Quadra-Fire MTV-E2-CSB User manual

1 7080-131B March 14, 2014
MT. VERNON PELLET STOVE E2
Model(s):
MTV-E2-CSB
MTV-E2-MBK
MTV-E2-PFT
MTV-E2-PDB
MTV-E2-PBK
MTV-E2-PMH
Installation Manual
Installation & Appliance Set-Up
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
replace.
• Alert children and adults to hazards of high temperatures
• High temperatures may ignite clothing or other
ammablematerials.
• Keep clothing, furniture, draperies and other ammable
materials away.
WARNING
If the information in these instruc-
tions is not followed exactly, a
recouldresultcausingproperty
damage, personal injury, or death.
• Donotstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityof
this or any other appliance.
• Donotoverre-Ifheaterorchimneycon-
nectorglows,youareoverring.Overring
willvoidyourwarranty.
• Complywithallminimumclearancesto
combustiblesasspecied.Failureto
complymaycausehousere.
CAUTION
Testedandapprovedforwoodpelletsonly
WARNING
NOTE
ToobtainaFrenchtranslationofthismanual,pleasecontact
yourdealerorvisitwww.quadrare.com
Pourobtenirunetraductionfrançaisedecemanuel,s’ilvous
plaîtcontactervotrerevendeurouvisitezwww.quadrare.com
CAUTION
Checkbuildingcodespriortoinstallation.
• InstallationMUSTcomplywithlocal,regional,stateandna-
tional codes and regulations.
• Consultlocalbuilding,reofcialsorauthoritieshavingjuris-
dictionaboutrestrictions,installationinspection,andpermits.
Pleasereadthisentiremanualbeforeinstallationanduseofthis
pelletfuel-burningroomheater.Failuretofollowtheseinstructions
couldresultinpropertydamage,bodilyinjuryorevendeath.
061-S-83-2

2 7080-131B March 14, 2014
MT VERNON E2
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicatesahazardoussituationwhich,ifnotavoidedwillresultindeathorseriousinjury.
• WARNING!Indicatesahazardoussituationwhich,ifnotavoidedcouldresultindeathorseriousinjury.
• CAUTION! Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
1 Important Safety Information............ 3
A.ApplianceCertication ......................................................3
B.BTU&EfciencySpecications........................................3
C.GlassSpecications .........................................................3
D. Electrical Rating................................................................3
E.MobileHomeApproved .................................................... 3
F.Non-CombustibleMaterials................................................3
G.CombustibleMaterials.......................................................3
2 Getting Started ................................... 4
A . Design, Installation & Location Considerations ..........................4
B. Remote Thermostat Location ............................................5
C. Tools And Supplies Needed..............................................5
D. Inspect Appliance and Components .................................5
E. Install Checklist..................................................................6
3 Dimensions and Clearances............. 7
A. Appliance Dimensions ......................................................7
B.ClearancestoCombustibles(US&Canada) ....................8
C.HearthPadRequirements(US&Canada)........................8
D.Alcove................................................................................9
4 Vent Information............................... 10
A.VentingTerminationMinimumRequirements ...................10
B.AvoidingSmokeandOdors ...............................................11
C.NegativePressure .....................................................12
D. Draft .................................................................................12
E. Chimney and Exhaust Connection ..................................12
F. EquivalentFeetofPipe ....................................................13
G. Pipe Selection Chart ........................................................13
5 Venting Systems .............................. 14
A. Through The Wall .............................................................14
B. Vertical into Existing Class A Chimney .............................15
C. Through The Wall & Vertical - Exterior ..............................15
D. Vertical - Interior - Typical Installation................................15
E. Masonry............................................................................16
F. Alternate Masonry .............................................................16
6 Appliance Set-Up ............................. 17
A.LegLevelingSystem .......................................................17
B.OutsideAirKitInstructions................................................17
C. Top Vent Adapter Installation ............................................18
D. Rear Vent & Rear Vent to Top Vent Adapter Installation...18
E.OptionalLogSetPlacementInstructions..........................19
F. Remote Thermostat Installation .......................................20
G. Power Cord .......................................................................20
7 Mobile Home Installation................. 21
8 Accessory List ................................. 22

