Qlightec STND100-N User manual
1
Signal/ Waring Lights with Built-in Sounder
STND100-N
STND100LR-N - 24 - R
[Model number] [Voltage] [Color]
| | |
• STND100LR-N
• STND100L-N
• STND100R-N
• 12-DC12V
• 24-DC24V
• 12/24-DC12-24V(STND100L-N only)
• 110/220- AC110V-220V
R-Red
A-Amber
G-Green
B-Blue
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
3OHDVHWXUQRWKH3RZHURIWKHSURGXFWLPPHGLDWHO\LILWIDLOVWRRSHUDWHSURSHUO\
&DUHIXOO\ZLUHWKHSURGXFWDFFRUGLQJWRHDFKSURGXFW¶VVSHFL¿FDWLRQ
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
)DLOXUHWRIROORZDQ\RIWKHLQVWUXFWLRQVDERYHPD\FDXVHPDOIXQFWLRQRUGDPDJHWRWKHSURGXFW¿UHDQGHOHFWULFVKRFN
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, and or malfunction of the
product that would void the warranty.
’XULQJZLULQJRUPDLQWHQDQFHSOHDVHFRPSOHWHO\WXUQRWKH3RZHURIWKHSURGXFW)DLOXUHWRIROORZWKLVPD\OHDGWRDQHOHFWULFVKRFN
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
UDWLQJVLQGLFDWHGIRUHDFKSURGXFW)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\FDXVHD¿UHWRWKHSURGXFWHOHFWULFVKRFNSK\VLFDOLQMXU\
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
IROORZWKHVHLQVWUXFWLRQVPD\OHDGWR¿UHHOHFWULFVKRFNRUSURGXFWGDPDJH
3OHDVHDSSO\WKHFRUUHFWYROWDJHWRWKHSURGXFW)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\OHDGWR¿UHHOHFWULFVKRFNRUSURGXFWGDPDJH
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
IROORZWKLVPD\FDXVHGDPDJHWRSURSHUW\¿UHHOHFWULFVKRFNDQGORVVRIOLIH
Ordering Specications
Please scan the QR code for more
detailed product information.
www.qlight.com
5020
54
105
HORN
5030
2
Product Specications
Dimensions
(Units : mm)
• Protection rating : IP54
• Ambient operating temperature : -20°C to +50°C (STND100LR-N, STND100R-N)
-30°C to +50°C (STND100L-N)
※CE compliant : DC24V
Model number Voltage Current Sound pattern and volume &HUWL¿FDWHVWeight Color
STND100LR-N
DC12V 0.440A
• Bit Input: 5Ch
• Binary Input: 30Ch
• Built-in sounds: Max.105dB
(Based on WS-Ch5)
1.40Kg
R-Red
A-Amber
G-Green
B-Blue
DC24V 0.340A
AC110V~220V Max.0.150A 1.62Kg
STND100L-N
DC12V 0.480A 1.37Kg
DC24V 0.305A
AC110V~220V Max.0.175A 1.78Kg
Model number Voltage Current
%XOEVSHFL¿FDWLRQV
Sound pattern and
volume &HUWL¿FDWHWeight Color
Volts/Watts &RQ¿JXUDWLRQ
Part#
STND100R-N
DC12V 1.190A
12V10W T16x35
15S
9
• Bit Input: 5Ch
• Binary Input: 30Ch
• Built-in sounds
: Max.105dB
(Based on WS-Ch5)
1.57Kg
R-Red
A-Amber
G-Green
B-Blue
DC24V 0.725A
24V10W 10
AC110V~220V Max.0.355A
24V10W 10
1.82Kg
Ø101
Ø119
360°/3-M5 BOLT
PCD70
Ø10
CABLE ENTRY
35112 94
26115
STND100LR-N/ STND100L-N/ STND100R-N-DC/AC
STND100LR-N/ STND100L-N/ STND100R-N
STND100L-N-DC/AC
Wiring Instructions
• External Power line - UL1015 AWG18(0.75sq) x 2C 400mm
External signal line - UL1007 AWG22(0.3sq) 400mm
• This product can be wired regardless of polarity.(STND100L-N only)
Red Red
Ch 1 Ch 1
EXTERNAL CONTACT
Ch 2 Ch 2
Ch 3 Ch 3
Ch 4 Ch 4
Ch 5 Ch 5
Amber Amber
Green Green
Blue Blue
Fuse Fuse
White White
White or Red White or Red
Black Black
Black Black
Common
Power Power
EXTERNAL TRANSISTOR-NPN
Common
3
)LUVWUHPRYHWKHDQJHQXWVIURPEROWVDQGSODFHWKHSURGXFWWKURXJKWKHPRXQWLQJVXUIDFHKROHV
• )DVWHQWKHDQJHQXWVRQWKHRSSRVLWHVLGHRIWKHPRXQWLQJVXUIDFHXQWLOWKHSURGXFWLVWLJKWHQHGVHFXUHO\
STND100L-N STND100LR-N STND100R-N
Lens(AS)
Rubber spacer
Housing(ABS)
LED unit
5HHFWRU
(Heat resistant ABS)
Control panel cover
(ABS)
Resonance chamber
(ABS)
Flange nut
Cover connector
(ABS)
Light bulb
LED unit
Parts Denition/ Installation
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP54.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating indica-
ted(IP54), it may cause malfunction or damage to the product.
