Programming and Installation Manual
Wireless Alarm System
RINS1549-4
EN50131-1:2006+A1:2009
EN50131-3:2009
EN50131-6:2008
EN50131-5-3:2005+A1:2008
PD6662:2010
Security Grade 2
Environmental Class II
Software Version >9.13
PIEZO WARNING
The Enforcer system contains a
100dBA siren, please be aware
of this after an activation

Enforcer Programming Manual
Page: 2
CONTENTS PAGE
1. Introduction ............................................................................................................................4
1.1 System Overview.................................................................................................................4
1.2 Number of Additional Devices ................................................................................................4
2. The Engineer Menu...................................................................................................................5
2.1 Entering The Engineer Menu..................................................................................................5
2.2 Exiting The Engineer Menu ....................................................................................................5
2.3 Useful Engineer Menu's.........................................................................................................5
3. General Information .................................................................................................................6
3.1 Default Codes .....................................................................................................................6
3.2 Initial Power Up...................................................................................................................6
3.3 Testing The Keypad .............................................................................................................6
3.4 Keypads / Readers...............................................................................................................6
3.5 Text Programming ...............................................................................................................7
3.6 Set / Unset System..............................................................................................................8
3.7 Forced Arm On Inputs ..........................................................................................................8
4. The Engineer Menu...................................................................................................................9
4.1 Software Revision ................................................................................................................9
4.2 Choose Mode ......................................................................................................................9
4.3 Install ZEMs...................................................................................................................... 10
4.4 Wireless Device Control ......................................................................................................10
4.5 Change Inputs ..................................................................................................................13
4.6 Assign Keypads/Readers.....................................................................................................14
4.7 System Displays ................................................................................................................16
4.8 Change Timers .................................................................................................................. 17
4.9 Date and Time .................................................................................................................. 17
4.10 Exit Modes ...................................................................................................................... 17
4.11 Change Codes .................................................................................................................18
4.12 Volume Control................................................................................................................ 19
4.13 Alarm Response...............................................................................................................19
4.14 Change Outputs............................................................................................................... 20
4.15 Intelligent Set ................................................................................................................. 21
4.16 Site Options ....................................................................................................................21
4.17 Engineer Reset Options.....................................................................................................23
4.18 Review Logs....................................................................................................................23
4.19 Engineer Tests.................................................................................................................24
4.20 Diagnostics .....................................................................................................................26
4.21 Set Up Downloading .........................................................................................................28
4.22 Program ARC / SMS? ........................................................................................................30
4.23 Dial Out Menu .................................................................................................................32

Page: 3
4.24 Clean Start ..................................................................................................................... 33
5. Specification and Warranty ......................................................................................................34
5.1 Technical Specification........................................................................................................34
5.2 Product Information ...........................................................................................................34
5.3 Warranty ..........................................................................................................................34
6. Installation Guide ...................................................................................................................35
6.1 Mains and Earth Wiring....................................................................................................... 35
6.2 Inside of the Enforcer 32-WE: Rear ...................................................................................... 36
6.3 Inside of the Enforcer 32-WE: Front .....................................................................................36
6.4 Connecting / Replacing the Control Panel Battery ...................................................................37
6.5 Important Installation Notes................................................................................................37
6.6 RS232 Connection / Uploading and Downloading Software....................................................... 38
6.7 Input / Output Board..........................................................................................................39
6.8 Connecting Peripherals to the I/O Board ...............................................................................39
6.9 Connecting an Input Expander.............................................................................................42
6.10 Connecting an Output Expander ......................................................................................... 42
6.11 PSTN Modem...................................................................................................................43
6.12 GSM Modem.................................................................................................................... 43
Appendix A. Defaults .............................................................................................................. 45
Appendix B. Input Types .........................................................................................................49
Appendix C. Timers ................................................................................................................50
Appendix D. Output Types .......................................................................................................51
Appendix E. Content Types ...................................................................................................... 54
Appendix F. Fault Codes.......................................................................................................... 55
Default Codes:
User Code: 1234
Master Manager Code: 2222
Factory Default Codes:
Clean start with the code ‘2000’ (UNGRADED) - See page: 33
This is the default clean start
Clean start with the code ‘2020’ (PD6662 EN Defaults) - See page: 33
Other Codes:
Keypad Security Code: ‘2000’
Delete All Wireless Data: ‘2000’

Enforcer Programming Manual
Page: 4
1. Introduction
The Enforcer 32-WE is a wireless alarm system that has been designed to enable easy installation and
minimal maintenance. The Enforcer 32-WE protects the property (domestic or commercial) with a
multitude of unique features:
• Two Way Wireless Protection
• Signal Strength Indicator (SSI)
• Instant Two Way Device Control
• Pyronix High Security Wireless Protocol Encryption
• Programmable Wireless Supervision Time
• Intelligent Wireless Jamming Detection
1.1 System Overview
Areas: 4 (1 single partition – 4 Levels Sets)
Wireless Inputs (max): 32
Wired Inputs (max): 34 (2 x inputs on I/O board (Inputs 33-34) and 4 x ZEMs
(Inputs 35-66)
Total Inputs: 66
Outputs (max): 38 (1 x output module and 3 x outputs on I/O board, 4 on each ZEM
if EURO-ZEM8+ or EURO-ZEM8+PSU are used, 1 on each RKP)
User / Manager Codes: 80 (Max 32 x wireless keyfobs)
Duress / Guard Codes: 10
Communications: PSTN (Digi-1200) or GSM (Digi-GSM) modem
Arm Devices (max): 4 (Including main keypad).
Logs: 750
Remote Arm and Soak Test: 
Event Signalling to UDL: 
Memory Type: EEPROM
Compliant to EN Grade*:2
Environmental Class: II
1.2 Number of Additional Devices
Input Expanders (Wired): 4
Wireless Keyfobs: 32
Code Combinations: 4294967295 (fully encrypted rolling code)
Wireless Keyfob Variants 1
Wireless Bells: 2
Output Expanders: 1
Additional Keypads:
External Readers: 3
Internal Readers:
NOTE : All wireless learning is performed in the ‘WIRELESS DEVICE CONTROL’menu, see page: 10 for
more details.
*Compliance labelling should be removed or adjusted if non-compliant configurations are used.
*Please note that technical functions for example fire, gas and flooding are not security graded as they
are outside the scope of EN50131-1 and EN50131-3.

