Pyronix ENFORCER V11 User manual

Document SAP: 102028845-01
ENFORCER V11
INSTALLATION GUIDE

ii ENFORCER V11 INSTALLATION GUIDE
DOCUMENT CONVENTIONS
TERMINOLOGY
INTERCHANGEABLE WORDS DESCRIPTION
Armed, set When an area or level is armed, if a zone is triggered, the system will follow
the appropriate (programmable) actions.
Disarmed, unset When an area or level is disarmed, the panel will not react unless specically
programmed to do so.
Siren, sounder, bell A warning device (usually external) that is generally congured to give
audible and visual notication that the system has been activated.
Area, partition
A group of zones assigned to be active when that particular area is armed.
This is usually named‘Area A’ or renamed to a personal choice such as‘Full Set’
or‘Shop’.
Zone, input This refers to a detector or sensor connected to the system, whether this be
wired or wireless.
Output, PGM, PG
An output is a signal from the panel to instruct another device to operate.
This is usually a voltage that triggers a wired siren, a garage door, a wireless
siren etc.
Bypass, omit
The act of stopping a zone from becoming armed. A wired zone will still
detect an intruder or object but the system will not react to it - a wireless
zone will become dormant.
ICONS
Important information
This information should be read and taken into consideration when installing. Failure to do so
may result in faults and unexpected errors with the system and/or peripherals.
Notes
Highlights parts of the process where extra care is needed or where sections of the programming
may be impacted by other options in the menus.
Hints
Helpful information for a smoother installation of the system.

3
ENFORCER V11 INSTALLATION GUIDE
CONTENTS
Document Conventions ii
Terminology ii
Icons ii
Introduction 4
Default codes 4
System Overview 4
Specication and Warranty 5
Technical Specication 5
Installation Guide 7
Mains and Earth Wiring 7
Inside of the Enforcer 8
Back plate 8
Front 8
Connecting the Control Panel Battery 9
Important Installation Notes 9
Input/Output Board 10
Connecting Arming Devices 10
Connecting keypads 10
Connecting internal proximity readers 11
Connecting external proximity readers 11
Connecting Peripherals 12
Wiring an external siren 12
Wiring zones 12
Connecting Expansion Modules 13
Connecting a wired zone expander 13
Connecting a wireless zone expander 13
Connecting an output expander 14
Certication 15

4ENFORCER V11 INSTALLATION GUIDE
INTRODUCTION
The Enforcer is a wireless alarm system that has been designed to enable easy installation and minimal
maintenance. The Enforcer protects the property (domestic or commercial) with a multitude of unique features:
• Two Way Wireless Protection
• Signal Strength Indicator (SSI)
• Instant Two Way Device Control
• Pyronix High Security Wireless Protocol Encryption
• Programmable Wireless Supervision Time
• Intelligent Wireless Jamming Detection
Default codes
Master Manager Code: 2222
Engineer Code: 1111
SYSTEM OVERVIEW
Areas 4
Wireless zones (max) 64 32x zones on board (zones 1-32)
1x wireless expander (zones 35-66)
Wired zones (max) 34 2x zones on I/O board (zones 33-34)
4x wired expanders (zones 35-66)
Total zones 66
Outputs (max):
38
3x outputs on I/O board
1x output module
4 on each wired expander
1 on each wired keypad
User/Manager codes: 80
(Max 32 x wireless keyfobs)
Duress/Guard codes: 2
Code combinations: 4294967295 (fully encrypted rolling code)
Communications: Additional to the on-board Wi-Fi module
DIGI-GPRS | DIGI-LAN | DIGI-PSTN | DIGI-PSTN/VOICE
Arming devices (max):
8
1x onboard keypad
3x wired keypads or internal/external proximity readers.
4x wireless keypads
4x tablets using HomeControlHUB application
Sirens: 2 wireless sirens or 2 wired sirens (in SCB mode)
Logs: 750
Remote arm and soak test P
Event signalling to UDL P
Memory type EEPROM
EN grade 2
Environmental class II