• In case of outdoor applications, install the product in the upright or horizontal position. Do not install the product upside-down or in
positions where water can potentially penetrate into the product and impact its operation.
• For further information, please visit our website(www.qlight.com).
•
Bit input mode(using external line) allows you to select
RQHRI¿YHVRXQGRSWLRQVE\VZLWFKLQJRQRQHRIWKH
channels (Ch1 - Ch5).
7RWDORIVRXQGRSWLRQVDUHFRQ¿JXUDEOH
•
Binary input mode(using external line) allows you to
receive multiple inputs by using the 5 channels
&K&KWRFRQ¿JXUHRQHRIVRXQGRSWLRQV
•7RWDORIVRXQGRSWLRQVDUHFRQ¿JXUDEOH
■
Bit Input Mode
■
Binary Input Mode
No. 1 2 3 4 5
0 0 0 0 0 0
1 1 0 0 0 0
2 0 1 0 0 0
3 0 0 1 0 0
4 0 0 0 1 0
5 0 0 0 0 1
※
The channel selection method
using a transistor is the same
as the external contact method,
SOHDVHUHIHUWRWKH¿JXUHRQ
the right.
※
7KHVZLWFK¿JXUHWRWKHULJKW
explains how to wire the exter-
nal
contacts of a signal line
product. If the product is not a
signal line product, use the
channelselectionswitch
attached
inside the product.
0 0 0 0 0 0
1 0 0 0 0 1
2 0 0 0 1 0
29 1 1 1 0 1
30 1 1 1 1 0
Binary Input Mode
Can select up to 30 sound options
Bit Input Mode
Can select up to 5 sound options
Ch 1 Ch 2 Ch 3 Ch 4 Ch 5
COM
Ch1 Ch2 Ch3 Ch4 Ch5
ON(1)
OFF(0)
Bit/ Binary Input Method Depending on Wiring Method
4
• To access the control panel, remove the front cover by
unscrewing the M3 bolts on the front cover.
Sound switch Volume switch
Front Cover Removal Instructions
Front Control Conguration
• The volume output of this product is adjustable.
•
Turn the volume dial clockwise to increase the volume, and
turn
counter clockwise to decrease the volume.
• There will be no sound when the dial is put at MIN.
Volume Dial
VOL.
MIN.
MAX.
Volume Adjustment
3-
Ø
6 HOLES
Min.Ø5 CABLE ENTRY
PCD70
STND100LR-N/ STND100L-N/ STND100R-N
• Machine holes on the mounting surface
referring to the diagram on the right.
Mounting Hole Specications
• Built-in sounds can be selected by using
a switch either bit or binary sounds.
•
Please be conscious of the number selected
for your desired sound option.
- Switch No. 1 : Select Bit or Binary
-
Switch No. 2,3,4 : Select Built-in sound group
■ Select built-in Bit sound group
■
Select built-in Bit sound group or Binary sound group
• It is being used when built-in sound is selected.
• Select between the six sound groups.
• Every group has 5 type of sounds.
• In bit input mode, Please set switch no.1 to
R
• In binary input mode, Please set switch no.1
to ON(1).
