Pulsar VK63 User manual

CAL. VK63, VK67, VK73
CHRONOGRAPH
ENGLISH
TIME/CALENDAR
CHRONOGRAPH
lHour and minute hands with small second hand
lSmall 24-hour hand (VK63 & VK73 only)
lDate displayed in numerals
lMeasures up to 60 minutes or 12 hours in 1/5 second
increments

English
English
32 a: Normal position c: Second click
a b c
b: First click
DISPLAY AND CROWN/BUTTONS
CROWN
B
CHRONOGRAPH
minute hand
Small second
hand
A
Minute hand
CHRONOGRAPH
1/5-second hand
Hour hand
24-hour hand
Date
a: Normal position c: Second clickb: First click
[VK63] [VK67]
60
8
10
20
30
40
50
60
30
15
45
6
3
9
12
23
24
12
6
18
60
10
20
30
40
50
60
30
15
45
a b c
CROWN
B
CHRONOGRAPH
hour hand
Small second
hand
A
Minute hand
CHRONOGRAPH
1/5-second hand
Hour hand
Date
CHRONOGRAPH
minute hand

English
English
54
24
12
6
18
60
10
20
30
40
50
60
30
15
45
2 8
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2Turn Crown clockwise while pressing it
lightly until tight.
Unlocking the crown
a: Normal position c: Second click
a b c
b: First click
CROWN
B
CHRONOGRAPH
minute hand
Small second
hand
A
Minute hand
CHRONOGRAPH
1/5-second hand
Hour hand
24-hour hand
Date
[VK73]

English
English
76
TIME/CALENDAR SETTING
1 2
3
4
5
1 Pullouttorstclick,andturnclockwiseuntilthepreviousday’sdateappears.
2 PullouttosecondclickwhenSmallsecondhandisatthe12o’clockposition.
3Turn clockwise until the desired date appears.
4Turn to set Hour and Minute hands.
5Push back in to normal position in accordance with a time signal.
CROWN
CHRONOGRAPH
CHRONOGRAPH
minute hand
CHRONOGRAPH
1/5-second hand
AStart / Stop /
Restart
BReset
l The chronograph can measure up to 60 minutes in 1/5 second increments.
(VK67 can measure up to 12 hours.)
lAfter60minutes,thechronographwillstopcounting.
(VK67 will stop counting after 12 hours.)
l Beforeusingthechronograph,besuretocheckthatthecrownissetatthenormal
position and that the CHRONOGRAPH hands are reset to the “0” position.
23
60
30
15
45
Small second
hand Date
[VK63 & VK73] [VK67]
60
10
20
30
40
50
60
10
20
30
40
50
6
3
9
12
A
B
CHRONOGRAPH
minute hand
CHRONOGRAPH
hour hand
(VK 67 only)

English
English
98
60
10
20
30
40
50
23
Standard measurement
START
s
A
STOP
s
B
RESET
Accumulated elapsed time measurement
A
START
s
A
STOP
s
A
s
RESTART STOP
s
B
RESET
A
A
*If the CHRONOGRAPH hands are incorrectly positioned, follow the procedure
below to reset the hands to the "0" position.
START
s
A
STOP
s
B
RESET
A
1 Use the stopwatch to determine
how many seconds it takes to go 1
km or 1 mile.
2 Locate the second marker on
the main dial that corresponds to
the measured seconds, and the
tachymeter scale it indicates
gives the average speed per
hour.
TACHYMETER
[for models with tachymeter scale on the dial]
To measure the hourly average speed of a vehicle
“90”(tachymeterscalegure)x
1 (km or mile) = 90 km/h or mph
Tachymeter
scale: “90”
Tachymeter scale can be used only when the time required is less than 60 seconds.
Ex. 1: If the measuring distance is extended to 2 km or miles or shortened
to 0.5 km or miles and CHRONOGRAPH second hand indicates “90”
CHRONOGRAPH
second hand:
40 seconds
s
Ex. 1

English
English
1110
60
10
20
30
40
50
23
Ex. 2
To measure the hourly rate of operation
1 Use the stopwatch to measure the
time required to complete 1 job.
2
Locate the second marker on
the main dial that corresponds
to the measured seconds, and
the tachymeter scale it indicates
gives the average number of
jobs accomplished per hour.
s
“180”(tachymeterscalegure)x
1 job = 180 jobs/hour
CHRONOGRAPH
second hand:
20 seconds
Tachymeter
scale : “180”
Ex. 2: If 15 jobs are completed in 20 seconds:
“180”(tachymeterscalegure)x15jobs=2700jobs/hour
on tachymeter scale:
“90”(tachymeterscalegure)x2(kmormile)=180km/hormph
“90”(tachymeterscalegure)x0.5(kmormile)=45km/hormph
NOTES ON OPERATING THE WATCH
TIME SETTING
lIt is necessary to adjust the date on the first day after a 30-day month and
February.
lDo not set the date between 9:00 p.m. and 3:00 a.m, as this will cause a
malfunction.
CALENDAR SETTING
lIf the crown is pulled out to the second click while the chronograph is counting,
the CHRONOGRAPH hands will continue to move. This is not a malfunction.
lWhen setting the minute hand, first advance it 4 to 5 minute ahead of the
desired time and then turn it back to the exact minute.
24-hour setting (VK63 & VK73 only)
lThe 24-hour hand moves correspondingly with the hour and minute hands.
lWhen setting the hour hand, check that the 24-hour hand is correctly set.
CHRONOGRAPH
lRestart and stop of the chronograph can be repeated as many times as
necessary by pressing button A.

