INSTRUCTION MANUAL
PLVH7IP
7"WideLCDMonitor
With4MountingOptions
www.pyleaduio.com

1
TableofContents
Abouttheliquidcrystaldisplay(LCD)panel
Precautions
Control&Layoutformonitor/ wirelessremote
Accessories
Connectiondiagram
Replacingtheremotecontrolbattery
Installingheadrestwithshroud
Installingsun-visorwithshroud
Installingofheadrestcase
FunctionSetting
Troubleshootingguide
Specifications
2
3
4
5
6
6
7-8
9-10
11
12-18
18
19

2
Abouttheliquidcrystal display(LCD)panel
1. Donot pressontheLCDpanelonthemonitorunit asdoingsocandistort thepictureorcausea
malfunction, thepicturemaybecomeunclear, ortheLCDpanelmaybedamaged.
2. Notesoncleaning
-cleantheLCDpanelwithaslightlydampsoft cloth.
-donot usesolventssuchbenzine, thinner, commerciallyavailablecleanersorantistaticspray.
o o o o
3. Donot usethisunit temperaturesunder5C(41F)orover45C(113F).
4. If yourcarwasparkedinaclodorhot place, thepicturemaynot beclear.Themonitorisnotdamaged.
Thepicturewillbecomeclearaftertemperatureinyourcarbecomesnormal.
5.Somestationaryblueorreddotsmayappearonthemonitor.Thesearecalledbrightspots,andhappen
withanyLCD.TheLCDpanelishighlysophisticated, andmorethen99.99% ofthesegmentsusedin
thepanelareflawless.However, thereisapossibilitythat lessthan0.01% of thesegmentsaredefective
andmaynot light upproperly.However, thesesegmentswillnot interferewithyourviewing.
Warning
ToPrevent fireorshockhazard,donot exposetheunit to
rainormoisture. Thissymbol isintendedtoalert theuser to
thepresenceof uninsulated DANGEROUS
VOLTAGE”withintheproduct’senclosure
that maybeof sufficient magnitudeto
constituteariskof electricshocktopersons.
Thissymbol isintendedtoalert theuser to
thepresenceof important operatingand
maintenance(servicing) instructionsinthe
literatureaccompanyingtheappliance.
!
!
CAUTION!!
RISKOFELECTRIC SHOCK
DONOTOPEN
Caution:Toreducetheriskof electricshock
Donot removecover(orBack)
Nouser-serviceablepartsinside
Referservicingtoqualifiedservicepersonnel
Disposalofoldelectrical&electronicequipment
(applicableintheEuropeanUnion&otherEuropean
countrieswithseparatecollectionsystems)
Thissymbolontheproductoronitspackagingindicatesthatthisproductshallnotbetreated
ashouseholdwaste.Insteaditshallbehandedovertotheapplicablecollectionpointforthe
recyclingofelectricalandelectronicequipment.Byensuringthisproductisdisposedof
correctly,youwillhelppreventpotentialnegativeconsequencesfortheenvironmentand
humanhealth,whichcouldotherwisebecausedbyinappropriatewastehandlingofthis
product.Therecyclingofmaterialswillhelptoconservenaturalresources.Formoredetailed
informationaboutrecyclingofthisproduct,pleasecontactyourlocalCivicOffice,your
householdwastedisposalserviceortheshopwhereyoupurchasedtheproduct
Safety
Toavoidtheriskofaccidentandthepotentialviolationofapplicablelaws,thefrontstvshould
Neverusedwhilethevehicleisbeingdriven.Also,reardisplaysshouldnotbelocationwhere
Itisavisibledistractiontothedriver.
Insomecountriestheviewingofimageonadisplayinsideavehicleevenbypersonsotherthan
Thedrivermaybeillegal.Wheresuchregulations,theymustbeobeyedandthisunit’sfeatures
Shouldnotbeused.

