Pulsar Axion 2 User manual

Axion 2
Manual

Content
Specifications
About the device
Description
Package Contents
Features
Components and Controls
Power supply
Precautions
Recommendations for Battery Use
Battery Charging
Battery Installation
External Power Supply
Getting Started
Powering on and Image Settings
Button Operation
Interface
Status Bar
Quick Menu
Main Menu
Enter the Main Menu
Colour Modes
Smoothing Filter
User Mode
Icon Brightness
PiP Mode
Wi-Fi Activation
Wi-Fi Settings
Microphone
Calibration Mode
General Settings
Defective Pixel Repair

Defective Pixel Repair
Restore Default Pixel Map
Device Information
Functions
Amplification Level
Video Recording and Photography
Discrete Digital Zoom
PiP Function
Display-Off Function
Wi-Fi Function
Stadiametric Rangefinder
Installing the Device on a Tripod
USB Connection
Software
Stream Vision 2
Firmware Update
Maintenance
Technical Inspection
Technical Maintenance and Storage
Troubleshooting
Legal Compliances and Disclaimers

Specifications
XQ35
Model XQ35
SKU 77478
Microbolometer 
Type uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame Rate, Hz 50
Optical
Characteristics 
Optical
Magnification, x 2
Smooth Digital
Zoom, x 2-8
Digital Zoom, x x1, x2, x4
Lens Focus, mm 35
Relative Aperture,
D/f' 1.0
Minimum Focus
Distance, m/y 5 / 5.47
Eye Relief
Diameter,
mm/inch 4 / 0.16

Angular Field of
View (Horizontal x
Vertical), degree 10.7х8
Linear Field of
View, m at 100 m 18.2
Eyepiece Focus
Range, Dioptre +4 / -5
Detection
Distance for Deer-
Sized Objects, m/y 1300 / 1422
Display 
Type AMOLED
Resolution, Pixels 640x400
Operational
Characteristics 
Power Supply, V 3 - 4.2
Battery
Type/Capacity/Nominal
Output Voltage
APS 5 Li-ion Battery Pack / 4900 mAh / DC
3.7 V
External Power
Supply 5 V, 9 V (USB Type-C)
Battery Run Time
at t=22°C, hours* 11
Degree of
Protection, IP
Code (IEC60529) IPX7
Operating
Temperature
Range, °C / °F -25 … +40 / -13 – +104
Dimensions,
mm/inch 152x50x74 / 5.98x1.97x2.91

Weight (without
battery), kg/oz 0.3 / 10.58
Video Recorder 
Photo/Video
Resolution, Pixels 528x400
Video/Photo
Format .mp4 / .jpg
Built-in Memory 16 GB
Wi-Fi Channel** 
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac
* Actual battery life may vary depending on the use of Wi-Fi and the built-in
video recorder.
** Reception range may vary depending on various factors: obstacles, other
Wi-Fi networks.

XG35
Model XG35
SKU 77476
Microbolometer 
Type uncooled
Resolution, Pixels 640x480
Pixel Pitch, µm 12
Frame Rate, Hz 50
Optical
Characteristics 
Optical
Magnification, x 2.5
Smooth Digital
Zoom, x 2.5-20
Digital Zoom, x x1, x2, x4, x8
Lens Focus, mm 35
Relative Aperture,
D/f' 1.0
Minimum Focus
Distance, m/y 5 / 5.47
Eye Relief
Diameter,
mm/inch 4 / 0.16
Angular Field of
View (Horizontal x
Vertical), degree 12.5х9.4
Linear Field of
View, m at 100 m 21.9
Eyepiece Focus
Range, Dioptre +4 / -5

Detection
Distance for Deer-
Sized Objects, m/y 1750 / 1914
Display 
Type AMOLED
Resolution, Pixels 1024x768
Operational
Characteristics 
Power Supply, V 3 - 4.2
Battery
Type/Capacity/Nominal
Output Voltage
APS 5 Li-ion Battery Pack / 4900 mAh / DC
3.7 V
External Power
Supply 5 V, 9 V (USB Type-C)
Battery Run Time
at t=22°C, hours* 7
Degree of
Protection, IP
Code (IEC60529) IPX7
Operating
Temperature
Range, °C / °F -25 … +40 / -13 – +104
Dimensions,
mm/inch 152x50x74 / 5.98x1.97x2.91
Weight (without
battery), kg/oz 0.3 / 10.58
Video Recorder 
Photo/Video
Resolution, Pixels 1024x768
Video/Photo
Format .mp4 / .jpg

Built-in Memory 16 GB
Wi-Fi Channel** 
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac
* Actual battery life may vary depending on the use of Wi-Fi and the built-in
video recorder.
** Reception range may vary depending on various factors: obstacles, other
Wi-Fi networks.