English
English
1312
BATTERY CHANGE
Battery life : Approx. 3 years
Battery : SEIKO SR936SW
3
Years
lIf the chronograph is used for more than 60 minutes a day, the battery life may
be less than the specified period.
lAs the battery is inserted at the factory to check the function and performance of
the watch, its actual life once in your possession may be less than the specified
period.
lWhen the battery expires, be sure to replace it as soon as possible to prevent
any malfunction.
lWe recommend that you contact an AUTHORIZED PULSAR DEALER for battery
replacement.
WARNING
lDo not remove the battery from the watch.
lIf it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
lNever short-circuit, tamper with or heat the battery, and never
expose it to re. The battery may burst, become very hot or catch
re.
CAUTION
l The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.

English
English
1514
TO PRESERVE THE QUALITY OF YOUR WATCH
WATER RESISTANCE
lNon-water resistant
lWater resistance (5 bar)*
If “WATER RESISTANT 5 BAR”
isinscribedonthecaseback,
your watch is designed and
manufactured to withstand
up to 5 bar and is suitable for swim-
ming,yachtingandtakingashower.
If “WATER RESISTANT 10
BAR”,“WATERRESISTANT15
BAR” or “WATER RESISTANT
20 BAR” is inscribed on the
lWater resistance (10 bar/15 bar/20 bar)*
case back, your watch is designed and
manufactured to withstand up to 10 bar/15
bar/20barandissuitablefortakingabath,
shallow diving, but not for scuba diving.
We recommend that you wear a PULSAR
Diver’swatchforscubadiving.
If “WATER RESISTANT” is
not inscribed on the case
back, your watch is not water
resistant, and care should be
If “WATER RESISTANT” is
inscribed on the case back,
your watch is designed and
manufactured to withstand
lWater resistance (3 bar)
up to 3 bar, such as accidental contact
withsplashesofwaterorrain,butitisnot
designedforswimmingordiving.
taken not to get it wet as water may dam-
agethemovement.Ifthewatchbecomes
wet, we suggest that you have it checked
by an AUTHORIZED PULSAR DEALER or
SERVICE CENTER.
*Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the
crown is pushed in completely.
Do not operate the crown when the watch is wet or in water. If used in sea water,
rinse the watch in fresh water and dry it completely.
*When taking a shower with the water resistance 5 bar watch, or taking a bath with
the water resistance 10, 15 or 20 bar watch, be sure to observe the following:
•Do not operate the crown when the watch is wet.
•If the watch is left in warm water, a slight time loss or gain may be caused.
This condition, however, will be corrected when the watch returns to normal
temperature.
NOTE:
Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the pressure
at a given depth. Care should also be taken on diving into water.
TEMPERATURES
50° C (122° F) may cause battery
Your watch works with
stable accuracy within a
temperature range of 5° C
and 35° C (41° F and 95°
F). Temperatures over
leakage or shorten the battery life.
Do not leave your watch in very low
temperatures below –5° C (+23° F) for
a long time since the cold may cause a
slighttimelossorgain.However, the
above conditions will be corrected
when the watch returns to normal
temperature.

English
16
CARE OF CASE AND BRACELET
To prevent possible rusting
of the case and bracelet
caused by dust, moisture
and perspiration, wipe them
periodically with a soft dry
cloth.
Light activities will not affect
yourwatch,butbe carefulnot
to drop your watch or hit it
against hard surfaces, as this
may cause damage.
SHOCKS & VIBRATION
Be careful not to expose the
watch to solvents, mercury,
cosmetic spray, detergents,
adhesives or paints. Other-
wise, the case, bracelet,
etc.maybecomediscolored,
deteriorated or damaged.
CHEMICALS
Your watch will be adversely
affected by strong magnetism.
Keep it away from close contact
with magnetic objects.
MAGNETISM
It is recommended that the
watch be checked once every
2 to 3 years. Have your watch
checked by an AUTHORIZED
PULSAR DEALER or SERVICE
PERIODIC CHECK
CENTER to ensure that the case, crown,
buttons, gasket and crystal seal remain
intact.
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
If your watch has a protective
lmand/orastickeronthecase
back, be sure to peel them off
before using your watch.