Precautions
Pleasereadthismanualcompletelyandcarefullypriortoattempt toinstallyournewcarvideo
equipment. Installcorrectly, yournewequipment willprovideyouwithyearsof enjoyableandsafeusage.
Installingthisunit requirestechnicalexpertise.Thisunit shouldbeinstalledbyaqualified
technicianorservicepersonnel. If youtrytoinstallthisunit byyourself, doit properly, referringtothe
installationandwiringdiagramsinthisoperatingmanual. Improperinstallationmayresult infireor
electricshock.
1.Donot operatethisequipment whiledriving-safedrivingshouldalwaysbeyourhighest priority.
2.Donot installcomponentsinareaswhicharesusceptibletorain, moisturedirect sunlight,extremely
heat orcold, excessivedust, dirt orhumidity.
3. Immediatelyunplugthepowercordandsendthemonitortoyourlocaldealerorservicecenteras
soonaspossible:
a)If thereissmokeoranypeculiarodorpresent duringused
b)If thereisdamagetoanyof theinternalcomponents
4.Toavoiddamagetothemonitorandriskof electronicshock, donot permit anyof thisequipment to
becomedamporwet fromwaterorliquid. If thisdoesoccur, immediatelyunplugthepowercordand
sendthemonitortoyourlocaldealerorservicecenterassoonaspossible.
5. Donot attempt torepair, openordisassembleanyof thecomponents. Dangeroushighvoltagesare
present whichmayresult inelectricshock.
6. UseonlyapowersourcewithDC12voltscarbattery(negativeground).
7. Donot placeorsuspendobjectsonthepowercord, asthismaydamagethecord.
8. Donot twist orplacethepowercordnearanysourceof heat inthevehicle.
9. Donot attempt torepairadamaged, brokenorfaultypowercord. Replaceit withanewoneimmediately.
10.Avoiddroppinganymetalobjectsorinflammableitemsintothemonitorventilationslots.
11.Afterthemonitorisinstalled, donot arbitrarilypullit downorstrikeit.Thismayloosethemounting
screwsandcauseit falldown.
12. Donot installthisunit where:
a)it willobstruct thedriver’sview.
b)it willobstruct theoperationof theairbagsystem.
c)it willobstruct theoperationof thevehicle, especiallythesteeringwheel, shift lever, orbrakepedal.
d)adiverorpassengersmayinjurethemselveswhengettingintoorout of thecar.
3

Controlandlayoutforthemonitor
Notice:somefunctionsareworkbyremotecontrol.
Bluescreenwhen
novideosignal
Controlandlayoutfortheremotecontrol
AdjustDecrease
Thismultipurposebuttonserves
todecreasetheselected
parameters, suchasvolume,
contrast etc.
Menu
PresstodisplayMENU
withfunctionsand setting
AdjustIncrease
Thismultipurposebutton
servestoincreasetheselected
parameters, suchasvolume,
contrast etc.
RemoteSensor
RemotecontrolIR sensor
PowerOn/ Off
Turnon/off themonitor
FrontA/VInput
Front audiovideoinput
FrontAudioOutput
Front audiooutput
(headphones)
PowerCord
(Male)
4
PowerOn/Off
TurnOn/ Off themonitor
V1/V2
Select Video1orVideo2Input
Volume
Adjust reduceheadphoneoutput
volume
Reduce
Menu
Thisbuttonbringsuptheon-screen
menuforadjustment of arangeof
monitorparameterssuchas,
vol, con, col, bri, tint. Etc
Preset
Picturepreset byfactory
AdjustIncrease
This multipurposebuttonserves to
adjustdowntoselectmenufunction
andincreasethe selectedparameters
suchascontrast,color,brightness etc
Invert
Toadjust thepicture
up/down/left/right
AdjustDecrease
Thismultipurposebuttonservesto
adjust uptoselect menufunction
anddecreasetheselectedparameters
suchascontrast, color, brightnessetc.
VolumeIncrease
Adjust increaseheadphoneoutput
volume
Mute
PresstoMutethesound, pressagain
torestorethepreviousvolumelevel
Whenyouuseawirelessradioor portabletelephonenear
thisunit, pictureor soundinterferencemayoccur. Donot
usesuchdevicesnear thisunit.
MMI Input
Front audiovideoinput
(Plug&PlayforPs2orgames)

