Pulsar YM91 User manual

INSTRUCTION MANUAL FOR WATCH CALIBRE
YM91

THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed or placed inside any part of the body, the battery can
cause severe or fatal injuries within 2 hours or less.
Button batteries are hazardous whether new or used. Keep batteries
out of reach of children.
If you think the battery may have been swallowed or placed inside
any part of the body, seek immediate medical attention. Contact the
Australian Poisons Information Centre immediately on 13 11 26
(New Zealand 0800 764 766) for 24 / 7 fast, expert advice.

CAL. YM91
CHRONOGRAPH
ENGLISH
TIME/CALENDAR
●Hour, minute and small second hands
●Date displayed in numerals
STOPWATCH
●Measures up to 60 minutes in 1/5 second increments.
●Split time measurement

English
2
DISPLAY AND CROWN/BUTTONS
c: Second clickb: First click
a: Normal position
Hour hand
STOPWATCH
minute hand
STOPWATCH
1/5-second hand Minute hand
a b c
Date
Small second
hand
CROWN
B
A

English
3
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2TurnCrownclockwisewhilepressing it lightly
until tight.
Unlocking the crown

English
4
SETTING THE TIME AND
ADJUSTING THE STOPWATCH HAND POSITION
●This watch is so designed that the following are all made with the crown at the
second click position:
1) main time setting
2) stopwatch hand position adjustment
Once the crown is pulled out to the second click, be sure to check and adjust 1)
and 2) at the same time.
CROWN Pull out to second click when the small second hand is at the
12 o’clock position.

English
5
1) MAIN TIME SETTING
Hour hand Minute hand
Small second hand
CROWN Turn to set the hour and
minute hands.
* Itis recommended that thehands be set
to the time a few minutes ahead of the
current time, taking into consideration
the time required to adjust the
STOPWATCH hand position .
2) STOPWATCH HAND POSITION ADJUSTMENT
●If the STOPWATCH hands are not in the “0” position, follow the procedure below
to set them to the “0” position.

English
6
▲
▲
BPress repeatedly to set STOP-
WATCH minute hand to the “0”
position.
* Thehand moves quickly if button
B is kept pressed.
▲
APress for 2 seconds.
* STOPWATCH 1/5-second hand
turns a full circle.
▲
STOPWATCH
1/5-second hand
STOPWATCH
minute hand
A
B
* STOPWATCHminutehandturns
a full circle.
APress for 2 seconds.

English
7
▲
▲
Push back in to normal
position in accordance
with a time signal.
CROWN
BPress repeatedly to set STOP-
WATCH 1/5-second hand to the
“0” position.
* Thehand moves quickly if button
B is kept pressed.

English
8
1Pull out to first click.
2Turn clockwise until the desired
date appears.
3Push back in to normal position.
CROWN
SETTING THE DATE
●Before setting the date, be sure to set the main time.
➠
➠
Date

English
9
STOPWATCH
●The stopwatch can measure up to 60 minutes in 1/5-second increments.
●After 60 minutes, it will start counting again from “0” repeatedly up to 12 hours.
AStart / Stop / Restart
BReset /
Split /Split release
STOPWATCH
minute hand
STOPWATCH
1/5-second hand
●Before using the stopwatch, be sure to check that the crown is set at the normal
position and that the STOPWATCH hands are reset to the “0” position.
* If the STOPWATCH hands do not return to the “0” position when the stopwatch
is reset to “0”, follow the procedure in “SETTING THE TIME AND ADJUSTING
THE STOPWATCH HAND POSITION”.

English
10
Split time measurement
A
START
▲
B
SPLIT
▲
B
▲
SPLIT
RELEASE
A
STOP
▲
B
RESET
Measurement of two competitors
A
START
▲
▲
A
▲
2ND
COMPETITOR
FINISHES
▲
B
RESET
FINISH TIME
OF 1ST
COMPETITOR
FINISH TIME
OF 2ND
COMPETITOR
Standard measurement
START
▲
A
STOP
▲
B
RESET
Accumulated elapsed time measurement
A
START
▲
A
STOP
▲
A
▲
RESTART STOP
▲
B
RESET
A
B
A
B

English
11
SETTING THE TIME AND ADJUSTING THE STOPWATCH HAND POSITION
NOTES ON OPERATING THE WATCH
●When the stopwatch is or has been measuring, if the crown is pulled out to the second
click, it will automatically reset the STOPWATCH hands to “0”.
[MAIN TIME SETTING]
●When setting the hour hand, be sure to check that AM/PM is correctly set. The watch
is so designed that the date changes once in 24 hours.
●When setting the minute hand, first advance it 4 to 5 minutes ahead of the desired time
and then turn it back to the exact minute.
SETTING THE DATE
●It is necessary to adjust the date at the end of February and 30-day months.
●Do not set the date between 9:00 p.m. and 1:00 a.m., as the date may not change
properly.
STOPWATCH
●Restart and stop of the stopwatch can be repeated by pressing button A.
●Measurement and release of split time can be repeated by pressing button B.