Page: 5
2. The Engineer Menu
The Engineer Menu must be accessed in order to program all system configurations.
NOTE 1: All tamper alarms (including case tamper), will be disabled once in the Engineer menu.
NOTE 2: All personal attack and fire alarms will cause an alarm in the Engineer Menu.
2.1 Entering The Engineer Menu
Access to the Engineer menu will be allowed if the Enforcer 32-WE is unset. If set, the Enforcer 32-
WE must be unset first via a valid user code/tag/keyfob in order to gain access. If the 'Allow Engineer
Menu' function in the Master Manager Menu is set as 'No', the message ‘Authorisation Required’ will
be shown and access will be denied until this option is set as 'Yes'.
1. Enter the Engineer code (default 1111).
2. Press if any faults appear.
3. 'SET/UNSET SYSTEM' is displayed (see page:8).
4. Press .
5. 'FORCE ARM ON 1st INPUT' is displayed (see page:8).
6. Press .
7. 'SOFTWARE REVISION' is displayed.
8. Engineers Menu has been accessed.
Refer to page: 9 for all functions.
When the Engineer Menu is accessed, a high pitch tone is generated intermittently.
NOTE 1: It is recommended that a factory default (Clean Start) is performed after initial power up to
ensure that the correct defaults have been chosen (see page: 33).
NOTE 2: Refer to Appendix F, page: 55 for all fault code display descriptions.
2.2 Exiting The Engineer Menu
1. On a Main Menu Item (a menu that is in capital
letters), press or scroll to 'EXIT ENGINEERS
MENU' and press .
2.3 Useful Engineer Menu's
WIRELESS DEVICE CONTROL (Page: 10): Learns and deletes all wireless inputs and bells. To
learn keyfobs enter the Master Manager menu and scroll to CHANGE CODES. (Refer to the user
manual)
CHANGE INPUTS (Page: 13): Programs all input types, attributes, areas and names and on the
Enforcer 32-WE.
ASSIGN KEYPADS/READERS (Page: 14): Assigns keypads and readers, and enables readers for
entry control. NOTE: Keypads and Readers must be addressed at the device and at the keypad.
CHANGE CODES (Page: 18): Changes the Engineer code and Master manager code. To change user
codes enter the Master Manager menu and scroll to CHANGE CODES. (Refer to the user manual).
CHANGE OUTPUTS (Page: 20): Programs any outputs and assigns output modules to the Enforcer
32-WE.
DIAGNOSTICS (Page: 26): Displays power, input status, wireless signal strength and wireless
battery levels.
PROGRAM ARC/SMS (Page: 30): Enables the modem (if connected) and allows signalling of
communication formats and SMS.
Enforcer
Time 13:43 c
Enter Your Code
[ ]
SET / UNSET
SYSTEM?
FORCE ARM ON 1st
INPUT? [01]
EXIT ENGINEER
MENU?

Enforcer Programming Manual
Page: 6
3. General Information
3.1 Default Codes
User: 1234. Master Manager: 2222 Engineers: 1111
3.2 Initial Power Up
Power up the Enforcer 32-WE system, an alarm will be generated. Proceed to the nearest keypad,
which will display (from power up):
1. Once power has been applied to the Enforcer 32-WE
(see page: 37). 'Please Wait' and then '485 Comms
Lost' will be displayed. After approximately one
minute, the Enforcer 32-WE will display the name and
the time on the display.
2. The Enforcer 32-WE is defaulted to keypad address
'0'.
NOTE: The wording 'Enforcer 32-WE' can be changed in the function ‘SYSTEM DISPLAYS' –see page:16.
3.3 Testing The Keypad
With the system unset, press the key for 10 seconds at any keypad. This will cause all the LEDs
on that keypad to illuminate, and the LCD screen to scroll a display testing each pixel. The keypad
will revert to normal display approximately 10 seconds after the key is released.
3.4 Keypads / Readers
3.4.1 The Enforcer Keypad and additional keypads (EUR-068)
3 additional wired keypads may also be connected to the Enforcer 32-WE. Refer to page: 39 for
installation details.
KEY FUNCTIONS:
a= Exit manager menu / Selects Area A.
b= Moves backwards to the previous menu item / Selects Area B.
c= Enables chime and displays additional information in the log / Scrolls back ‘one’ in a sub
menu / Selects Area C.
D= Moves forward in the log / scrolls between options and enters the master manager menu
/Selects Area D.
fp = Not used.
[] = Directional buttons.
I= Selects items and enters menus.
A= Cancels items, resets the panel and moves to next item in a menu item.
NOTE: If any additional keypads are installed on the Enforcer 32-WE, it is possible to access the
Engineer Menu on any keypad. For example, if the Engineer menu is accessed on keypad address
0, the other keypads will display ‘system busy’, to access the Engineer menu on any other
keypad, press the key on the relevant keypad and the Engineer menu will be displayed.
Please Wait...
Enforcer
Time 13:43 c
Enforcer
Time 13:43 c
Enforcer
Time 13:43 c
Tag

