Quadra-Fire MTVERNINSAE-MBK User manual

R
www.quadra re.com 7036-135F August 27, 2009
MT VERNON PELLET INSERT
ADVANCED ENERGY (AE)
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
Owner’s Manual
Installation and Operation
Models:
Tested and approved for wood pellets, shelled eld
corn, wheat and black oil sunfl ower seeds. Burning
of any other type of fuel voids your warranty.
CAUTION
DO NOT DISCARD THIS MANUAL
NOTICE
• Important operating and
maintenance instruc-
tions included.
• Leave this manual with
party responsible for use
and operation.
• Read, understand and
follow these instruc-
tions for safe installa-
tion and operation.
DO NOT
DISCARD
WARNING
Please read this entire manual
before installation and use of this
pellet fuel-burning room heater.
Failure to follow these instructions
could result in property damage,
bodily injury or even death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• Do not over re - If any external part starts to
glow, you are over ring. Reduce feed rate.
Over ring will void your warranty.
• Comply with all minimum clearances to com-
bustibles as speci ed. Failure to comply may
cause house re.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and national
codes and regulations.
• Consult local building, re of c ials or authorities having jurisdic-
tion about restrictions, installation inspection, and permits.
CAUTION
WARNING
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
r eplace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl a mmable materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
MTVERNINSAE-MBK
MTVERNINSAE-PMH
MTVERNINSAE-CSB
MTVERNINSAE-CWL

Page 2 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
Hearth & Home Technologies welcomes you to our tradition
of excellence! In choosing a Quadra-Fire appliance, you
have our assurance of commitment to quality, durability, and
performance.
This commitment begins with our research of the market,
including ‘Voice of the Customer’ contacts, ensuring we
make products that will satisfy your needs. Our Research
and Development facility then employs the world’s most
advanced technology to achieve the optimum operation of
our stoves, inserts and replaces. And yet we are old-fash-
ioned when it comes to craftsmanship. Each unit is meticu-
lously fabricated and surfaces are hand- nished for lasting
beauty and enjoyment. Our pledge to quality is completed
as each model undergoes a quality control inspection.
We wish you and your family many years of enjoyment in
the warmth and comfort of your hearth appliance.
Thank you for choosing Quadra-Fire.
LABEL LOCATION: On Beaded Chain on e behind Right Side Panel
SAFETY LABEL / ÉTIQUETTE DE SÉCURITÉ
Listed Solid Fuel Room Heater/Pellet Type Insert.
Also suitable for Mobile Home
Installation. This appliance has been tested and listed for use in Manufactured
Homes in accordance with OAR 814-23-9000 through 814-23-909.
R
Mt. Vernon Pellet Insert AE
Tested to: ASTM E1509-04, ULC S628-93, ULC/ORD-C1482-M1990
Room Heating Pellet Burning Type, (UM) 84-HUD FOR USE ONLY WITH
PELLETIZED WOOD. SEE OWNER’S MANUAL FOR OTHER FUEL OPTIONS.
Input Rating: 60,000 BTU/HR.
Electrical Rating: 115 VAC, 60 Hz, Start 5 Amps, Run 1.25 AMPS.
Route power cord away from unit. Do not route cord under or in front of
appliance.
DANGER: Risk of electrical shock. Disconnect power supply before
servicing.
Replace glass only with 5mm ceramic available from your dealer.
To start, set thermostat above room temperature, the stove will light
automatically. To shutdown, set thermostat to below room temperature.
For further instruction refer to owner's manual.
Keep viewing and ash removal doors tightly closed during operation.
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS
Masonry or Zero Clearance
AS A BUILT-IN UNIT
JAN FEB MAR APR MAY JUNE JULY AUG SEPT OCT NOV DEC
7036-137
AInsert side to combustible / Insérez le côté au mur combustible latéral
BInsert top to face trim / Insérez le dessus de la garniture de façade
CInsert side to face trim / Insérez le côté de la garniture de façade
DHearth extension from door opening /Prolongement d’âtre depuis l’ouverture de la porte devant
EHearth extension from side of door opening / Prolongement d’âtre depuis le côté
del’ouverture de la porte
6 in. 152mm
0 in. 0mm
0 in. 0mm
6 in. 152mm
6 in. 152mm
NE PAS ENLEVER L'ÉTIQUETTE
SERIAL NO. /NUMÉRO DU S É RIE
Report /Rapport
#061-S-69-6
Made in U.S.A.
Fabriqué par:
CAUTION :
ATTENTION:
H OT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT MAY CAUSE SKIN
BURNS. SEE NAMEPLATE AND INSTRUCTIONS. Operate this unit with fuel hopper lid closed. Failure to do so may
result in emissions products’ combustion from the hopper under certain conditions. Maintain hopper seal in
good condition. Do not overfill hopper.
CHAUD LORS DE L'OPÉRATION. NE PAS TOUCHER. GARDEZ LES ENFANTS ET LES VÊTEMENTS LOIN DE L'ESPACE
DÉSIGNÉ DE L'INSTALLATION. LE CONTACT PEUT CAUSER DES BRÛLURES À LA PEAU. VOIR L'ÉTIQUETTE ET LES
INSTRUCTIONS. Opérez cet appareil avec le couvercle de la trémie fermé. Le défaut de ne pas suivre les instructions peut résulter,
sous certaines conditions, en une combustion des émissions des produits venant de la trémie. Ne pas remplir la trémie trop pleine.
ESPACES LIBRES MINIMUM DES MATÉRIAUX COMBUSTIBLES:
A Des Conduits Du Haut/Arrières: 3 in. (76mm)
B Des Conduits Du Haut/Arrières: 2in. (51mm)
C Des Conduits Du Haut: 2 . 75 in. (70mm)
Arrières 7 . 5 in. (191mm)
D Des Conduits Arrières/Du Haut 3in. (76mm)
E Côté de Fonte au Mur Latéral: 6 in. (152mm)
A Top of Hopper Top/Rear Vent 3 in. (76mm)
B Side of Outside Skin Top/Rear Vent 2 in. (51mm)
C Back of Hopper Top Vent 7.5 in. (191mm)
Rear Vent 2.75 in. (70mm)
D Vent Pipe to Combustible Top/ Rear Vent 3in. (76mm)
E Cast Side to Side Wall Top/Rear Vent 6 in (152mm)
Testé à: ASTM #1509-04, ULC S628-93, ULC/ORD-C1482-M1990 Room Heating. Pellet
Burning Type, UM) 84-HUD POUR USAGE AVEC LES BOULETTES DE BOIS. VOIR LE
MANUAL DU PROPRI ÉTAIRE POUR D’AUTRES OPTIONS DE CARBURANT.
Puissance de Rendement: 60,000 BTU/HR
Puissance Électrique: 115 VAC, 60 Hz, Début 5 Amps, Courir 1.25 Amps,
Éloignez le fil électrique de l'appareil. Ne pas faire passer le fil électrique au dessus ou en dessous
de l'appareil.
DANGER: Il y a risque de décharge électrique. Déconnectez le fil électrique de la prise de contact
avant le service. Remplacez la vitre seulement avec une vitre céramique de 5 mm disponible
chez votre fournisseur.
Pour allumer, monter la température du thermostat au dessus de la température de la pièce, le
poêle s'allumera automatiquement. Pour éteindre, descendre la température du thermostat en
dessous de la température de la pièce. Pour des instructions supplémentaires, référez vous au
manuel du propriétaire. Gardez la porte d'ouverture et la porte des cendres fermées
hermétiquement durant l'opération.
Appareil de chauffage inséré de combustible solide/de type de boulettes. Accepté dans
l'installation dans les maisons mobiles. Cet appareil a été testé et enregistré pour l 'usage
dans les Maisons Mobiles en accord avec OAR 814-23-9000 jusqu'à 814-23-909.
1445 Highway North, Colville, WA 99114
B
D
C
C
A
B
E
COMME APPAREIL INSÉRÉ
0 in. Clearance To Exposed Section and Face Trim / Espace libre
de 0 mm de la section expos é e et de la garniture du devant.
SIDE WALL
MANTEL
A
B
D
C
E
Face Trim
007002
2009 2010 2011
Fait Aux États-Unis
Dégagement de la maçonnerie ou Dégagement zéro*
MUR LATÉRAL
Garniture
de façade
MANTEAU
DO NOT REMOVE THIS LABEL
Manufactured by:
See manual for mantel clearances.
www.quadrafire.com
SAMPLE
O-T L
Tes ted and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
Serial Number
Model Name
Test Lab &
Report No.
Mfg Dates
NOTE: Consult insurance carrier, local building inspector, fire
offi
cials or authorities having jurisdiction over restrictions,
installation inspection and permits.