UniversalStand
Key-forremovingthemonitor
from headrestorvisorshroud
RemoteControl
Headrest&
SunVisorShroud
5
Accessories
HeadrestBag
InstructionManual
INSTRUCTIONMANUAL
Earphone
ExtensionMinDinCable
AVCable

6
PULLOUT
PUSHIN
ReplacingtheRemoteControlBattery
1)Alwaysusenewbatterywhenreplacetheoldset.
2)Donotattempttocharge,short-circuit,disassemble,
heatorburnusedbatteries,batterymaybeexplode
ifmistreated.
3)Batteryreplacementisnecessarywhenremote
controlactssporadicallyorstopsoperating.
4)Donotdrop,applyshockorstepontheremotecontrol.
5)Donotspillwaterontheremotecontrol.
6)Donotplaceobjectsbetweentheremotecontrolandremotesensor.
7)Donotuseremotecontrolfortheotherequipmentsatthesametime.
8)Donotleavetheremotenearanyheatsources,orinaplacesubjecttodirectsunlight
(especiallyonthedashboard).
9)Keepthelithiumbatteryoutofthereachofchildren.Shouldthebatterybeswallowed,immediately
consultadoctor.
10)IftheMONITORdoesnotoperateevenwhenyouoperatetheremotecontrolfromacloserange,
itistimetoreplacethebattery(useCR-2025lithiumbattery),referringtothelabelonthebackof
thebasiccontrol.
11)Donotholdthebatterywithmetallictweezers,otherwiseashort-circuitmayoccur.
ConnectionDiagram
Fuse
(2A)
Fusereplacement
Never usefusewithanamperagerating
exceedingtheonesuppliedwiththeunit as
thiscoulddamagetheunit.
Whenreplacingthefuse, besuretouseone
that matchestheamperagedescribedonthe
original fuse. If thefuseblows, checkthe
power connectionandreplacethefuse. If the
fuseblowsagainafter replacement, therema
y
beaninternal malfunction. Insuchacase,
consult your nearest your’sdealer.
1
2
BATTERY
Bluescreenwhen
novideosignal
RED
BLACK
RED
YELLOW
Audio Input (Red RCA) Video Input (Yellow RCA)
Video
Player
RED
YL
ELOW
Audio Input (Red RCA) Video Input (Yellow RCA)
Games
ne
Earpho

CAUTION:makesurethescrewsarenotlongenoughtogothrough
theheadrest!
Ifyouhaveanydoubtsaboutthistypeofinstallation,pleaseconsult
yourlocalmobileelectronicsretailer.Cuttingandmakingholesin
theheadrestwillcauseelectronicdamagewhichisexpensivetorepair.
Setupwork
Removetheheadrest andset it inanuncluttered
workarea. Paytheappropriateprecautionsto
ensurethat it isnot damagedduringtheinstallation.
StepsForInstallingHeadrestwithShroud
Measurements
Presstheheadrest withyourfingerstomake
suretherearenoobstructionsthat wouldhinder
theinstallation. Usepapertemplatetomarkthe
areatobecut.
Cuttheheadrest
Useanadjustable-depthblade, start
yourcut 1/4inchinsideonecornerand
cut diagonallyacross, stopping1/4inchin
fromtheothercorner. Repeat thisprocedure
fortheothertwocorners.
Removefoam&obstructions
Carefullypeeloffthematerial.Setthe
adjustablebladetooneinchdepthandcut
aroundtheedgesofthehole,staying1/4inch
insidetheedge.Pulluponecornerofthefoam
andusethebladetocutunderneath.Remove
smallsectionatatimeandensuretobethe
uniformdepth.Useadremelorotherappropriate
toolstoremoveotherobstructions.Insertthemonitorto
measurethefitandmakeadjustmentifnecessary
7

