Pulsar W650 User manual

CAL. W240, W620, W650
DIGITAL QUARTZ
●Time/calendar
●Stopwatch with 8 lap memory
●Countdown timer with preset and
adjustable timer functions
●Daily alarm
●Stroke function (Cal. W240, W620)
●Auto illumination function (Cal. W650)
●Electroluminescent panel

2
Mode mark
MODE CHANGE
Cal. W240, W620
(No mode mark in TIME/
CALENDAR mode)
Change modes A
STOPWATCH
➡
STROKE
ALARM
➡
➡
TIME/
CALENDAR
TIMER
➡
➡
Cal. W650
A
Mode mark
Change
modes
➡
➡
TIME/
CALENDAR
➡
STOPWATCH
➡
TIMER
ALARM

3
TIME/CALENDAR MODE
TIME/CALENDAR SETTING
Press for 2 to 3 seconds.
B
▲
CSelect the digits to be adjusted.
▲
DSet the flashing digits.
▲
▲
BReturn to TIME/CALENDAR
mode.
D
BC
Selection of the digits
Cal. W240, W620 Cal. W650
Seconds ➾Minutes ➾Hour ➾Date
➾
12-/24-hour indication Year Month
➾
➾
➾
➾Seconds ➾Minutes
AUTO ILLUMINATION
on/off
Hour
➾
➾➾
Date
12-/24-hour
indication
➾➾
Year Month
➾

4
AUTO ILLUMINATION FUNCTION (only for Cal. W650)
When the function is turned on:
●The display is illuminated with each press of a button to operate the watch.
●While the stopwatch or timer is counting, the display is illuminated every
minute to signal the lapse of time: For the first 19 minutes in the stopwatch
function and for the last 19 minutes in the timer function.
Press for 2 to 3 seconds.
B
▲
D
▲
B
Turn on/off the AUTO
ILLUMINATION FUNCTION.
The function
is on.
Return to TIME/CALENDAR mode.

5
STOPWATCH MODE
Lap time measurement
C
D
Start / Stop / Restart
Reset /
Measure lap time
▲
▲
▲
▲
C
START
D
LAP
D
LAP
D
RESET
C
STOP
Current time
B
Time measured

6
MEMORY RECALL FUNCTION
B
D
▲
B
▲
**In memory recall after measurement,
the oldest data in memory is displayed.
In memory recall during measurement,
the newest one is displayed.
D
B
●The stored data can be recalled either during or after the measurement.
Press to activate the memory
recall function.
**
With each press, stored data
are recalled from the oldest to
the newest.
Return to STOPWATCH mode.

7
STROKE MODE
(For Cal. W240 and W620)
●The number of strokes per minute is automatically calculated by measuring the
time required to make three strokes.
CPress to start measurement.
C
▲
CPress to stop measurement
when the third stroke is made.
* The number of strokes per minute
will be displayed.

8
TIMER MODE
PRESET TIMER SETTING
Select the preset time.
D
●Two types of timer are available: preset timer and adjustable timer.
* For Cal. W240 and W620, 9 different
lengths of time have been preset
for the timer.
For Cal. W650, 4 different lengths
of time have been preset for the
timer.
BC
D
Selection of the preset time/adjustable timer
Cal. W240, W620 Cal. W650
3 min. ➾5 min. ➾10 min. ➾15 min. ➾20 min.
45 min. 40 min. 35 min. 30 min.
➾
➾
➾
➾
➾
Adjustable timer ➾3 min.
15 min. 10 min. 5 min.
➾
➾
➾
➾

9
ADJUSTABLE TIMER SETTING
Select the adjustable timer. (only for Cal. W650)
D
▲
Press for 2 to 3 seconds.
B
▲
▲
CSelect the digits to be adjusted (hour/minutes).
▲
DSet the flashing digits.
▲
Return to TIMER mode.
B
TIMER OPERATION
B
Time measured
CStart / Stop / Restart
DReset
No. of times the countdown
is repeated
* When the set time is up, a
warning sound beeps for 5
seconds. To stop it manually,
press any one of the buttons.

10
ALARM MODE
ALARM SETTING
Press for 2 to 3 seconds.
B
▲
C
▲
▲
D
B
Set the flashing digits.
Return to ALARM mode.
▲
Select the digits to be adjusted
(hour/minutes).
BC
D
* The alarm is automatically engaged.
Alarm engagement/disengagement
“on” mark
Engage/disengage the alarm
C
Alarm mark
[ ]
[ Alarm engaged ]