R
August 27, 2009 7036-135F Page 3
Mt. Vernon Pellet Insert (AE)
Section 1: Listing and Code Approvals
A. Appliance Certi cations . . . . .. . . . . . . . .. . . . . . . .4
B. Mobile Home Approved .. . . . . . .. . . . . . . .. . . . . .4
C. Glass Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
D. Electrical Rating ..................................4
E. BTU & Ef ciency Speci cations . . . . . . . . . . 4
Section 2: Getting Started
A. Design, Installation & Location
Considerations ....................................5
B. Wall Control Thermostat . . . . . . . . . . . . . . . . . . . . . 6
C. Tools & Supplies Needed ...................6
D. Pre-Check List ....................................6
Section 3: Dimensions & Clearances
A. Appliance Dimensions ........................7
B. Clearances to Combustibles
As A Built-In Rear & Vertical . . ... . .. . .. .. . . 8-9
C. Clearances to Combustibles,
Masonry & Zero Clearance Fireplace . . 9
D. Floor Protection .................................. 9
E. Minimum Opening for Masonry
& Zero Clearance Fireplace . . .. . .. . ... . .. . 9
F. Mantel Projections ..............................9
G. Removing Metal Floor of Factory
Built Fireplace .....................................10
H. Prefabricated Metal Chimney . . . . . . . . . . . . . . 11
I. Altering the Factory-Built Firepalce .....11
Section 4: Vent Information
A. Venting Termination Minimum
Requirements ..................................... 12
B. Avoiding Smoke and Odors ................13
C. Negative Pressure . . . . . . . . . . . . . . . ......... . . . . . . 14
D. Draft ....................................................14
E. Chimney & Exhaust Connections .......15
F. Equivalent Feet of Pipe.......................15
G. Pipe Selection Chart ...........................16
Section 5: Venting Systems
A. Full Reline with Outside Air, Horiztontal . 17
B. Full Reline with Outside Air, Vertical . . . . . . 18
Section 6: Mobile Home Installation ............19
Section 7: Appliance Set-Up
A. Leveling System .................................20
B. Outside Air Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
C. Hearth Support for ZC Fireplace .........21
D. Removal of Cast Sides .......................21
E. Panel & Cast Trim Set ........................22
F. Panel & Trim Set, Basic ......................22
G. Log Set Placement ..............................23
H. Wall Control Thermostat . . . . . . . . . . . . . . . . . . . . . . 24
Section 8: Operating Instructions
A. Fire Safety . . . . . .. . .. . .. . .. . .. . . . .. . .. . .. . .. . .. . . . .. . . 25
B. Combustion/Non-Combustion Material . 25
C. Fuel Size, Material & Storage .............25-26
D. General Operation Information ...........26
E. Before Your First Fire ......................... 27
F. Filling the Hopper................................27
G. Starting Your First Fire . . . . . . . . . . . . . . . . . . . . . . . . 27
H. Fire Characteristics & Flame
Height Adjustment .............................. 27
I. Battery Back-Up System ....................28
J. Clear Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
K. Ignition Cycles .................................... 29-30
L. Quick Start Quide ............................... 31-32
M. Frequently Asked Questions...............33
Section 9: Troubleshooting ............................ 34
Section 10: Maintaining & Servicing Appliance
A. Proper Shutdown Procedure . . . . . . . . . . . . . . . 35
B. Quick Reference Maintenance Chart ....35
C. General Maintenance & Cleaning .......35-39
D. High Ash Fuel Content Maintenance .. 40
E. Baffl e Removal ....................................40
F. Glass Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
G. Convection Blower Replacement . . . . . . . . 41-42
Section 11: Reference Material
A. Component Functions.........................43-44
B. Component Locations .........................45
C. Exploded Views ..................................46-47
D. Service Parts & Accessories...............48-53
G. Warranty Policy ...................................54-55
H. Contact Information ............................ 56
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.