5
ENFORCER V11 INSTALLATION GUIDE
SPECIFICATION AND WARRANTY
TECHNICAL SPECIFICATION
ELECTRICAL
European rated voltage 230V AC -15/+10%
European rated current 83mA
Capable operating voltage 90 - 264V AC
Current 222mA - 75mA
Rated frequency 50/60Hz
Zone fuse rating T 2A (cannot replace)
PSU Type A
Radio frequency 868MHz, FM Transceiver Narrow Band
ENFORCER BATTERY
Output instant voltage 11V (with no mains and battery fully charged)
Peak to peak ripple voltage 10mVpk
Battery low voltage cut o value 8.5V
Type NiMH 8 cell 2200mAh rechargeable battery
CIE current when operating on battery backup 90mA
ENVIRONMENT
Physical dimensions (W x H x D) 220 x 160 x 50mm
Weight 1025g
Operating temperature -10°C to +40°C
Nominal temperature -10°C to +50°C
Storage temperature -20°C to +60°C
I/O BOARD IF CONNECTED
Zones 2 Wired (DEOL, SEOL)
Output voltage 13.2 VDC (nominal)
Max current for PGM output 70mA
SAB outputs 250mA Continuous Load
Bus fuse F500mA 250V Bus Fuse
Aux fuse F500mA 250V Aux Fuse
SYSTEMS ANALYSIS: ZONES MAX 66
Wireless 32
Wired 2
Zone expansion modules
4 wired (8 wired zones each)
EURO-ZEM8, EURO-ZEM8+ or EURO-ZEM8+PSU
1 wireless (32 wireless zones)
EURO-ZEM32-WE

6ENFORCER V11 INSTALLATION GUIDE
SYSTEMS ANALYSIS: OUTPUTS MAX 38
I/O Board 3 wired
Keypads/readers 3 wired
EURO-LCDPZ, EUR-107
Zone expansion modules 4 wired
EURO-ZEM8+
Output module 1 wired
EURO-OEM8R8T, EURO-OEM16R+PSU
Fuses 2x F500mA 250V
SYSTEM ANALYSIS: ADDITIONAL DEVICES
Keypads Up to 3
Readers Up to 3
External sirens 2
Wireless arming stations 4
Please note:
Compliance labelling should be removed or adjusted if non-compliant congurations are used.
Technical functions for example re, gas and ooding are not security graded as they are outside the
scope of EN50131-1 and EN50131-3.

7
ENFORCER V11 INSTALLATION GUIDE
INSTALLATION GUIDE
Please note:
It is recommended that the Engineer Menu is accessed prior to opening a powered Enforcer.
If any new peripherals are installed such as communications modules, expanders or arming devices, the
whole system should be powered down mains and battery prior to installing.
1. Slightly unscrew the two screws
located at the bottom.
Please note: Do not fully
unscrew as these can be used as
a‘hanger’ to the rear casing as
shown in Step 3.
2. Unhinge the front from the top
and pull down to disconnect.
Please note: Take care when
removing as modems, I/O
boards etc. may be connected to
the front.
3. Hang the front on the opening
screws at the bottom if required.
Shown above.
MAINS AND EARTH WIRING
It is important that the electrical earth connection is
connected when connecting the 230VAC mains supply
to the Enforcer.
Please note:
 Do not locate the mains cables next to internal cabling.
 Ensure that the control panel is not mounted on any metal surfaces.
 That the mains cables should not be internally‘looped’. This may interfere with the wireless antenna’s.
Where possible it is recommended that all mains cables should be installed through the area nearest the
mains terminals as shown above.
 The panel should be mounted at least 1 metre away from any source of electrical or radio interference
including but not limited to, mains consumer units, solar PV control equipment etc.
 If cable management is an issue, a spacer is available: ENF/SPACER-WE