English
12
BATTERY CHANGE
Battery life : Approx. 5 years
Battery : SEIKO SR927SW
● If the stopwatch is used for more than 2 hours a day, the battery life may be less than
the specified period.
● As the battery is inserted at the factory to check the function and performance of the
watch, its actual life once in your possession may be less than the specified period.
● When the battery expires, be sure to replace it as soon as possible to prevent any
malfunction.
● After the battery is replaced with a new one, set the time/calendar and adjust the
stopwatch hand position.
5
Years
●Battery life indicator
When the battery nears its end, the small second hand moves at two-second intervals
instead of normal one-second intervals. In that case, have the battery replaced with a
new one as soon as possible.
* The watch remains accurate while the small second hand is moving at two-second
intervals.

English
13
WARNING
●Do not remove the battery from the watch.
●If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
●Never short-circuit, tamper with or heat the battery, and never expose
it to fire. The battery may burst, become very hot or catch fire.
CAUTION
●The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.

English
14
TO PRESERVE THE QUALITY OF YOUR WATCH
WATER RESISTANCE
●Non-water resistant
●Water resistance (5 bar)*
If “WATER RESISTANT 5 BAR”
is inscribed on the case back, your
watch is designed and manu-
factured to withstand up to 5 bar
5 bar WR
and is suitable for swimming, yachting and taking
a shower.
If “WATER RESISTANT 10 BAR”,
“WATER RESISTANT 15 BAR”
or “WATER RESISTANT 20 BAR”
is inscribed on the case back,
10/15/20
bar WR
● Water resistance (10 bar/15 bar/20 bar)*
your watch is designed and manufactured to
withstand up to 10 bar/15 bar/20 bar and is
suitable for taking a bath, shallow diving, but not
for scuba diving. We recommend that you wear
a PULSAR Diver’s watch for scuba diving.
If “WATER RESISTANT” is not
inscribed on the case back, your
watch is not water resistant, and
care should be taken not to get it
If “WATER RESISTANT” is inscribed
on the case back, your watch is
designed and manufactured to
withstand up to 3 bar, such as acci-
●Water resistance (3 bar)
dental contact with splashes of water or rain, but it is
not designed for swimming or diving.
wet as water may damage the movement. If
the watch becomes wet, we suggest that you
have it checked by an AUTHORIZED PULSAR
DEALER or SERVICE CENTER.

English
15
* Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the
crown is pushed in completely.
Do not operate the crown when the watch is wet or in water. If used in sea water,
rinse the watch in fresh water and dry it completely.
* When taking a shower with the water resistance 5 bar watch, or taking a bath with
the water resistance 10, 15 or 20 bar watch, be sure to observe the following:
• Do not operate the crown when the watch is wet with soapy water or shampoo.
• If the watch is left in warm water, a slight time loss or gain may be caused. This
condition, however, will be corrected when the watch returns to normal
temperature.
NOTE:
Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the
pressure at a given depth. Care should also be taken on diving into water.
TEMPERATURES
+50°C
-5°C
Temperatures over 50°C (122°F) may
cause battery leakage or shorten the
Your watch works with
stable accuracy within a
temperature range of 5°
C and 35°C (41°F and 95°
F).
battery life. Do not leave your watch
in very low temperatures below –5°
C (+23°F) for a long time since the
cold may cause a slight time loss or
gain.
However, the above conditions will
be corrected when the watch returns
to normal temperature.

English
16
MAGNETISM
NS
Your watch will be
adversely affected by
strong magnetism. Keep
it away from close contact
with magnetic objects.
Be careful not to expose
the watch to solvents,
mercury, cosmetic spray,
detergents, adhesives or
paints. Otherwise, the
CHEMICALS
case, bracelet, etc. may become
discolored, deteriorated or damaged.
Light activities will not
affect your watch, but be
careful not to drop your
watch or hit it against hard
surfaces, as this may
SHOCKS & VIBRATION
cause damage.
To prevent possible rusting of
the case and bracelet caused
by dust, moisture and
perspiration, wipe them
periodically with a soft dry cloth.
CARE OF CASE AND BRACELET
It is recommended that the
watch be checked once
every 2 to 3 years. Have
your watch checked by an
AUTHORIZED PULSAR
2 - 3
Years
PERIODIC CHECK
DEALER or SERVICE CENTER to
ensure that the case, crown, buttons,
gasket and crystal seal remain intact.
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
If your watch has a
protective film and/or a
sticker on the case back,
be sure to peel them off
before using your watch.
