Pyle PLCM34WIR User manual

PLCM34WIR
Wireless Back Up Night Vision Camera
And Monitor System
INSTALLATION AND OPERATION MANUAL
Powe r Wi re
Double-Sided Paper Paste
These installation instructions do not apply to all types of vehicles.
They are meant only as a general guide due to the large number
of vehicle makes and models. Consult your local motor vehicle
laws on the use of this product to be sure it is permitted.
WARNING:
Through installation of the Vehicle Back-Up Camera you should
be sure not to degrade the safety of any system or device on
your vehicle.
Improper installation and wiring of the Vehicle Back-Up Camera
system may damage the vehicle's electrical system, including
vital vehicle computer and operating systems. That could lead
to an accident or fire, causing property damage and /or serious
personal injury. It is highly recommended to seek professional
installation advice from a qualified auto electrician or ,in the
alternative, to have the installation performed by a qualified
auto electrician.
MONITOR INSTALLATION
NOTICE: Please ensure that monitor is secured and mounted
where it would NOT obstruct any OEM vehicle safety features.
In an event of an accident, manufacturer is not responsible for
bodily injury caused by the monitor being a projectile.
Select location for mounting the monitor in desired location.
Ensure monitor location will not obstruct your vision while
driving.
INSTALLATION INSTRUCTION
MONITOR OPERATION INSTRUCTION
POWER ON /OFF
1．The POWER ON /OFF button turns the LCD Monitor On or Off.
2．When the monitor was turned on , it automatica lly co nnected
to the Reversing Camera.
A V
Press AV button ,the monitor will show AV images
Rotate
Control the rotation of the image.
Brightness
Control the brightness of the Monitor.
Color
Control the color of the monitor .
USB Slot
Recharging only for items that can be rechar ged via USB such
as mobile phone、MP3、etc…
12V Power Input
Supply the power for the monitor.
AV Input Jack
Connect the monitor with AV sources.

CAMERA INSTALLATION
1
1
2
2
CAUTION: It is highly recommended to remove the bulbs as
a precation.
9) Connect camera wires
3
3
4
4
TESTING THE SYSTEM
