Pulsar w863 User manual

CAL. W863
DIGITAL QUARTZ
ENGLISH
lFull-panel dot-matrix liquid crystal panel
lTime/calendar
lStopwatch with memory recall function
lCountdown timer
l3-channel regular alarm
lWorld time
lIlluminating light (LED panel)
lAuto illumination

2 3
English
English
MODE CHANGE
B
AD
C
E
With each pressing, the mode in the digital display changes
in the following order:
ALARM
TIME/CALENDAR
(TIME)
STOPWATCH
(CHRONO)
TIMER
WORLD TIME
lSelection of a desired mode can be made by pressing and holding
button A for more than two seconds.
AUTO ILLUMINATION
DWith each pressing for more than 2 seconds in any mode, the
auto illumination can be set or cancelled.
A A
A
A
A
A
MEMORY
RECALL
A
ILLUMINATING LIGHT (LED PANEL)
Auto illumination mark
DPress to turn on the LED light.
The display panel is evenly illuminated for 2 seconds.
lIf set in advance, the display is illuminated for approximately 2
seconds with each press of any of the buttons (except pressing
buttons for adjusting items or digits).
The auto illumination cannot be set or
cancelled when either of the setting
displays is shown.

4 5
English
English
TIME/CALENDAR MODE (TIME) TIME/CALENDAR SETTING
Press and hold for 2 seconds to show TIME/CALENDAR
SETTING display.
A
s
lOnce the time/calendar of your area is set in the TIME/CALENDAR
mode, the times of the 33 cities in the WORLD TIME mode will be set
automatically.
Press until the watch enters TIME/CALENDAR mode. Press to select the digits to be adjusted.
Selection of the digits
SecondCity
12-/24-hour indication Year Month
Date
E
s
Set the ashing digits. (Increasing digits)
Set the ashing digits. (Decreasing digits)
C
B
or
s
AReturn to TIME/CALENDAR mode.
B
AD
C
Date
Minute
Month
Year
Day of the
week Minute Hour
➾ ➾➾ ➾
➾
➾
➾➾
A
Hour
Second
AM/PM mark
➾
DST
➾
Contrast level
adjustment
s
“TIME” is shown, and the
watch enters the TIME/
CALENDAR display in 2
seconds.
E

6 7
English
English
STOPWATCH MODE (CHRONO)
lThe stopwatch measures up to 9 hours, 59 minutes and 59.99 seconds
in 1/100 second increments.
Press until the watch enters STOPWATCH mode.
Start /
Stop /
Restart
C
E
Measure lap & split time
/ Reset
A
CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME
If the daylight saving time is effective in the selected city, press to
show the daylight saving time.
E
With each press of button E, the standard time and daylight saving time of
the city are alternatively shown.
A
Press to turn the key sound on or off.
C
The key sound can be heard by
pressing and holding buttons C
and E at the same time.
Key sound mark
KEY SOUND SETTING
s
“CHR” is shown, and the watch enters the STOPWATCH display
in 2 seconds.
Remaining memory capacity

8 9
English
English
CHANGEOVER BETWEEN LAP TIME AND SPLIT TIME
Press and hold for more than 2 seconds to change over Lap time and
Split time.
B
C
STOPWATCH OPERATION
Press to start the stopwatch.
E
Press to take a lap time.
Lap number
Lap time
LAP/SPLIT 1
ELAP/SPLIT 2
CPress to stop the stopwatch.
s
s
s
Split time
STOPWATCH
mark
While the stopwatch is measuring, STOPWATCH mark is flashing.
s
s
s
s
B
B

10 11
English
English
lTherst100lapandsplittimesareautomaticallystoredinmemory.
lThestoreddatacanberecalledeitherduringorafterthemeasurement.
BC
EChannel
number
A
MEMORY RECALL MODE
E
APressuntilthewatchentersMEMORYRECALLmode.
Total time Lap and Split times
with Lap number
Best lap time
Average
lap time
Channel
number
E E
E
E
Press to view the contents of the selected chanel data.
E
Show the desired channel
number.(Movesforward)
Show the desired channel
number.(Movesbackward)
C
B
or
s
s
When the best lap time is displayed, "BEST" and "L-** are alternately displayed.
Press and hold for 2 seconds to
delete the selected channel data.
A
Press and hold for 2 seconds
again to delete all the stored data.
A
HOW TO DELETE THE CHANNEL
s
s
Keep pressed for another 2 seconds.
A
s
After "F-100" is displayed, the watch au-
tomatically returns to MEMORY RECALL
display and "----" mark is displayed.
s
s
s
s
s
s

12 13
English
English
TIMER MODE
lThe timer can be set from 1 minute up to 59 minutes 59 seconds in
one-second increments.
Press to show TIMER mode.
B
D
C
A
Set time
A
TIMER SETTING
APress for 2 seconds to show TIMER SETTING display.
The minute digits start ashing.
s
Set the ashing digits. (Increasing digits)
Set the ashing digits. (Decreasing digits)
C
B
or
s
AReturn to TIMER mode.

14 15
English
English
TIMER OPERATION
l While the timer is counting, TIMER mark is flashing.
lWhen the set time is up, a warning sound beeps for 10 seconds. To stop it
manually, press any of the buttons.
CStart / Stop / Restart
Reset
Set time
ALARM MODE
lThe alarm can be set to ring daily at three different times per day.
Press until the watch enters ALARM mode.
B
D
C
Alarm channel
A
E
Timer mark
E
A

16 17
English
English
ALARM TIME SETTING
E
s
Press to select the desired alarm channel (from AL-1 to AL-3).
A
s
Press for 2 seconds to show ALARM SETTING display.
s
Press to select the digits to be adjusted (hour/minute).
E
s
Set the ashing digits. (Increasing digits)
Set the ashing digits. (Decreasing digits)
C
B
or
s
AReturn to ALARM mode.
“ON” and the alarm marks appear and the alarm is automatically
engaged.
ALARM ENGAGEMENT/DISENGAGEMENT
lThe alarms can be engaged and disengaged independently of one
another.
Press to select the desired alarm channel (from AL-1 to AL-3).
E
s
With each pressing, the selected alarm is engaged and disengaged
alternately.
C
At the designated time, the alarm rings for 20 seconds. To stop it
manually, press any of the buttons.
E
C
Alarm mark
“ON” markSet alarm time
Alarm channel

18 19
English
English
WORLD TIME MODE
lThe time of 33 cities in different time zones throughout the world can
be displayed.
Bor Press to select the desired city. C
Press to show WORLD TIME mode.
B
D
C
A
Current time of
selected city
City mark
DST mark
A
E
If the daylight saving time is effective in the selected city, press to
show the daylight saving time.
E
Press button E to return to the standard time.
GMT = Greenwich Mean Time
0
0
+ 1
G M T
L O N
P A R
Greenwich
London*
Paris*
TIME DIFFERENCES
(As of January 2012)
United Kingdom
United Kingdom
France
CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME
Country nameCity mark City name
GMT± (hours)
