Puls Dimension CP Series User manual

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
1/29
POWER SUPPLY
AC 100-240V Wide-range Input
Width only 32mm
Efficiency up to 94.3%
Excellent Partial Load Efficiency
20% Output Power Reserves
Easy Fuse Breaking – 3 times nominal current for 12ms
Safe HiccupPLUS Overload Mode
Active Power Factor Correction (PFC)
Minimal Inrush Current Surge
Full Power Between -25°C and +60°C
DC-OK Relay Contact
3 Year Warranty
PRODUCT DESCRIPTION
The Dimension CP-Series are cost optimized power
supplies without compromising quality, reliability and
performance. The CP-Series is part of the DIMENSION
power supply family.
The CP5.241 power supplies come with three connection
terminal options: screw, spring-clamp or push-in
terminals, which are optimized for automated wiring.
The CP5.241-C1 is equipped with conformal coated pc-
boards preferred for the use in harsh environments and
the CP5.242 features an enhanced DC input voltage
range.
The most outstanding features of these units are the
small size, the high efficiency, the electronic inrush
current limitation, active PFC and the wide operational
temperature range. The devices have a power reserve of
20% included, which may even be used continuously at
temperatures up to +45°C. Additionally, they can deliver
3 times the nominal output current for 12ms which
helps to trip fuses on faulty output branches.
High immunity to transients and power surges as well as
low electromagnetic emission, a DC-OK signal contact
for remote monitoring, and a large international
approval package for a variety of applications makes
this unit suitable for nearly every situation.
SHORT-FORM DATA
Output voltage DC 24V Nominal
Adjustment range 24 - 28V Factory setting 24.1V
Output current 6.0 - 5.1A Below +45°C ambient
5.0 – 4.3A At +60°C ambient
3.8 – 3.2A At +70°C ambient
Derate linearly between +45°C and +70°C
Input voltage AC AC 100-240V -15%/+10%
Mains frequency 50-60Hz ±6%
Input current AC 1.09 / 0.6A At 120 / 230Vac
Power factor 0.98 / 0.91 At 120 / 230Vac
Input voltage DC DC 110-150V ±20% For CP5.241 (-xx)
DC 110-300V
±20% For CP5.242
Input current DC 1.21 / 0.43A At 110 / 300Vdc
AC Inrush current 4 / 4A At 120 / 230Vac
Efficiency 93.6 / 94.3% At 120 / 230Vac
Losses 8.2 / 7.3W At 120 / 230Vac
Hold-up time 35 / 35ms At 120 / 230Vac
Temperature range -25°C to +70°C
Size (WxHxD) 32x124x102mm Without DIN-rail
Weight 440g / 0.97lb
ORDER NUMBERS
Power Supply CP5.241 Screw terminals
CP5.241-C1 Screw terminals and
conformal coated pc-boards
CP5.241-S1 Spring-clamp terminals
CP5.241-S2 Push-in terminals
CP5.242 Screw terminals and
enhanced DC input
Mechanical Accessory
ZM10.WALL Wall/Panel mount bracket
MAIN APPROVALS
For details or a complete approval list see chapter 19.
IEC 62368-1
IEC 61010-1
IEC 61010-2-201
IND. CONT. E
Q.
planned

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
2/29
INDEX
Page Page
1. Intended Use .......................................................3
2. Installation Instructions ......................................3
3. AC-Input...............................................................5
4. DC-Input...............................................................6
5. Input Inrush Current ...........................................7
6. Output .................................................................8
7. Hold-up Time.....................................................10
8. DC-OK Relay Contact ........................................10
9. Efficiency and Power Losses..............................11
10. Functional Diagram...........................................12
11. Front Side and User Elements...........................12
12. Connection Terminals .......................................13
13. Lifetime Expectancy ..........................................14
14. MTBF ..................................................................14
15. EMC....................................................................15
16. Environment......................................................16
17. Safety and Protection Features ........................17
18. Dielectric Strength ............................................18
19. Approvals and Fulfilled Standards ...................19
20. Regulatory Compliance.................................... 19
21. Physical Dimensions and Weight ..................... 20
22. Accessories ........................................................ 21
22.1. ZM10.WALL – Wall/Panel Mount Bracket21
22.2. YR2.DIODE - Redundancy Module...........22
22.3. YR20.242 - Redundancy Module..............22
22.4. YR20.246 - Redundancy Module with
Automated Load Sharing ....................................22
22.5. UF20.241 Buffer Module ..........................23
23. Application Notes............................................. 24
23.1. Peak Current Capability ...........................24
23.2. Charging of Batteries ...............................25
23.3. Series Operation .......................................25
23.4. Parallel Use to Increase Output Power....25
23.5. Parallel Use for Redundancy ....................26
23.6. Operation on Two Phases ........................28
23.7. Use in a Tightly Sealed Enclosure ............28
23.8. Mounting Orientations ............................29
The information given in this document is correct to the best of our knowledge and experience at the time of
publication. If not expressly agreed otherwise, this information does not represent a warranty in the legal sense of the
word. As the state of our knowledge and experience is constantly changing, the information in this data sheet is
subject to revision. We therefore kindly ask you to always use the latest issue of this document (available under
www.pulspower.com).
No part of this document may be reproduced or utilized in any form without our prior permission in writing.
Packaging and packaging aids can and should always be recycled. The product itself may not be disposed of as
domestic refuse.
TERMINOLOGY AND ABREVIATIONS
PE and symbol PE is the abbreviation for Protective Earth and has the same meaning as the symbol .
Earth, Ground This document uses the term “earth” which is the same as the U.S. term “ground”.
T.b.d. To be defined, value or description will follow later.
AC 230V A figure displayed with the AC or DC before the value represents a nominal voltage with
standard tolerances (usually ±15%) included.
E.g.: DC 12V describes a 12V battery disregarding whether it is full (13.7V) or flat (10V)
230Vac A figure with the unit (Vac) at the end is a momentary figure without any additional
tolerances included.
50Hz vs. 60Hz As long as not otherwise stated, AC 230V parameters are valid at 50Hz mains frequency.
may A key word indicating flexibility of choice with no implied preference.
shall A key word indicating a mandatory requirement.
should A key word indicating flexibility of choice with a strongly preferred implementation.