How to select bit type sound group
Sounds
No. 2 3 4
1 0 0 1
5 Warning Sounds
2 0 1 0
5 Special Warning Sounds (1st Group)
3 0 1 1
5 Melodies
4 1 0 0
5Alarms
5 1 0 1
5 Special Warning Sounds (2nd Group)
6 1 1 0
5 Special Warning Sounds (3rd Group)
ON(1)
OFF(0)
Sound Setting
5
%LWLQSXWPHWKRGVRXQGFRQ¿JXUDWLRQ
Type of sound
(WS group as an example)
No. 1 2 3 4 5
0 0 0 0 0 0 No sound
1 1 0 0 0 0 Fire.A-ANG(560Hz-1.5kHz)
2 0 1 0 0 0 Emergency WA-U
(600Hz-1.5kHz)
3 0 0 1 0 0 Ambulance PI-PO
(450Hz-900Hz)
4 0 0 0 1 0 Machinery Fault(820Hz)
5 0 0 0 0 1 High Expansion(1kHz)
※ 3OHDVHEHQRWHGWKDWWKHFRQ¿JXUDWLRQFKDUWDERYHLVH[
plaining how to wire terminal blocks. The actual product
does not have a switch.
ON(1)
OFF(0)
■ Sound Type by Group
%LWLQSXWPHWKRGVRXQGFRQ¿JXUDWLRQ
Group
Channel
Type of sound
WS
5 Warning
Sounds
Ch1
Fire.A-ANG (560Hz-1.5kHz)
Ch2
Emergency WA-U (600Hz-1.5kHz)
Ch3
Ambulance PI-PO (450Hz-900Hz)
Ch4
Machinery Fault (820Hz)
Ch5
High Expansion (1kHz)
WP
5 Special
Warning
Sounds
(1st Group)
Ch1
Fire.A-ANG (560Hz-1.5kHz)
Ch2
Abandon Alarm (820Hz)
Ch3
Machinery Fault (820Hz)
Ch4
High Expansion (1kHz)
Ch5
7 Short PI. / 1 Long (1kHz)
WM 5 Melodies
Ch1
Sweet Home
Ch2
For Elise
Ch3
Cuckoo's Waltz
Ch4
Piano Sonata
Ch5
Turkish March
WA 5 Alarms
Ch1
Beep Intermittent
Ch2
Door Chime
Ch3
Phone Ring
Ch4
PI.PI.PI Short
Ch5
Tripping Beat
WO
5 Special
Warning
Sounds
(2nd Group)
Ch1
Rel rel rel (730Hz-920Hz)
Ch2
Slow Ambulance PI-PO
(820Hz-1.05kHz)
Ch3
Wye yong Wye yong (770Hz-1.2kHz)
Ch4
Phone ring 2 (740Hz-910Hz)
Ch5
Fire.A-ANG (770Hz-1.11kHz)
WN
5 Special
Warning
Sounds
(3rd Group)
Ch1
Oit Oit (500Hz-1.11kHz)
Ch2
Pi o Pi o (940Hz-2.19kHz)
Ch3
Slow Di o Di o
(680Hz-840Hz)
Ch4
Li long Li ling (420Hz-470Hz)
Ch5
911 Siren (150Hz-1kHz)
• In bit input mode, you can chooses one sound from 1
VRXQGE\FRQ¿JXULQJWKHFKDQQHOV
• )RUVRXQGFRQ¿JXUDWLRQVUHIHUWRWKHWDEOHEHORZ
■ Bit Input - Playing Built-in Sound
Sound Type and Combination Manual
%LQDU\LQSXWPHWKRGVRXQGFRQ¿JXUDWLRQ
Type of sound
No. 1 2 3 4 5
0 0 0 0 0 0 No sound
1 0 0 0 0 1 Fire.A-ANG (560Hz-1.5kHz)
2 0 0 0 1 0 EmergencyWA-U (600Hz-1.5kHz)
3 0 0 0 1 1 Ambulance PI-PO (450Hz-900Hz)
4 0 0 1 0 0 Pi-ik Pi-ik (800Hz)
5 0 0 1 0 1 Machinery Fault (820Hz)
6 0 0 1 1 0 High Expansion (1kHz)
7 0 0 1 1 1 Alarm (1kHz)
8 0 1 0 0 0 Sweet Home
9 0 1 0 0 1 For Elise
10 0 1 0 1 0 Cuckoo's Waltz
11 01011Piano Sonata
12 0 1 1 0 0 Turkish March
13 0 1 1 0 1 Magic Flute
14 0 1 1 1 0 Badinerie
15 0 1 1 1 1 Pineapple Rag
16 1 0 0 0 0 Beep Intermittent
17 1 0 0 0 1 Door Chime
18 1 0 0 1 0 Phone Ring
