PureAir OMNI User manual

1
www.GreenTechEnv.com
Owner’s Manual
OMNI

2
CONGRATULATIONS
RECORDS
TABLE OF CONTENTS
Product Contents ............................................................. 3
Installation Hardware .......................................................... 3
Replacement Parts ............................................................ 3
About pureAir OMNI ........................................................... 4
Specications ................................................................ 4
Warnings..................................................................... 5
Recommended Installation Tools ................................................ 6
Installation Requirements ....................................................... 6
Installation ................................................................... 7
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Changing the PCO Cell ........................................................ 9
Maintenance/Lamp Indicator ................................................. 10
Warranty.................................................................... 11
on your purchase of the pureAir OMNI. This unit is designed to be installed into a number
of different situations in need of an air and surface purication solution. With proper
cleaning and maintenance your OMNI should operate at maximum efciency for years.
Please read and follow all service procedures outlined in this manual.
Please record the name and phone number of your Dealer
Name: __________________________________________________________________
Phone #:________________________________________________________________
Please record the serial number of your pureAir OMNI
Serial #: _________________________________________________________________

3
PRODUCT CONTENTS/UNIT DIAGRAM
INSTALLATION HARDWARE
REPLACEMENT PARTS
PCO Cell
Ballast & Fan
PCO Power Cable
DC Power In
DC Power Plug
(4) Filters
Filters
Grill Plate Exhaust
(4) Sheet Metal Screws (4) Wall Anchors
Filter Part #: FILTER-MERV7-25425
PCO Cell Part #: CELL-HV-09-03-AP

4
SPECIFICATIONS
ABOUT pureAir OMNI
WARRANTY:
• 2 Year Manufacturer’s Warranty
FEATURES:
• Unit Operating Window
• Replaceable PCO Cell
ELECTRICAL:
• 120VAC 60Hz
• 14W Power Consumption
• .20 Amps
MECHANICAL:
• Distribution via blower
SIZE: (HxWxD)
• 4.4” x 4.3” x 18.5”
WEIGHT:
• 4.7 lbs.
COVERAGE:
• Up to 1,000ft2
pureAir OMNI is a new generation Air and Surface Purication System. It is designed to
eliminate, bacteria, viruses, and odors from commercial or residential spaces.
When the OMNI is in operation, it creates an Advanced Oxidation Process consisting
of hydroperoxides, superoxide-ions, and a safe low level ozone. These are all friendly
oxidizers that revert back to oxygen and hydrogen after the oxidation of a pollutant.

5
WARNINGS
UV light in operation. Disconnect unit from power supply before servicing.
Failure to follow warnings may result in severe eye damage.
To reduce the risk of electric shock, this equipment has a grounding type
plug that has a third (grounding) pin. The plug will only t into a grounding
type power outlet. If the plug does not t into the outlet, contact qualied
personnel to install the proper outlet. Do not alter the plug in any way.
Never insert hands into the unit’s fan motor while it is plugged in or running.
Follow all installation instructions.
Before servicing or cleaning the unit, unplug it from its power source.
Replace the lters regularly to maximize efciency and avoid damaging your unit.
For your safety and the safety of the product, please read through the
warnings below before beginning installation, cleaning, or maintenance.

6
RECOMMENDED INSTALLATION TOOLS
INSTALLATION REQUIREMENTS
ELECTRICAL REQUIREMENTS (110 V units only)
To use the 120 V plug, be sure to locate the unit within 6 ft. of a standard 120 V grounded
outlet. Long term use of an extension cord is not recommended due to safety considerations.
Power Drill Longneck #2 Phillips
Head Screwdriver
Knife or Scissors

7
INSTALLATION
Longneck #2 Phillips
Head Screwdriver
1. Begin by nding an open wall space near your area in need of purication. Make sure
it is near a power receptacle and is easily accessible for maintenance or cleaning.
2. Mark four (4) spots on the wall through the holes on the mounting brackets.
3. Pre-drill pilot holes; place wall anchors if necessary.
4. Place the unit, with the Exhaust facing up, and use the Wall Mount Screws to attach
the unit to the wall.
5. Once installed, plug your unit into the receptacle and enjoy its benets.