Routethecablethroughtheheadrest
Runthesuppliedcablethroughtheopening
andouttothebottomoftheheadrest.Ifpossible,
concealthewireswithashaftcovering.
Connectthepower,groundandvideoleadsto
testtheMONITOR.
Beforeconnectingthemonitor,pullthe
connectingcablethroughtheheadrestshroudas
shownindiagram.Placetheheadresthousingintothe
openingandsecurewithcorrectfasteners.
Installtheheadrest
Pulltheconnectingcablethroughthecenterof
theshroudasshownindiagram,andsecurethe
headrestshroudwithcorrectfasteners
shroud
Removal
headrestshroudgapandpullitouttoremovethe
monitorfromheadrestshroud.
Insertthereleasekeybetweenthemonitorand
Insertthemonitor
totheheadrest shroud.
Pushtoinsert themonitor
8

StepsForInstallingSun-visorwithShroud
Setupwork
Removethevisorandset it inanuncluttered
workarea. Payappropriateprecautionsto
ensurethat it isnot damagedduringtheinstallation.
Measurements
Presspushontheheadlinerwithyourfingerstomake
suretherearenoobstructionsthat wouldhinder
theinstallation. Usepapertemplatetomarkthe
areatobecut.
Cutthevisor
Useanadjustable-depthblade, start
yourcut 1/4inchinsideonecornerand
cut diagonallyacross, stopping1/4inchin
fromtheothercorner. Repeat thisprocedure
fortheothertwocorners.
Removefoam&obstructions
Carefullypeeloffthematerial.Setthe
adjustablebladetooneinchdepthandcut
aroundtheedgesofthehole,staying1/4inch
insidetheedge.Pulluponecornerofthefoam
andusethebladetocutunderneath.Remove
smallsectionatatime,ensuretobethe
uniformdepth.Useadremelorotherappropriate
toolstoremoveotherobstructions.Insertthe
monitortomeasurethefitandmake
adjustmentifnecessary.
CAUTION:makesurethescrewsarenotlongenoughtogothrough
thevisor!
Ifyouhaveanydoubtsaboutthistypeofinstallation,pleaseconsult
yourlocalmobileelectronicsretailer.Cuttingandmakingholesin
thevisorwillcauseelectronicdamagewhichisexpensivetorepair.
9

Operateyoursysteminasafeandlegalmanner
Whenoperateamotorvehicle,itshouldalwaysbeyourhighestpriorityto
maintainsafedrivinghabits.
ItisillegalinmanyareasofmostcountriestodrivewithTVorMONITOR
on,whenitisvisibletothedriver.Pleasecheckyourlocalandstate
lawsgoverningtheuseofMOBILEENTERTAINMENTSYSTEMinyourarea.
Routethecablethroughthevisor
Runthesuppliedcablethroughtheopening
andouttothebottomofthevisor.Ifpossible,
concealthewiresusingashaftcovering.
Connectthepower,groundandvideoleadsto
testtheMONITOR.Beforeconnectingthe
monitor,pulltheconnectingcableassembly
throughthevisorhousingasshownindiagram.
Placesun-visorshroudintotheopeningand
secureitwithcorrectfasteners.
Installthesun-visor
Pulltheconnectingcablethroughthecenterof
thehousingasshownindiagram,andsecure
thesun-visorshroudwithcorrectfasteners
shroud
Insertthemonitor
Pushtoinsert themonitor
tothesun-visorshroud.
Removal
visorshroudgapandpullitouttoremovethe
monitorfromheadrestshroud.
Insertthereleasekeybetweenthemonitorand
10

11
Rearsideofheadrest
Frontsideofheadrest
Insertthemonitortotheheadrestbag
Putthemonitorwithheadrestbagatthe
rearsidecenterofpillow.
Cutthemagictapetothefityourpillowsize,
thenfastenitasXasdiagramshow.
StepsForInstallingHeadrestBag

Functionsetting
PressMENU button(1)fromtheremoteorpress
manubutton(1)fromthemonitortocallout the
functionmenu, pressbutton(2or3)tothe
desiredsetting.
2
1
3
Remote Monitor
Pressthebutton(2or3)tomovethesymbol
andchoosevideosignalinput.
Pressmenubutton(1)toconfirmyourselection.
MovethesymboltoRETURN andpress
menubutton(1)toexit input setting.
2
1
3
Remote
Monitor
12
2
1
3
Remote
Monitor
Whenscreenappears SOURCE”PressMenu
button(1)toentervideosignalinput selection.
[Thesymbol showcurrent videoinput.]
AV1
AV2
AV3
RETURN
SOURCE
AV1
AV2
AV3
RETURN
SOURCE
AV1
AV2
AV3
RETURN
SOURCE

