Qlightec QCML Series User manual
Ordering Specications
1
Multiple Paurpose Waterproof LED Light Bars
QCML/ QCMLC
QCML - 200 - PY - 24
[Model number] [Product length] [Light color] [Voltage]
| | | |
• QCML- Translucent lens
• QCMLC - Transparent lens • 200 - 200mm
• 300 - 300mm
• 400 - 400mm
• 500 - 500mm
• 900 - 900mm
• 1200 - 1200mm
• 1500 - 1500mm
• W - Cool daylight
• PY - Incandilight
• R - Red
•A-Amber
• 24 – DC24V
67
69K
5030
Please scan the QR code
for more
detailed product information.
www.qlight.com
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o-• the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci¿cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, ¿re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn o-• the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a ¿re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to ¿re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to ¿re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, ¿re, electric shock and loss of life.)
QCML/ QCMLC-200/ 300/ 400/ 500/ 600/ 900/ 1200/ 1500
A
C
6- Ø4.5 FITTING HOLES
27
36
33
23
B
45
26
Model
QCML/ QCMLC-200
QCML/ QCMLC-300
QCML/ QCMLC-400
QCML/ QCMLC-500
QCML/ QCMLC-600
QCML/ QCMLC-900
QCML/ QCMLC-1200
QCML/ QCMLC-1500
A
262
362
462
562
662
962
1262
1562
B
213
313
413
513
613
913
1213
1513
C
45~217
45~317
45~417
45~517
45~617
45~917
45~1217
45~1517
D
2
2
2
2
2
3
4
4
2
Dimensions
Product Specications
Model number
QCML-200/
QCMLC-200 QCML-300/
QCMLC-300 QCML-400/
QCMLC-400 QCML-500/
QCMLC-500 QCML-600/
QCMLC-600 QCML-900/
QCMLC-900 QCML-1200/
QCMLC-1200 QCML-1500/
QCMLC-1500
Lens color
Translucent/
Transparent Translucent/
Transparent Translucent/
Transparent Translucent/
Transparent Translucent/
Transparent Translucent/
Transparent Translucent/
Transparent Translucent/
Transparent
Light color/
Color
temperature
Cool daylight
6,000-7,000K
Incandilight
2,500-3,500K
Red
618-632nm
Amber
585-595nm
Luminous ux
(Cool daylight)
276lm/
322lm 381lm/
436lm 729lm/
833lm 742lm/
849lm 754lm/
863lm 1,126lm/
1,291lm 1,492lm/
1,691lm 1,855lm/
2,105lm
Illumination(at 1m)
(Cool daylight)
85Lux/
100Lux 130Lux/
155Lux 200Lux/
245Lux 210Lux/
250Lux 250Lux/
295Lux 380Lux/
430Lux 500Lux/
560Lux 550Lux/
600Lux
Model number
QCML-200/
QCMLC-200 QCML-300/
QCMLC-300 QCML-400/
QCMLC-400 QCML-500/
QCMLC-500 QCML-600/
QCMLC-600 QCML-900/
QCMLC-900 QCML-1200/
QCMLC-1200 QCML-1500/
QCMLC-1500
Rated voltage DC24V
Range for operation
voltage DC21.5V~26.5V
Power consumption
5.5W 6W 11W 11.5W 12W 18W 23W 30W
Insulation resistance
Min. 100M(500V DC mega ohm meter)
Withstanding
voltage DC : 500VAC, 60Hz, 1 minute
Operating
temperature -30°C to +50°C
Protection rating IP67/ IP69K
Materials Lens : PC,
Side Cover : PC,
Heat sink : AI,
Bracket : PC
Certi¿cate
DC 24V Only
Weight(approx.) 0.16kg 0.20kg 0.26kg 0.33kg 0.40kg 0.56kg 0.76kg 0.94kg
Wiring Instructions
• External power line - UL2464 AWG22(0.3sq) x 2C 450mm
• This product can be wired regardless of polarity.
※D : Recommended quantity of mounting bracket
DC
White
Black Fuse Power
■
Optics Specications
■
General Product Specications
(Units : mm)
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP67/ IP69K.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
indicated(IP67/IP69K), it may cause malfunction or damage to the product.
• For further information, please visit our website(www.qlight.com).
3
• Mounting brackets are removable with special sliding structure that allows easy adjustment of distance between the two mounting brackets.
Number of mounting brackets per unit varies depending on product length.
■
Bracket Adjustment
■
Parts Denition
Parts Denition/ Bracket Adjustment
Lens(PC)
Side cover(PC)
Bracket(PC)
Side cover(PC)
QCML/ QCMLC
A
MODEL
QCML/ QCMLC-200
QCML/ QCMLC-300
QCML/ QCMLC-400
QCML/ QCMLC-500
QCML/ QCMLC-600
A
45~217
45~317
45~417
45~517
45~617
2-Ø4.5 HOLES
45~917
3-Ø4.5 HOLES
A
MODEL
QCML/ QCMLC-1200
QCML/ QCMLC-1500
A
45~1217
45~1517 4-Ø4.5 HOLES
QCML/ QCMLC-200/ 300/ 400/ 500/ 600
QCML/ QCMLC-1200/ 1500
QCML/ QCMLC-900
Installation/ Mounting Hole Specications
•
First, machine taps or holes on the mounting surface ①.
• The mounting hole of this product is 4.5mm in diameter(long hole).
• When machining taps, fasten the bolt through the mounting hole of the product.
• When machining holes, insert the bolt through the hole of the product,
and tighten the nut from the opposite side of the mounting surface.
• Install at washer and spring washer when fastening bolt and nut.
•
To secure the product to brackets, place the products to brackets and push it lightly until
it makes “clark” sound.
• Machine holes on the mounting surface referring to the diagram below.
■
Installation
■
Mounting Hole Specications
①
Head O-ce | Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea
Tel. +82-2-2679-6152(Toll free. +82-80-328-2222) Fax. +82-2-2679-6154
Factory | 185-25, Mukbang-ro, Sangdong-myeon, Gimhae-si, Gyeongsangnamdo, Korea Tel. +82-55-328-1111(Toll free. +82-80-328-1111)
Qlight OverSEAs Sales Dept |
704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel : +82-51-620-4100
Qlight Public Relations & Marketing Team O-ce | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel. +82-51-245-0017
3003 North First Street, Suite #341, San Jose, CA 95134 USA Tel. +1 - 408 - 519 - 5740 Fax. +1 - 408 - 519 - 5739
China Factory/ Shanghai Sales O-ce | #19, Nanda Road, Baoshan Area, Shanghai, China Tel. +86
-
21
-
6651
-
7100 Fax. +86
-
21
-
6315
-
3929
China Factory Site 2 (Qidong) | #33, Haiyan Road, Qidong High-tech Industrial Development Zone, Qidong, Jiangsu Province, China
Tel +86
-
513
-
8384
-
9999 Fax +86
-
513
-
8384
-
9910
Product Operation Inquiry / Customer Support +82-51-620-4100
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea ( Postal Code : 08507)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea ( Postal Code : 50805)
For your safety
Speci¿cation and dimensions listed in this catalogue subject to change without notice for product quality improvement.
The newest product information is available on our website.(www.qlight.com)
Please read the instruction manual attached to the product carefully before installation and use.
www.qlight.com
EN - QCML-200 - 2207A