March 14, 2014 7080-131B 3
MT VERNON E2
TheQuadra-FireMt.VernonE2PelletStovemeetstheU.S.Envi-
ronmentalProtectionAgency’s1990particulateemissionstandards.
1 Important Safety Information
NOTE:Hearth&HomeTechnologies,manufacturerof
thisappliance,reservestherighttoalteritsproducts,their
specicationsand/orpricewithoutnotice.
Improper installation, adjustment, alteration, service or
maintenancecancauseinjuryorpropertydamage.
Forassistanceoradditionalinformation,consultaqualied
installer,serviceagencyoryourdealer.
• Installationanduseofanydamagedappliance.
• Modicationoftheappliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installationand/oruseofanycomponentpartnotapprovedby
Hearth & Home Technologies.
• Operatingappliancewithoutfullyassemblingallcomponents.
• Operatingappliancewithoutlegsattached(ifsuppliedwithunit).
• DoNOTOverre- Ifapplianceorchimneyconnectorglows,
youareoverring.
Anysuchactionthatmaycausearehazard.
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibilityfor,andthewarrantywillbevoidedby,
thefollowingactions:
 • Thestructuralintegrityofthemobilehomeoor,ceil-
ing,andwallsmustbemaintained.
 • Theappliancemustbeproperlygroundedtotheframe
of the mobile home and use only Listed pellet vent
Class “L” or “PL” connector pipe.
 • OutsideAirKit,partOAK-3mustbeinstalledinamo-
bilehomeinstallation.
F. Non-Combustible Materials
Materialwhichwillnotigniteandburn,composedofany
combinationofthefollowing:
- Steel - Plaster
- Brick - Iron
- Concrete - Tile
- Glass - Slate
Materials reported as passing ASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace of 750° C.
G. Combustible Materials
Materialmadeof/orsurfacedwithanyofthefollowingma-
terials:
- Wood - Compressed Paper
 -PlantFibers  -Plastic
 -Plywood/OSB  -SheetRock(drywall)
Anymaterialthatcanigniteandburn:ameproofedornot,
plastered or un-plastered.
*BTUwillvary,dependingonthetypeoffuelyouuseinyour
appliance.ConsultyourQuadra-Firedealerforbestresults.
C.GlassSpecications
Thisstoveisequippedwith5mmceramicglass.Replace
glass only with 5mm ceramic glass. Please contact your
dealer for replacement glass.
D. Electrical Rating
115 VAC, 60 Hz, Start 2.9 Amps, Run 2.45 Amps
E. Mobile Home Approved
 • Thisapplianceisapproved for mobile homeinstalla-
tions when not installed in a sleeping room and when
anoutsidecombustionairinletisprovided.
Model Mt.VernonPelletStoveE2
Laboratory OMNITestLaboratories,Inc.
Report No. 061-S-83-2
Type SolidFuelRoomHeater/PelletFuel
Burning Type
Standard ASTM E1509-12, ULC S627-00 and
(UM)84-HUD,MobileHomeApproved.
FCC Complies with Part 15 of FCC Rules.
Operationissubjecttothefollowing
twoconditions:(1)thisdevicemaynot
causeharmfulinterference,and(2)this
devicemustacceptanyinterference
received,includinginterferencethatmay
cause undesired operation.
A.ApplianceCertication
NOTICE: This installation must conform with local codes. In
theabsenceoflocalcodesyoumustcomplywiththeASTM
E1509-12, ULC S627-00, (UM) 84-HUD and ULC/ORD-
C-1482.
B.BTU&EfciencySpecications
EPACertied: 1.7 grams per hour low
2.7gramsweightedaverage
Efciency(LHV): up to 87%
BTU Input: 18,000 to 52,500
BTU Output: 13,800 to 37,600
Heating Capacity: upto3,000sqftdepending
on climate zone
Vent Size: 3inches‘L’or‘PL’
Fuel: Wood Pellets
Shipping Weight: 440lbs

4 7080-131B March 14, 2014
MT VERNON E2
Install Guide
2 Getting Started
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 4.1
A . Design, Installation & Location Considerations
1. Appliance Location
NOTICE: Checkbuildingcodespriortoinstallation.
• InstallationMUSTcomplywithlocal,regional,stateand
national codes and regulations.
• Consult insurance carrier, local building inspector, re
ofcialsorauthoritieshavingjurisdictionoverrestrictions,
installation inspection and permits.
It is a good idea to plan your installation on paper, using exact
measurements for clearances and oor protection, before
actuallybeginningtheinstallation.Locationoftheappliance
and chimney will affect performance.
Considerationmustbegivento:
• Safety,convenience,trafcow
• Placementofthe chimney and chimney connector and to
minimize the use of chimney offsets.
• Placetheappliancewheretherewillbeaclearpassage
foraListedchimneythroughtheceilingandroof(vertical)
orthroughexteriorwall(horizontal).
• Installingtherequiredoutsideairkitwillaffectthelocation
oftheventtermination.
Whenlocatingventandventingtermination,theidealloca-
tionistoventaboverooflinewhenpossible.Thisminimizes
the affects of wind loading.
Since pellet exhaust can contain ash, soot or sparks, you
mustconsiderthelocationof:
• Windows
• AirIntakes
• AirConditioner
• Overhang,softs,porchroofs,adjacentwalls
• Landscaping,vegetation
• Horizontalorverticalventtermination
2. Floor Support
The supporting oor under the appliance must be able to
handle the weight of the appliance, fuel load and the weight
of the chimney.
Ensure that your oor will support these weights prior to
installation. Add sufcient additional support to meet this
weightrequirement priorto installation. The weight of the
applianceis440lbs.withafullloadoffuelthemaxweight
is520lbs.
WARNING
Risk of Fire.
Damaged parts could impair safe operation. Do NOT
installdamaged,incompleteorsubstitutecomponents.

