Qlightec EPLS Series User manual

EPLS Series
EPLS - 380 - 24
[Model number] [Product length] [Voltage]
 | | |
EPLS 380-391mm
550-556mm
24-DC24V
20
5525
Model number
L1 L2
EPLS380 380 391
EPLS550 545 556
Model number
EPLS380 EPLS550
Lens Color Translucent
Directions Cooldaylight
Light color
6,000-6,500K
Luminous ux DC 1,000lm 1,500lm
E󰀩cacy(lm/W) DC 300Lux 500Lux
Model number
EPLS380 EPLS550
Voltage
DC24V
Range for operation voltage
DC24V
Power
consumption
DC24V 10W 15W
Insulation resistance
Min. 100MΩ(500V DC mega ohm meter)
Withstanding voltage
DC:500VAC, 60Hz, 1minute/AC:1,500VAC,
60Hz,1minute
Operating temperature
-25°C to +55°C
Protection rating
IP20
Materials
Housing-Al, Lens -PC
Certication
Weight(Approx.)
0.27kg 0.40kg
36
22
5
L1
Ø3.2
R2.5
15
L2
EPLS
LED Work Lights
Thank you for purchasing Qlight’s products. Please read this user manual
carefully prior to installation and operation to ensure safe and correct use.
1. During wiring or maintenance, please completely turn o󰀨 the
power of the product. (Failure to follow this may lead to an electric
shock.)
2. Do not install the product in locations that subjects it to excessive
dust or water other than the conditions designated by the IP
protection ratings indicated for each product. (Failure to follow
these instructions may cause a re to the product, electric shock,
physical injury, malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service
is required, please contact your local Qlight contact point.
(Failure to follow these instructions may lead to re, electric shock,
or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow
these instructions may lead to re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives
or property, please make sure to have a double safety device.
(Failure to follow this may cause damage to property, re, electric
shock and loss of life.)
Precautions for Safety
Failure to follow the instructions below may cause a
loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation
around the product.
2. Please turn o󰀨 the power of the product immediately if it fails
to operate properly.
3. Carefully wire the product according to each product’s
specication.
4. Please be careful in preventing chemicals such as thinner,
benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause
malfunction or damage to the product, re, and electric
shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause
damage to property, the product, or malfunction of the
product that would void the warranty.
Product Specications
Dimensions
(Units : mm)
Ordering Specications
Please scan the QR code for more
detailed product information.
www.qlight.com
■ Optics Specications
■ Specications

+
-
21
34
+
-
EN - EPLS - 2306A
Lens(PC)Housing(Al)
Bracket(STS)
EPLS
Model number
A
EPLS380 380
EPLS550 545
Fuse
Fuse
Fuse
h
22
4-Ø4 HOLES
1
Wiring Instructions Parts Denition/ Installation
■

Parts Denition
■ Installation
• First, machine taps or holes on the mounting surface ①.
• The mounting hole of this product is 3.2mm in diameter(Slot hole).
• When machining taps, fasten the bolt through the mounting hole
of the product.
• When machining holes, insert the bolt through the hole of the
product, and tighten the nut from the opposite side of the
mounting surface.
M12 connector type
Red
Black
Red
Black
Power
Power
Power
• This product can be wired regardless of polarity(AC Type).
• Please connect the 4 pins located in M12 connector cable to
the M12 socket of the product.
DC
AC
Installation Environment and Protection Rating
• This product is designed for indoor use with protection rating of IP20.
• If the product is installed in locations that subject it to excessive dust
or water other than the designated IP protection rating
indicated, it may cause malfunction or damage to the product.
• For further information, please visit our website (www.qlight.com).
Mounting Hole Specications
• Machine holes on the mounting surface referring to the
diagram below.
Product Operation Inquiry / Customer Support [phone]
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.

※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
www.qlight.com
