Puretec SOL-E3 Series User manual

User Guide
Volumetric Water Softening Appliance
SOL-E3 Series
For correct operation & installation it is essential to observe these instructions.
JAN2019
ATS5200.103
Licence No. WM 74593
Australian Certication
Services

2
Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
What's Inside
What's Inside
Puretec Customer Service ............................................................................................................................3
Installation Record ............................................................................................................................................4
Before Installation..............................................................................................................................................5
Specications........................................................................................................................................................7
Exploded Diagram..............................................................................................................................................8
Diagram Identication .....................................................................................................................................9
Installation Procedure...................................................................................................................................10
Programming .....................................................................................................................................................14
Start-Up ................................................................................................................................................................16
Regeneration......................................................................................................................................................16
Replenishment of Salt Supply ..................................................................................................................17
Type of Salt to Use.........................................................................................................................................17
Brine Tank Clean-Out (Yearly)...................................................................................................................17
Media Replacement........................................................................................................................................17
Bypass Valve Operation - optional accessory .................................................................................18
Troubleshooting Guide..................................................................................................................................19
Warranty...............................................................................................................................................................23

3
Copyright © Puretec Pty Ltd 2019 SOL-E3 User Guide
Puretec Customer Service
Thank you for purchasing a Puretec Sorol Volumetric Water Soening System. Your
system is a proven performer manufactured from only quality materials and components.
It will give years of reliability and trouble free operation if maintained properly.
This user guide is designed for Puretec SOL-E3 Water Treatment Systems. Be careful to
ensure the information and illustration is applicable to your particular unit.
Caution: Do not use with water that is microbiologically unsafe or without
adequate disinfection before or aer the system.
The systems are designed for metropolitan supply water but can be used in other
situations. For other types of water supply, please contact your local Puretec dealer.
Puretec Water Soeners are designed to run economically for many years, dependent on
the initial installation and periodic maintenance.
Flush system for 5 minutes or more, aer any period of non-use, more than 2 weeks.
Note: For point of entry installations an approved dual check backow prevention device
must be installed.
When line pressure exceeds 500 kPa, a pressure limiting valve is recommended.
Pressures above 875 kPa must have PLV must have a pressure limiting valve installed.
Note: Water soener salt not supplied.
Puretec Customer Care

4
Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Product Information
Model Number:
Serial / Batch Number:
Purchased from:
Date of Installation:
Installer / Plumber Details:
Water Analysis Information
Hardness: ___________ ppm / mg/L
Iron: ___________ ppm / mg/L
Manganese: ___________ ppm / mg/L
pH: ___________
TDS (Total Dissolved Salts): ___________ ppm / mg/L
Conductivity: ___________ EC / uS/cm
Chloride: ___________ ppm / mg/L
Sodium: ___________ ppm / mg/L
Installation Record
For future reference, ll in the following data
Installation Record

5
Copyright © Puretec Pty Ltd 2019 SOL-E3 User Guide
Before Installation
Professional Installation Required
• Installation requires shutting water o to home, cutting home water supply pipe
and using a welding torch to add piping and ttings. Specialised tools and skills are
required, this must be completed by a qualied tradesperson.
Make Sure Your Water Has Been Thoroughly Tested
• An analysis of your water should be made prior to the selection of your water
conditioning equipment. Your dealer will generally perform this service for you, and
may send a sample to the factory for analysis and recommendations. Enter your
analysis information on page 4 for your permanent record.
• Soeners are designed to reduce hardness but can handle reasonable amounts
of soluble iron if consideration is given to content when selecting model and
regeneration settings. For best results contact Puretec to discuss.
Install Water Conditioning Equipment Correctly
Select the location of your water soener with care. Various conditions which contribute
to proper location are as follows:
• Install as close as possible to a drain.
• Install in correct relationship to other water treatment equipment. Contact Puretec
for assistance.
• Install the soener in the supply line BEFORE the water heater. Temperatures above
43.3°C (110°F) will damage the soener and void the warranty.
• DO NOT install the soener in a location where freezing temperatures occur.
Freezing may cause permanent damage and will also void the warranty.
• DO NOT install where water hammer conditions may occur without installing an
arrestor.
• Allow sucient space around the installation for easy servicing. Provide a non-
switched 240V power source for the control valve.
Before Installation