8
UV Light in operation. Disconnect unit from power supply before servicing.
Failure to follow warnings may result in severe eye damage.
Your OMNI’s filter should be replaced every 1-2 months depending on
the quality of air in the establishment.
If your OMNI has any maintenance problems or requires replacement of parts
you will need to contact GreenTech Environmental.
1. Remove the Power Cable from OMNI.
2. Remove the cover and use an Air Duster to rst clear any debris inside the machine.
3. If any remains, wipe it down with a damp cloth.
4. Replace the Cover and Plug in the Power Cable.
CLEANING

9
UV Light in operation. Disconnect unit from power supply before servicing.
Failure to follow warnings may result in severe eye damage.
If your OMNI has any maintenance problems or requires replacement of parts
you will need to contact GreenTech Environmental.
CHANGING THE PCO CELL
If you need to replace you PCO Cell (that is no longer under warranty) for any reason, you
will need to contact your dealer to purchase a new one.
1. Remove the Power Cable from OMNI.
2. Remove the Cover from OMNI.
3. Remove the Power Cable from your expired PCO Cell.
4. Remove the (2) Screws holding the plate beneath your PCO Power Cable into place.
5. Remove the Hooked Plate and expired PCO Cell.
6. Replace the new PCO Cell and the Hooked Plate that holds it in place.
7. Replace the (2) Screws that hold the Hooked Plate in place.
8. Replace the PCO Power Cable into the new PCO Cell.
9. Replace the Cover to secure the PCO Cell in place before plugging your unit in again.

10
MAINTENANCE
UV LAMP INDICATOR
Your pureAir OMNI unit requires no periodic maintenance beyond normal
replacement of the PCO cell every 3 years.
Note: For optimal performance, we recommend the replacement of the PCO cell every 3 years, even if the
UV lamp appears to be operating normally.
The UV lamp operation indicator on the face of the unit will glow when the UV lamp is in use.
If the indicator does not glow and the unit has power, the PCO cell should be replaced.
Optional Ported Plate
If you decide to use your OMNI in any situation that will need to utilize the port and
hose system (i.e. Ice Machine, Refrigeration Unit, or RV), you can exchange the
Grill End Plate with a Ported Plate that can be purchased through your dealer or
GreenTech Environmental.
Please do not throw a used PCO Cell in the garbage.
The special germicidal UVX bulb used in the OMNI
contains a very small amount of mercury. Contact
your local Waste Management Center for a proper
disposal procedure.
DISPOSAL OF THE PCO CELL

11
LIMITED WARRANTY INFORMATION
Your pureAir OMNI (Product) is warranted to be free from all defects in material and workmanship in
normal household use for a period of 2 Years from date of purchase. The warranty is granted only to the
original purchaser. The warranty is subject to the following provisions:
Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Product
Owner’s Manual are not covered by this warranty. Likewise, any defects or damages caused by
unauthorized service or the use of other than Genuine GreenTech Environmental Parts are not covered.
GreenTech Environmental, LLC will, at its option, repair or replace a defective Product or part(s) for the
Product that is/are covered by this warranty. As a matter of warranty policy, GreenTech Environmental,
LLC will not refund the customer’s purchase price.
OBTAINING WARRANTY SERVICE
To obtain warranty service you must return the defective product along with proof of purchase to the
GreenTech Environmental Authorized Service Center. All shipping costs submitted under this Warranty shall
be borne by purchaser. Unless this Warranty is expressly renewed or extended by GreenTech Environmental,
LLC, any repaired or replaced part of unit shall be warranted to the original purchaser only for the length
of the unexpired portion of the original warranty. For the location of the nearest GreenTech Environmental
Authorized Service Center or for other service information, please visit us online at:
www.GreenTechEnv.com/service
Before any product is sent for service, the customer should contact the GreenTech Environmental Service
Center to obtain a Return Merchandise Authorization (RMA) Number. This RMA Number should be clearly
written on the box before shipping. All components/parts including the remote (if applicable), manuals,
and original packaging should be included in the return if available.
FURTHER LIMITATIONS AND EXCLUSIONS ARE AS FOLLOWS
Any warranty that may be implied in connection with your purchase or use of the Product, including any
warranty of merchantability or any warranty for Fitness For A Particular Purpose is limited to the duration
of this warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above
limitations may not apply to you.
Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event shall
GreenTech Environmental, LLC be liable for any consequential or incidental damages you may incur in
connection with your purchase or use of the Product. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This Warranty gives you specic legal rights, and you may also have other rights which vary from state to
state.
REGISTRATION
Please register your Product within 10 days of purchase by visiting www.GreenTechEnv.com/warranty.
Registering your new GreenTech product entitles you to the most up-to-date GreenTech warranty and
promotion information.