8ENFORCER V11 INSTALLATION GUIDE
INSIDE OF THE ENFORCER
Back plate
1. Terminals for incoming mains power.
2. If a second communications path is required this space is
used to install the communications module.
DIGI-PSTN, DIGI-PSTN/VOICE, DIGI-GPRS, DIGI-LAN
3. Ferrite beads.
4. The transformer, which is situated in an insulated housing.
5. The rear tamper adjustment screw.
This should be used if the tamper from the front of the Enforcer isn’t sitting ush
to the back plate. E.g. if the Enforcer is installed on an uneven surface.
6. The I/O board.
1
3
2
4 5 6
Front
1. Back up battery compartment.
2. Tamper spring.
3. RS232 connection for upload/download to InSite software.
4. Communications module power connection.
5. I/O board connection.
6. The connection for a communication module to
be installed.
7. Transformer connection. (15VDC)
21
4
5 6 7
3

9
ENFORCER V11 INSTALLATION GUIDE
CONNECTING THE CONTROL PANEL BATTERY
1. Unscrew the battery
compartment.
2. Connect the battery pack. 3. Close the battery compartment
making sure no battery cables
are trapped underneath.
IMPORTANT NOTE: The control panel back up battery must be replaced by the manufacturer’s
recommendation. The part code for this battery is BATT9V6/2Ah1-WE and is a NiMH 8 cell 2200mAh
rechargeable battery.
Install the batteries in the space provided and connect the battery connector to the three pins as shown
above.
Reinstall the battery holder cover and dispose of the batteries in accordance with the local regulations.
IMPORTANT INSTALLATION NOTES
Ensure wiring is done to the national wiring regulations in the country where the installation is taking place. In
the UK, this is BS 7671 Requirements for electrical installations; IET Wiring Regulations (17th edition). If in doubt,
consult a local qualied electrician.
Ensure that a readily accessible disconnect device (such as an un-switched fused spur or plug and socket
(with approved cover to prevent accidental disconnection from mains supply)) is incorporated in the premises’
installation wiring. It must be provided external to the equipment at a distance of 30mm minimum and is
connected as closely as possible to the supply.
Ensure that the Input Output Board (I/O Board) used to connect wired keypads, readers, inputs and outputs to the
Enforcer is only connected to circuits operating at SELV voltage.
When securing external wires, ensure that means are provided in the installation to prevent the SELV or signal
circuits from coming into contact with live parts of the power supply circuit. Wires should be xed near their
terminal blocks.
The end of stranded conductor shall not be consolidated by soft soldering at places where the conductor is
subjected to contact pressure.
On completion of wiring use tie-wraps to prevent any loose wires causing a safety hazard (material of cables tie
shall be rated at least HB or better).
Cables ties and hoses shall be separate for power supply cable and SELV wirings.
Size of protective bonding conductors: minimum section 1.5mm².

10 ENFORCER V11 INSTALLATION GUIDE
INPUT/OUTPUT BOARD
The input/output (I/O) board contains the RS485 terminals that are used to connect additional wired keypads,
readers, zone expanders and output expanders along with terminals for wired zones and outputs.
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
BUS fuse
F500mA 250V
Auxiliary fuse
F500mA 250V
D1-
RS485 0V
D2+
RS485 +12V
D3
RS485‘A’Bus
D4
RS485‘B’ Bus
PGM
Programmable output
BELL
Bell output for a wired external siren
STB
Strobe output for a wired external siren
Z33
Wired zone 33
COM
Common terminal for Z33 and Z34 and -12VDC
auxiliary supply
+12V
+12VDC auxiliary supply
Z34
Wired zone 34
CONNECTING ARMING DEVICES
Connecting keypads
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
Up to 3 additional keypads can be connected to the Enforcer. These will be addressed individually and also
congured in the engineer function‘Assign KeypAds/ReAdeRs?’.
Addressing at the keypad
Each keypad is addressed individually in the keypad menu, press and hold the Dkey on the keypad until
‘SECURITY CODE’is displayed. Enter ‘2000’ and enter the assigned address (the rst keypad that is connected
should be addressed as‘01’). Press the akey to save the data and exit.

