Pyle PWLB805 User manual

-4-
Thinnest design: Distance to the wall is only 30mm
Safe lock: install safe bolt to luck up
Important: If don't understand about right install ways, please
consult to normal installing specialist.
TV Size Rang 10 24:"-"
Plasma LCD bracket
INSTALLATION GUIDE
Item No.:PWLB805Item No.:PWLB805
Fig3b
Fig3a
2
3
Warning: It needs 2 people to put up some TV! Our company will not
responsible for any damage by man-made.
Warning:
Max load capacity:15kg/33lbs

-2- -3-
Parts:
2
Fig 1
1
Step1:Install the display
According to the Fig. 1, mount the
part-a to the back of the LCD . First
determine the right holes,which should
be level to each other,on the part-a
accordingtotheholesinthebackof
the LCD. Mount the part-a to the back
of the LCD by 4 bolts and washers (D).
Step1:Install the display
Carefully: Don'tforcethebolttoLCD
hole,avoidingdamagetopeopleand
instrument. Don't use electronics drill to fasten screw.
Step 2:Mount the part-b to the wall.(Wood stud, Brick, Solid Concrete and
Masonry wall mo-unting options are provided below)
Wood stud mounting
First determine the required position in the wall.Mark 4 locations at the wall
according to the holes in the , according to the Fig 2a. Then
pre-drill 50mm (at least) deep hole with a 3mm drill bit. Fix the
to the wall by bolt ( F ) , as the Fig 2b shows. Please note the hooks in the
is up.
Wall Plate(2)
Wall Plate(2)
Wall Plate(2)
Step 2:Mount the part-b to the wall.(Wood stud, Brick, Solid Concrete and
Masonry wall mo-unting options are provided below)
Wood stud mounting
2
F
Fig2a Fig2b
Brick, Solid Concrete and Masonry wall mounting
After determine the required position in the wall, mark 4 locations at the
wall according to the holes in the , then pre-drill 50mm (at
least) deep hole with a 11mm drill bit at the position of marks. Insert the
Wallanchorcovertoeveryhole.Lastfixthe tothewallby
bolt (F).Please note the hooks in the is up.
Wall Plate(2)
Wall Plate(2)
Wall Plate(2)
Brick, Solid Concrete and Masonry wall mounting
Step3mounttheLCDdisplaytothepartbinthewall
Lift the against to the with hole to hole, and
according to the Fig 3a.Then slide the part a to the slot of the part b,as the
Fig 3b shows.Then tighten the safety bolt.
Monitor Plate Wall Plate(2)
Step 3mount the LCD display to the part bin the wall
Description
A
3
B
D
C
E
1
1
4
4
2
4
4
G
F
4
4
Letter
Monitor Plate
Wall Plate
M4x12 bolt
M4x8 bolt
Safety bolt
Long bolt
Wall anchor
Qty
M5x12 bolt
M5x8 bolt
M5 washer
4
1
2
3
ABD
CE F G
A,B,C,D
1
E