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
3/29
1. INTENDED USE
This device is designed for installation in an enclosure and is intended for commercial use, such as in industrial control,
process control, monitoring and measurement equipment or the like.
Do not use this device in equipment where malfunction may cause severe personal injury or threaten human life.
If this device is used in a manner outside of its specification, the protection provided by the device may be impaired.
2. INSTALLATION INSTRUCTIONS
WARNING Risk of electrical shock, fire, personal injury or death.
- Turn power off before working on the device. Protect against inadvertent re-powering.
- Do not modify or repair the unit.
- Do not open the unit as high voltages are present inside.
- Use caution to prevent any foreign objects from entering the housing.
- Do not use in wet locations or in areas where moisture or condensation can be expected.
- Do not touch during power-on, and immediately after power-off. Hot surfaces may cause burns.
Obey the following installation instructions:
This device may only be installed and put into operation by qualified personnel.
This device does not contain serviceable parts. The tripping of an internal fuse is caused by an internal defect.
If damage or malfunction should occur during installation or operation, immediately turn power off and send unit to
the factory for inspection.
Install the device in an enclosure providing protection against electrical, mechanical and fire hazards.
Install the device onto a DIN-rail according to EN 60715 with the input terminals on the bottom of the device. Other
mounting orientations require a reduction in output current.
Make sure that the wiring is correct by following all local and national codes. Use appropriate copper cables that are
designed for a minimum operating temperature of 60°C for ambient temperatures up to +45°C, 75°C for ambient
temperatures up to +60°C and 90°C for ambient temperatures up to +70°C. Ensure that all strands of a stranded wire
enter the terminal connection. Use ferrules for wires on the input terminals. Unused screw terminals should be
securely tightened.
The device is designed for pollution degree 2 areas in controlled environments. No condensation or frost is allowed.
The enclosure of the device provides a degree of protection of IP20.
The isolation of the device is designed to withstand impulse voltages of overvoltage category III according to IEC
60664-1.
The device is designed as “Class of Protection I” equipment according to IEC 61140. Do not use without a proper PE
(Protective Earth) connection.
The device is suitable to be supplied from TN, TT or IT mains networks. The continuous voltage between the input
terminal and the PE potential must not exceed 300Vac.
The input can also be powered from batteries or similar DC sources. The continuous voltage between the supply
voltage and the PE/ground potential must not exceed 360Vdc.
A disconnecting means shall be provided for the input of the device.
The device is designed for convection cooling and does not require an external fan. Do not obstruct airflow and do not
cover ventilation grid!
The device is designed for altitudes up to 5000m (16400ft). Above 2000m (6560ft) a reduction in output current and
over voltage category is required.

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
4/29
Keep the following minimum installation clearances: 40mm on top, 20mm on the bottom, 5mm left and right side.
Increase the 5mm to 15mm in case the adjacent device is a heat source. When the device is permanently loaded with
less than 50%, the 5mm can be reduced to zero.
The device is designed, tested and approved for branch circuits up to 32A (IEC) and 30A (UL) without additional
protection device. If an external fuse is utilized, do not use circuit breakers smaller than 6A B- or C-Characteristic to
avoid a nuisance tripping of the circuit breaker.
The maximum surrounding air temperature is +70°C (+158°F). The operational temperature is the same as the ambient
or surrounding air temperature and is defined 2cm below the device.
The device is designed to operate in areas between 5% and 95% relative humidity.