19 1 0 0 1 1 PI.PI.PI Short
20 1 0 1 0 0 Tripping Beat
21 1 0 1 0 1 Rel rel rel (730Hz-920Hz)
22 1 0 1 1 0 Slow Ambulance PI-PO
(820Hz-1.05kHz)
23 1 0 1 1 1 Wye yong Wye yong
(770Hz-1.2kHz)
24 1 1 0 0 0 Phone ring 2 (740Hz-910Hz)
25 1 1 0 0 1 Fire.A-ANG (770Hz-1.11kHz)
26 1 1 0 1 0 Oit Oit (500Hz-1.11kHz)
27 1 1 0 1 1 Pi o Pi o (940Hz-2.19kHz)
28 1 1 1 0 0 Slow Di o Di o (680Hz-840Hz)
29 1 1 1 0 1 Li long Li ling (420Hz-470Hz)
30 1 1 1 1 0 911 Siren (150Hz-1kHz)
•
In binary input mode, you can chooses one sound from
30
VRXQGVE\FRQ¿JXULQJWKHFKDQQHOV
• )RUVRXQGFRQ¿JXUDWLRQVUHIHUWRWKHWDEOHEHORZ
• 3OHDVHEHDZDUHWKDWWKHFRQ¿JXUDWLRQIRUVRXQGXVLQJ
WKHELQDU\LQSXWPHWKRGLVGLHUHQWIURPWKHELWLQSXWPHWKRG
■ Binary Input - Playing Built-in Sound
ON(1)
OFF(0)
※ 3OHDVHEHQRWHGWKDWWKHFRQ¿JXUDWLRQFKDUWDERYHLVH[
plaining how to wire terminal blocks. The actual product
does not have a switch.
6
Operation Method and Setting
When Using a Built-in Sound Source
Bit input Binary input
3OD\RQHRI¿YHVRXQGVIURP
6 groups Play one of 30 sounds
■ When using a built-in sound source in bit input mode
3OHDVHVHWVZLWFKQRWRR
- For more information, see page 4
‘Sound Selection’
section.
2. Use one of the SOUND setting switches 2, 3 and 4 to select one of the
6 groups.
- For more information, see page 4
‘Sound Selection’
section.
8VHWKHWHUPLQDOEORFNRQWKHEDFNWRVHOHFWRQHRIWKH¿YHEXLOWLQ
sounds.
- For more information, please refer to page 5
‘Sound Type and Combi-
nation for Built-in Sound’ - ‘Bit Input’
section.
※Sound switch setting → Channel selection
■ When using a built-in sound source in binary input
mode
1. Please set switch no. 1 to ON.
- For more information, see page 4
‘Sound’
section.
2. Use the terminal block on the back to select one of the 30 built-in
sounds.
- For details, please refer to page 5
‘Sound Type and Combination for
Built-in Sound’ - ‘Binary input’
section.
※Sound switch setting → Channel selection
Product installation direction
■ Install the product in accordance with the manual. Otherwise rainwater or moisture may penetrate into the product.
ㆍELECTRONIC SOUNDER/SIGNAL HORN
Sounder part shall not be facing the sky.
Sounder part shall not be facing the sky.
ㆍBEACON/SIGNALING LIGHT
Power cord inlet part shall not be facing the sky.
Power cord inlet part shall not be facing the sky.
ㆍSIGNAL TOWER LIGHTS
ㆍHEAVY-DUTY & EXPLOSION PROOF SIGNALINGS
※For products with a protection rating of less than IPX4, please install it vertically.
※For products with a protection rating of less than IPX4, please install it vertically.
