Pyle view PLVWR750T User manual

7'' 16:9 Roofmount TFT LCD Colour TV
MANUAL
Please read this manual before operating
V Trouble Shooting
Phenomenon Reason
No picture and sound
AC adapter orautomobile adapter is
improperly connected. Powerswitch
is off.
Audio volume is off or in "mute" cond-
ition. Press VOL+
No sound
Remote Control
not working
Notice to Customers
Don't knock orpress the LCD surface.
HIGH VOLTAGE INSIDE! DO NOT dismantle the unit for
your own safety.
LCD may havea few color dots, which is common for the matrix display
technology, and doesn't indicates defects or fault.
WARNING:
FOR YOUR SAFETY, PLEASE DON'T OPERATE
OR WATCHDISPLAYWHILE DRIVING.
Components or manufacturing process may be subject
to change within the specification for improving purpose.
(B 060322 V2.0)
Check Remote Control Battery and
make sure itis installed correctly.
Battery may not have power or
signal is blocked.
R
www.pyleaudio.com
R
PLVWR750T
PLVWR750T
Picture for reference only, articles asarrival, will notnotice separately
if has any changes.

I Installation Guide
1 This unit should be installed by a qualified service Technician.
2 This product is designed to operate with a 12V DC, negative ground
battery system.
3 Don t connect the ground wirefrom the battery terminal prior to
connecting the unitto the electrical system.
4 Please use accessories that come with this unit in order to avoid fire or
electrical damage to it.
'
66Menu
Power ON/OFF button
Channel increase
Analog decrease
Analog increase
Channel decrease
77
1111
88
1010
1212
11Open button
22Left light control button
33Right light control button
44Left light 55Right light
99Remote window
II Performance Parameter
Panel size: 7"
Display mode: 16:9
System: NTSC/PAL
Power supply: DC 12V
Power consumption: 12W
Resolution: 480 RGB 234
Operation temperature: +5 +40
Storage temperature: -5 +75
2
Brightness: 300cd/m
Contrast: 300:1
Built-in TV Tuner
IR Transmitter
III Remote Control
IV Connection
Red to battery +12V
Black to grounding
Yellowto Video
Inset to LCD S terminalInset to LCD S terminal
44
55
77
66881010 1111 1212
99
1111
33
22
Audio Left
Audio Right
Red to battery +12V
Black to grounding
Yellow to door control
Mute
Channel increase+
Volume -
TV/AV
Number key
Channel decrease -
Mirror
Picture System
Return key
Sleep time
Volume +
View mode
Menu
Power on /off
0
90
0
180
0
0
TV ANT