March 14, 2014 7080-131B 5
MT VERNON E2
•  Installation and use of any damaged
appliance.
•Modicationoftheappliance.
• InstallationotherthanasinstructedbyHearth&Home
Technologies.
• Installation and/or use of any component part not
approvedbyHearth&HomeTechnologies.
• Operating appliance without fully assembling all
components.
• Operatingappliancewithoutlegsattached(ifsupplied
withunit).
• DoNOTOverre
Oranysuchactionthatmaycausearehazard.
WARNING
Hearth & Home Technologies disclaims any
responsibilityfor,andthewarrantywillbe
voidedby,thefollowingactions:
Reciprocating Saw Channel Locks
Hammer  PhillipsScrewdriver
TapeMeasure  PlumbLine
1/4”Self-TappingScrews FramingMaterial
Hi-tempCaulkingMaterial Gloves
SafetyGlasses  FramingSquare
ElectricDrill&Bits(1/4”) Level
Mayalsoneed:
Vent Support Straps Venting Paint
Tools and building supplies normally required
for installation, unless installing into an existing
masonryreplace:
C. Tools And Supplies Needed
B. Remote Thermostat Location
The remote thermostat’slocationwillhavesomeaffect on the
appliance’soperation.
• When located close to the appliance, it may require a
slightly higher temperature setting to keep the rest of the
housecomfortable.
• When locatedinanadjacentroomoronadifferentoor
level,youwillnoticehighertemperatures near the appli-
ance.
CAUTION! Theremotethermostatisanintegralpartofthe
appliance.  No other wall control or thermostat can be
substituted.
D. Inspect Appliance and Components
• Opentheapplianceandremoveallthepartsandarticles
packed inside the Component Pack. Inspect all the parts
and glass for shipping damage.
• Reporttoyourdealeranypartsdamagedinshipment.
• Alllabelshavebeenremovedfromtheglassdoor.
• Platedsurfaceshavebeenwipedcleanwithasoftcloth,
ifapplicable.
• Readalltheinstructionsbeforestartingtheinstallation.
Follow these instructions carefully during the
installationtoensuremaximumsafetyandbenet.
• Followpipemanufacturerinstructionsforinstallation
and air clearance requirements.
**HHTrecommendsarangelimitof20feetforbestperfor-
mance
MODE/SET
Risk of Fire!
Damaged parts could impair safe operation.
DoNOTinstalldamaged,incompleteor
substitutecomponents.
WARNING

6 7080-131B March 14, 2014
MT VERNON E2
ATTENTION INSTALLER:
Follow this Standard Work Checklist
Thisstandardworkchecklististobeusedbytheinstallerinconjunctionwith,notinsteadof,theinstructionscontainedinthisinstallationmanual.
Customer:
Date Installed:
Lot/Address:
Location of Fireplace:
Installer:
Dealer/ Distributor Phone #:
Serial #:
Model (circle one): MTV-E2-MBK MTV-E2-CSB MTV-E2-PFT MTV-E2-PDB MTV-E2-PBK MTV-E2-PMH
WARNING! Risk of Fire or Explosion! Failuretoinstallreplaceaccordingtotheseinstructionscanleadtoareorexplosion.
Hearth & Home Technologies recommends the following:
•Photographingtheinstallationandcopyingthischecklistforyourle.
•Thatthischecklistremainvisibleatalltimesonthereplaceuntiltheinstallationiscomplete.
Comments: Furtherdescriptionoftheissues,whoisresponsible(Installer/Builder/OtherTrades,etc.)andcorrectiveactionneeded:
Commentscommunicatedtopartyresponsible by on
(Builder/Gen.Contractor) (Installer)(Date)
Part#4017-254•RevB•01/29/13
E. Install Checklist
Appliance Install
Requirednon-combustibleoorprotection(Pg.9)
Veriedclearancetocombustible(Pg.8)
Unitisleveledandsecured(Pg.18)
Venting/Chimney Section 4 (Pg. 12)
Ventingcongurationcomplieswithdiagrams
Venting installed, sealed and secured in place with proper clearance
Exteriorwall/roofashinginstalledandsealed
Terminations installed and sealed
OAKinstalledandsealed(ifneeded)(Pg.16&17)
Electrical
120VACunswitchedpowerprovidedtotheappliance(Pg.21)
Appliance Setup Section 5 (Pg. 17)
Allpackagingandprotectivematerialsremoved
Accessories installed properly
Startedapplianceandveriedthatallmotorsandblowersoperateastheshould
Manualbagandallofitscontentsareremovedfrominside/underthereplace
andgiventothepartyresponsibleforuseandoperation.
YES IF NO, WHY?

March 14, 2014 7080-131B 7
MT VERNON E2
Figure 7.4 - Front View
Figure 7.1 - Top View with Top Vent Adapter
and 3 to 6 in (76-152mm) Adapter
Figure 7.5 - Side View
Figure 7.2 - Side View with Top Vent Adapter and 3 to 6
in (76-152mm) Offset Adapter.
31-1/16
[788]
29-3/16
[741]
q
5-13/16
[147]
2-9/16
[65]
3-13/16
[97]
14-1/16
[357]
28-1/8 [714]
32-5/16
[821]
28-7/16 [722]
19-9/16
[497]
20 [508]
28-3/4 [730]
26-7/8 [683]
18-1/2 [470]
3-5/8
[93]
q
Figure 7.3 - Top View
3 Dimensions and Clearances
A. Appliance Dimensions