Page 4 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
1Listing and Code Approvals
A. Appliance Certification
C. Glass Specifications
E. BTU & Efficiency Specifications
This appliance is equipped with 5mm ceramic glass. Replace
glass only with 5mm ceramic glass. Please contact your
dealer for replacement glass.
B. Mobile Home Approved
NOTE: This installation must conform with local codes. In
the absence of local codes you must comply with the ASTM
E1509-04, ULC S628-93, ULC/ORD-C-1482-M1990 and
(UM) 84-HUD.
D. Electrical Rating
115 VAC, 60 Hz, Start 5 Amps, Run 1.25 Amps
*BTU output will vary, depending on the brand of fuel you
use in your appliance. Consult your Quadra-Fire dealer
for best results.
MODEL: Mt. Vernon Pellet Insert AE
LABORATORY: OMNI Test Laboratories, Inc
REPORT NO. 061-S-69-6
TYPE: Solid Fuel Room Heater/Pellet Type
Insert
STANDARD: ASTM E1509-04, ULC S628-93 and
ULC/ORD-C1482-M1990 Room Heater
Pellet Fuel Burning Type and (UM) 84-
HUD, Mobile Home Approved
FCC Complies with Part 15 of FCC Rules.
Operation is subject to the following
two conditions: (1) this device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that
may cause undesired operation.
Emissions Rating: EPA Compliant
*BTU Output: 14,620 - 60,200 / hr
Efficiency: 81.4% - 83.6%
Heating Capacity: 2,400 - 3,800 square feet depend-
ing on climate zone
Hopper Capacity: 56 lbs
Fuel: Pellets, Shelled Field Corn, Wheat
and Black Sunfl ower Seeds
Shipping Weight: 425 lbs.
This appliance is approved for mobile home installations
when not installed in a sleeping room and when an outside
combustion air inlet is used.
The structural integrity of the mobile home fl oor, ceiling, and
walls must be maintained.
The appliance must be properly grounded to the frame of
the mobile home and use only Listed pellet vent Class “L”
or “PL” connector pipe.
A Quadra-Fire Outside Air Kit must be installed in a mobile
home installation. You must order the Outside Air Kit sepa-
rately.
NOTICE: Hearth & Home Tec hnologies, manufacturer
of this appliance, reserves the right to alter its prod-
ucts, their speci cations and/or price without notice.
Quadra-Fire is a registered trademark
of Hearth & Home Tec hnologies.
WARNING! Risk of Fire! Hearth & Home Technologies dis-
claims any responsibility for, and the warranty and agency
listing will be voided by the above actions.
DO NOT:
•Install or operate damaged appliance
•Modify appliance
•Install other than as instructed by Hearth & Home
Technologies
•Operate the appliance without fully assembling all
components
•Overfire
•Install any component not approved by Hearth &
Home Technologies
•Install parts or components not Listed or approved.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualified
installer, service agency or your dealer.
Note: The appliance is also approved for installation
into a shop.

R
August 27, 2009 7036-135F Page 5
Mt. Vernon Pellet Insert (AE)
2Getting Started
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 5.1
A
. Design, Installation & Location Considerations
WARNING! Risk of Fire Damaged parts could impair safe
operation. Do NOT install damaged, incomplete or substitute
components.
1. Appliance Location
NOTICE: Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building inspector, re
of cials or authorities having jurisdiction over restrictions,
installation inspection and permits.
It is a good idea to plan your installation on paper, using exact
measurements for clearances and fl oor protection, before
actually beginning the installation. Location of the appliance
and chimney will affect performance.
Consideration must be given to:
• Safety, convenience, traf c fl o w
• Placement of the chimney and chimney connector and to
minimize the use of chimney offsets.
• Place the appliance where there will be a clear passage
for a Listed chimney through the ceiling and roof (vertical)
or through exterior wall (horizontal).
• Installing the required outside air kit will affect the location
of the vent termination.
When locating vent and venting termination, the ideal loca-
tion is to vent above roof line when possible. This minimizes
the affects of wind loading.
CAUTION! If burning shelled field corn, you must use ap-
proved venting specifically designed for corn to prevent
corrosion or degradation. Follow the instructions from the
venting manufacturer.
Since pellet exhaust can contain ash, soot or sparks, you
must consider the location of:
• Windows
• Air Intakes
• Air Conditioner
• Overhang, sof ts, porch roofs, adjacent walls
• Landscaping, vegetation
• Horizontal or vertical vent termination
2. Floor Support
The supporting fl oor under the appliance must be able
to handle the weight of the appliance, fuel load and the
weight of the chimney.
Ensure that your fl oor will suport these weights prior to in-
stallation. Add suf cient additional support to meet this
weight requirment prior to installation. The weight of the
appliance is 425 lbs.

