Pulsar W510 User manual

CAL. W510
DIGITAL QUARTZ
●Time/calendar
●Single-time alarm
●Regular alarm
●Illuminating light
(electroluminescent panel)

2
MODE CHANGE
AWith each press, the mode changes in the following order:
➡➡
TIME/
CALENDAR
➡
SINGLE-TIME
ALARM REGULAR ALARM
A

3
TIME/CALENDAR MODE
TIME/CALENDAR SETTING
APress to show TIME/
CALENDAR mode.
A
▲
Press for 2 to 3 seconds.
▲
C
▲
Select the digits to be
adjusted.✽
D
▲
Set the flashing digits.
▲
AReturn to TIME/CALENDAR
mode.
AD
C
Minutes
Hour

4
✽Selection of the digits
* If the flashing “ –– ”is shown in the middle row of the display, the digits indicate the
time, and otherwise, they indicate the calendar.
Minutes Hour Month Date
▲
▲
▲
▲
C
Month
Date
CPress and hold in TIME/
CALENDAR mode.
* While the button is kept pressed,
the month and date are displayed.
SHOWING THE CALENDAR DISPLAY

5
SINGLE-TIME ALARM MODE
●The single-time alarm can be set to ring only once at the designated time. As it
rings, it is automatically disengaged.
●The single-time alarm can be set in minute increments starting from the current
time.
SINGLE-TIME ALARM SETTING
A
▲
Press to show SINGLE-TIME
ALARM mode.
C
A
D
or
Return to TIME/CALENDAR
mode.
Set the desired alarm time.
▲
* The single-time alarm mark “1-
AL”remains displayed and the
single-time alarm is engaged.
A D
C
Hour
Minutes

6
* At the designated time, the single-time alarm rings for 20 seconds. To stop it manually,
press any of the buttons.
●To cancel the single-time alarm you have set, press buttons C and D at the same
time in the SINGLE-TIME ALARM mode, or press button C or D to set the alarm
time to the current time.

7
REGULAR ALARM MODE
●The regular alarm can be set to ring on a 24-hour basis.
REGULAR ALARM SETTING
A
▲
C
A
D
or
Return to REGULAR ALARM
mode.
Set the desired alarm time.
▲
Press for 2 to 3 seconds.
* The regular alarm mark is
automatically displayed and the
regular alarm is engaged.
A D
C
APress to show REGULAR ALARM mode.
Minutes
Hour
Regular alarm
mark

8
C
ENGAGEMENT/DISENGAGEMENT OF
REGULAR ALARM AND HOURLY TIME SIGNAL
With each press in REGULAR ALARM
mode,theengagement/disengagement
of the regular alarm and hourly time
signal are made as follows:
Both engaged
Regular alarm engaged
Neither engaged
Hourly time signal engaged
C
▲
▲
▲
▲
* At the designated time, the regular alarm rings for 20 seconds. To stop it manually,
press any of the buttons.
Regular alarm mark
Hourly time signal mark

9
ILLUMINATING LIGHT (Electroluminescent panel)
BTurn on the illuminating light.
* The display panel is evenly illuminated
for 3 seconds.
●is a new type of liquid crystal panel that makes possible various
colors and high contrast.
●Excellent light reflection and transmission make the display bright and clear.
●Various color options are available.
●Either the whole panel or the displayed data only can be illuminated.
* Features vary in different models.
ViViDiGi
B

10
NOTES ON USING THE WATCH
MODE CHANGE
●The displayed numerals have unique forms. The positions where they are shown on the
display, therefore, shift between both sides of the display, depending on the numeral
shown.
●If the watch is left untouched in the SINGLE-TIME ALARM and REGULAR ALARM
mode, it will automatically return to the TIME/CALENDAR mode in 2 to 3 minutes.
TIME/CALENDAR MODE
[TIME/CALENDAR SETTING]
●The calendar automatically adjusts for odd and even months except February of leap
years.
●Setting the seconds:
The second digits are not shown on the display. To set the seconds accurately, follow
the procedure below.
1) While the minute digits are flashing, set them to one minute ahead of the current
minutes.
2) Press button “A”in accordance with a time signal of the set minutes. The watch
returns to the TIME/CALENDAR mode, and the seconds are reset to “00”and start
counting immediately.
●The flashing digits move quickly if button D is kept pressed.
●When setting the hour digits, check that AM/PM is properly set. Only the “PM”mark