8 7080-131B March 14, 2014
MT VERNON E2
Straight Back Against Wall Inches Millimeters
ABack Wall to Appliance 2 51
BSide Wall to Appliance 6 152
Corner Installation Inches Millimeters
CWalls to Appliance 2 51
Vertical Installation Inches Millimeters
DBack Wall to Flue Pipe 3 76
ESide Wall to Appliance 6 152
FBack Wall to Appliance 8 203
Installations with:
3 to 3 inch Top Vent Adapter and
3 to 6 inch Offset Adapter Kit
Corner Installation Inches Millimeters
GSide Wall to Flue Pipe 3 76
Alcove Installation Inches Millimeters
MinimumAlcoveHeight 43 1092
MinimumAlcoveSideWall 6 152
MinimumAlcoveWidth 40 1016
MaximumAlcoveDepth 36 914
D
E
F
A
B
*L Exception for Horizontal Installations:
USA INSTALLATIONS: A non-combustible oor protec-
tion is recommended extendingbeneaththeuepipewhen
installed with horizontal venting or under the Top Vent
Adapterwithverticalinstallation.
CANADA INSTALLATIONS:A non-combustibleoorpro-
tection extendingbeneaththeuepipeis required with hor-
izontalventing or underthe Top VentAdapter with vertical
installation.
Must extend 2 inches (51mm) beyond each
side of pipe (shaded area)
NOTE:
• IllustrationsreecttypicalinstallationsandareFOR
DESIGNPURPOSESONLY.
•Illustrations/diagramsarenotdrawntoscale.
• Actualinstallationmayvaryduetoindividualdesign
preference.
C
C
G
G
L*
K
K
M
Use a non-combustible oor protector, extending beneath
appliance and to the front, sides and rear as indicated. Mea-
sure front distance “M” from the surface of the glass door.
Hearth Pad Requirements Inches Millimeters
KSides 2 200
L* Back 2 200
MFront 6 450
B. Clearances to Combustibles (US & Canada) C. Hearth Pad Requirements (US & Canada)
Fire Risk.
Comply with all minimum clearances to
combustiblesasspecied.
WARNING
Failuretocomplymaycausehousere.

March 14, 2014 7080-131B 9
MT VERNON E2
A
C
B
D
NOTE:
• IllustrationsreecttypicalinstallationsandareFOR
DESIGNPURPOSESONLY.
• Illustrations/diagramsarenotdrawntoscale.
• Actualinstallationmayvaryduetoindividualdesign
preference.
D. Alcove
Figure 9.1
*Allminimumslistedaretoacombustiblesurface.
Minimum* Maximum
Inches Millimeters Inches Millimeters
AHeight 43 1092 n/a n/a
BWidth 40 1016 n/a n/a
CDepth n/a n/a 36 914
DTo Side Wall 6 152 n/a n/a

10 7080-131B March 14, 2014
MT VERNON E2
4 Vent Information
A. Venting Termination Minimum Requirements
J or K
X
V
M
I
H
A
V
G
B
V
V
A
B
V
FV
C
B
B
E
L
V
D
V
Electrical
Service
V
N
VN
V
N
N
V
Inside Corner
FIXED
CLOSED
OPEN
OPEN
FIXED
CLOSED
VX
G
G
Termination Cap Air Supply Inlet Gas Meter Restricted Area
O
P
Figure 10.1
A12 in. AboveFinishGrade(thegradesurface
mustbeanon-combustiblematerial
B12 in.
48in.noOAK
Opendoororwindow:belowortotheside
B12 in. Opendoororwindow:above
C6 in. Permanentlyclosedwindow:above,below
or to the side
D18 in.
36in.noOAK
Verticalclearancetoaventilatedsoft
locatedabovetheterminalwithinahori-
zontal distance of 2 ft from the center-line
of the terminal
E12 in. Clearancetounventilatedsoft
F12 in. Clearance to outside corner
G12 in. Clearance to inside corner
H36 in. Abovegasmeter/regulatormeasuredfrom
horizontal center-line of regulator
I36 in. USA
72 in. Canada
Clearancetoserviceregulatorventoutlet
J12 in.
48in.noOAK
Clearance to non-mechanical air supply
inlettothebuildingorthecombustionsair
inlet to any other appliance
K10 ft horizontal
3ftvertical
Clearance to mechanical air supply
L7 ft. Abovepavedsidewalk,paveddriveway
located on public property
M12 in. Underanopenveranda,porch,deckor
balcony
NSee Note
below*
Electricservice:above,belowortothe
side(locationmustnotobstructorinterfere
withaccess)
O24 in. Adjacentbuilding,fencesandprotruding
parts of the structure
P12 in. Clearanceaboverooflineforvertical
terminations
All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below.
24 in. Abovegrass,topofplants,woodoranyothercom-
bustible
12 in.
36in.noOAK
Clearance from any forced air intake of other appli-
ance
12 in. Clearancehorizontallyfromcombustiblewall
15 in. Vented directly through a wall, minimum length of
horizontal pipe
6 in. horizontal
12in.vertical
Minimumhorizontalorverticalterminationsmust
protrude from wall
*NOTE: Consultlocalbuilding,reofcialsorauthoritieshavingjurisdic-
tion.Localcodesorregulationsmayrequiredifferentclearances.
NOTICE:
Do NOT Terminate Vent:
• Inanylocationthatwillallowuegasesorsootfromen-
teringorstainingthebuilding
• Inanylocationwhichcouldcreateanuisanceorhazard
• In any enclosed or semi-enclosed area such as a carport,
garage, attic, crawl space, under a sun deck or porch,
narrow walkway
• Closely fenced area, or any location that can build up
a concentration of fumes such as a stairwell, covered
breezeway,etc.
NOTICE:
Termination must exhaust above air inlet elevation.
• Itisrecommendedthatatleast60inches(1.52m)ofver-
ticalpipebeinstalledwhenapplianceisventeddirectly
through a wall. This will create a natural draft, which will
helppreventthepossibilityofsmokeorodorventinginto
the home during a power outage.
• Itwillalsokeepexhaustfromcausinganuisanceorhazard
byexposingpeopleorshrubstohightemperatures.
• Thesafestandpreferredventingmethodistoextendthe
ventverticallythroughtherooforabovetheroof.