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
5/29
3. AC-INPUT
The device is suitable to be supplied from TN, TT or IT mains networks with AC voltage. For suitable DC supply voltages
see chapter 4.
AC input Nom. AC 100-240V
AC input range Min. 85-264Vac Continuous operation
Min. 264-300Vac Occasionally for maximal 500ms
Allowed voltage L or N to earth Max. 300Vac Continuous, according to IEC 60664-1
Input frequency Nom. 50–60Hz ±6%
Turn-on voltage Typ. 80Vac Steady-state value, see Fig. 3-1
Shut-down voltage Typ. 74Vac Steady-state value, see Fig. 3-1
External input protection See recommendations in chapter 2.
AC 100V AC 120V AC 230V
Input current Typ. 1.30A 1.09A 0.60A At 24V, 5A, see Fig. 3-3
Power factor Typ. 0.99 0.98 0.91 At 24V, 5A, see Fig. 3-4
Crest factor Typ. 1.7 1.8 2.2 At 24V, 5A, The crest factor is the
mathematical ratio of the peak
value to RMS value of the input
current waveform.
Start-up delay Typ. 420ms 380ms 385ms See Fig. 3-2
Rise time Typ. 80ms 80ms 80ms At 24V, 5A const. current load, 0mF
load capacitance, see Fig. 3-2
Typ. 100ms 100ms 110ms At 24V, 5A const. current load, 5mF
load capacitance,, see Fig. 3-2
Turn-on overshoot Max. 200mV 200mV 200mV See Fig. 3-2
Fig. 3-1 Input voltage range Fig. 3-2 Turn-on behavior, definitions
Turn-on
85V
Rated
input range
max.
500ms
VIN
POUT
300Vac264V
Shut-down
Start-up
delay Rise Time
Overshoot
- 5%
Output
Voltage
Input
Voltage
Fig. 3-3 Input current vs. output current at
24V output voltage
Fig. 3-4 Power factor vs. output current at
24V output voltage
6A
0.51234
0
0.25
0.5
0.75
1.0
1.25
1.5A
Input Current, typ.
5
a) 100Vac
b) 120Vac
c) 230Vac
Output Current
(a)
(b)
(c)
Power Factor, typ.
123456A
0.75
0.8
0.85
0.9
0.95
1.0
Output Current
(a) 100Vac,
(b) 120Vac,
(c) 230Vac
(a)
(b)
(c)

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
6/29
4. DC-INPUT
The device is suitable to be supplied from a DC input voltage. Use a battery or a similar DC source. A supply from the
intermediate DC-bus of a frequency converter is not recommended and can cause a malfunction or damage the unit.
Connect +pole to L, –pole to N and the PE terminal to an earth wire or to the machine ground.
DC input Nom. DC 110-150V ±20%
For CP5.241, CP5.241-C1, CP5.241-S1, CP5.241-S2
Nom. DC 110-300V ±20%
For CP5.242
DC input range Min. 88-180Vdc Continuous operation
For CP5.241, CP5.241-C1, CP5.241-S1, CP5.241-S2
88-360Vdc Continuous operation for CP5.242
DC input current Typ. 1.21A At 110Vdc, at 24V, 5A
Typ. 0.43A At 300Vdc, at 24V, 5A
Allowed Voltage (+) or (-) input
to Earth
Max. 360Vdc Continuous according to IEC 60664-1
Turn-on voltage Typ. 74Vdc Steady state value
Shut-down voltage Typ. 67Vdc Steady state value
Fig. 4-1 Wiring for DC Input
+
-
Load
L
PE
+
-
Power Supply
AC
DC
Battery
N

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
7/29
5. INPUT INRUSH CURRENT
An active inrush limitation circuit (NTCs, which are bypassed by a relay contact) limits the input inrush current after
turn-on of the input voltage.
The charging current into EMI suppression capacitors is disregarded in the first microseconds after switch-on.
AC 100V AC 120V AC 230V
Inrush current Max. 8Apeak 7Apeak 7Apeak At 40°C, cold start
Typ. 5Apeak 4Apeak 4Apeak At 25°C, cold start
Typ. 5Apeak 5Apeak 6Apeak At 40°C, cold start
Inrush energy Max. 0.4A²s 0.5A²s 1A²s At 40°C, cold start
Fig. 5-1 Typical turn-on behaviour at nominal
load, 120Vac input and 25°C ambient
Fig. 5-2 Typical turn-on behaviour at nominal
load, 230Vac input and 25°C ambient
50ms/DIV
Output voltage
Input
voltage
200V/DIV
Input
current
2A/DIV
4A
50ms/DIV
Input
current
2A/DIV
Input
voltage
200V/DIV
Output voltage
4A