11
ENFORCER V11 INSTALLATION GUIDE
Connecting internal proximity readers
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
Up to 3 readers can be connected to the Enforcer. Each reader must be addressed as described below. These will
also need conguring in the engineer function ‘Assign KeypAds / ReAdeRs’.
Addressing at the reader
Address 01
SWITCH 1 ON.
Address 02
SWITCH 2 ON.
Address 03
SWITCH 1: ON, SWITCH 2: ON.
Please note: If using the internal reader as access control or entry control please refer to the peripheral
instructions for connection details
Connecting external proximity readers
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
If an additional external reader is connected, this will need to be assigned in the programming,‘Assign KeypAds/
ReAdeRs’. Each reader will also need to be addressed individually via connecting certain wires to ground.
Addressing at the external reader
Address 01
Brown and orange to 0V/GND
Address 02
Brown and green to 0V/GND
Address 03
Brown to 0V/GND
Please note: If using the external reader as access control or entry control please refer to the peripheral
instructions for connection details

12 ENFORCER V11 INSTALLATION GUIDE
CONNECTING PERIPHERALS
Wiring an external siren
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4 SCB
SAB
J3
B (G2)
A (G3)
J4
J7
LED
DISABLE
EXT
INT
J8
SOUNDER
J12
BL
TAMPER
SOUNDER
Red
Gold
Red
Red
To create the siren tamper circuit, a 2k2 resistor is required across 0V supply and one of the tamper terminals in
the external siren. The other tamper terminal should be connected to the tamper return (either zone 33 or 34 on
the I/O board). Note, the zone must be programmed as‘tamper’.
The resistor value will correspond to the value selected in‘WiRing ChoiCe’.
IMPORTANT NOTE: The external siren connected needs to be set in SCB mode unless it is a Pyronix
external siren.
Wiring zones
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
+ -
6K8
5K6
4K7
2K2
1K
5K6
4K7
2K2
1K
TAMPERALARM
ALARM
NCNO
TAMPER LED
+ -
6K8
5K6
4K7
2K2
1K
5K6
4K7
2K2
1K
TAMPERALARM
ALARM
NCNO
TAMPER LED
The End of Line (EOL) value for all wired zones is programmed in‘Choose Mode’. At default the resistor values are
4k7 for alarm and 2k2 for tamper.

13
ENFORCER V11 INSTALLATION GUIDE
CONNECTING EXPANSION MODULES
Connecting a wired zone expander
Up to 4 wired zone expanders can be connected to the Enforcer.
- + D3 D4
---485 BUS---
0V +12V
AUX
ALARM TAMPER
EOL INPUT 1 COM
ALARM TAMPER
EOL INPUT 2 COM
ALARM TAMPER
EOL INPUT 3 COM
ALARM TAMPER
EOL INPUT 4 COM
ALARM TAMPER
EOL INPUT 5 COM
ALARM TAMPER
EOL INPUT 6 COM
ALARM TAMPER
EOL INPUT 7 COM
ALARM TAMPER
EOL INPUT 8 COM
POWER OK FAU LT
HOLD OFF
1 2 4 8
16 32
RESET
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
Please note: The above shows the I/O board connected to a EURO-ZEM8, a EURO-ZEM8+ is connected in
the same way. If using a EURO-ZEM8+PSU, the D2+ MUST NOT be connected.
ZEM address 0
Zones 35-42
ZEM address 1
Zones 43-50
ZEM address 2
Zones 51-58
ZEM Address 3
Zones 59-66
Connecting a wireless zone expander
1 wireless zone expander can be connected to the Enforcer however, this expander can take the place of 4
addresses potentially expanding the system by 32 wireless peripherals.
IMPORTANT NOTE: The wireless ZEM must be addressed as‘Device B’via the jumper headers.
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
- + D3 D4 T T
The wireless ZEM allows a maximum 32 wireless zones to be learnt. These 32 zones are programmed as 4 dierent
ZEMs (addresses), and each having 8 wireless zones assigned.
Example
Wired and wireless zone expanders can be installed together on a system and, as long as they are addressed
uniquely, they will work alongside each other. For instance, if you wish to use 24 wireless zones and 8 wired zones,
you can program the wireless ZEM as ZEM addresses 00, 01 and 02 in the menu item‘instAll ZeM’ and learn 24
zones to the system using the‘WiReless deviCe ContRol’menu. Then address a wired ZEM as ZEM 03.