Page: 7
3.4.2 The Internal Tag Reader (EUR-107)
The Internal tag reader can be used for setting/unsetting, entry control or access control. Refer
to page: 40 for installation details.
Tag Area (Where a valid tag must
be presented to set/unset)
Alert LED
Alarm LED
Tamper LED
Fault LED
Unset LED
3.4.3 The External Tag Reader (EUR-108)
The Internal tag reader can be used for setting/unsetting, entry control or access control. Refer
to page: 40 for installation details.
To set/unset the system using the External Tag Reader,
present a pre-programmed tag to the centre of the prox.
The prox will display the system status: Green = Unset.
Red = Set. Present the tag again within 10 seconds and
the system will set or unset.
The system will then set depending on the type of exit
mode programmed (Final door, Timed or Push to set)
3.5 Text Programming
Text may be programmed for input names, for the ‘sign-on’
message, and to identify the Set Level being set / unset. Each key is
allocated alpha-numeric and punctuation marks characters as shown
below:
The Enforcer 32-WE incorporates predictive text, so the system will
predict the word that is being spelt. For example, if ‘B’ is pressed,
and then and ‘e’ is pressed, Bedroom will be displayed, to accept
this press . If the word that is required doesn’t appear on the
LCD display, type the word as normal.
To type a word, press the relevant key the appropriate number of
times – e.g. for the letter ‘k’ press twice, or for the letter ‘s’
press four times.
For punctuation marks, press the key.
In addition, the keys are used as follows:
= make the character into a capital
= move cursor left
= clears cursor / adds a space
= moves cursor right

Enforcer Programming Manual
Page: 8
3.6 Set / Unset System
Setting and unsetting the system can be done using the Engineer code.
1. Enter the Engineer code (default 1111).
2. Press if any faults appear.
3. 'SET/UNSET SYSTEM' is displayed.
4. Press .
5. Select the areas to set. Press .
6. The setting period will begin.
7. Once the timer expires, and a beep is heard, the Enforcer
32-WE is set.
8. To unset, enter the engineer code again.
3.7 Forced Arm On Inputs
The 'Force Arm On Inputs' function enables two nominated inputs on the Enforcer 32-WE to be set.
Either input can be triggered to allow real life signalling or alarm testing. This function is useful when
a building is full of people and these tests are needed.
NOTE 1: The system will give the correct signalling response to the Setting, and any resulting alarm.
NOTE 2: If the system has been set by any other code, the Engineer code will not unset it.
1. Enter the Engineer code (default 1111).
2. Press if any faults appear.
3. 'SET/UNSET SYSTEM' is displayed.
4. Press .
5. 'FORCE ARM ON 1st INPUT' is displayed.
6. Enter the 1st input that is to be active. Press .
7. Enter the 2nd input that is to be active. Press .
8. Select the areas to set. Press .
9. The setting period will begin
10. Once the timer expires, and a beep is heard, the
Enforcer 32-WE is set and the 2 inputs chosen will be
active.
11. To unset, enter the engineer code again.
SET / UNSET
SYSTEM?
SET AREAS
[A ]
Setting [007]
Full Set
FORCE ARM ON 1st
INPUT? [01]
FORCE ARM ON 2nd
INPUT? [01]
SET AREAS
[A ]

Page: 9
4. The Engineer Menu
Any programming is only saved when exiting the Engineer menu. It is recommended that a Clean start is
performed after initial power up. See page: 33.
4.1 Software Revision
This option identifies the software version number, software serial number and product.
Software Revision Programming
1. Press or to scroll to 'SOFTWARE REVISION'.
Press .
2. The software revision will be displayed (e.g. V9.13)
Press orto return to the Engineer menu.
NOTE: The HUB software version is labelled on the PCB.
4.2 Choose Mode
If an Enforcer 32-WE I/O board or any Zone Expander Module (Input Expanders: ZEMs) are used, the
resistance, EOL mode and response time of the inputs can be programmed.
NOTE: Alarm 4K7, Tamper 2K2 must be selected if wiring double pole to an expander.
4.2.1 EOL Range (End of Line Range)
EOL Range programs the panel to operate with different resistor values
[0] Alarm: 1K, Tamper: 1K. [1] Alarm: 4K7, Tamper: 2K2.
[2] Alarm: 4K7, Tamper: 4K7. [2] Wide range.
4.2.2 EOL mode (Double End of Line (DEOL) or Single End of Line (SEOL))
EOL Mode programs all input expanders to operate as:
[0] Single End of Line (SEOL). [1] Double End of Line (DEOL).
4.2.3 Input Response Time
Input Response time programs the time that an input trigger must be present before the
Enforcer 32-WE system generates an alarm.
[01]-[30] = 100ms to 3000ms
NOTE: Settings below (<) 400ms do not comply with PD6662/EN50131.
Choose Mode Programming
1. Press or to scroll to 'CHOOSE MODE'. Press
.
2. Press [or ]to select the 'EOL Range' for all wired
inputs*. Press .
3. Press [or ]to select the 'EOL Mode' for all wired
inputs*. Press .
 Press [or ]to select the 'Input Response
Mode' for all wired inputs*. Press to return to the
Engineer Menu.
*On the I/O board and the expanders
SOFTWARE
REVISION?
Rev v09.13
0000ee02Enforcer
CHOOSE MODE?
EOL Range
4K7/2K2 [1]
EOL Mode
DR [1]
Input Response
100ms [01]

