Pulsar V658 User manual

CAL. V658
CHRONOGRAPH
TIME
CHRONOGRAPH
●Hour, minute and second hands
●Measures up to 60 minutes in 1/10 second increments.
●Split time measurement
ENGLISH

2
English
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
a: Normal position b: Extended position
CHRONOGRAPH
second hand
DISPLAY AND CROWN/BUTTONS
CHRONOGRAPH
minute hand
Second hand
Minute hand
CHRONOGRAPH
1/10-second hand
Hour hand
CROWN
a b
A
B

3
English
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2TurnCrownclockwisewhilepressingitlightly
until tight.
Unlocking the crown

4
English
●Before setting the time, be sure to check that the CHRONOGRAPH hands are in
“0” position when the chronograph is reset. (For resetting the chronograph, see
“CHRONOGRAPH” on page 6)
ADJUSTING CHRONOGRAPH HAND POSITION
Pull out.
Push back in to normal
position.
Press repeatedly to reset
CHRONOGRAPH 1/10-
second hand to “0” position.
BPress repeatedly to reset
CHRONOGRAPH second
and minute hands to “0”
position.
A
▲
▲
▲
CROWN
CROWN
* If any of the CHRONOGRAPH hands do not return to “0” position, follow the
procedure below to reset the hands.
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
B
A
CROWN

5
English
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
TIME SETTING
1Pull out when Second hand is at the 12 o’clock position.
2Turn to set Hour and Minute hands.
3Push back in to normal position in accordance with a time signal.
CROWN
1
2
3

6
English
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
CHRONOGRAPH
CHRONOGRAPH
minute hand
✩After the measurement exceeds 1 minute, the CHRONOGRAPH 1/10-
second hand stays at “0” position.
When the measurement is stopped, it will move to indicate the elapsed 1/10
seconds.
CHRONOGRAPH
1/10-second hand
✩AStart / Stop / Restart
BReset /
Split /Split release
Ex.: 15 minutes and 10.6 seconds
CHRONOGRAPH
second hand

7
English
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
1Use the chronograph to
determine how many seconds it
takes to go 1 km or 1 mile.
2Locate the second marker on the
main dial that corresponds to the
measured seconds, and the
tachymeterscaleitindicatesgives
the average speed per hour.
TACHYMETER
[for models with tachymeter scale on the dial]
To measure the hourly average speed of a vehicle
Ex. 1
“90” (tachymeter scale figure) x
1 (km or mile) = 90 km/h or mph
Tachymeter
scale: “90”
Tachymeter scale can be used only when the time required is less than 60 seconds.
Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to
0.5 km or miles and CHRONOGRAPH second hand indicates “90” on
CHRONOGRAPH
second hand:
40 seconds
▲

8
English
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
To measure the hourly rate of operation
1Use the chronograph to measure
the time required to complete 1
job.
2Locate the second marker on the
main dial that corresponds to the
measured seconds, and the
tachymeter scale it indicates gives
the average number of jobs
accomplished per hour.
Ex. 1
“180” (tachymeter scale figure) x
1 job = 180 jobs/hour
Ex. 2: If 15 jobs are completed in 20 seconds:
“180” (tachymeter scale figure) x 15 jobs = 2700 jobs/hour
tachymeter scale:
“90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph
“90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph
CHRONOGRAPH
second hand:
20 seconds
Tachymeter
scale: “180”
▲

9
English
ADJUSTING CHRONOGRAPH HAND POSITION
●The “0”position of the CHRONOGRAPH 1/10-second hand differs depending on the
models.
NOTES ON OPERATING THE WATCH
●The CHRONOGRAPH minute hand moves correspondingly with the CHRONOGRAPH
second hand.
●The hands move quickly if the respective buttons are kept pressed.
TIME SETTING
* Some models have the “0”position of the CHRONOGRAPH 1/10-second hand at 3
and 9 o’clock sides of the small dial. In that case, check if the hand is level with its
both ends pointing to those “0”positions.
●When setting the minute hand, first advance it 4 to 5 minute ahead of the desired time
and then turn it back to the exact minute.
●While the crown is at the extended position, do not press the buttons. Otherwise, the
CHRONOGRAPH hands will move. To reset them to “0”position, see “ADJUSTING
CHRONOGRAPH HAND POSITION”on page 4.
CHRONOGRAPH
●While the chronograph is counting, do not pull out the crown to set the time. Otherwise,
the chronograph operation cannot be made.