March 14, 2014 7080-131B 11
MT VERNON E2
B. Avoiding Smoke and Odors
Negative Pressure, Shut-Down and Electrical Power
Failure
To reduce the probability of back-drafting or burn-back in
the pellet appliance during power failure or shut down con-
ditions, it must be able to draft naturally without exhaust
bloweroperation.
Negativepressureinthehousewillresistthisnaturaldraftif
not accounted for in the pellet appliance installation.
Heatrisesinthehouseandleaksoutatupperlevels.This
airmustbereplacedwithcoldairfromoutdoorswhichows
intolowerlevelsofthehouse.
Ventsandchimneysintobasementsandlowerlevelsofthe
house can become the conduit for air supply and reverse
under these conditions.
Outside Air
Anoutsideairkit(OAK-3)isrecommendedinallinstallations
andmustbeorderedseparately.
Pernationalbuildingcodes,considerationmustbegivento
combustionairsupplytoallcombustionappliances.Failure
tosupplyadequatecombustionairforallappliancedemands
mayleadtobackdraftingofthoseandotherappliances.
Whentheapplianceisroofvented(stronglyrecommended):
Theairintakeisbestlocatedontheexteriorwalloriented
towardstheprevailingwinddirectionduringtheheating
season.
Whentheapplianceisside-wallvented:
Theairintakeisbestlocatedonthesameexteriorwallas
theexhaustventoutletandlocatedloweronthewallthan
theexhaustventoutlet.
The outside air supply kit can supply most of the demands of
thepelletappliance,butconsiderationmustbegiventothe
total house demand.
House demand may consume the air needed for the appli-
ance. Itmaybenecessarytoaddadditionalventilationto
the space in which the pellet appliance is located.
Consult with your local HVAC professional to determine the
ventilationdemandsforyourhouse.
VentCongurations
To reduce probability of reverse drafting during shut-down
conditions Hearth & Home Technologies strongly recom-
mends:
 • Installingthepelletventwithaminimumverticalrunof
5feet(1.52m).Preferablyterminatingabovetheroof
line.
 • Installingtheoutsideairkitatleast4feet(1.22m)below
theventtermination.
Topreventsootdamagetoexteriorwallsofthehouseandto
preventre-entryofsootorashintothehouse:
 • Maintain specied clearances to windows, doors and
air inlets, including air conditioners.
 • Vents should not be placed below ventilated softs.
Runtheventabovetheroof.
 • Avoidventingintoalcovelocations.
 • Ventsshouldnotterminateunderoverhangs,decksor
ontocoveredporches.
 • Maintain minimum clearance of 12 inches (305mm)
from the vent termination to the exterior wall.  If you
seedepositsdevelopingonthewall,youmayneedto
extend this distance to accommodate your installation
conditions.
CAUTION
• DONOTCONNECTTHISUNITTOACHIMNEYFLUE
SERVICINGANOTHERAPPLIANCE.
• DONOTCONNECTTOANYAIRDISTRIBUTIONDUCT
ORSYSTEM.