+HDG2FH_6XLWH67;97RZHU*DVDQGLJLWDOUR*HXPFKHRQJX6HRXO.RUHD
Tel. +82-2-2679-6152(Toll free. +82-80-328-2222) Fax. +82-2-2679-6154
Factory | 185-25, Mukbang-ro, Sangdong-myeon, Gimhae-si, Gyeongsangnamdo, Korea Tel. +82-55-328-1111(Toll free. +82-80-328-1111)
Qlight OverSEAs Sales Dept |
704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel : +82-51-620-4100
4OLJKW3XEOLF5HODWLRQV0DUNHWLQJ7HDP2FH_1DNGRQJGDHUR6DVDQJJX%XVDQ.RUHD(RPJXQJ’RQJ7HO
3003 North First Street, Suite #341, San Jose, CA95134 USATel. +1-408-519-5740 Fax. +1-408-519-5739
&KLQD)DFWRU\6KDQJKDL6DOHV2FH_1DQGD5RDG%DRVKDQ$UHD6KDQJKDL&KLQD7HO
-
21
-
6651
-
7100 Fax. +86
-
21
-
6315
-
3929
China Factory Site 2 (Qidong) | #33, Haiyan Road, Qidong High-tech Industrial Development Zone, Qidong, Jiangsu Province, China
Tel +86
-
513
-
8384
-
9999 Fax +86
-
513
-
8384
-
9910
Product Operation Inquiry / Customer Support +82-51-620-4100
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALLPRODUCT, PRODUCT SPECIFICATIONSAND DATAARE SUBJECT TO CHANGE WITHOUTNOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea (Postal Code : 08507)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea (Postal Code : 50805)
For your safety
6SHFL¿FDWLRQDQGGLPHQVLRQVOLVWHGLQWKLVFDWDORJXHVXEMHFWWRFKDQJHZLWKRXWQRWLFHIRUSURGXFWTXDOLW\LPSURYHPHQW
7KHQHZHVWSURGXFWLQIRUPDWLRQLVDYDLODEOHRQRXUZHEVLWHZZZTOLJKWFRP
3OHDVHUHDGWKHLQVWUXFWLRQPDQXDODWWDFKHGWRWKHSURGXFWFDUHIXOO\EHIRUHLQVWDOODWLRQDQGXVH
www.qlight.com
EN - STND100L-N - 2305A
This manual suits for next models
3
Table of contents
Other Qlightec Lighting Equipment manuals
Qlightec
Qlightec QCML Series User manual
Qlightec
Qlightec ST56MEL-BZ-3-24-RAG-JC User manual
Qlightec
Qlightec ST45ML-Ex User manual
Qlightec
Qlightec ST45ML-NEC User manual
Qlightec
Qlightec S150US User manual
Qlightec
Qlightec QLEX-SLM-650-EMG User manual
Qlightec
Qlightec S50L User manual
Qlightec
Qlightec STA35SL User manual
Qlightec
Qlightec S80AR User manual
Qlightec
Qlightec QTG50(M)L User manual
Qlightec
Qlightec S60R User manual
Qlightec
Qlightec SEA User manual
Qlightec
Qlightec QTEX User manual
Qlightec
Qlightec STND Series User manual
Qlightec
Qlightec S80ADR User manual
Qlightec
Qlightec MTG50 Series User manual
Qlightec
Qlightec SNE User manual
Qlightec
Qlightec SKLR User manual
Qlightec
Qlightec QTG-WIZ User manual
Qlightec
Qlightec STB45ML-Ex User manual
Popular Lighting Equipment manuals by other brands
Chauvet Professional
Chauvet Professional ROGUEOUTCAST2HYBRID Quick reference guide
LED World
LED World HH-S2835P-60-24-5M-PINK Important instructions
U-Line
U-Line H-6436 installation instructions
Outwell
Outwell EPSILON instruction manual
Vision & Control
Vision & Control DL30x60-IR850/UDC/-a Instructions for use
RayLight
RayLight STROBES Technical document
Iluminar
Iluminar iLi3 user manual
HYBRYD
HYBRYD CRYSTAL LED Installation and maintenance manual
X4-Life
X4-Life 701350 user manual
Future light
Future light DSC-60 user manual
Home Accents Holiday
Home Accents Holiday Bilt Immortal Werewolf 22SV23409 Easy Assembly and operation instructions
Nexxus Lighting
Nexxus Lighting Savi SAVI-PL-12-50 Installation instructions & owner's manual
