
and through
Bolt
20ft*lbs
(Carriage Bolt)
90○
STEP 3. Set Gate ush in railing opening.
a. Install Hinge Stop Brackets.
b. Adjust bolts as needed.
Not Flush
Tighten Nuts
evenly
Gate Flush
in Opening
1
2
3
4
5
6
1
1/
4”
2
3
4
5
6
Loosen
Tighten
Step 4
Illustration I
Push
Slide
Slide
Install

3
LSGPS & LSGPSD Series
Rev041823
© 2023 PS Industries®Incorporated. All Rights Reserved.
Quick Start Installation Guide
(Full Installation and O&M Manual online)
Models:
LSGPSD-2030
LSGPSD-3040
LSGPSD-4060
Website
pssafetyaccess.com
Toll Free Phone
877.446.1519
NOTICE Alternate mounting congurations detailed in full O&M available online.
STEP 1. Install Second Gate.
a. Follow STEP 1 through STEP 4 on Page 2.
STEP 2. Refer to Measuring Guide for gate gap clearance.
CRITICAL End of gate tube must be installed within ”HOOP ADJ. RANGE”
Step 2
Illustration I
FINISHED GATE
TOP VIEW Swing Direction
(On to Platform)
✔
✖
90○
90○
Not Flush
Gate Flush
in Opening
1
/
2
” MIN. GAP 3” MAX. GAP
MAXIMUM RAILING OPENING WIDTH
MINIMUM RAILING
OPENING WIDTH
Step 2
Illustration II
Scan for full O&M

877.446.1519
[email protected] | pssafetyaccess.com
1150 South 48th Street | Grand Forks, ND 58201
Product Registration:
psindustries.com/contact/register-your-product