Enforcer Programming Manual
Page: 10
4.3 Install ZEMs
The Enforcer 32-WE supports up to 66 inputs. This is mapped by 32 wireless inputs and 34 wired
inputs.
4.3.1 ZEM Address
[0] ZEM Address 0 (Inputs 35-42) [1] ZEM Address 1 (Inputs 43-50)
[2] ZEM Address 2 (Inputs 51-58) [3] ZEM Address 3 (Inputs 59-66)
NOTE: Inputs 33 and 34 are taken from the I/O board, this does not need to be addressed.
4.3.2 ZEM Installed
[0] No [1] ZEM8 / EURO37R (see page: 39)
4.3.3 Enter Location
The text entered here will be displayed on the LCD display if a fault occurs on the ZEM, so the
ZEM can be easily located or referenced. For example, the location text maybe "ZEM Kitchen",
"ZEM Loft" etc.
Install ZEMS Programming
1. Press or to scroll to 'INSTALL ZEMS'. Press
.
2. Press [or ]to select the 'ZEM Address' . Press
.
3. Press [or ]to select the 'ZEM8 or EURO37R' or
No' to 'ZEM Installed'. Press .
4. Enter the location of the ZEM. This is so it is
referenced and will appear on the display if a fault
occurs. Press to return to ZEM addressing.
5. Press to return to the Engineers menu.
4.4 Wireless Device Control
The Enforcer 32-WE supports a maximum of 32 wireless inputs, 32 wireless keyfobs and 2 wireless
Deltabell external sounders.
4.4.1 Control Inputs
'Control Inputs' learns and deletes wireless inputs.
4.4.2 Control Bells
'Control Bells' learns and deletes wireless Deltabell external sounders.
4.4.3 Programming Keyfob Buttons
'Program Keyfob Buttons' assigns actions to each buttons on the keyfob.
NOTE: Keyfobs are learnt in the Master Manager Menu in the function 'CHANGE CODES'. Refer to
the user manual (RINS1548).
[0] No action: Disables the button [1] Show Status: GREEN = Unset. RED = Set.
[2] Set Area: Sets the chosen area [3] Unset Any Area: Unsets any area on the system
[4] Latch Output: Latches an output (programmable) when the nominated button is pressed.
[5] Timed Output: Activates an output for a period of time (programmable in seconds)
[6] Personal attack: Activates a personal attack activation (programmed in Engineers only)
INSTALL ZEMS?
ZEM Address
[0]
ZEM Installed
No [0]
Enter Location
_

Page: 11
Wireless Device Control Programming: Learning Inputs
1. Press or to scroll to 'WIRELESS DEVICE CONTROL'. Press
.
2. 'Control Inputs' will be displayed. Press .
3. 'Learn Devices' will be displayed. Press .
4. Press [or ]to select the input (1-32) to learn and press .
5. Open the Enforcer 32-WE wireless device and press and hold the
'LEARN' button until all LEDs flash
NOTE: The learn process is the same on all wireless contacts,
detectors, and sensors. Once the GREEN LED is flashing, the learn
process has been successful. Repeat the process above if the learn
procedure has not been successful.
Wireless Device Control Programming: Deleting Inputs
1. Press or to scroll to 'WIRELESS DEVICE CONTROL'. Press
.
2. 'Control Inputs' will be displayed. Press .
3. 'Learn Devices' will be displayed. Press .
4. 'Delete Devices' will be displayed. Press .
5. 'Delete All' will be displayed, press and enter '2000' to delete
all wireless peripherals, or press to delete individual inputs.
6. The inputs that are learnt will be displayed, press [or ]to
select the inputs and press to delete it.
7. 'Input Deleted' will be displayed.
8. NOTE: Once a wireless input is deleted, the input type must be
set to 'unused' in the function 'CHANGE INPUTS' (see page: 13).
LEARN
>5s
WIRELESS DEVICE
CONTROL?
Control Inputs?
Learn Devices?
Input 01
Available [01]
Learning...
Input Learnt!
WIRELESS DEVICE
CONTROL?
Control Inputs?
Learn Devices?
Delete Devices?
Delete All?
Input 01
Learnt [01]

Enforcer Programming Manual
Page: 12
Wireless Device Control Programming: Learning Bells
1. Press or to scroll to 'WIRELESS DEVICE CONTROL'. Press
.
2. 'Control Inputs' will be displayed. Press .
3. 'Control Bells' will be displayed. Press .
4. 'Learn Devices' will be displayed. Press .
5. Press [or ]to select the bell (1 or 2) to learn and press .
6. Open the Enforcer 32-WE wireless Deltabell and press and hold the
'LEARN' button until all LEDs flash
NOTE: Once the GREEN LED is flashing, the learn process has been
successful. Repeat the process above if the learn procedure has not
been successful.
Wireless Device Control Programming: Deleting Bells
1. Press or to scroll to 'WIRELESS DEVICE CONTROL'. Press
.
2. 'Control Inputs' will be displayed. Press .
3. 'Control Bells' will be displayed. Press .
4. 'Learn Devices' will be displayed. Press .
5. 'Delete Devices' will be displayed. Press .
6. 'Delete All' will be displayed, press and enter '2000' to delete
both wireless Deltabell external sounders, or press to delete
individual external sounders.
7. The external sounders that are learnt will be displayed, press [
or ]to select the bell and press to delete it.
8. 'Bell Deleted' will be displayed.
LEARN
>5s
WIRELESS DEVICE
CONTROL?
Control Inputs?
Control Bells?
Learn Devices?
Select Bell
Available [1]
Learning...
Bell Learnt!
WIRELESS DEVICE
CONTROL?
Control Inputs?
Control Bells?
Learn Devices?
Delete Devices?
Delete All?
Select Bell
Learnt [1]

