Pyroistech FJORD-X2-1330-1550 User manual

FJORD-X2-1330-1550
Electrical characteristics
Power input (1)
Input Voltage 5 V
Input Current 2 A max
Connector type DC female 2.1 mm
(1) AC/DC adapter is included with the source. Input 100-240V 50-60Hz.
Optical characteristics
Output connector FC/APC or FC/PC
Peak wavelength 1330 –1550 nm
Spectral range FWHM 215nm
(2) Measured with a single mode fiber (Corning© SMF-28)
and an Optical Spectrum Analyzer (Anritsu MS9740A)
Other characteristics
Working Temperature 0 –50 ºC
Humidity <80 % HR
Cooling Air cooling (no fan)
Temperature control ±0.1 ºC
Stabilization time 1 min typ.
Size 127 x 49 x 180 mm
Characteristics
FJORD broadband light source covers the NIR
spectrum from 1200 to 1600 nm by means of the
combination of two SLED (Superluminescent Light
Emitting Diode) and delivers high output power into
single mode fibers. Temperature control enables
reduced stabilization time and stable output power.
Its compact, silent and sturdy design allows its
integration in whatever type of application, covering a
wide range of possibilities, from optical laboratories,
fiber optics testing, Bragg grating interrogation,
tomography, or industrial sensors among others.
Broadband multi SLED Light Source
www.pyroistech.com
[email protected]
-70
-65
-60
-55
-50
-45
-40
-35
-30
-25
-20
1100 1150 1200 1250 1300 1350 1400 1450 1500 1550 1600 1650 1700
Power (dBm/nm)
λ (nm)
Spectral power distribution
(2)

Safety Notes
•Do not remove or modify any installed safety device on this
equipment. Doing so will void your warranty and create an
unsafe operating environment.
•Dangerous currents are present in this device. There are NO
user serviceable parts inside.
•Only allow qualified personnel to service this unit.
•Inspect this unit and its power supply before using it for the
first time.
•Do not use the unit if it is damaged in any way. Contact your
dealer for repair or replacement information.
•During operation do not cover the source.
•Optical radiation can damage your eyes. Do not stare directly
at the light source output.
•Electrostatic discharge can harm inside parts of the source.
Take precautions to prevent ESD.
Operation Mode
Connect a proper power source (included with the light source) prior to operation.
The light source has an On/Off power button. Push the button to turn the light source on (a green
light will shine the power button when the light source is on). Wait for 2-3 minutes before using it, in
order to allow temperature stabilization of the SLED modules.
Press the On/Off button to turn off the light source.
Cover the fiber optic output with a cap when the light source is not in use to prevent dust and dirt
from getting inside the connector.
Laser classification
This light source is associated with class 3R according to the
norm IEC 60825-1. Do not look or stare directly into the fiber
connector output, invisible radiation can harm the users’ eyes.
FJORD-X2-1330-1550