Page 6 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
• Installation and use of any damaged appliance.
• Modi cation of the appliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not
approved by Hearth & Home Tec hnologies.
• Operating appliance without fully assembling all
components.
• Operating appliance without legs attached (if supplied
with unit).
• Do NOT Over re
Or any such action that may cause a fire hazard.
WARNING
Hearth & Home Tec hnologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
Reciprocating Saw
Channel Locks
Hammer
Phillips Screwdriver
Tape Measure
Plumb Line
Level
Framing Material
Hi-temp Caulking Material
Gloves
Safety Glasses
Framing Square
Electric Drill & Bits (1/4”)
1/4” Self-Tapping Screws
May also need:
Vent Support Straps
Venting Paint
Tools and building supplies normally required
for installation, unless installing into an existing
masonry fireplace:
C. Tools And Supplies Needed
E. Pre-Use Check List
1. Place the appliance in a location near the
n al installation area and follow the proce-
dures below:
2. Open the appliance and remove all the parts
and articles packed inside the Component
Pack.
Inspect all the parts and glass for shipping
damage. Contact your dealer if any irregulari-
ties are noticed.
Remove rubber band from ash pan installed for
shipping purposes only.
3. All safety warnings have been read and fol-
lowed.
4. This Owner’s Manual has been read.
5. Floor protection requirements have been met.
6. Venting is properly installed.
7. The proper clearances from the appliance and
chimney to combustible materials have been
met.
8. The masonry chimney is inspected by a profes-
sional and is clean, or the factory built metal
chimney is installed according to the manufac-
turer’s instructions and clearances.
9. The chimney meets the required minimum
height.
10.
All labels have been removed from the glass
door.
11.Plated surfaces have been wiped clean, if
applicable.
12. Wall Control Thermostat has been installed.
13. A power outlet is available nearby.
14. A good quality surge protectory is highly recom-
mended to protect the electronics.
B. Thermostat Wall Control Location
The thermostat wall control’s location will have some affect
on the appliance’s operation.
• Maximum wire length from appliance is 100 feet (30.48m)
continuous unspliced wire. Recommended 20 gauge wire,
solid copper .
• When located close to the appliance, it may require a
slightly higher temperature setting to keep the rest of the
house comfortable.
• When located in an adjacent room or on a different fl oor
level, you will notice higher temperatures near the appli-
ance.
CAUTION! The wall control is an integral part of the appli-
ance. No other wall control or thermostat can be substi-
tuted.
D. Inspect Appliance and Components
WARNING! Risk of Fire! Damaged parts could impair safe
operation. Do NOT install damaged, incomplete or substitute
components.
• Open the appliance and remove all the parts and articles
packed inside the Component Pack. Inspect all the parts
and glass for shipping damage.
• Report to your dealer any parts damaged in shipment.
• All labels have been removed from the glass door.
• Plated surfaces have been wiped clean with a soft cloth,
if applicable.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the
installation to ensure maximum safety and benefit.
• Follow pipe manufacturer instructions for installation
and air clearance requirments.

R
August 27, 2009 7036-135F Page 7
Mt. Vernon Pellet Insert (AE)
3Dimensions and Clearances
A. Appliance Dimensions
Figure 7.3 - Front View with Basic Surround Panel Set
Figure 7.1 - Top View Figure 7.2 - Side View
26-1/4 in.
(667mm)
13-1/8 in.
(333mm)
15 in.
(382mm)
23-7/8 in.
(606mm)
32 in. (812mm)
8-1/8 in.
(206mm)
2-3/8 in.
(59mm)
C
L
29-3/4 in.
(756mm) 23-7/8 in.
(605mm)
28-1/8 in.
(714mm)
50 in. (1270mm)
33 in.
(838mm)
36-5/8 in.
(929mm)
34-7/8 in.
(886mm)
46-1/8 in.
(1171mm)
Figure 7.4 - Front View with Cast Panel Set

Page 8 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
Fire Risk.
Comply with all minimum
clearances to combustibles as
speci ed.
WARNING
Failure to comply may cause
house re.
NOTE:
• Illustrations refl ect typical installations
and are FOR DESIGN PURPOSES
ONLY.
• Illustrations/diagrams are not drawn to
scale.
• Actual installation may vary due to
individual design preference.
A
C
B
D
C
B
0 inch Clearance To Exposed Section And Face Trim
E
B. Clearance To Combustibles, UL and ULC
Location Con guration Inches Millimeters
ATop of Hopper Top or Rent Vent 3 76
B Side of Outside Skin Top or Rear Vent 2 51
C Back of Hopper Top Vent 7-1/2 191
Rear Vent 2-3/4 70
DVent Pipe to Combustible Top or Rear Vent 3 76
E Cast Side to Side Wall Top or Rear Vent 6 152
Outside Air
Top/Rear Vent
3 in. (76mm)
Back of Hopper
2.75 in. (70mm)
6 in
(152mm)
Built-in Unit - Rear Vent with Outside Air
Figure 8.1
Figure 8.2
Built-in Unit - Rear Vent

R
August 27, 2009 7036-135F Page 9
Mt. Vernon Pellet Insert (AE)
E. Minimum Opening for Masonry and Zero
Clearance Fireplaces
Location Inches Millimeters
A Insert side to combustible side wall 6 152
BInsert top to max. 2-1/4 inch face trim 0 0
C Insert side to max. 2-1/4 inch face trim 0 0
Location Inches Millimeters
F Rear Width 24 610
GDepth 15 381
H Height 23-7/8 606
I Front Width 34 864
Figure 9.2
Figure 9.3
C. Masonry and Zero Clearance Fireplaces
Location Inches Millimeters
D Floor protection hearth extension from
door opening 6 152
E Floor protection to the side of door
opening
6 152
D. Floor Protection
F
GH
I
F. Mantel Projections
J
K
Mantel Face
Trim
D
E
AC
B
Side Wall
Figure 9.4
Built-In Vertical
Figure 9.1
Use two 45 degree elbows to
clear heat shield and hopper.
7.5 in
(191mm)
3.0 in
(76mm)
3.0 in
(76mm)
The maximum mantel depth (J) is 12 inches (305mm) with
a minimum vertical height (K) of 12 inches (305mm).
However if your mantel has a depth of 10 inches (254mm)
then the vertical minimum height is 10 inches (254mm).