Description
Axion 2thermal imaging monoculars are designed for use both at night-
time and during the day and provide exceptional image quality even in
adverse weather conditions (fog, smog, rain) and beyond obstacles like
branches, tall grass, dense foliage, etc. known to hinder target detection.
Unlike night-vision devices based on electron-optical converters, thermal
imaging devices do not need an external light source and are resistant to
bright light.
Axion 2thermal imagers are designed for various applications including
hunting, observation, security, terrain orientation, search and rescue
operations, etc.
To get started, see the sections:
Battery Charging
Battery Installation
Powering on and Image Setting

Package Contents
Axion 2 thermal monocular
APS 5 rechargeable battery
2 battery-locking covers
Power adapter
USB Type-C cable
Carrying case
Hand strap
Quick reference user manual
Lens cleaning cloth
Warranty information
Tripod adapter

Features
Compact and lightweight
Functional and ergonomic design
8-colour display palette
3 calibration modes: Manual, Semi-Automatic, Automatic
Three levels of sensitivity enhancement: Normal, High, Ultra
Stadiametric Rangefinder
Display-Off function
Defective pixel repair
Updatable firmware
Wide operating temperature range (-25°С to +40°С / -13°F to +104°F)
Fully waterproof (IPX7 rated)
Tripod mount
Video/Audio Recording
Built-in video and sound recorder
Integration with iOS and Android devices
Wi-Fi remote control and viewing using a smartphone
Storing photos and videos in Cloud when using the Stream Vision 2 App
Battery Pack
Quick Change Li-Ion Battery Pack APS 5
Charging from USB Power Bank
Quick-Charge power delivery󰾬

Components and Controls

1. Eyepiece focus ring
2. LED indicator
3. DOWN/REC button
4. MENU button
5. UP/ZOOM button
6. Power ON/OFF/CALIBRATION button
7. Lens focus ring
8. Lens cover
9. USB Type-C connector

10. Tripod adapter socket
LED indicator (2) displays the current status of the device:
LED Indicator Operating Mode
Device is turned on
The device is turned on/video
recording
The device is turned on/battery
charge < 10%
The device is turned on/video
recording/battery charge <
10%

Precautions
Always use the APS 5 charger (purchased separately) to charge APS 5
batteries. Using an unsuitable charger can cause irreparable damage to
the battery and fire.
Do not charge the battery immediately after exposure to a cold
environment. Let the battery warm for at least 30 minutes before
charging.
Do not leave the battery unattended while charging.
Do not use the charger if it has been modified or damaged.
Do not leave the battery in a plugged-in charger after charging is
complete.
Do not expose the battery to high temperatures or open flames.
Do not use the battery as a power source for devices that do not support
APS 5 batteries.
Do not disassemble or deform the battery or charger.
Do not drop or strike the battery or charger.
Protect the battery and charger from water and moisture.
Keep the battery out of the reach of children.

Recommendations for
Battery Use
The batteries should be partially charged (50 to 80 %) for long-term
storage.
Charge at an ambient temperature of 0°C to +35°C (32°F to 95°F) or
the lifespan of the battery will decrease significantly.
Using the battery at sub 0°C (<32°F) ambient temperature decreases
battery capacity. This is normal and not a defect.
Using the battery at temperatures outside the range of -25°C to +40°C (-
13°F to 104°F) may reduce battery life.
The battery is short-circuit protected. Any situation that may cause
short-circuiting should be avoided.

Battery Charging
The Axion 2thermal imager comes with an APS 5 rechargeable Lithium-ion
battery. APS 5 batteries support USB Power Delivery fast charging
technology when using a standard charging set (charger*, USB Type-C
cable, power adapter). Before first use, make sure the battery is fully
charged.
Option 1

Image not found or type unknown

Image not found or type unknown

1. Install the APS 5 battery (11) in the battery compartment (13) of the
device.
2. Connect the USB cable (17) to the USB Type-C connector (9) of the