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
8/29
6. OUTPUT
The output provides a SELV/PELV rated voltage, which is galvanically isolated from the input voltage.
The output is designed to supply any kind of loads, including capacitive and inductive loads. If extreme large
capacitors, such as EDLCs (electric double layer capacitors or “UltraCaps”) with a capacitance > 0.3F are connected to
the output, the unit might charge the capacitor in an intermittent mode.
The output is electronically protected against overload, no-load and short-circuits. In case of a protection event,
audible noise may occur.
Output voltage Nom. 24V
Adjustment range Min. 24-28V Guaranteed value
Max. 30.0V This is the maximum output voltage which can
occur at the clockwise end position of the
potentiometer due to tolerances. It is not a
guaranteed value which can be achieved.
Factory settings Typ. 24.1V ±0.2%, at full load and cold unit
Line regulation Max. 10mV Between 85 and 300Vac
Load regulation Max. 50mV Between 0A and 6A, static value, see Fig. 6-1
Ripple and noise voltage Max. 50mVpp Load >0.2A, Bandwidth 20Hz to 20MHz, 50Ohm
Max. 200mVpp Load <0.2A, Bandwidth 20Hz to 20MHz, 50Ohm
Output current Nom. 6A1) At 24V and an ambient temperatures below 45°C
Nom. 5A At 24V and 60°C ambient temperature
Nom. 3.8A At 24V and 70°C ambient temperature
Nom. 5.1A1) At 28V and an ambient temperatures below 45°C
Nom. 4.3A At 28V and 60°C ambient temperature
Nom. 3.2A At 28V and 70°C ambient temperature
Derate linearely between +45°C and +70°
Fuse breaking current Typ. 15A Up to 12ms once every five seconds, see Fig. 6-2.
The fuse braking current is an enhanced transient
current which helps to trip fuses on faulty output
branches. The output voltage stays above 20V.
Overload behaviour Continuous current For output voltage above 13Vdc, see Fig. 6-1
Intermittent current2) For output voltage below 13Vdc, see Fig. 6-1
Overload/ short-circuit current Max. 7.2A Continuous current, see Fig. 6-1
Typ. 9A Intermitted current peak value for typ. 1s
Load impedance 50mOhm, see Fig. 6-3
Discharge current of output capacitors is not
included.
Max. 3.5A Intermitted current average value (R.M.S.)
Load impedance 50mOhm, see Fig. 6-3
Output capacitance Typ. 1 800μF Included inside the power supply
Back-feeding loads Max. 35V The unit is resistant and does not show
malfunctioning when a load feeds back voltage to
the power supply. It does not matter whether the
power supply is on or off. The absorbing energy
can be calculated according to the built-in large
sized output capacitor.
1) This current is also available for temperatures up to +70°C with a duty cycle of 10% and/ or not longer than 1 minute every 10 minutes.
2) At heavy overloads (when output voltage falls below 13V), the power supply delivers continuous output current for 1s. After this, the
output is switched off for approx. 9s before a new start attempt is automatically performed. This cycle is repeated as long as the overload
exists. If the overload has been cleared, the device will operate normally. See Fig. 6-3.

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
9/29
Fig. 6-1 Output voltage vs. output current,
typ.
Fig. 6-2 Dynamic output current capability,
typ.
Output Voltage
0
06
4
8
12
28V
16
20
24
10A41 2 5 7839
Adjustment
Range
Output Current
A: continuous current
B: intermittent current
A
B
Output Voltage (dynamic behavior, < 12ms)
0
0
4
8
12
28V
16
20
24
25
A
10515202.5 7.5 12.5 17.5 22.5
Adjustment
Range
Output Current
Fig. 6-3 Short-circuit on output, HiccupPLUS mode, typ.
Output
Current
0
9A
9s 9s
9s 1s 1s
1s
t
Short -circuit Normal
operation
Normal
operation

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
10/29
7. HOLD-UP TIME
The hold-up time is the time during which a power supply’s output voltage remains within specification following the
loss of input power. The hold-up time is output load dependent. At no load, the hold-up time can be up to several
seconds. The green DC-ok lamp is also on during this time.
AC 100V AC 120V AC 230V
Hold-up Time Typ. 70ms 70ms 70ms At 24V, 2.5A, see Fig. 7-1
Min. 55ms 55ms 55ms At 24V, 2.5A, see Fig. 7-1
Typ. 35ms 35ms 35ms At 24V, 5A, see Fig. 7-1
Min. 27ms 27ms 27ms At 24V, 5A, see Fig. 7-1
Fig. 7-1 Hold-up time vs. input voltage Fig. 7-2 Shut-down behavior, definitions
0
15
30
45
60
90ms
90 120 155 190 230Vac
Input Voltage
75
Hold-up Time
a
b
c
d
a) 24V 2.5A typ.
b) 24V 2.5A min. c) 24V 5A typ.
d) 24V 5A min.
- 5%
Hold-up Time
Zero Transition
Output
Voltage
Input
Voltage
8. DC-OK RELAY CONTACT
This feature monitors the output voltage on the output terminals of a running power supply.
Contact closes As soon as the output voltage reaches typ. 90% of the adjusted output voltage level.
Contact opens As soon as the output voltage dips more than 10% below the adjusted output voltage.
Short dips will be extended to a signal length of 100ms. Dips shorter than 1ms will be ignored.
Switching hysteresis Typically 0.7V
Contact ratings Maximal 60Vdc 0.3A, 30Vdc 1A, 30Vac 0.5A, resistive load
Minimal permissible load: 1mA at 5Vdc
Isolation voltage See dielectric strength table in section 18.
Fig. 8-1 DC-ok relay contact behavior
100ms
0.9* V
ADJ
<
1ms
10%
open
V
OUT
= V
ADJ
openclosed closed
>
1...4ms