Page 10 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
Mark area of
floor to cut
Starter hole
Use 2 x 4 from insert
packaging to support insert
Keep sharp edge of
metal floor away from
power cord
Leveling Leg
G. Removing Metal Floor of Factory-Built Firebox
• The r ebrick (refractory), glass doors, screen rails, screen
mesh and log grates can be removed from a factory-built
r ebox in order to gain minimum insert opening require-
ments.
• Any smoke shelves, shields and baffl es may be removed
from a factory-built rebox if attached with mechanical fas-
teners.
• The metal fl oor of the factory-built rebox may be removed
to facilitate the installation of the insert only when a 1/4
inch (6mm) airspace is provided between the insert and
the fl oor of outer wrap.
Figure 10.1. Measure and mark the metal
fl o or for cutting. With a drill, make a starter
hole in each corner.
Figure 10.2. Using a saws-all, cut out the
fl o or.
Figure 10.3. If the fl oor is made of thin metal,
we recommend using the 2 x 4 from the insert
packaging to support the insert. The 2 x 4
may need to be cut to the appropriate size.
Figure 10.4. Place the insert into the fac-
tory-built rebox. Ensure that the power
cord can not be damaged by the sharp metal
edge. You may need to cut out a notch to
accomodate the cord.
Figure 10.5. Ensure that the leveling leg is
positioned over the 2 x 4 before leveling the
insert.
The following is only one example as there are many differ-
ent models of factory-built replaces.

R
August 27, 2009 7036-135F Page 11
Mt. Vernon Pellet Insert (AE)
• The fireplace must not be altered, except for the
exceptions listed below. Do not removal the bricks and
mortar from the existing replace.
The following modi cations are permissible:
• Removal of damper or locked in open position
• Removal of smoke shelf or baffl e
• Removal of ember catches
• Removel of re grate
• Removal of view screen/curtain
• Removal of doors
• External trim pieces which do not affect the operation
of the replace may be removed providing they can be
stored on or within the replace for reassembly if the insert
is removed.
• The permanent metal warning label provided must be
attached to the back of the replace, with screws or
nails, stating that the replace may have been altered to
accommodate the insert, and must be returned to original
condition for use as a conventional replace. Figure
11.1
• If the hearth extension is lower than the replace opening,
the portion of the insert extending onto the hearth must
be supported.
• Manufacturer designed adjustable support kit can be
ordered from your dealer.
• Final approval of this installation type is contingent upon
the authority having jurisdiction.
I. Altering the Factory-Built Fireplace
WARNING! Risk of Fire!
Follow venting manufacturer’s clearances and instructions
when installing venting system.
NOTICE: In Canada when using a factory-built chim-
ney it must be safety listed, Type UL103 HT (2100
o
F)
[1149oC] CLASS “A” or conforming to CAN/ULC-
S629M, STANDARD FOR 650oC FACTORY-BUILT
CHIMNEYS.
NOTE: Refer to chimney liner manufacturer for recom-
mendations on supporting the liner. Installation into
fi r eplaces without a permit will void the listing
250-2061
WARNING
THIS FIREPLACE MAY HAVE BEEN ALTERED
TO ACCOMMODATE AN INSERT. IT MUST BE
RETURNED TO ITS ORIGINAL CONDITION
BEFORE USE AS A SOLID FUEL BURNING
FIREPLACE. 250-2061
Figure 11.1
H. Prefabricated Metal Chimney
The chimney can be new or existing, masonry or prefabricated
and must meet the following minimum requirements:
• Must be minimum 6 inch (152mm) inside diameter of
high temperature chimney listed to UL 103 HT (2100oF)
or ULC-S628.
• Must use components required by the manufacturer for
installation.
• Must maintain clearances required by the manufacturer
for installation.
• Refer to manufacturers instructions for installation
•This insert is listed to UL 1482 Standard and is approved
for installation into listed factory-built zero clearance re-
places listed to UL 127 conforming to the following speci-
c ations and instructions:
•The original factory-built clearance replace chimney
cap must be re-installed after installing the approved
chimney liner meeting type UL 103 HT requirements
(2100°F) per UL 1777.
•If the chimney is not listed as meeting HT requirements,
or if the factory built replace was tested prior to 1998, a
full height listed chimney liner must be installed from the
appliance fl ue collar to the chimney top.
•The liner must be securely attached to the insert fl ue collar
and the chimney top.
•The air fl ow of the factory-built zero-clearance replace
system must not be altered. The fl ue liner top support
attachment must not reduce the air fl ow for the existing
air-cooled chimney system.
•No dilution air is allowed to enter the chimney.
1. Secure the replace damper in the open position. If
this cannot be accomplished, it will be necessary to
remove the damper
2. Seal damper area of chimney around chimney
connector with a high temperature sealant or seal
insert against the face of the replace.
3. Both methods must be removable and replaceable
for cleaning and re-installation.

