Pylontech US Series Installation guide

PYLONTECH
Training Course

Why Energy Storage?
Why Lithium-ion Phosphate?
Why Pylontech?

PYLONTECH
US series / Phantom-S
PRODUCT TRAINING

UNPACKING
01
02 INSTALLATION
03 POWER ON/OFF
C O N T E N T
04 MULTIPLE STRINGS
05 TROUBLE SHOOTING

Product Parameter

UNPACKING
01

CHECKING LIST
1) For battery module package:
One pair of power cables,one communication cable,one grounding cable, user manual and warranty card.

CHECK LIST
2) For battery system connects to inverter:( extra small cable box)
One pair of power cables and one communication.

INSTALLATION
02

BEFORE YOU START
•Installation Manual
•Location & Environment
•Tools & Accessories
•Compatible Inverter

INSTALLATION
1) Battery Module Front Interface:

INSTALLATION
2) Connection:
The one with empty Link Port 0 is the Master
Battery Module, Which is connected to the
Inverter，others are slaves.
1 master battery configure with maximum 7
slave batteries in one string.

INSTALLATION
Power ≤ 5kW 5kW ＜Power ＜10kW

POWER ON/OFF
03

POWER ON/OFF
1) Power on:
Double check all the power cable and communication cable.
1.Switch ON all the battery modules by hard switch.
2.Press the Red SW button of master battery(≥ 0.5 sec).

POWER ON/OFF
1) Power on:

POWER ON/OFF
2) Power OFF:
Double check all the power cable and communication cable.
1.Press the Red SW button of master battery(≥0.5 sec).
2.Switch OFF the battery modules by the hard switch.

MULTIPLE STRINGS
04

LV-HUB
1) LV-HUB Front Interface:

Multiple Strings
1) Cables Connection Diagram for RS485: To Inverter