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
11/29
9. EFFICIENCY AND POWER LOSSES
AC 100V AC 120V AC 230V
Efficiency Typ. 92.9% 93.6% 94.3% At 24V, 5A
Typ. 92.7% 93.5% 94.5% At 24V, 6A (Power Boost)
Average efficiency*) Typ. 91.3% 91.7% 92.0% 25% at 1.25A, 25% at 2.5A,
25% at 3.75A. 25% at 5A
Power losses Typ. 1.3W 1.3W 1.4W At 24V, 0A
Typ. 4.6W 4.4W 4.1W At 24V, 2.5A
Typ. 9.2W 8.2W 7.3W At 24V, 5A
Typ. 11.3W 9.8W 8.4W At 24V, 6A (Power Boost)
*) The average efficiency is an assumption for a typical application where the power supply is loaded with 25% of the nominal load for 25%
of the time, 50% of the nominal load for another 25% of the time, 75% of the nominal load for another 25% of the time and with 100%
of the nominal load for the rest of the time.
Fig. 9-1 Efficiency vs. output current at 24V,
typ.
Fig. 9-2 Losses vs. output current at 24V, typ.
Efficiency
123 56A
89
90
91
92
93
94
95%
Output Current
4
(a)
(b)
(c)
(a) 100Vac
(b) 120Vac
(c) 230Vac
88
87
Power Losses
023 6A
2
0
4
6
8
12W
5
10
1 4
Output Current
(a)
(b)
(c)
(a) 100Vac
(b) 120Vac
(c) 230Vac
Fig. 9-3 Efficiency vs. input voltage at 24V,
5A, typ.
Fig. 9-4 Losses vs. input voltage at 24V, 5A,
typ.
Efficiency
120 180 230 264Vac
89
90
91
92
Input Voltage
93
94
95%
100
Power Losses
120 180 230 264Vac
5
6
7
8
Input Voltage
9
10
11W
100

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
12/29
10. FUNCTIONAL DIAGRAM
Fig. 10-1 Functional diagram
+
+
-
-
Output
Over-
Voltage
Protection
PFC
Converter
Output
Voltage
Regulator
Power
Converter
Output
Filter
Output
Voltage
Monitor
Output
Power
Manager
Temper-
ature
Shut-
down
Input Fuse
Input Filter
Input Rectifier
Inrush Current Limiter
V
OUT
L
N
DC-ok
Contact
DC-ok
LED
DC-ok
Relay
11. FRONT SIDE AND USER ELEMENTS
Fig. 11-1 Front side
CP5.241,
CP5.241-C1
CP5.241-S1 CP5.241-S2 CP5.242
AInput Terminals
N, L Line input
PE (Protective
Earth) input
BOutput Terminals
Two identical + poles and
two identical - poles
+ Positive output
–Negative output
(return)
COutput Voltage
Potentiometer
DDC-OK LED (green)
On, when the output
voltage is >90% of the
adjusted output voltage
EDC-OK Relay Contact
The DC-OK relay contact is
synchronized with the DC-
OK LED. See chapter 8 for
details.

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
13/29
12. CONNECTION TERMINALS
The terminals are IP20 Finger safe constructed and suitable for field- and factory wiring.
CP5.241, CP5.241-C1, CP5.242 Input Output DC-OK-Signal
Type Screw termination Screw termination Push-in termination
Solid wire Max. 6mm2Max. 6mm2Max. 1.5mm2
Stranded wire Max. 4mm2Max. 4mm2Max. 1.5mm2
American Wire Gauge AWG 20-10 AWG 20-10 AWG 24-16
Max. wire diameter (including ferrules) 2.8mm 2.8mm 1.6mm
Recommended tightening torque Max. 1Nm, 9lb-in Max. 1Nm, 9lb-in -
Wire stripping length 7mm / 0.28inch 7mm / 0.28inch 7mm / 0.28inch
Screwdriver 3.5mm slotted or cross-
head No 2
3.5mm slotted or cross-
head No 2
3mm slotted to open
the spring
CP5.241-S1 Input Output DC-OK-Signal
Type Quick-connect spring-
clamp termination
Quick-connect spring-
clamp termination
Push-in termination
Solid wire Max. 6mm2Max. 6mm2Max. 1.5mm2
Stranded wire Max. 4mm2Max. 4mm2Max. 1.5mm2
American Wire Gauge AWG 20-10 AWG 20-10 AWG 24-16
Max. wire diameter (including ferrules) 2.8mm 2.8mm 1.6mm
Wire stripping length 10mm / 0.4inch 10mm / 0.4inch 7mm / 0.28inch
Screwdriver - - 3mm slotted to open
the spring
CP5.241-S2 Input Output DC-OK-Signal
Type Push-in termination Push-in termination Push-in termination
Solid wire Max. 2.5mm2Max. 2.5mm2Max. 1.5mm2
Stranded wire Max. 2.5mm2Max. 2.5mm2Max. 1.5mm2
Stranded wire with ferrules Max. 1.5mm2Max. 1.5mm2Max. 1.5mm2
American Wire Gauge AWG 24-12 AWG 24-12 AWG 24-16
Max. wire diameter (including ferrules) 2.3mm 2.3mm 1.6mm
Wire stripping length 10mm / 0.4inch 10mm / 0.4inch 7mm / 0.28inch
Screwdriver 3.0mm slotted to open
the spring
3.0mm slotted to open
the spring
3mm slotted to open
the spring
Daisy chaining:
Daisy chaining (jumping from one power supply output to the next) is allowed as long as the average output current
through one terminal pin does not exceed 25A or 15A for the CP5.241-S2. If the current is higher, use a separate
distribution terminal block as shown in Fig. 12-2.
Fig. 12-1 Daisy chaining of outputs Fig. 12-2 Using distribution terminals
Load
+
-
Power
Supply
+ +
- -
Output
Power
Supply
+ +
- -
Output
Maximal 15A continuous for CP5.241-S2
Maximal 25A continuous for all other units
Distribution
Terminals
Load
+
-
Power
Supply
+ +
- -
Output
Power
Supply
+ +
- -
Output