12 7080-131B March 14, 2014
MT VERNON E2
C. Negative Pressure
Negative pressure results from the imbalance of air avail-
ablefortheappliancetooperateproperly.Itcanbestrongest
inlowerlevelsofthehouse.
Causesinclude:
• Exhaustfans(kitchen,bath,etc.)
• Rangehoods
• Combustionairrequirementsforfurnaces,waterheaters
andothercombustionappliances
• Clothesdryers
• Locationofreturn-airventstofurnaceorairconditioning
• ImbalancesoftheHVACairhandlingsystem
• Upperlevelairleakssuchas:
- Recessed lighting
- Attic hatch
- Duct leaks
Tominimizetheeffectsofnegativeairpressure:
• Installtheoutsideairkitwiththeintakefacingprevailing
winds during the heating season
• Ensureadequateoutdoorairforallcombustionappliances
andexhaustequipment
• Ensurefurnaceandairconditioningreturnventsarenot
locatedintheimmediatevicinityoftheappliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessedlightingshouldbea“sealedcan”design
• Attichatchesweatherstrippedorsealed
• Atticmountedductworkandairhandlerjointsandseams
taped or sealed
D. Draft
Draftisthepressuredifferenceneededtoventanappli-
ance successfully. When an appliance is drafting suc-
cessfully,allcombustionbyproductsareexitingthehome
through the chimney.
Installthroughthewarmairspaceenclosedbythebuild-
ingenvelope.Thishelpstoproducemoredraft,especially
duringlightinganddie-downofthere.
Considerationsforsuccessfuldraftinclude:
• Preventingnegativepressure
• Locationofapplianceandchimney
WARNING
Risk of Asphyxiation!
Negativepressurecancausespillageofcombustion
fumes and soot.
NOTICE: Hearth & Home Technologies assumes no
responsibilityfortheimproperperformanceofthechimney
systemcausedby:
• Inadequatedraftduetoenvironmentalconditions
• Downdrafts
• Tightsealingconstructionofthestructure
• Mechanicalexhaustingdevices
E. Chimney and Exhaust Connection
1. Chimney & Connector:  Use 3 or 4 inch (76-102mm)
diametertype“L”or“PL”ventingsystem.Itcanbevented
verticallyorhorizontally.
2. Mobile Home: ApprovedforallListedpelletvent.Ifusing
the3inch(76mm)verticalTopVentAdapterKitorthe3
to6inch(76-152mm)TopVentOffsetAdapter,useListed
doublewallueconnector.AQuadra-FireOutsideAirKit
(OAK-3)mustbeusedwithmanufacturedhomeinstalla-
tions.
3. Residential: The3inch(76mm)verticalTopVentAdapter
Kitandthe3to6inch(76-152mm)TopVentOffsetAdapter
aretestedtouse24gaugesinglewallueconnectoror
ListeddoublewallueconnectortoClassAListedmetal
chimneys, or masonry chimneys meeting International
Residential Code standards for solid fuel appliances.
4. INSTALL VENT AT CLEARANCES SPECIFIED BY THE
VENT MANUFACTURER.
5. Secureexhaustventingsystemtotheappliancewithat
least3screws.Alsosecureallconnectorpipejointswith
atleast3screwsthrougheachjoint.
6. DONOTINSTALLAFLUEDAMPERINTHEEXHAUST
VENTINGSYSTEMOFTHISUNIT.
7. DONOTCONNECTTHISUNITTOACHIMNEYFLUE
SERVINGANOTHERAPPLIANCE.
NOTE: All pipe must be welded seam pipe whenever
possible. Seal pipe joints with high temperature silicone
(500°F [260°C] minimum rated only).
WARNING
USEONLYRECOMMENDEDVENTINGCOMPONENTS;
OTHERWISEMAKESHIFTPARTSMAYRESULTINPROP-
ERTYDAMAGE,PERSONALINJURY,ORDEATH.

March 14, 2014 7080-131B 13
MT VERNON E2
F. Equivalent Feet of Pipe
Thetablebelowcanhelpyoucalculatetheequivalentfeet
ofpipewhichisamethodusedtodeterminepelletventsize.
Figure 13.1.
2 ft.
2 ft.
3 ft.
2 ft.
Example of 3 Elbow-Rear Vent Termination Calculation
Pellet Venting
Component
# of
Elbows
Feet of
Pipe
Multiplied
By
Equivalent
Feet
Components
Equivalent Feet
90oElboworTee 3X515
45oElbow X3
Horizontal Pipe 7X17
Vertical Pipe 2X0.5 1
TotalEquivalentFeet 23
Note:Thisisagenericexampleandisnot
intendedtorepresentanyspecicfueltype.
VentsurfacesgetHOT,cancauseburnsif
touched.Non-combustibleshieldingorguards
mayberequired.
WARNING
Figure 13.2
3 in. or 4 in. (76mm or 102mm) Diameter Pipe
Equivalent Pipe
Length In Feet
ALTITUDE IN THOUSANDS OF FEET
0
20
30
1 2 3 4 5 6 7 8 9 10
4 in. (102mm) Diameter Pipe Only
10
Example 1
Example 2
Example 1:Iftheequivalentlengthofpipeis23feet(7m)with
altitudeof8,000feet(2438m)youmustuse4inch(102mm)
diametertype“L”or“PL”vent.
Example 2:Iftheequivalentlengthofpipeis12feet(3.7m)
withaltitudeof6,000feet(1829m)youmayuse3or4inch
(76to102mm)diametertype“L”or“PL”vent.
G. Pipe Selection Chart
The chart will help you in determining proper venting size
accordingtotheequivalentfeetofpipecalculatedpreviously
andthealtitudeabovesealevelofthisinstallation.
Figure 13.2
a. Locatethecalculatedequivalentfeetofpipeonthevertical
left side of the chart.
b. Movetotherighthorizontallyonthechartuntilyoureach
youraltitudeabovesealevel.
c. Ifyoufallbelowthediagonalline,3or4inch(76to102mm)
pipemaybeused.
d. Ifitisanywhereabovethediagonalline,a4inch(102mm)
diameterpipeisrequired.
NOTICE:
• A90°elbowis5timesasrestrictivetotheowofexhaust
gasesunderpositivepressureas1foot(305mm)ofhori-
zontal pipe.
• Afootofhorizontalpipeistwiceasrestrictiveasafootof
verticalpipe.
WARNING
RISK OF INJURY OR PROPERTY DAMAGE!
• Improperinstallation,adjustment,alteration,serviceormain-
tenancecancauseinjuryorpropertydamage.
• Refertotheowner’sinformationmanualprovidedwiththis
appliance.
• Forassistanceoradditionalinformationconsultaqualied
installer,serviceagencyoryourdealer.
Risk of Fire!
•OnlyLISTEDventingcomponentsmaybeused.
•NOOTHERventcomponentsmaybeused.
•Substituteordamagedventcomponentsmay
impair safe operation.
WARNING
Figure 13.1