10
English
●The CHRONOGRAPH 1/10-second scale and hand differ in design and shape depending
on the models.
* Some models have the CHRONOGRAPH 1/10-second scale graduated on the upper
half of the small dial and the hand which is so designed that both ends can indicate
the elapsed 1/10 second. In that case, read the marker on the scale where either end
of the hand points to.
BATTERY CHANGE
Battery life : Approx. 2 years
Battery : SEIKO SR920SW
2
Years
● If the chronograph is used for more than 60 minutes a day, the battery life may be less
than the specified period.
● As the battery is inserted at the factory to check the function and performance of the
watch, its actual life once in your possession may be less than the specified period.
● When the battery expires, be sure to replace it as soon as possible to prevent any
malfunction.

11
English
5
10
15
20
25
35
40
50
55
1/10
MIN.
SEC.
SEC.
● We recommend that you contact an AUTHORIZED PULSAR DEALER for battery
replacement.
●Necessary procedure after battery change
After the battery is replaced with a new one, or in case any of the hands should move
improperly, follow the procedure below to reset the hands to “0” position.
Aand BPress and hold at the same
time for 2 seconds.
*
▲
APress repeatedly to reset
CHRONOGRAPH 1/10-
second hand to “0” position.
**
▲
Press repeatedly to reset
CHRONOGRAPHsecondand
minute hands to “0” position.
**
B
▲
Pull out.
▲
CROWN
Turn to set the time.
CROWN
▲
A
B

12
English
▲
Push back in to normal
position.
CROWN
* The CHRONOGRAPH second hand turns half a circle counterclockwise and then
returns where it was. The CHRONOGRAPH 1/10-second hand turns a full circle
clockwise and stops.
** The hands move quickly if the respective buttons are kept pressed.
WARNING
●Do not remove the battery from the watch.
●If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
●Never short-circuit, tamper with or heat the battery, and never expose
it to fire. The battery may burst, become very hot or catch fire.
CAUTION
●The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.

13
English
TO PRESERVE THE QUALITY OF YOUR WATCH
●Non-water resistant
• If the watch becomes wet, have it checked by an AUTHORIZED
PULSAR DEALER or SERVICE CENTER.
●Water resistant 5/10/15/20 bar
• Before using in water, be sure the crown is pushed in completely.
• Do not operate the crown and buttons when the watch is wet or in
water. If used in sea water, rinse the watch in fresh water and dry it
completely.
• When taking a shower with the water resistant 5 bar watch, or
taking a bath with the water resistant 10, 15 or 20 bar watch, be
sure to observe the following:
* Do not operate the crown or push the buttons when the watch is
wet with soapy water or shampoo.
* If the watch is left in warm water, a slight time loss or gain may
be caused. This condition, however, will be corrected when the
watch returns to normal temperature.
5 bar WR
10/15/20
bar WR
WATER RESISTANCE

14
English
* Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the pressure
at a given depth. Care should also be taken on diving into water.
** We recommend that you wear a PULSAR Diver’s Watch for scuba diving.
Your watch will be
adversely affected by
strong magnetism. Keep
it away from close contact
with magnetic objects.
Temperatures over 50°C (122°F)
may cause battery leakage or shorten
the battery life. Do not leave your
watch in very low temperatures below
–5°C(+23°F) for a long time since
the cold may cause a slight time loss
or gain.
However, the above conditions will
be corrected when the watch returns
to normal temperature.
Your watch works with
stable accuracy within a
temperature range of 5°
C and 35°C (41°F and
95°F). NS
To prevent possible
rusting of the case and
bracelet caused by dust,
moisture and perspiration,
wipe them periodically
with a soft dry cloth.
TEMPERATURES MAGNETISM
CARE OF CASE AND BRACELET
+50°C
-5°C

15
English
Light activities will not
affect your watch, but be
careful not to drop your
watch or hit it against hard
surfaces, as this may
cause damage.
It is recommended that the
watch be checked once
every 2 to 3 years. Have
your watch checked by an
AUTHORIZED PULSAR
Be careful not to expose
the watch to solvents,
mercury, cosmetic spray,
detergents, adhesives or
paints. Otherwise, the
case, bracelet, etc. may become
discolored, deteriorated or damaged.
DEALER or SERVICE CENTER to
ensure that the case, crown, buttons,
gasket and crystal seal remain intact.
If your watch has a
protective film and/or a
sticker on the case back,
be sure to peel them off
before using your watch.
2 - 3
Years
SHOCKS & VIBRATION
CHEMICALS
PERIODIC CHECK
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