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
14/29
13. LIFETIME EXPECTANCY
The Lifetime expectancy shown in the table indicates the minimum operating hours (service life) and is determined by
the lifetime expectancy of the built-in electrolytic capacitors. Lifetime expectancy is specified in operational hours and
is calculated according to the capacitor’s manufacturer specification. The manufacturer of the electrolytic capacitors
only guarantees a maximum life of up to 15 years (131 400h). Any number exceeding this value is a calculated
theoretical lifetime which can be used to compare devices.
AC 100V AC 120V AC 230V
Lifetime expectancy 265 000h 270 000h 274 000h At 24V, 2.5A and 40°C
748 000h 764 000h 775 000h At 24V, 2.5A and 25°C
128 000h 143 000h 166 000h At 24V, 5A and 40°C
363 000h 405 000h 469 000h At 24V, 5A and 25°C
81 000h 96 000h 119 000h At 24V, 6A and 40°C
228 000h 271 000h 336 000h At 24V, 6A and 25°C
14. MTBF
MTBF stands for Mean Time Between Failure, which is calculated according to statistical device failures, and indicates
reliability of a device. It is the statistical representation of the likelihood of a unit to fail and does not necessarily
represent the life of a product.
The MTBF figure is a statistical representation of the likelihood of a device to fail. A MTBF figure of e.g. 1 000 000h
means that statistically one unit will fail every 100 hours if 10 000 units are installed in the field. However, it can not
be determined if the failed unit has been running for 50 000h or only for 100h.
For these types of units the MTTF (Mean Time To Failure) value is the same value as the MTBF value.
AC 100V AC 120V AC 230V
MTBF SN 29500, IEC 61709 800 000h 807 000h 867 000h At 24V, 5A and 40°C
1 402 000h 1 414 000h 1 510 000h At 24V, 5A and 25°C
MTBF MIL HDBK 217F 339 000h 343 000h 368 000h At 24V, 5A and 40°C;
Ground Benign GB40
490 000h 496 000h 529 000h At 24V, 5A and 25°C;
Ground Benign GB25
81 000h 83 000h 89 000h At 24V, 5A and 40°C;
Ground Fixed GF40
109 000h 111 000h 119 000h At 24V, 5A and 25°C;
Ground Fixed GF25

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
15/29
15. EMC
The EMC behavior of the device is designed for applications in industrial environment as well as in residential,
commercial and light industry environments.
The device is investigated according to EN 61000-6-1, EN 61000-6-2, EN 61000-6-3 and EN 61000-6-4.
EMC Immunity
Electrostatic discharge EN 61000-4-2 Contact discharge
Air discharge
8kV
15kV
Criterion A
Criterion A
Electromagnetic RF field EN 61000-4-3 80MHz-2.7GHz 20V/m Criterion A
Fast transients (Burst) EN 61000-4-4 Input lines
Output lines
DC-OK signal (coupling clamp)
4kV
2kV
2kV
Criterion A
Criterion A
Criterion A
Surge voltage on input EN 61000-4-5 L ÆN
L ÆPE, N ÆPE
2kV
4kV
Criterion A
Criterion A
Surge voltage on output EN 61000-4-5 + Æ-
+ / - ÆPE
1kV
2kV
Criterion A
Criterion A
Surge voltage on DC-OK EN 61000-4-5 DC-OK signal ÆPE 1kV Criterion A
Conducted disturbance EN 61000-4-6 0.15-80MHz 20V Criterion A
Mains voltage dips EN 61000-4-11 0% of 100Vac
40% of 100Vac
70% of 100Vac
0% of 200Vac
40% of 200Vac
40% of 200Vac
70% of 200Vac
0Vac, 20ms
40Vac, 200ms
70Vac, 500ms
0Vac, 20ms
80Vac, 200ms, <4A
80Vac, 200ms, >4A
140Vac, 500ms
Criterion A
Criterion C
Criterion A
Criterion A
Criterion A
Criterion C
Criterion A
Voltage interruptions EN 61000-4-11 0% of 200Vac (=0V) 5000ms Criterion C
Powerful transients VDE 0160 Over entire load range 750V, 0.3ms Criterion A
Performance criterions:
A: The device shows normal operation behavior within the defined limits.
C: Temporary loss of function is possible. The device may shut-down and restarts by itself. No damage or hazards for the device will occur.
EMC Emission
Conducted emission
input lines
EN 55011, EN 55022, FCC Part 15, CISPR 11, CISPR 22 Class B
Conducted emission
output lines
IEC/CISPR 16-1-2, IEC/CISPR 16-2-1 Limits for local DC power
networks fulfilled
Radiated emission EN 55011, EN 55022 Class B
Harmonic input current (PFC) EN 61000-3-2 Fulfilled for Class A equipment
Voltage fluctuations, flicker EN 61000-3-3 Fulfilled,tested with constant
current loads, non pulsing
This device complies with FCC Part 15 rules.
Operation is subjected to following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
Switching Frequencies
PFC converter 30kHz to 140kHz Input voltage and output load dependent
Main converter 60kHz to 140kHz Output load dependent
Auxiliary converter 30kHz to 60kHz Output load dependent