14 7080-131B March 14, 2014
MT VERNON E2
2 in [51mm] min
6 in
[152mm]
Min
6 in
[152mm]
Min
Non-combustible Hearth Pad
Wall
Thimble
Horizontal
Termination
Cap
Straight Out
Figure 14.1
Figure 14.2
Wall
Thimble
Illustration shows venting going in both directions.
Choose which one is best for your installation.
2 in. (51mm)
Minimum
2 in.
(51mm)
Minimum
6 in. (152mm)
Minimum
6 in. (152mm)
Minimum
45 Degree
5 Venting Systems
A. Through The Wall
Horizontalterminationcapmustbeaminimumof6inches.
(152mm)fromthewall.Approvedformobilehomeinstalla-
tions.Mustuse3or4inch(76-102mm)“L”or“PL”Listed
pelletventingorListeddoublewallpipeandaQuadra-Fire
OutsideAirKitinmobilehomes.
NOTE:
In Canada, where passage through a wall or partition
ofcombustibleconstructionisdesired,theinstallation
shallconformtoCAN/CSA-B365

March 14, 2014 7080-131B 15
MT VERNON E2
C. Through The Wall & Vertical - Exterior
Firestop
Flashing
Rain Cap
6 in
[152mm]
Min
Non-combustible Hearth Pad
3 in [76mm] Min
Clean-out Cover
12 in. [305mm] Min
Ceiling Support
3 to 6 in [76 to 152mm]
Offset Adapter
6 in. [152mm] Class A
Chimney Connector
Adapter
3 to 3 in
[76-76mm]
Top Vent Kit
Non-combustible Hearth Pad
Clean-out
Cover
Tee
Wall Thimble
Support
Bracket
every 60 in
[1524mm]
12 in
[305 mm]
Minimum
Rain
Cap
Flashing
2 in [51mm] min
6 in
[152mm]
Min
Figure 15.1
Figure 15.2
D. Vertical - Interior - Typical Installation
Firestop
Non-combustible Hearth Pad
12 in
[305 mm]
Minimum
Rain
Cap
Flashing
3 in [76mm] Min
6 in
[152mm]
Min
3to 3 in
[76 to 76mm]
Top Vent Kit
Clean-out Cover
Figure 15.3
We recommend a minimum of 60 inches
(1524mm) vertical, however above the eave
is preferred.
Allthreeinstallationsareapprovedformobile
homeinstallations. Mustuse3or4inch(76
to102mm)“L”or“PL”Listedpelletventingor
ListeddoublewallpipeandQuadra-FireOutside
AirKit  in mobile homes.  Single wall pipe is
approvedforresidentialinstallationsonly.
*NOTE: Clearance to combustibles are for
standard pellet pipe. If pellet pipe manufacturer
allows reduced clearances to their pipe, reduced
clearances are allowed.
B. Vertical into Existing Class A Chimney
NOTE:
A chimney connector shall not pass through
an attic or roof space, closet or similar
concealed space, or a foor or ceiling.

16 7080-131B March 14, 2014
MT VERNON E2
E. Masonry
F. Alternate Masonry
Concrete Cap
Non-combustible Hearth Pad
6 in
[152mm]
Min
Airtight clean-out door
Sheathing
1 in [25mm] clearnance
2 in [51mm] min to
combustible material
Flashing
Fireclay Flue Liner
with airspace
1 in [25mm] clearance
with firestop
Figure 16.1
Figure 16.2
Concrete Cap
Non-combustible Hearth Pad
6 in
[152mm]
Min
Airtight clean-out door
Sheathing
1 in [25mm] clearnance
Flashing
Fireclay Flue Liner
with airspace
1 in [25mm] clearance
with firestop
3 in [76mm] min to
combustible material
Clean-out cover
Fire Risk.
InspectionofChimney:
• Masonrychimneymustbeingoodcondition.
• MeetsminimumstandardofNFPA211
• Factory-builtchimneymustbeaminimum6inch(152mm)
UL103 HT.
WARNING