6
Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
• The control valve, ttings and/or bypass are designed to accommodate minor plumbing
misalignment but are not designed to support the weight of a system or the plumbing.
• Do not use petroleum jelly, oils, other hydrocarbon lubricants or spray silicone anywhere.
A silicon lubricant may be used on the black o-rings but it is not necessary.
• Do not use pipe dope or other sealants on threads. Thread seal tape is the preferred
sealant but is not necessary on the nut connection or caps because of o-ring seals.
• All plumbing should be done in accordance with local plumbing codes. The pipe size for
the drain line should be a minimum of ⅝”.
• Avoid getting primer and solvent cement on lter system.
• Install grounding strap on metal pipes if required.
• Ensure the system is protected against high pressure and extreme temperatures.
Things to Remember While Planning Your Installation:
• All installation procedures MUST conform to local plumbing codes.
• If lawn sprinklers, a swimming pool, or geothermal heating/cooling or water for other
devices/activities are to be treated by the water soener, a larger model MUST be
selected to accommodate the higher ow rate plus the backwashing requirements of
the water soener. Contact Puretec for assistance.
WARNINGS
Before Installation

7
Copyright © Puretec Pty Ltd 2019 SOL-E3 User Guide
Specications
Specications
Operating Pressure Min/Max: 140-875 kPa
Operating Temperature Min/Max: 0-48 °C (protect from
freezing)
Electrical Connection: 240V / 50 Hz
Inlet/Outlet Connection: 25 mm
Drain Connection: ⅝”
Overow Connection: ⅝”
Width (mm) (W): 285
Height (mm) (H): 1125
Depth (mm) (D): 490
Dry Weight (kg): SOL30-E3 - 29 kg.
SOL40-E3 - 37 kg.
Maximum salt storage capacity: 150 kg
1125
285 490

8
Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Exploded Diagram
Exploded Diagram
1
2
3
4
5
7
9
8
11
12
15
16
18
17
14
13
6
10

9
Copyright © Puretec Pty Ltd 2019 SOL-E3 User Guide
Item Part no Description
1 WTD2030 Riser Pipe
2 - Pressure Tank
3 WTB1035 Cabinet Domestic Soener
4 - Brine Well
5 Brine Pick-Up Assembly
6 WTB1035 2pc Overow Kit
7 - Brine Tank Lid
8 - Brine Well Blank
9 - Brine Well Lid
10 WTV3030 Pressure Tank Collar UV Shield
Item Part no Description
11 WTD1010 Top Screen
12 WTV4200 Volumetric Valve
13 WTV5135 Transformer Suits Auto Valves
14 - Drain Tube Assembly
15 WTB2100 Soener Cover
16 WTV5060 Plastic Fitting Kit
17 WTV5000 Bypass Assembly (purchased
separately)
18 KTU6BK Tubing High Pressure 3/8" Black
Diagram Identication
Brine ⅜”
Outlet 1"
Control Panel
Inlet 1"
Drain ⅝”
Parts Identication
Parts Identication

10
Installation & Operation Manual Copyright © Puretec Pty Ltd 2019
Installation Procedure
Ensure Water Has Been Tested
Input values into Table on page 4 and the analysis has been inspected by Puretec.
3
Water Analysis Information
Hardness ___________ ppm / mg/L
Iron ___________ ppm / mg/L
Manganese ___________ ppm / mg/L
pH ___________
TDS (Total Dissolved Salts) ___________ ppm / mg/L
Conductivity ___________ EC / uS/cm
Chloride ___________ ppm / mg/L
Sodium ___________ ppm / mg/L
130
0.3
0.1
7
275
404
121
96
✓✓
Customer Service Helpline
1300 140 140 (AU) 0800 130 140 (NZ)
✓
Extra Items Required
2
Unpack the Equipment
Ensure all parts are present and have not been damaged in transport.
You should have:
1
User Guide
Volumetric Water Softening Appliance
SOL-E3 Series
For correct operation & installation it is essential to observe these instructions.
ATS5200.103
LicenceNo. WM 74593
Services
Water Soener
Drain Tube Assembly
Bypass Assembly
(purchased separately) User Guide
⅝" Tubing high pressure for
drain and overow (refer to
page13).
Bag of Salt (refer to page
17 for the type of salt to
be used).
Installation Procedure