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
16/29
16. ENVIRONMENT
Operational temperature -25°C to +70°C (-13°F to 158°F) Operational temperature is the same as the ambient
or surrounding temperature and is defined as the air
temperature 2cm below the unit.
Storage temperature -40°C to +85°C (-40°F to 185°F) For storage and transportation
Output de-rating 1.6W/°C
3W/°C
0.33A/1000m or 5°C/1000m
Between +45°C and +60°C (113°F to 140°F)
Between +60°C and +70°C (140°F to 158°F)
For altitudes >2000m (6560ft), see Fig. 16-2
The de-rating is not hardware controlled. The user has to take this into consideration to
stay below the de-rated current limits in order not to overload the unit.
Humidity 5 to 95% r.h. According to IEC 60068-2-30
Atmospheric pressure 110-54kPa See Fig. 16-2 for details
Altitude Up to 5000m (16 400ft) See Fig. 16-2 for details
Over-voltage category III According to IEC 60664-1 for altitudes up to 2000m
II According to IEC 60664-1, for altitudes above 2000m
Degree of pollution 2 According to IEC 62477-1, not conductive
Vibration sinusoidal 2-17.8Hz: ±1.6mm;
17.8-500Hz: 2g
2 hours / axis
According to IEC 60068-2-6
Shock 30g 6ms, 20g 11ms
3 bumps per direction, 18
bumps in total
According to IEC 60068-2-27
Shock and vibration is tested in combination with DIN-Rails according to EN 60715 with a
height of 15mm and a thickness of 1.3mm and standard orientation.
LABS compatibility As a rule, only non-silicon precipitating materials are used. The unit conforms to the
LABS criteria and is suitable for use in paint shops.
Corrosive gases Tested according to ISA-71.04-1985, Severity Level G3 and IEC 60068-2-60 Test Ke
Method 4 for a service life of minimum 10years in these environments.
Audible noise Some audible noise may be emitted from the power supply during no load, overload or
short circuit.
Fig. 16-1 Output current vs. ambient temp. Fig. 16-2 Output current vs. altitude
Allowed Output Current at 24V
0
-25 0 45 70°C
3.8A
5A
6A
60
A
Ambient Temperature
A... 85 to 264Vac, continuous
B... short term
B
2000m 5000m
4A
5A
6A
Altitude
Allowed Output Current at 24V
B
A...Tamb<60°C
B...Tamb<45°C
C...Shortterm
A
C
AP
*)
80kPa 54kPa110kPa
0m
*) Atmospheric pressure