14 ENFORCER V11 INSTALLATION GUIDE
Wireless ZEM header addressing
WIRELESS ZEM ADDRESS DEVICE A
03
DEVICE B
47
DEVICE C
811
ZEM32-WE
ZEM address 00 OFF ON OFF
ZEM address 01 OFF ON OFF
ZEM address 02 OFF ON OFF
ZEM address 03 OFF ON OFF
Wireless ZEM zone mapping
WIRELESS ZEM ADDRESS ZONES
ZEM32-WE
ZEM address 00 35-42
ZEM address 01 43-50
ZEM address 02 51-58
ZEM address 03 59-66
Please note: Wireless zones 35-66 can take upto 5 minutes to become active when armed.
Connecting an output expander
1 remote output expander can be connected to the Enforcer. The output expander allows 16 additional outputs.
PGM STB BELL Z33 COM +12V Z34D1- D2+ D3 D4
D1- D2+ D3 D4 D1- D2+ D3 D4
Please note: The above shows the I/O board connected to a EURO-OEM8R8T. If the expander is a EURO-
OEM16R+PSU, the D2+ terminal must not be connected to the I/O board.

15
ENFORCER V11 INSTALLATION GUIDE
CERTIFICATION
All wireless devices comply with the following EU and UK requirements:
DIRECTIVE EU UK
EMC 2014/30/EU Electromagnetic Compatibility Regulations 2016
No. 1091
Low Voltage 2014/35/EU Electrical Equipment (Safety) Regulations 2016
No. 1101
RE Directive 2014/53/EU Radio Equipment Regulations 2017 No. 1206
RoHS 2011/65/EU and COMMISSION
DELEGATED DIRECTIVE (EU) 2015/863
The Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Regulations 2012 No 2032
And meet the following standards where relevant:
EMC
EN 61000-6-3:2007 +A1:2011 EMC. Generic emission standard. Residential, commercial and light
industry
EN 50130-4:2011 +A1:2014 EMC. Immunity requirements for components of re, intruder and
social Wireless Alarm Systems
ETSI EN 301 489-3: V2.1.1 (2019-03) EMC. Radio equipment. Part 3: Short range devices (SRD) 9kHz to
40GHz
LOW VOLTAGE SAFETY
EN 62368-1:2014+A11:2017 Audio/video, information and communication technology equipment.
Safety requirements
RE DIRECTIVE
ETSI EN 300 220-1 EMC. Receiver Class 1, Environmental Category 1
CERT/ERC Recommendation 70-03 Annex 1
SECURITY STANDARDS
EN 50131-1: 2006 + A1: 2009
+A2:2017
Alarm systems — Intrusion and hold-up systems - Part 1: System
requirements
EN 50131-3: 2009 Alarm systems – Intrusion and hold-up systems - Part 3: Control and
indicating equipment
EN 50131-6: 2017 Alarm systems – Intrusion and hold-up systems - Part 6: Power supplies
EN 50130-5: 2011 Alarm systems - Part 5: Environmental test methods
EN 50131-5-3:2017 Grade 2. Interconnections for equipment using radio frequency
techniques
PD 6662: 2017 (UK only) PUBLISHED DOCUMENT Scheme for the application of European
Standards for intrusion and hold-up alarm systems
ROHS
BS EN IEC 63000: 2018
Technical documentation for the assessment of electrical and
electronic products with respect to the restriction of hazardous
substances
Compliant operation is only guaranteed when installed and operated according to the relevant installation and
user manuals.
