Pulsar PJU Series User manual

5-93 Printed in Japan
EFSGIP – A22
(E.F.S.G.I.P.)
GEBRAUCHSANWEISUNGEN
UND GARANTIE FÜR EUROPA /
OZEANIEN
ISTRUZIONI E GARANZIA
PER EUROPA / OCEANIA
INSTRUÇÕES E GARANTIA PARA A
EUROPA / OCEÂNIA
INSTRUCTIONS AND GUARANTEE
FOR EUROPE / OCEANIA
INSTRUCTIONS ET GARANTIE
POUR L’EUROPE / OCEANIE
INSTRUCCIONES Y GARANTIA
PARA EUROPA / OCEANIA
ANALOGUE TYPE
Series PJU (Cal. V656)

ES – A22
ANALOGUE TYPE
INSTRUCTIONS AND
LIMITED THREE-YEAR WARRANTY
Series PJU & PJN (Cal. V656, V657)
INSTRUCCIONES Y
GARANTIA LIMITADA
POR TRES AÑOS
3-94 Printed in Japan
(E.S.)

EF – A22
ANALOGUE TYPE
Series PJU (Cal. V656)
5-93
(E.F.)
Printed in Japan
Imprimé au Japon
INSTRUCTIONS AND THREE-YEAR WARRANTY
FOR CANADA
INSTRUCTIONS ET GARANTIE TROIS ANS
POUR CANADA

PULSAR ANALOGUE QUARTZ
WITH CHRONOGRAPH FUNCTION
Cal. V656, V657
FEATURES
There are two buttons and a crown as indicated in the
illustration below.
[Cal. V656]
DISPLAYS AND CROWN OPERATION
This is a multi-display analogue watch featuring a chronograph
function.
The measured time is indicated by the small chronograph hands
that move independently of the center hands.
■TIME
Cal. V656 : Hour, minute, second and 24-hour hands.
Cal. V657 : Hour, minute and second hands.
■CALENDAR (for Cal. V657)
Date is displayed in numerals.
■CHRONOGRAPH
It can measure up to 60 minutes in 1/10 seconds.
Split time measurement is also possible.
Chronograph 1/10-
second hand
Hour hand
Chronograph
minute hand
Second
hand
Minute hand
A
a b
Crown
B
(a) Normal position : Free
(b) Extended position :
• Setting the hour, minute and 24-hour hands.
• Activating the chronograph hand position adjusting function.
Crown operation
24-hour hand
Chronograph second hand

• If any of the chronograph hands do not return to the “0” position
when the chronograph is reset, follow the procedure below to
reset the hands.
ADJUSTING THE CHRONOGRAPH HAND POSITION
Before setting the time, be sure to check if the chronograph
hands are in the “0” position when the chronograph is reset.
Note: The “0” position of the chronograph 1/10 second hand
differs depending on the models.
* Some models have the “0” position of the chronograph
1/10 second hand at 3 and 9 o’clock sides of the small
dial. In that case, check if the hand is level with its both
ends pointing to those “0” positions.
* If the chronograph is in use, press the buttons in the following
order to reset it, and then check if the hands return to the “0”
position. (For details, refer to “CHRONOGRAPH”.)
•If the chronograph is counting : A →B
•If the chronograph is stopped : B
•If the split time is displayed : B →A →B
Chronograph 1/10-
second hand A
[Cal. V657]
(a) Normal position : Free
(b) First click : Date setting
(c) Second click :
• Setting the hour and minute hands.
• Activating the chronograph hand position adjusting function.
Crown operation
Chronograph second hand
BDate
Crown
a b c
Minute hand
Second hand
Chronograph
minute hand
Hour hand

TIME/CALENDAR SETTING
Note: While the crown is at the extended position (Cal. V656) or
at the second click (Cal. V657), do not press any button.
Otherwise, the chronograph hands will move. To reset
them to the “0” position, refer to“ADJUSTING THE CHRONOGRAPH
HAND POSITION”.
B
A
Second hand
[Cal. V656] [Cal. V657]
B
A
Second
click
()
1. Pull out the crown all the way.
2. Press “A” repeatedly to reset the chronograph 1/10 second
hand to the “0” position. Press “B” repeatedly to reset the
chronograph second and minute hands to the “0” position.
* The chronograph minute hand moves correspondingly with
the chronograph second hand.
* The hands move quickly if the respective buttons are kept
pressed.
3. Push the crown back in to the normal position.
BB
AA
[Cal. V656] [Cal. V657]
Crown
Extended
position
()
Crown
Second
click
()Second
hand
Minute hand
Crown
First
click
()
Date
Crown
Extended
position
()
24-hour hand
Hour hand

1. Pull out the crown when the second hand is at the 12 o’clock
position. The second hand will stop on the spot.
2. Turn the crown clockwise or counterclockwise to set the hour,
minute and 24-hour hands to the desired time.
* When setting the hour hand, be sure to check that the 24-
hour hand is set properly.
3. Push the crown back in to the normal position in accordance
with a time signal.
Time setting for Cal. V656
Time/calendar setting for Cal. V657
1. Pull out the crown to the first click, and turn it clockwise until
the previous day’s date appears.
* Do not set the date between 9:00 p.m. and 1:00 a.m. Otherwise,
the date may not change properly.
2. Pull out the crown to the second click when the second hand is
at the 12 o’clock position. The second hand will stop on the
spot.
3. Turn the crown clockwise until the desired date appears, and
set the hour and minute hands to the desired time.
* When setting the hour hand, be sure to check that AM/PM is
correctly set. The watch is so designed that the date changes
once in 24 hours. Turn the hands past the 12 o’clock marker
to determine whether the watch is set for the A.M. or P.M.
period. If the date changes, the time is set for the A.M.
period. If it does not change, the time is set for the P.M.
period.
4. Push the crown back in to the normal position in accordance
with a time signal.
Note: When setting the minute hand, first advance it 4 to 5
minutes ahead of the desired time and then turn it back to
the exact minute.