Page: 13
Wireless Device Control Programming: Program Keyfob Buttons
1. Press or to scroll to 'WIRELESS DEVICE CONTROL'. Press
.
2. 'Control Inputs' will be displayed. Press .
3. 'Control Bells' will be displayed. Press .
4. 'Program Keyfob Buttons' will be displayed. Press .
5. Press [or ]to select the user (1-80) to learn and press .
6. Press [or ]to select the button to be programmed and press
.
7. Press [or ]to select the action of the button and press .
8. Select the area that the keyfob should be programmed in, press
.
NOTE: Keyfobs are learnt in the Master Manager Menu under
'CHANGE CODES'. Refer to the user manual.
4.5 Change Inputs
A total of 66 inputs can be programmed on the Enforcer 32-WE system. All inputs are unused by
default. To save any programming the Engineer menu must be exited.
4.5.1 Input Types
See Appendix B, page 49 for all input type options.
Most commonly used input types:
[06] Intruder. [07] Final Exit. [08] Entry Route. [13] Day Alarm.
NOTE 1: If an alarm is triggered from an Entry Route input, it will store for 2 seconds before an
alarm is activated. If a Final Exit input is triggered within this time, the system will select entry
time, rather than an intruder alarm.
NOTE 2: Inputs may be automatically inhibited (omitted) at the time of reinstatement at the end
of confirmation time.
4.5.2 Input Areas
The Enforcer 32-WE supports up to 4 areas. This allows 'home and away' settings. For example:
Area A: All inputs set in the house.
Area B: All inputs downstairs are active. All inputs upstairs are inactive (night time setting)
Area C: All inputs upstairs are active. All inputs downstairs are inactive
Area D: Inputs in Garage are active.
NOTE: The areas are not independent of one another, they work on the same level.
4.5.3 Input Attributes
The following attributes can be applied to any input:
Chime: The internal sounder of the Enforcer will sound a chime if enabled. Single: Chimes once
when the input is triggered. Follow: Chimes when the input is triggered and only stops once the
input is inactive. To enable/disable the chime in day mode press , when a 'c' is displayed on
the keypad, the chime is enabled.
Omittable: Enables the input to be manually omitted (disabled) from the setting procedure. To
omit inputs, there is a function in the Master Manager menu called 'OMIT INPUTS'.
Double Knock: The control will only generate an alarm if this input is triggered twice within a
pre-set period, or if the input remains in fault condition for that period.
WIRELESS DEVICE
CONTROL?
Control Inputs?
Control Bells?
Program Keyfob
Buttons?
User [01]
Select Button
Lock [1]

Enforcer Programming Manual
Page: 14
Normally Open: Enables the system to respond correctly when detectors of ‘normally open’
configuration are wired to the system. Alternatively converts input types which default to
‘normally open’ (e.g. Push to set) to operate with normally closed devices.
Confirm Group: If inputs are selected into the same confirm group, each input will only
generate an unconfirmed alarm (and will not generate a confirmed activation). This is useful
when two or more shock sensors are being activated by the same event. If a confirm group is
selected as ‘00’, the inputs are not part of any group.
4.5.4 Input Description
A name and location can be entered here. The name will appear on the display if an alarm has
occurred; the location is used for a more detailed reference if required.
Change Inputs Programming
1. Press or to scroll to 'CHANGE INPUTS'. Press .
2. Press [or ]to select the input to program (01-66). Press .
'Input Type' will be displayed. Press [or ]to select the
input type or input the shortcut number (see Appendix B,
page 49 for all input type options.
3. Press 
4. 'Input Area' will be displayed. Select the Area's to be assigned to
the input and press .
5. 'Input Attributes' will be displayed. If any attributes are needed for
the input, press and press [or ]to select between the
attribute enable/disable options and press to go to the next
attribute.
6. 'Enter Name' will be displayed. Enter the name of the input and
press . This will be displayed if it is activated or when a fault
occurs.
7. 'Enter Location' will be displayed. Enter the location of the input
and press . This will be displayed if it is activated or when a
fault occurs after the name of the input has been shown.
8. Press [or ]to select another input to program (01-66) or
press the key to return to the Engineer menu.
4.6 Assign Keypads/Readers
Any additional keypads or readers must be addressed correctly before enabling them in this function.
The Enforcer 32-WE keypad is automatically addressed as 0 on initial power up. Refer to page: 39 for
more information.
4.6.1 Address
Up to 3 x additional keypads or readers may be installed. Address 0 is used for the Enforcer 32-
WE on-board keypad.
NOTE: Each keypad has its own individual menu that programs the key-click volume, tag volume
and master volume. It will address a keypad, show the status of the keypad inputs (if
programmed), force the backlight on or off and the identification number of a tag (once a tag is
presented). The PA/Fire timer can be programmed. This menu also addresses the keypad.
To enter the keypad menu, press and hold the key until ‘SECURITY CODE’ is displayed, and
then enter ‘2000’. This function is also used to address the keypad.
4.6.2 Type
[0] Keypad. [1] Reader. [2] Not Used.
4.6.3 Reader is
If a reader is installed, the following options can be assigned to the reader:
[0] Set Point: Reader used for setting and unsetting.
[1] Not Used: Reader disabled
[2] Access Control: If an access control system is installed then the reader must be
CHANGE INPUTS?
Input [01]
Input 01
Input Type [07]
Final Exit
Input Areas
[A ]
Input Attribtes?
Enter Name
_
Enter Location
_

