Pyle view LCD Monitor PL71PHB User manual

Instruction Manual
PL71PHB
HTTP://WWW.PYLEAUDIO.COM
AV MENU MODE POWER IR
PL71PHB
Pair of Adjustable Headrest with Built-in 7" TFT-LCD Monitors

Warning
Read this manual before using this product.
This product is composed of precision components
and should not be dissembled Service must be
perfurmed by a factory authorized technician.
Protect the product from moisture and shock.
1
1. When connect the electric power wires, you should make clear about the
positive and negative electrode ( the red one is positive and the black
is negative). If you wrongly connected the fuse in the filter box will be
broken protectively. Please replace the fuse in same parameter.
2. Because the LCD screen is the main component It should be paid
attention to be damp-proof.
3. The device must be installed firmly to prevent falling of device that will
possibly cause injury and device-broken.
4. The connecting-point of direct current (12V) should connect on the Main
line of storage battery as possible as it can , for keeping this device in
normal operation and be away from the large voltage drop influence.
5. There is high voltage cluster in this machine, if you are the professional
person, should never to take part the machine if malfunction and
contact the dealer in time.
Attentions:

2
UNIVERSAL HEADREST WITH PRE-INSTALLED
MONITOR OWNER'S MANUAL
Congratulations on your purchase of this headrest monitor system. The
product
is designed and built to deliver excellent video quality and long
lasting high performance. For best results please consult a professional
mobile electronics installer for application advice
or troubleshooting.
Please read these instructions thoroughly before installation.
Installation Instructions
1. Remove the existing headrest from the seat.
2. Adjust the posts ofthe new headrest to fit the holes in the seat where
the headrest will
be installed. The post can be moved together or
apart: grasp one post
in each hand, move the posts in opposing
directions (like they were walking) while pushing them toward each
other oraway from each other.
3. Insert the cable in the proper hole. Insert the posts into the holes in
the seat and carefully work the headrest into position. Make sure the
cable
is not pinched.
4. Run the cable down the seat and out to the location of the video
source unit (such as a
DVD player).
5. Connect the wires as indicated:
a. Red: Connect to a switched (+) 12 volt source (ACC). Use a lead
that has (+) 12V when the ignition is
on or in the ACC position so
the monitors turn off when the key
is in the off position. Wiring the
monitors "hot" could cause your battery to
run down when the
engine is not running.
b. Black: Connect to a good chassis ground.
c. Reversing the polarity of the red and black leads will damage the
monitor.
d. Connect the video input connector to the video output from the
source unit (Le.DVD player).
e. Test the system.

3
VCD/DVD
Sound system
Red line (+12V)
Black line (ground)
Yellow line (signal)
Install the Pillow
How to use the adapter tubes

4
Monitor Controls and Features
1. V2 in (Alternate video input)
2. Earphone jack
3. Positive adjustment
4. Negative adjustment
5. Activation of menu indicator
6.
7. Power on/off
8. IR remote window
16:9/4:3 mode select
AV MENU MODE POWER IR
PL71PHB
1 2 3 4 5 6 7 8

5
Remote Contorl
Power ON/OFF
Analog variable increase
Menu button
V1/V2 conversion
Analog variable decrease
Switch for mode
Installation Diagram
(Yellow) Video 2 input
Changing the battery in the remote control
The remote battery is held in a small " drawer"
on one edge of the remote. To open this
drawer, press and hold the small button on
the edge of this drawer (as shown below) and
slide the drawer out.
Insert a new battery and push the drawer
back fully into the remote.
Battery
Release button
(Yellow) Video 1 input
(Red) Audio right input
(White) Audio left input
(Black) Grounding
(Red) Battery +12V

Specification
6
Troubleshooting
* Screen Size: 7" TFT-LCD Monitor
* Built-in Mini Speaker
* Aspect Ratio: 16:9 Wide Screen
* 1440 x 234 Resolution
* Contrast Ratio: 300:1
* Brightness: 350cd/m2
* Viewing Angle: U/D: 160°, L/R: 160°
* Response Time: 25ms
* Video Input Systems: AV1, AV2
* PAL/NTSC Compatible
* Full Function Wireless Remote Control
* English OSD Menu
* Built-In IR Transmitter for Wireless IR Headphones
* Adjustable Mouning Posts From 4 3/4" - 7 1/2"
* Dual Diameter Mounting Posts (1/2" 3/8")
* Dimensions: 10" W x 7.5" H x 4.5 D
* Sold as: Pair

7
Accessories
7" TFT LCD Pillow Monitor
Wireless Remote Control
Assembling Stick
AV Input Line
Power Wire
User's Manual
2
1
2
1
1
2
Thank you for purchasing the headrest TFT LCD color monitor. To enjoy the
features of this device and to ensure years of trouble-free operation, please read
this manual carefully and follow the instructions.
WARNING:
Hazard do not operate this unit unless vehicle is parked in safe and legal area.