13
Pressbutton3: adjust brightnesstodarkerlevel.
Pressbutton1toconfirmsetting.
[Brightnessadjustablelevel: 0~100. Preset: 50]
Pressbutton2: adjust brightnesstolighterlevel.
2
1
3
Remote
Monitor
Pressthebutton(2or3)toadjust thesymbol
tochoose BRIGHT”.
Pressmenubutton(1)toenterBRIGHTsetting.
[ ]Brightness: Makesblackappear darker or lighter
2
1
3
Remote
Monitor
BRIGHT
CONTRAST
COLOR
RETURN
BRIGHT50
BRIGHT
CONTRAST
COLOR
RETURN
PICTURE Whenscreenappears PICTURE”pressthemenu
button(1)toenterpictureparameterssetting.
2
1
3
Remote
Monitor

14
Pressthebutton(2or3)toadjust thesymbol
tochoose COLOR”.
Pressmenubutton(1)toenterhuesetting.
[COLOR: adjustsmoreor lesscolor intensity]
2
1
3
Remote
Monitor
Pressbutton3: adjust contrast todarkerlevel.
Pressbutton1toconfirmsetting.
[Contrast adjustablelevel: 0~100. Preset: 50]
Pressbutton2: adjust contrast tobrighterlevel.
2
1
3
Remote
Monitor
CONTRAST50
BRIGHT
CONTRAST
RETURN
COLOR
Pressthebutton(2or3)toadjust thesymbol
tochoose CONTRAST”.
Pressmenubutton(1)toenterCONTRASTsetting.
[
(darken&brighten)]
Contrast: Narrowsor widensthegapbetweenblack&white
2
1
3
Remote
Monitor
BRIGHT
COLOR
RETURN
CONTRAST

15
BRIGHT
CONTRAST
COLOR
RETURN
COLOR 50
Exit Picturesetting, Pressthebutton(2or3)to
adjust thesymbolto RETURN”.
Pressmenubutton(1)toexit.
2
1
3
Remote
Monitor
Whenscreenappears PICTURE”pressthemenu
button(1)toenterpictureparameterssetting.
Pressthebutton(2or3)toadjust thesymbol
tochoose VOLUME”.
Pressmenubutton(1)toentervolumesetting.
[VOLUME: adjust soundsoft or loud]
2
1
3
Remote
Monitor
VOLUME
RETURN
AUDIO
2
1
3
Remote
Monitor
Pressbutton3: adjust lesscolorintensitylevel.
Pressbutton1toconfirmsettingandexit.
[Color adjustablelevel: 0~100. Preset: 50]
Pressbutton2: adjust morecolorintensitylevel.

16
AUDIO
VOLUME50
INVERT1
SIZE:
Full 16:9
LanguageSelect:
RETURN
FUNCTION
INVERT1
SIZE:
Full 16:9
LanguageSelect:
RETURN
FUNCTION
2
1
3
Remote
Monitor
Whenscreenappears FUNCTION”pressthemenu
button(1)toenterfunctionparameterssetting.
Pressthebutton(2or3)toadjust thesymbol
tochoosedesiredsetting
2
1
3
Remote
Monitor
Pressbutton3: adjust soundtomoresoft level.
Pressbutton1toconfirmsettingandexit.
[Volumeadjustablelevel: 0~100. Preset: 50]
Pressbutton2: adjust soundtomoreloudlevel.
2
1
3
Remote
Monitor
Whenthesymbolat INVERT1”andPressthe
MENU (1)buttonrepeatedlytoinvert thepicture,
eachtimethebuttonpressthepicturerotateas
clockwiseasthediagramshow.
Invert1
LCD
MONITOR
Invert3
LCD
MONITOR