Page: 15
programmed as this type. The lock open time and door open time can be programmed (in
seconds).
[3] Unset Only: If the Reader is to be used as an unset device only, select this type.
[4] Entry Control: Used to lock/unlock doors. The external or internal reader can have
magnetic locks connected to them. This option is used in conjunction with ‘tag opens doors’ in
'SITE OPTIONS' page: 21. The lock open time and door open time can be programmed (in
seconds).
4.6.4 Default Level
Selects the area that the device will be defaulted to.
4.6.5 Set Point Description
A name and location can be entered here. The name will appear on the display if an alarm has
occurred, the location is used for a more detailed reference if required. E.g. Name = Entrance
Keypad. Location = Hall
Programming Keypads: Assign Keypads/Readers
1. Press or to scroll to 'ASSIGN KEYPADS/READERS'. Press
.
2. Press [or ]to select the address. Press .
3. 'Type' will be displayed. Press 0to select keypad.Press 
4. 'Default Area' will be displayed. Select the default area. Press .
5. 'Set Point Description' will be displayed. Press to enter the
name and location if required.
6. 'Enter Name' will be displayed. Enter the name of the keypad and
press .
7. 'Enter Location' will be displayed. Enter the location of the keypad
and press .
8. Press [or ]to select another device address to program (0-3)
or press the key to return to the Engineer menu
Programming Readers for Set Point or Unset Only: Assign
Keypads/Readers
1. Press or to scroll to 'ASSIGN KEYPADS/READERS'. Press
.
2. Press [or ]to select the address. Press .
3. 'Type' will be displayed. Press 1to select reader.Press 
4. 'Reader is' will be displayed. Press 0for 'Set Point' or press 1
for 'Unset Only' Press .
5. 'Default Area' will be displayed. Select the default area. Press .
'Set Point Description' will be displayed. Press to enter the
name and location if required.
6. 'Enter Name' will be displayed. Enter the name of the keypad and
press .
7. 'Enter Location' will be displayed. Enter the location of the keypad
and press .
8. Press [or ]to select another device address to program (0-3)
or press the key to return to the Engineer menu.
ASSIGN KEYPADS/
READERS?
Address
[0]
Type
Keypad [0]
Default Level
[A ]
Set Point
Description?
Enter Location
_
ASSIGN KEYPADS/
READERS?
Address
[1]
Type
Reader [1]
Reader is [0]
Set Point
Default Level
[A ]
Set Point
Description?

Enforcer Programming Manual
Page: 16
Programming Readers for Entry Control or Access Control:
Assign Keypads/Readers
1. Press or to scroll to 'ASSIGN KEYPADS/READERS'. Press
.
2. Press [or ]to select the address. Press .
3. 'Type' will be displayed. Press 1to select the reader.Press 
4. 'Reader is' will be displayed. Press 2for 'Access Control' or press
4for 'Entry Control' Press .
5. 'Default Area' will be displayed if 'Entry Control' is selected. Select
the default area and press .
6. 'Lock Open Time' will be displayed. Enter the Lock Open Time in
seconds and press . (Max 255 seconds).
7. 'Door Open Time' will be displayed. Enter the Door Open Time in
seconds and press . (Max 255 seconds).
8. 'Access Control Description' will be displayed. Press .
9. 'Enter Name' will be displayed. Enter the name of the keypad and
press .
10. 'Enter Location' will be displayed. Enter the location of the keypad
and press .
11. Press [or ]to select another device address to program (0-3)
or press the key to return to the Engineer menu.
4.7 System Displays
This function programs the text display on the keypad for when the system is unset, or an area is set.
The Site Name reference is programmed here which must match the site name programmed on the
InSite software. There are options to enable or disable displaying when set, alarms, hold ups or
inputs.
4.7.1 Area Texts
This programs how each Area will be displayed. For example if 'Area A' is used to set the full
house this can be text as “Full House Set”. There is a maximum of 16 characters on the display.
4.7.2 Sign On Message
The Sign on Message is the main display on the top line in unset mode.
4.7.3 Site Name
The Site Name is used as a reference for the InSite software if used.
4.7.4 Display When Set / Display Alarms / Display HU’s / Display Inputs*
If ‘Display when set’ is enabled, then the Area Text will be displayed on the LCD keypad once the
system is fully set. If Display Alarms / HU’s are enabled, they will show any alarms that are
activated before a valid user code/tag is entered. If Display Inputs is enabled, any inputs
activated in day mode will be displayed.
NOTE: Must be set to NO to comply with EN50131-1
System Displays Programming
1. Press or to scroll to 'SYSTEM DISPLAYS'. Press .
2. 'Area A Text' will be displayed. Enter the text and press .
Repeat for all areas.
3. 'Sign on Message' will be displayed. Enter the text and press .
4. 'Site Name' will be displayed. Enter the text and press .
5. 'Display When Set' will be displayed. Press [or ]to enable or
disable the function. Press . Repeat for 'Display Alarms',
'Display Hus', and 'Display Inputs'. Press to return to the
Engineer menu.
ASSIGN KEYPADS/
READERS?
Address
[1]
Type
Reader [1]
Reader is [4]
Entry Control
Default Level
[A ]
Lock Open Time
[005]
Door Open Time
[005]
SYSTEM DISPLAYS?
Area A Text
Full Set
Sign On Message
Enforcer