Page 12 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
4Vent Information
4Vent Information
A. Venting Termination Minimum Requirements
NOTICE:
Termination must exhaust above air inlet elevation.
• It is recommended that at least 60 inches (1524mm) of
vertical pipe be installed when appliance is vented directly
through a wall. This will create a natural draft, which will
help prevent the possibility of smoke or odor venting into
the home during a power outage.
• It will also keep exhaust from causing a nuisance or hazard
by exposing people or shrubs to high temperatures.
• The safest and preferred venting method is to extend the
vent vertically through the roof or above the roof.
J or K
X
V
M
I
H
AVG
B
V
V
A
B
V
FV
C
B
B
E
L
V
D
V
Electrical
Service
V
N
VN
V
N
N
V
Inside Corner
FIXED
CLOSED
OPEN
OPEN
FIXED
CLOSED
VX
G
G
Termination Cap Air Supply Inlet Gas Meter Restricted Area
O
P
Figure 12.1
A12 in. Above Finish Grade (the grade surface
must be a non-combustible material
B12 in.
48 in. no OAK
Open door or window: below or to the side
B12 in. Open door or window: above
C6 in. Permanently closed window: above, below
or to the side
D18 in.
36 in. no OAK
Vertical clearance to a ventilated sof t
located above the terminal within a hori-
zontal distance of 2 ft from the center-line
of the terminal
E12 in. Clearance to unventilated sof t
F12 in. Clearance to outside corner
G12 in. Clearance to inside corner
H36 in. Above gas meter/regulator measured from
horizontal center-line of regulator
I36 in. USA
72 in. Canada
Clearance to service regulator vent outlet
J12 in.
48 in. no OAK
Clearance to non-mechanical air supply
inlet to the building or the combustions air
inlet to any other appliance
K10 ft horizontal
3 ft vertical
Clearance to mechanical air supply
L7 ft. Above paved sidewalk, paved driveway
located on public property
M12 in. Under an open veranda, porch, deck or
balcony
NSee Note
below*
Electric service: above, below or to the
side (location must not obstruct or interfere
with access)
O24 in. Adjacent building, fences and protruding
parts of the structure
P12 in. Clearance above roof line for vertical
terminations
All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below.
24 in. Above grass, top of plants, wood or any other com-
bustible
12 in.
36 in. no OAK
Clearance from any forced air intake of other appli-
ance
12 in. Clearance horizontally from combustible wall
15 in. Vented directly through a wall, minimum length of
horizontal pipe
6 in. horizontal
12 in. vertical
Minimum horizontal or vertical terminations must
protrude from wall
*NOTE: Consult local building, re of cials or authorities having jurisdic-
tion. Local codes or regulations may require different clearances.
NOTICE:
Do NOT Terminate Vent:
• In any location that will allow fl ue gases or soot from enter-
ing or staining the building.
• In any location which could create a nuisance or hazard.
• In any enclosed or semi-enclosed area such as a carport,
garage, attic, crawl space, under a sun deck or porch,
narrow walkway.
• Closely fenced area, or any location that can build up
a concentration of fumes such as a stairwell, covered
breezeway, etc.

R
August 27, 2009 7036-135F Page 13
Mt. Vernon Pellet Insert (AE)
B. Avoiding Smoke and Odors
Negative Pressure, Shut-Down and Electrical Power
Failure
To reduce the probability of back-drafting or burn-back in
the pellet appliance during power failure or shut down con-
ditions, it must be able to draft naturally without exhaust
blower operation.
Negative pressure in the house will resist this natural draft
if not accounted for in the pellet appliance installation.
Heat rises in the house and leaks out at upper levels. This
air must be replaced with cold air from outdoors which
fl o ws into lower levels of the house.
Vents and chimneys into basements and lower levels of the
house can become the conduit for air supply and reverse
under these conditions.
Outside Air
An outside air kit is recommend in all installations. The
Outside Air Kit must be ordered seperately.
Per national building codes, consideration must be given
to combustion air supply to all combustion appliances.
Failure to supply adequate combustion air for all appli-
ance demands may lead to backdrafting of those and other
appliances.
When the appliance is roof vented (strongly recommended):
The air intake is best located on the exterior wall ori-
ented towards the prevailing wind direction during the
heating season.
When the appliance is side-wall vented:
The air intake is best located on the same exterior wall
as the exhaust vent outlet and located lower on the wall
than the exhaust vent outlet.
The outside air supply kit can supply most of the demands
of the pellet appliance, but consideration must be given to
the total house demand.
House demand may consume the air needed for the appli-
ance. It may be necessary to add additional ventilation to
the space in which the pellet appliance is located.
Consult with your local HVAC professional to determine the
ventilation demands for your house.
Vent Configurations
To reduce probability of reverse drafting during shut-down
conditions Hearth & Home Te c hnologies strongly recom-
mends:
• I n stalling the pellet vent with a minimum vertical run
of 5 feet (1.52m). Preferably terminating above the
roof line.
• I n stalling the outside air kit at least 4 feet (1.22m)
below the vent termination.
To prevent soot damage to exterior walls of the house and
to prevent re-entry of soot or ash into the house:
• M aintain speci ed clearances to windows, doors and
air inlets, including air conditioners.
• Ve nts should not be placed below ventilated sof ts.
Run the vent above the roof.
• Av oid venting into alcove locations.
• Ve nts should not terminate under overhangs, decks
or onto covered porches.
• M aintain minimum clearance of 12 inches (305mm)
from the vent termination to the exterior wall. If you
see deposits developing on the wall, you may need
to extend this distance to accommodate your installa-
tion conditions.
CAUTION
• DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE
SERVICING ANOTHER APPLIANCE.
• DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT
OR SYSTEM.
Optional Battery Back-Up
Hearth & Home Technologies supplies an optional battery
back-up system that operates the appliance during power
failure conditions to prevent smoking. In shutdown mode,
the battery back-up will not prevent smoking. See Section
8 for details.
Hearth & Home Te c hnologies assumes no responsibility for,
nor does the warranty extend to, smoke damage caused
by reverse drafting of pellet appliances under shut down or
power failure conditions.