17
INVERT1
SIZE:
Full 16:9
LanguageSelect:
RETURN
FUNCTION
2
1
3
Remote
Monitor
Diagram
Whenthesymbolat SIZE”PresstheMENU (1)
buttonrepeatedlytochangethepicturedisplay
sizetoFull 16:9orNormal4:3asthediagramshow.
Diagram
Normal 4:3 Full 16:9
INVERT1
SIZE:
Full 16:9
LanguageSelect:
RETURN
FUNCTION
English
German
French
Spanish
Portugal
Italian
ChineseC
RETURN
FUNCTION
2
1
3
Remote
Monitor
Whenthesymbolat LanguageSelect:”Press
theMENU (1)buttontoentertheOSD languages
display.
2
1
3
Remote
Monitor
Pressthebuttons2or3tothedesiredlanguage,
andpress MENU”toconfirm.

Exit
FUNCTION
2
1
3
Remote
Monitor
Whenthesymbolat Exit”PresstheMENU (1)
buttontoexit thesetup.
18
Nopicture, nosound Thepowercordorbatteryhasbeendisconnected.
Thefusehasblown.
Presspoweron.
Goodpicture, butnosound
Dolledlinesorstripes Thismaybecausedbylocalinterferencesuchascar
engineormotorcycle.
Nopicture, ornosoundwhenyou
connecttheoptional equipment
Thecordhasbeendisconnected. Connect thecord
securely.
Presspoweron.
Noresponsewhenpressingthebuttonson
thewirelessremote Thewirelessremotebatteriesmaybeexhausted.
Pressthevolumeincreasebuttononthewireless
remote, oronthemonitor.
Pressthemutebuttonfromthewirelessremote.
(TIP: refer topage4for thecontrol &layout”)
Problem Cause/solution
Troubleshootingguide
Thefollowingchecklist willhelpyousolveproblemsyoumayencounterwithyourunit.
Beforegoingthroughthechecklist below, checktheconnectionandoperating.
if youcannot solvetheproblemwithfollowsguide, pleasecontact yournearest dealer.

#1 Ameasureofthetimeunitscreenbrightnessdeclinesbyhalfundercontinuousviewing
o
inacar/roomat25Cwithscreen brightnessinstandardmode.(50%originalbrightness)
#2 o
Ameasureoftheunittemperaturedeclinesinacar/roomat25C
withscreen brightness instandardmode.(50%originalbrightness)
#3 2
Ameasureofthebacklight350cd/mbrightness willinstandard
lampvoltageat560Vrms.
19
LCDDriveMethod: TFTActiveMatrix
VisibleScreenSize: 7InchWideScreen(Diagonal)
AspectRatio: 16:9
DisplayFormat: 480xRGBx234
NumberofPixels: 336,960
ResponseTime: 15ms
Backlight: HighBrightnessCCFT
2#3
Luminance: 380cd/m
#1
BacklightLife: 15,000Hrs
ContrastRatio: 300:1
o o
ViewingAngle: (H/V):120/100
o o o o
OperationTemperature: -20C~70C/ -2F~158F
VideoColorSystemInput: NTSC&PALCompatible
OnScreenDisplay: MultiLanguages
(English, German, French, Spanish, Portugal, Italian, Chinese)
RearVideoInputTerminals: RCAx1(1Vp-p,75ohm)
FrontVideoInputTerminals: 3.5mmJackx1(1Vp-p,75ohm)
FrontAudioInputTerminals: 3.5mmJackx1(-10dBs,10Kohm)
FrontAudioOutputTerminals: 3.5mmJackx1(-10dBs,10Kohm)
FrontVideoInputTerminals: MMIPlug
FrontAudioInputTerminals: MMIPlug
RemoteControl: Included
Volume/ Brightness/ Contrast/ Color: Adjustable
BlueScreen: Yes
PowerInput: DC12Voltscarbattery(negativeearth)
Specifications:
a-SI
CurrentConsumption: 6WMax
Weight: 340g/ 0.75Lbs
Size: 186x105x22.5cm(WxHxD)
7.32x4.13x0.88inch(WxHxD)
Pyle,Inc.
rd
160063street
Brooklyn,NY11204 0
7
6888888359