Page: 17
4.8 Change Timers
This function controls all timers of the Enforcer 32-WE.
4.8.1 Timers
For a list of all timers, refer to Appendix C, on page 50.
Most commonly used timers:
Entry Time (0-255 seconds), Exit Time (0-255 seconds), Siren Time (2-15 minutes), Confirm
Time (1-99 minutes), Wireless Supervision Time (0-99 hours).
NOTE: The timer for inputs on 'Soak Control' is in the function 'ENGINEER TESTS'.
Change Timers Programming
1. Press or to scroll to 'CHANGE TIMERS'. Press .
2. 'A Entry Time' will be displayed. Enter the time and press .
Refer to Appendix C, page 50 for all timers and enter the time on
the required function and press for the next timer.
3. Press to return to the Engineer menu.
4.9 Date and Time
All log entries and the system display include the time and date. This is also programmed in the
Master Manager Mode.
NOTE: Please note that powering down the system will reset the time and date information.
4.9.1 Year, Month, Day, Hours, and Minutes
Enter the year, month, day, hours and minutes.
4.9.2 DST Adjust
Enable or disable the 'Day Saver Time Adjust' as required.
Set Date and Time Programming
1. Press or to scroll to 'SET DATE AND TIME'. Press .
2. 'Year' will be displayed. Enter the year and press . Repeat for
Month, Day, Hours and Minutes and press .
3. 'DST Adjust' will be displayed. Press [or ]to enable or disable
the function and press .
4. Press to return to the Engineer menu.
4.10 Exit Modes
The ‘Exit Modes’ operate the Setting procedure of the Enforcer 32-WE system. The following Exit
Modes are available:
4.10.1 Exit Modes
[0] Timed: The Enforcer 32-WE system will set when the programmed 'Exit Time' has expired
(See ‘Change Timers’ on page 17).
NOTE: This is NOT suitable for systems installed to comply with BS8243.
[1] Final Door: The Enforcer 32-WE system will set when an input programmed as 'Final Exit' is
either closed (if the input was opened when setting started) or it is opened and closed. 'Final
door' is used for the ‘lock set’ operation; securing the lock completes the setting procedure and
unlocking starts the entry time.
[2] Timed/Final: The Enforcer 32-WE system will set when a 'Final Exit' input has been closed,
or when an 'Exit Time' has expired. The 'Final Exit' input will override any 'Exit Time'
programmed if opened/closed.
NOTE: This is NOT suitable for systems installed to comply with BS8243.
[3] Push to Set (PTS): The Enforcer 32-WE system will only Set when a ‘Push to Set’ button
has been pressed. This function will override the programmed Exit Time.
CHANGE TIMERS?
A Entry Time
[030]
SET DATE & TIME?
Year (00-99)
[07]
DST Adjust?
No [0]

Enforcer Programming Manual
Page: 18
Exit Modes Programming
1. Press or to scroll to 'EXIT MODES'. Press .
2. 'A Exit Mode' will be displayed. Press [or ]to select the Exit
Mode and press . Repeat for all areas.
3. Press to return to the Engineer menu.
4.11 Change Codes
This function changes the Engineer code, the Master Manager code and adds/changes/deletes any
Duress or Guard codes.
Default Codes: User: 1234. Master Manager: 2222. Engineer: 1111
NOTE: User codes, fobs and keyfobs can only be changed in The Master Manager Menu. Please see
the user manual for more information.
4.11.1 5 Digit Pins?
If enabled, a 5 or 6 digit code will automatically block several possible 4 digit codes that clash
with it.
4.11.2 Change Duress Codes
[2] Duress Code: If the Enforcer 32-WE is unset using a 'Duress' code, a silent 'Duress' or 'Hold
Up' signal is sent.
NOTE: ACPO policy prevents use of Duress codes for police call purposes.
[3] Guard Code: A 'Guard code' can be used to unset the Enforcer 32-WE only after an alarm
has been activated for a minimum time (see 'Change Timer' Appendix C, page 50). The code will
set a system and an output type is available to signal when this code is used (00058 Guard
Code).
[4] Dial Out: If a dial out code is programmed and entered when the Enforcer 32-WE is unset,
the PC number 1 that is programmed (see 'SET UP DOWNLOADING' on page: 28) will be dialled.
4.11.3 Change Master Manager Code
The Master Manager code can be 4, 5 or 6 digits long, or can be assigned to a tag. It may also
have the following functions:
[0] Unset / Set. [1] Unset Only. [2] Set Only. [3] None (used only to access the menu).
Flexi Set: If enabled, the default area the device is assigned to, will set. If disabled, the default
area will be shown on the display, and from here other areas can be selected.
Wards/Access: This will only be displayed if an Entry Control or Access Control reader is
installed on the system. If the address of the Entry Control or Access Control device is entered
here, then the code will be assigned to that reader only.
4.11.4 Change Engineer Code
The Engineer code can be 4, 5 or 6 digits long.
Change Codes Programming
1. Press or to scroll to 'CHANGE CODES'. Press .
2. '5 Digit Pins' will be displayed. Press [or ]to enable or disable
and press .
3. 'Change Duress Codes' will be displayed. Press to add any
Duress, Guard or Dial out codes (as described previously) or press
.
4. 'Change Master Manager Code' will be displayed. Press to
change the Master Manager code or press .
5. 'Change Engineer Code' will be displayed. Press to change the
Engineer code or press to return to the Engineer menu.
EXIT MODES?
A Exit Mode
Final Door [1]
CHANGE CODES?
5 Digit Pins?
No [0]
Change Duress
Codes?
Change Master
Manager Code?
Change Engineer
Code?

