Pylontech UP5000 Reference guide

Page 1
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
PYLONTECH
Product Presentation

Page 2
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
01 PRODUCT OVERVIEW
03 INSTALLATION
04 MULTIPLE STRINGS
02 APPLICATION & CONFIGURATION
05 TROUBLESHOOTING

Page 3
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
PRODUCT OVERVIEW
01

Page 4
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Figure UP5000 product parameters[2]
*Double single string module quantity
*95% DoD
*Double installation altitude
*Pre-charge: smooth inrush current
*Dual-active protection: enhanced safety
*Flexible current steps: enable 50%
more power during critical temperature
condition.
*Dry contact wake up: available for Dry
contact wake up.

Page 5
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
*Double single string module quantity
*95% DoD
*Double installation altitude
*Pre-charge: smooth inrush current
*Dual-active protection: enhanced safety
*Flexible current steps: enable 50% more
power during critical temperature
condition.
*Dry contact wake up: available for dry
contact wake up.
Figure 1 US3000C product parameters[1]
Product parameter feature
@60s

Page 6
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Ascendancy
Lithium-ion Battery Testing Report from ITP renewable Australia shows the estimated state of
health (SOH) against cycles completed for each Phase 2 battery pack still cycling. SOH is
estimated by dividing the energy delivered at each capacity test by the energy delivered in the
first capacity test.
Figure 3: Capacity fade of Phase 2 battery packs based on monthly capacity tests[3]

Page 7
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Compared with most types of LV batteries in the
market,
Pylon batteries posses:
A. DoD –95%
B. Weight –40kG for a 5kWh module
C. Power strength –Available for max. 1C rate
operation, peak up to 200 Amps @15 sec
per single module
D. Safety –IEC/CE/UL/UN38.3 proved
E. Expansion -Max. 70kWh per single string,
expandable to 350 kWh per system
F. Life span –more than 6000 cycles
G. Operation environment –4000m altitude, 0
–50 ℃
Ascendancy

Page 8
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
APPLICATION & CONFIGURATION
02

Page 9
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Application

Page 10
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
•Back-up
•Peak Shaving
•PV ESS
Inverter
Hybrid
Residential

Page 11
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Item Amount Rated
Power(kW)(1)
Max Power(kW,
60S)
Peak Power(kW,
15S)
Nominal
Capacity(kWh)
Usable
Capacity(kWh)
Min. Back-
up time(2)
US3000C
11.8 3.6 4.3 3.6 3.4
1.9hrs
23.6 7.1 8.6 7.1 6.7
35.3 10.7 13.0 10.7 10.1
47.1 14.2 17.3 14.2 13.5
58.9 17.8 21.6 17.8 16.9
610.7 21.3 25.9 21.3 20.2
712.4 24.9 30.2 24.9 23.6
814.2 28.4 34.6 28.4 27.0
916.0 32.0 38.9 32.0 30.4
10 17.8 35.5 43.2 35.5 33.7
11 19.5 39.1 47.5 39.1 37.1
12 21.3 42.6 51.8 42.6 40.5
13 23.1 46.2 56.2 46.2 43.9
14 24.9 49.7 60.5 49.7 47.2
15 26.6 53.3 64.8 53.3 50.6
16 28.4 56.8 69.1 56.8 54.0
(1) Rated Power is based on ideal operation temperature(10 -45℃)，during charging the power will leveling decrease when reaching full
capacity.
(2) Min. Back-up time is based on rated power and related condition during beginning of life, in real application please consider the load.
Quotation Item:
1.Battery Module(US3000C/UP5000) –varying amount depends on application.
2.External Cable kits–1 kit per 5kW installation.
3.Brackets/Cabinets –if necessary.
Residential Configuration

Page 12
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Residential Configuration
Item Amount Rated
Power(kW)(1)
Max Power(kW,
60S)
Peak Power(kW,
15S)
Nominal
Capacity(kWh)
Usable
Capacity(kWh)
Min. Back-up
time(2)
UP5000
12.4 4.8 4.3 4.8 4.6
1.9hrs
24.8 9.6 8.6 9.6 9.1
37.2 14.4 13.0 14.4 13.7
49.6 19.2 17.3 19.2 18.2
512.0 24.0 21.6 24.0 22.8
614.4 28.8 25.9 28.8 27.4
716.8 33.6 30.2 33.6 31.9
819.2 38.4 34.6 38.4 36.5
921.6 43.2 38.9 43.2 41.0
10 24.0 48.0 43.2 48.0 45.6
11 26.4 52.8 47.5 52.8 50.2
12 28.8 57.6 51.8 57.6 54.7
13 31.2 62.4 56.2 62.4 59.3
14 33.6 67.2 60.5 67.2 63.8
15 36.0 72.0 64.8 72.0 68.4
16 38.4 76.8 69.1 76.8 73.0
(1) Rated Power is based on ideal operation temperature(10 -45℃)，ensuring charging the power will decrease in levels when reaching full capacity.
(2) Min. Back-up time is based on rated power and related condition during beginning of life, in real application please consider the load.

Page 13
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
INSTALLATION
03

Page 14
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
CHECKING LIST
For battery module package:
1 PC pair of power cables
1 PC grounding cable
1 PC user manual and warranty card
Figure 4: US3000C battery module package

Page 15
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
For battery module package:
1 PC pair of power cables
1 PC grounding cable
1 PC user manual and warranty card
CHECKING LIST
Figure 5: UP5000 battery module package

Page 16
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
External cable kits
1 Pair of power cables
( NB: Please apply an advised
communication cable with
corresponding pin definitions of
two terminals)
Figure 6: Battery external cable kits
CHECKING LIST

Page 17
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
Before You Start
•Installation Manual
•Location & Environment
•Tools & Accessories
•Compatible Inverter

Page 18
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
1)Battery Module Front Interface: US3000C
Figure 7: US3000C battery module front interface
Installation

Page 19
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
1)Battery Module Front Interface: UP5000
Figure 8: UP5000 battery module front interface
Installation

Page 20
Contact SegenSolar (PTY) Ltd | e: [e-mail] | t: 08780 20663
2) Cable connection
Figure 10: UP5000 battery cable connection diagramFigure 9: US3000C battery cable connection diagram
Installation