Page 14 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
Negative pressure results from the imbalance of air available
for the appliance to operate properly. It can be strongest in
lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water heaters
and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
- Recessed lighting
- Attic hatch
- Duct leaks
To minimize the effects of negative air pressure:
• Install the outside air kit with the intake facing prevailing
winds during the heating season
• Ensure adequate outdoor air for all combustion appliances
and exhaust equipment
• Ensure furnace and air conditioning return vents are not
located in the immediate vicinity of the appliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and seams
taped or sealed
WARNING! Risk of Asphyxiation! Negative pressure can
cause spillage of combustion fumes and soot.
C. Negative Pressure
Draft is the pressure difference needed to vent an ap-
pliance successfully. When an appliance is drafting suc-
cessfully, all combustion byproducts are exiting the home
through the chimney.
Install through the warm airspace enclosed by the building
envelope. This helps to produce more draft, especially dur-
ing lighting and die-down of the re.
Considerations for successful draft include:
• Preventing negative pressure
• Location of appliance and chimney
NOTICE: Hearth & Home Technologies assumes no
responsibility for the improper performance of the chimney
system caused by:
• Inadequate draft due to environmental conditions
• Downdrafts
• Tight sealing construction of the structure
• Mechanical exhausting devices
D. Draft

R
August 27, 2009 7036-135F Page 15
Mt. Vernon Pellet Insert (AE)
E. Chimney and Exhaust Connection
1. Chimney & Connector: Use 3 or 4 inch (76-102mm)
diameter type "L" or "PL" venting system. It can be vented
vertically or horizontally.
2. Mobile Home: Approved for all Listed pellet vent. If using
the 3 inch (76mm) vertical Top Vent Adapter Kit or the 3
to 6 inch (76-152mm) Top Vent Offset Adapter, use Listed
double wall fl ue connector. A Quadra-Fire Outside Air Kit
must be used with manufactured home installations.
3. Residential: The 3 inch (76mm) vertical Top Vent Adapter
Kit and the 3 to 6 inch (76-152mm) Top Vent Offset Adapter
are tested to use 24 gauge single wall fl ue connector or
Listed double wall fl ue connector to Class A Listed metal
chimneys, or masonry chimneys meeting International
Residential Code standards for solid fuel appliances.
4. INSTALL VENT AT CLEARANCES SPECIFIED BY THE
VENT MANUFACTURER.
5. Secure exhaust venting system to the appliance with at
least 3 screws. Also secure all connector pipe joints with
at least 3 screws through each joint.
6. DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST
VENTING SYSTEM OF THIS UNIT.
7. DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE
SERVING ANOTHER APPLIANCE.
NOTE: All pipe must be welded seam pipe whenever
possible. Seal pipe joints with high temperature silicone
(500°F [260°C] minimum rated only).
NOTE: If burning shelled field corn, you must use
approved venting specifically designed for corn. Follow
the instructions from the venting manufacturer.
The table below can help you calculate the equivalent feet
of pipe which is a method used to determine pellet vent size.
Figure 15.1.
F. Equivalent Feet of Pipe
2 ft.
2 ft.
3 ft.
2 ft.
Example of 3 Elbow-Rear Vent Termination Calculation
Figure 15.1
Pellet Venting
Component
# of
Elbows
Feet of
Pipe
Multiplied
By
Equivalent
Feet
Components
Equivalent Feet
90o Elbow or Tee 3 X 515
45o Elbow X3
Horizontal Pipe 7 X 17
Vertical Pipe 2X0.5 1
Total Equivalent Feet 23
Note: This is a generic example and is not
intended to represent any speci c fuel type.
• Only LISTED venting components may be used.
• NO OTHER vent components may be used.
• Substitute or damaged vent components may impair
safe operation.
WARNING! RISK OF FIRE!
WARNING! RISK OF INJURY OR PROPERTY
DAMAGE!
• Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
• Refer to the owner’s information manual provided with this
appliance.
• For assistance or additional information consult a quali ed
installer, service agency or your dealer.
Vent surfaces get HOT, can cause burns
if touched. Non-combustible shielding or
guards may be required.
WARNING

Page 16 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
G. Pipe Selection Chart
Do NOT pack insulation or other combustibles between
r estops.
• ALWAYS maintain speci ed clearances around venting
and restop systems.
• Install r estops as speci ed.
Failure to keep insulation or other material away from vent
pipe may cause re.
Figure 16.1
3 in. or 4 in. (76mm or 102mm) Diameter Pipe
Equivalent Pipe
Length In Feet
ALTITUDE IN THOUSANDS OF FEET
0
20
30
1 2 3 4 5 6 7 8 9 10
4 in. (102mm) Diameter Pipe Only
10
Example 1
Example 2
Example 1: If the equivalent length of pipe is 23 feet (.58m) with alti-
tude of 8,000 feet (203m) you must use 4 inch (102mm) diameter type
“L” or “PL” vent.
Example 2: If the equivalent length of pipe is 12 feet (.30m) with altitude
of 6,000 feet (152m) you may use 3 or 4 inch (76 to 102mm) diameter
type “L” or “PL” vent.
The chart will help you in determining proper venting size
according to the equivalent feet of pipe calculated previously
and the altitude above sea level of this installation.
Figure 16.1.
a. Locate the calculated equivalent feet of pipe on the verti-
cal left side of the chart.
b. Move to the right horizontally on the chart until you reach
your altitude above sea level.
c. If you fall below the diagonal line, 3 or 4 inch (76 to
102mm) pipe may be used.
d. If it is anywhere above the diagonal line, a 4 inch (102mm)
diameter pipe is required.
NOTICE:
• A 90° elbow is 5 times as restrictive to the fl ow of exhaust
gases under positive pressure as 1 foot (305mm) of hori-
zontal pipe.
• A foot of horizontal pipe is twice as restrictive as a foot of
vertical pipe.
WARNING! RISK OF FIRE!