Page: 19
4.12 Volume Control
The Volume Control function applies to the loudspeaker output only. Volume levels at the keypad are
programmed individually – refer to page: 14 on how to access the menu.
4.12.1 Volume Controls
The following volume on each sound can be controlled: Entry, Exit, Alarm, Fire, Tamper, Day
alarm, Chime, and Intelligent Set.
Volume controls: 0 = Completely silent. 1 = Silent but sounds a beep when the system is set
2-7 volume of tones (7 = loudest).
4.12.2 Code Stops Sound
If this function is enabled, then once an alarm has been generated (even if the code is not
programmed for that area) the alarm will be silenced, and a ‘Misoperation (Abort) signal’ will be
sent. The area will remain set until a code or tag is presented that is assigned to that area.
4.12.3 Entry/Exit Keypads Only
If this function is disabled, any entry and exit tones will be heard through the main sounder. If
enabled, the entry and exit tones will only be heard through the keypad speaker.
4.12.4 Alert Kps Only
If this function is enabled, any 'Alert' tones will be heard on the Keypad only and not the main
sounder. If disabled, the alert tones will heard through both.
4.12.5 Silent Technical Alert
If this function is enabled then any technical alerts will be silenced, e.g line fault, ARC call fail.
4.12.6 Use Main Sounder
If enabled, all volumes that are programmed as 2-7 will activate on the main sounder. If
disabled, the sounder will only activate on activations programed on volume 6-7.
Volume Control Programming
1. Press or to scroll to 'VOLUME CONTROL'. Press .
2. 'A Entry' will be displayed. Enter the volume and press . Repeat
for all areas.
3. 'Code Stops Sound' will be displayed. Press [or ]to enable or
disable and press .
4. 'E/E Keypads Only' will be displayed. Press [or ]to enable or
disable and press .
5. 'Alert Kps Only' will be displayed. Press [or ]to enable or
disable and press .
6. 'Silent Tech Alert' will be displayed. Press [or ]to enable or
disable and press .
7. 'Use Main Sounder' will be displayed. Press [or ]to enable or
disable and press . The Engineer menu will be displayed.
4.13 Alarm Response
The Alarm Response function controls how certain activations are to perform.
4.13.1 Silent 1st Alarm
If this function is selected as ‘confirmed’, then the first alarm to activate on the system will be
silent, but only if another input activates (i.e. a confirmed alarm) then the alarm will activate and
the alarm tones will be heard. This option is only valid once the system has been set for 3
minutes and not if the entry time has started.
4.13.2 Disable Confirm On Entry
To comply with BS8243 clauses 6.4.3 and 6.4.4, this option should be set to YES to disable
confirmation once the entry procedure has started. For use with BS8243 option 6.4.5, this
option should be ‘No’. If ‘Disable Confirm On Entry’ is set to YES this option will disable ALL
confirmation signals on entry. If NO the confirmation signals are enabled on expiry of entry time.
VOLUME CONTROL?
A Entry
[0]
Code Stops Sound
No [0]
E/E Keypads Only
No [0]
Alert Kps Only
Yes [1]

Enforcer Programming Manual
Page: 20
4.13.3 Alarm Starts / Stops (Alarm Responses)
There are 4 different 'Alarm Responses' that can be programmed:
[0] Keypads: If an alarm occurs, the keypad sounder will activate.
[1] Internal Sounders: If an alarm occurs, the internal sounder will activate.
[2] Bells Only: If an alarm occurs, the external sounders will activate.
[3] Signal Digi: If an alarm occurs, the digi will communicate.
[4] Confirm: If an confirmed alarm occurs.
If the Alarm Response for Area A is programmed as 'Start At' "Keypads" and 'Stop at' "Bells
Only" then it will take 15 seconds to go through each alarm responses before stopping at "Bells
Only".
If the Alarm Response is programmed as 'Start At' "Signal Digi" and 'Stop At' "Confirm", all
keypads, internal sounders and bells only will activate the same time as 'Signal Digi' and all will
stop when there is a 'Confirmed Alarm'.
The Enforcer 32-WE can operate on a combined Area basis, for example if both Areas ‘A’ and ‘B’
are set; you may want the process of the alarm responses to change. Therefore The ‘If Areas set’
section of this function should be used and select the desired Areas and the Alarm Responses.
Alarm Responses Programming
1. Press or to scroll to 'ALARM RESPONSES'. Press .
2. 'Silent 1st Alarm' will be displayed. Press [or ]to enable or
disable and press .
3. 'Disable Confirm on Entry' will be displayed. Press [or ]to
enable or disable and press .
4. 'Area A start at' will be displayed. Press [or ]to select the
alarm responses and press . Repeat for all alarm notifications.
5. The Engineer menu will be displayed.
4.14 Change Outputs
This function programs all output types, Any output type may be programmed to any of the systems
outputs, including any outputs for wireless bells. Outputs must be used within their rated capacity.
Please see the installation manual.
4.14.1 Output Types
Refer to Appendix D, page 51 for all output type options. Most commonly used input types:
[0003] Intruder Any. [0006] Confirmed Any. [0014] Siren Any. [0016] Strobe Any.
[0018] Unconfirmed Any. [0051] Line Fault. [0052] Mains Fail. [1###] Follow Input.
4.14.2 Endstation Outputs
This function programs the Bell, Strobe and PGM output on the I/O board if connected (see page:
39 for connections).
4.14.3 ZEM Outputs
If a EURO-ZEM8+ or EURO-ZEM8+PSU has been connected to the Enforcer 32-WE (Zone
Expander Modules), this function programs the 4 outputs on each expander. The address of the
expander is required before the output programming. Refer to page: 42 for connections.
4.14.4 Wireless Bells
At default, any wireless bells learnt to the Enforcer 32-WE have the two outputs programmed as
'Siren Any' and 'Strobe Any'. These outputs can be programmed differently if required.
4.14.5 Output Module Outputs
If a EURO-OEM8R8T, or EURO-OEM16R+PSU is connected to the Enforcer 32-WE, they must be
addressed in this function. All output programming is done also here. A maximum of 1 output
expander can be connected to the Enforcer 32-WE. Refer to page: 42 for connections
ALARM RESPONSE?
Silent 1st Alarm
Never [0]
Disable Confirm
On Entry. No [0]
Area A starts at
Digi [3]