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
17/29
17. SAFETY AND PROTECTION FEATURES
Isolation resistance Min. 500MOhm At delivered condition between input and output,
measured with 500Vdc
Min. 500MOhm At delivered condition between input and PE,
measured with 500Vdc
Min. 500MOhm At delivered condition between output and PE,
measured with 500Vdc
Min. 500MOhm At delivered condition between output and DC-OK
contacts, measured with 500Vdc
PE resistance Max. 0.1Ohm Resistance between PE terminal and the housing in
the area of the DIN-rail mounting bracket.
Output over-voltage protection Typ. 30.5Vdc
Max. 32.0Vdc
In case of an internal defect, a redundant circuit limits the maximum output
voltage. The output shuts down and performs three restart attempts. If the
failure continues, the output shuts down. Cycle input power to reset.
Class of protection I According to IEC 61140
A PE (Protective Earth) connection is required
Degree of protection IP 20 According to EN/IEC 60529
Over-temperature protection Included Output shut-down with automatic restart.
Temperature sensors are installed on critical
components inside the unit and turn the unit off in
safety critical situations, which can happen e.g. when
ambient temperature is too high, ventilation is
obstructed or the de-rating requirements are not
followed. There is no correlation between the
operating temperature and turn-off temperature
since this is dependent on input voltage, load and
installation methods.
Input transient protection MOV (Metal Oxide
Varistor)
For protection values see chapter 15 (EMC).
Internal input fuse Included Not user replaceable slow-blow high-braking
capacity fuse
Touch current (leakage current) Typ. 0.10mA / 0.27mA At 100Vac, 50Hz, TN-,TT-mains / IT-mains
Typ. 0.13mA / 0.38mA At 120Vac, 60Hz, TN-,TT-mains / IT-mains
Typ. 0.20mA / 0.60mA At 230Vac, 50Hz, TN-,TT-mains / IT-mains
Max. 0.13mA / 0.35mA At 110Vac, 50Hz, TN-,TT-mains / IT-mains
Max. 0.17mA / 0.51mA At 132Vac, 60Hz, TN-,TT-mains / IT-mains
Max. 0.27mA / 0.81mA At 264Vac, 50Hz, TN-,TT-mains / IT-mains

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
18/29
18. DIELECTRIC STRENGTH
The output voltage is floating and has no ohmic connection to the ground.
The output is insulated to the input by a double or reinforced insulation.
Type and routine tests are conducted by the manufacturer. Field tests may be conducted in the field using the
appropriate test equipment which applies the voltage with a slow ramp (2s up and 2s down). Connect all input-
terminals together as well as all output poles before conducting the test. When testing, set the cut-off current settings
to the value in the table below.
We recommend that either the + pole or the – pole shall be connected to the protective earth system. This helps to
avoid situations in which a load starts unexpectedly or can not be switched off when unnoticed earth faults occur.
Fig. 18-1 Dielectric strength
A B C D
Type test 60s 2500Vac 3000Vac 1000Vac 500Vac
Routine test 5s 2500Vac 2500Vac 500Vac 500Vac
Field test 5s 2000Vac 2000Vac 500Vac 500Vac
Field test cut-off
current settings
> 10mA > 10mA > 20mA > 1mA
AD
C
B
B
*)
N
L
Input DC-ok
Earth, PE Output
-
+
B*)
When testing input to DC-OK ensure that the maximal voltage between DC-OK and
the output is not exceeded (column D). We recommend connecting DC-OK pins and
the output pins together when performing the test.

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
19/29
19. APPROVALS AND FULFILLED STANDARDS
IEC 61010 CB Scheme Certificate
IEC 61010-2-201 Electrical Equipment for Measurement, Control
and Laboratory Use - Particular requirements for control
equipment
IEC 62368 CB Scheme Certificate
IEC 62368-1 Audio/video, information and communication
technology equipment - Safety requirements
Output safety level: ES1
UL 61010-2-201
(former UL 508)
planned
Ind. Cont. Eq.
UL Certificate
Listed equipment for category NMTR - UL 61010-2-201 Electrical
Equipment for Measurement, Control and Laboratory Use -
Particular requirements for control equipment
Applicable for US and Canada
E-File: E198865
20. REGULATORY COMPLIANCE
CE
EU Declaration of Conformity
Trade conformity assessment for Europe
The CE mark indicates conformance with the European
- RoHS directive,
- EMC directive and the
- Low-voltage directive (LVD)
REACH Directive
Manufacturer's Statement
EU-Regulation regarding the Registration, Evaluation,
Authorisation and Restriction of Chemicals
WEEE Directive
Manufacturer's Statement
EU-Directive on Waste Electrical and Electronic Equipment
RoHS (China RoHS 2) Manufacturer's Statement
Administrative Measures for the Restriction of the Use of
Hazardous Substances in Electrical and Electronic Products
25 years
EAC
EAC Certificate
EAC EurAsian Conformity - Registration Russia, Kazakhstan and
Belarus

CP5.241, CP5.241-C1, CP5.241-S1,
CP5.241-S2, CP5.242
CP-Series 24V, 5A, 120W, SINGLE PHASE INPUT
Jul. 2019 / Rev. 1.0 DS-CP5.241-EN All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 5A output load,
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone [phone] Germany
20/29
21. PHYSICAL DIMENSIONS AND WEIGHT
Width 32mm 1.26’’
Height 124mm 4.88’’
Depth 102mm 4.02’’
The DIN-rail height must be added to the unit depth to calculate the total required
installation depth.
Weight 440g / 0.97lb
DIN-Rail Use 35mm DIN-rails according to EN 60715 or EN 50022 with a height of 7.5 or 15mm.
Housing material Body: Aluminium alloy
Cover: zinc-plated steel
Installation clearances See chapter 2
Penetration protection Small parts like screws, nuts, etc. with a diameter larger than 3.5mm
Fig. 21-1 Front view
CP5.241, CP5.241-S1 CP5.241-S2
CP5.241-C1,
CP5.242
Fig. 21-2 Side view
All dimensions in mm
All dimensions in mm