R
August 27, 2009 7036-135F Page 17
Mt. Vernon Pellet Insert (AE)
5Venting Systems
NOTE:
In Canada, where passage through a wall or partition of
combustible construction is desired, the installation shall
conform to CAN/CSA-B365.
Figure 17.1
Fire Risk.
Inspection of Chimney:
• Masonry chimney must be in good condition.
• Meets minimum standard of NFPA 211
•
Factory-built chimney must be a minimum 6 inch
(152mm) UL103 HT.
WARNING
CAUTION
Never draw outside combustion air from:
• Wall, fl oor or ceiling cavity
• Enclosed space such as an attic or garage
NOTE:
• Illustrations refl ect typical installations and are FOR
DESIGN PURPOSES ONLY.
• Illustrations/diagrams are not drawn to scale.
• Actual installation may vary due to individual design
preference.
A. Full Reline With Outside Air - Horizontal
Outside Air through Rear
Wall (Horizontal)
NOTE; Use metal plate around
exhaust vent pipe and seal all
edges with non-flammable insu-
lation such as fiberglass, mineral
wool or ceramic.
Do not use high temperature
caulking materials to seal any
edge to prevent furture service-
ability.

Page 18 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
NOTE: Check clearances carefully for this type of instal-
lation to ensure adequate room for outside air venting.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult local building, re of c ials or authorities having
jurisdiction about restrictions, installation inspection, and
permits.
CAUTION
NOTE: In Canada only a full reline is allowed per ULC
S628, ORD ULC C1482-M1990.
B. Full Reline With Outside Air - Vertical
Figure 18.1
Outside Air
Termination
at
Chimney Top
(Vertical)
305mm min.
below
305mm min.
above
NOTE; Use metal plate around
exhaust vent pipe and seal all
edges with non-flammable insula-
tion such as fiberglass, mineral
wool or ceramic.
Do not use high temperature caulk-
ing materials to seal any edge to
prevent furture serviceability.
NOTE: In Canada this replace insert must be installed
with a continous chimney liner a 6 inch (152mm) in diam-
eter extending from the replace insert to the top of the
chimney. The chimney liner must conform to the Class
3 requirments of CAN/ULC-S635, Standard for Lining
Systems for Extising Masonry or Factory-Built Chimneys
and Vents, or CAN/ULC-S640, Standard for Lining Sys-
tems for New Masonry Chimneys.

R
August 27, 2009 7036-135F Page 19
Mt. Vernon Pellet Insert (AE)
6Mobile Home
1. An outside air inlet must be provided for the combustion
air and must remain clear of leaves, debris, ice and/or
snow. It must be unrestricted while the appliance is
in use to prevent room air starvation which causes
smoke spillage. Smoke spillage can also set off smoke
alarms.
2. The combustion air duct system must be made of metal.
It must permit zero clearance to combustible construc-
tion and prevent material from dropping into the inlet or
into the area beneath the dwelling and contain a rodent
screen.
3. The appliance must be secured to the mobile home
structure by bolting it to the fl oor (using lag bolts).
Use the same holes that secured the appliance to the
shipping pallet.
4. The appliance must be grounded with #8 solid copper
grounding wire or equivalent, terminated at each end
with an NEC approved grounding device.
5. Refer to Clearances to Combustibles and fl oor pro-
tection requirements on pages 8 & 9 for listings to
combustibles and appropriate chimney systems.
6. Use silicone to create an effective vapor barrier at
the location where the chimney or other component
penetrates to the the exterior of the structure.
7. Follow the chimney manufacturer’s instructions when
installing the vent system for use in a mobile home.
8. Installation shall be in accordance with the Manufactur-
ers Home & Safety Standard (HUD) CFR 3280, Part
24.
NEVER INSTALL IN A SLEEPING ROOM.
WARNING
You must use a Quadra-Fire Outside Air Kit
for installation in a mobile home.
Spark Arrestor Cap
Roof Flashing
Storm Collar
Joist Shield/Firestop Approved Class L
or PL Pellet Vent
Figure 19.1
CAUTION
Never draw outside combustion air from:
• Wall, fl oor or ceiling cavity
• Enclosed space such as an attic or garage
CAUTION
THE STRUCTURAL INTEGRITY OF THE MOBILE HOME
FLOOR, WALL AND CEILING/ROOF MUST BE MAIN-
TAINED
Do NOT cut through:
• Floor joist, wall, studs or ceiling trusses.
• Any supporting material that would affect the structural
integrity.

Page 20 7036-135F August 27, 2009
R
Mt. Vernon Pellet Insert (AE)
7Appliance Set-Up
A. Leveling System B. Outside Air Kit Instructions
Included in Kit: 2 wire ties, 1 collar assembly,
1 termination cap assembly, 1 trim ring, fasteners.
NOTE: 3 INCH (76mm) ALUMINUM FLEX PIPE NOT
INCLUDED.
1. Measure distance from fl oor to air vent opening in appli-
ance and mark location on wall.
2. Use saw to cut opening in wall. Cut a 3-1/2 to 4 inch
(89-102mm) opening on inside wall and a 4 to 4-1/2
inch (102-114mm) opening on outside of house.
3. Use wire ties to secure fl ex pipe to collar assembly.
4. Slide trim ring over fl ex pipe and run pipe through wall.
5. Attach fl e x pipe (not included) to outside termination
cap with second wire tie.
6. Secure termination cap to outside surface.
7. Secure trim ring to interior wall.
Tools Needed: Phillips head screw driver; wire cutters;
hole saw or jig saw.
CAUTION
Never draw outside combustion air from:
• Wall, fl oor or ceiling cavity
• Enclosed space such as an attic or garage
The leveling bolts are located on the sides of the appliance,
front and rear. To access the bolts, remove the front access
panels. Reach in and turn the bolt to the desired height to
level the appliance.
Figure 20.1
Collar
Wire Ties
Trim Ring
Termination Cap
3 inch Aluminum Flex
Pipe (not included)
Figure 20.2
Leveling Bolts - 2 on each side