1. Standard measurement
To start : Press “A”.
To stop : Press “A”.
To reset to “0” : Press “B”.
2. Accumulated elapsed time measurement
To start : Press “A”.
To stop : Press “A”.
To restart : Press “A”.
Chronograph operation
A
B
CHRONOGRAPH
The chronograph can measure up to 60 minutes in 1/10 seconds.
The measured time is indicated by the small chronograph hands
that move independently of the center hands.
Note: While the chronograph is counting, do not pull out the
crown to set the time. Otherwise, the chronograph operation
cannot be made.
Ex.) Elapsed time measured is 15 minutes and 10.6 seconds :
How to read the hands
Chronograph
1/10-second hand A
B
Chronograph
minute hand Chronograph second hand
Crown
Normal
position )
(
• The chronograph 1/10 second scale and hand differ in design
and shape depending on the models.
* Some models have the chronograph 1/10 second scale graduated
on the upper half of the small dial and the hand which is so
designed that both ends can indicate the elapsed 1/10 second.
In that case, read the marker on the scale where either end of
the hand points to.
• After the measurement exceeds 1 minute, the chronograph 1⁄10
second hand stays at the “0” position.
When the measurement is stopped, it will move to indicate the
elapsed 1/10 seconds.

When the battery is replaced, the time information stored in the
built-in IC and the time indicated by the hands do not correspond
with each other. Before using the watch, therefore, be sure to
reset the hands to the “0” position, following the procedure below.
* In case any of the hands should move improperly, follow the
procedure below to adjust the hand movement.
NECESSARY OPERATION AFTER BATTERY CHANGE
A
[Cal. V656] [Cal. V657]
A
B
Crown
Extended
position
()B
Crown
Second
click
()
To stop : Press “A”.
To reset to “0” : Press “B”.
3. Split time measurement
To start : Press “A”.
To measure split time : Press “B”.
To release split time : Press “B”.
To stop : Press “A”.
To reset to “0” : Press “B”.

1. Pull out the crown all the way.
2. Keep “A” and “B” pressed at the same time for 2 seconds, and
then release the buttons. The chronograph second hand turns
half a circle counterclockwise and then returns where it was.
The chronograph 1/10 second hand turns a full circle clockwise
and stops.
3. Press “A” repeatedly to reset the chronograph 1/10 second
hand to the “0” position. Press “B” repeatedly to reset the
chronograph second and minute hands to the “0” position.
* The “0” position of the chronograph 1/10 second hand differs
depending on the models. (Some models have the “0” position
of the chronograph 1/10 second hand at 3 and 9 o’clock sides
of the small dial. In that case, check if the hand is level with
its both ends pointing to those “0” positions.)
* The chronograph minute hand moves correspondingly with
the chronograph second hand.
* The hands move quickly if the respective buttons are kept
pressed.
4. Turn the crown clockwise or counterclockwise to set the hour
and minute hands to the desired time. (For details, refer to
“TIME/CALENDAR SETTING”.)
5. Push the crown back in to the normal position.
TO PRESERVE THE QUALITY OF YOUR WATCH
Your watch contains a highly precise electronic circuit and a
crystal oscillator, and to maintain its high accuracy you should
not subject it to violent shocks or extreme temperatures.
Your watch is classified into one of the following four groups by
the degree of water resistance. Please read the appropriate item
below for proper use.
If your watch is water resistant, “WATER RESISTANT” is shown
on the back of your watch case. If your watch is 200 m, 100m or
50 m water resistant, it is so indicated on the dial. If your watch
is non-water resistant, there is no such indication.
Water resistant: These watches are designed to withstand
accidental contact with water, for example, splashes or rain, but
should not be worn while swimming or diving.
Water resistant (50 m/5 BAR): These watches are suitable
for swimming and can be worn in the shower, but not for diving.
If the watch is exposed to salt water, rinse it in fresh water and
then wipe it thoroughly dry.
Do not press any buttons or turn the crown when the watch is wet.

The miniature battery SEIKO SR920SW which powers your watch
should last approximately 2 years. However, because the battery
is inserted at the factory, its actual life once in your possession
may be less than the specified period.
Note: If the chronograph is used for more than 60 minutes a day,
battery life may be less than the specified period.
BATTERY CHANGE
Water resistant (100 m/10 BAR, 200 m/20 BAR): These
watches are suitable for swimming or skin diving (without heavy
breathing apparatus), but not for scuba diving. If the watch is
exposed to salt water, rinse it in fresh water and then wipe it
thoroughly dry.
Do not press any buttons or turn the crown when the watch is wet.
Non-water resistant: Care should be taken not to get your
watch wet as water may damage the movement.
•Have your Pulsar watch checked by a PULSAR DEALER periodi-
cally to be sure that the case, buttons, crown, gasket, crystal
seal and push pins remain intact.