March 14, 2014 7080-131B 17
MT VERNON E2
6 Appliance Set-Up
Figure 17.3 - Bolt fully extended
Figure 17.2
Figure 17.1
A. Leg Leveling System
1. ThreadAllenboltsthroughnutsuntilush.Figure 17.1.
The Allenboltsandnutsareincludedinthecomponentpack
inside the appliancerebox.
2.Slideassemblednutsandboltsintoslotsonlegswiththe
nutsonthebottom.Figure 17.2.Usea5/32in.(3.96mm)
Allenwrenchtoadjustlegsupanddowntodesiredlevel.
Figure 17.3.
B. Outside Air Kit Instructions
Included in Kit:2wireties,1collarassembly,
1terminationcapassembly,1trimring,fasteners.
NOTE: 3 INCH ALUMINUM FLEX PIPE NOT INCLUDED.
Tools Needed:Phillipsheadscrewdriver;wirecuttershole
saworjigsaw.
1. Measuredistancefromoortoairventopeninginappli-
ance and mark location on wall.
Use saw to cut opening in wall. Cut a 3-1/2 to 4 inch
(89-102mm)openingoninsidewallanda4to4-1/2inch
(102-114mm)openingonoutsideofhouse.
2. Usewiretietosecureexpipetocollarassembly.
3. Slidetrimringoverexpipeandrunpipethroughwall.
4. Attachexpipe(notsupplied)tooutsideterminationcap
with second wire tie.
5. Secure termination cap to outside surface.
6. Secure trim ring to interior wall.
CAUTION
Neverdrawoutsidecombustionairfrom:
• Wall,oororceilingcavity
• Enclosedspacesuchasanatticorgarage
Figure 17.4 - OAK exploded view
Termination Cap
Wire
Tie
Trim Ring
Wire Tie
Collar
3 inch Aluminum
Flex Pipe
(not included)

18 7080-131B March 14, 2014
MT VERNON E2
3 in. to 6 in.
Offset Adapter
Silicone Rear
Exhaust Outlet
3 in. to 3 in. Top
Vent Adapter
Clean-Out
Cover
Drill Hole, 1
on each side
C. Top Vent Adapter Installation
3 to 3 inch (76-76mm) Top Vent Adapter
3 to 6 inch (76-152mm) Top Vent Offset Adapter
Installing the Top Vent Adapter
1. Put a layer of high temperature silicone on the 3 inch
(76mm)exhaustoutlet. Do not put silicone inside of
pipe. Figure 18.1.
2. Slidethetopventadapterontotherearexhaustoutlet
andadjusttheassemblytoaverticalpositionuntilthe
topoftheueoutletiscenteredandisinalevelposition.
Figure 18.1.
3. Alignslotonleftofadapterwithholeinthebackofthe
unit and secure with screw. You may drill out the hole
using#26drillbitprovidedbutonlyifneeded. Figure
18.2.
4. Install the 5 mounting screws, 3 on the left and 2 on the
right.
5. Drill2holeswith#26drillbitthroughtherearexhaust
outlet using the 2 holes already in the short horizontal
pipeinthetopventadapterasaguide.Installthescrews.
6. Installtheventpipeintothetopventadapter(besure
tosiliconealljoints).Touseanexisting6inch(152mm)
vent system, install the 3 to 6 in (76-152mm) offset
adapterbeforeinstallingventpipe.
7. To clean top vent adapter, open clean-out cover and
removeanydebrisbuild-up.Figure 18.2.
Figure 18.2
Figure 18.1
D. Rear Vent & Rear Vent to Top Vent Adapter
Installation
Clean-Out Cover
Clean-Out Cover
Figure 18.3 - Rear Vent Adapter
Figure 18.4 - Rear to Top Vent Adapter - 90o
1. Put a layer of high temperature silicone on the 3 inch
(76mm)exhaustoutlet. Do not put silicone inside of
pipe. Figure 18.1.
2. Slidetheadapterontotherearexhaustoutletandadjust
theassemblytotheappropriateposition.
3. Installtheventpipeintotheadapter(besuretosilicone
alljoints)

March 14, 2014 7080-131B 19
MT VERNON E2
CAUTION
Logs are FRAGILE. Use extreme care when handling or
cleaning logs.
NOTICE:
Duetotheabrasivenatureofapelletappliancere,thelogs
arenotcoveredunderwarranty. Anyplacement variation
otherthanshownherecancauseexcessiveheatandshall
voidtheappliancewarranty.
Figure 19.1
Log fits over screws
Left Log
Log has indentations on the
bottom to fit over the screw
heads.
Log rests in front of screws
Right Log
Figure 19.3
Figure 19.4
E. Optional Log Set Placement Instructions
2 PIECE LOG SET INSTALLATION
1. Place the left log as shown. There are 2 indentations in
thebottomof the log tot over the screwheads in the
rebox. Figures 19.1 and 19.2.
2. Place the right log in front of the 2 screw heads in the
rebox.Figures 19.3 & 19.4.
Figure 19.2

20 7080-131B March 14, 2014
MT VERNON E2
F. Remote Thermostat Installation
1. Whenmountingthethermostatonthewall,besureto
followyourremotethermostat’sinstallationinstructions
carefully.
NOTE: The remote thermostat should be mounted
on an inside wall and not in direct line with the ap-
pliance convection air.
NOTE: If the remote thermostat is located too close
to the appliance, you may need to set the tempera-
ture setting slightly higher to maintain the desired
temperature in your home.
Photo of Thermostat separated from its docking station
below:
Shock hazard.
• DoNOTremovegroundingprongfromplug.
• Plugdirectlyintoproperlygrounded3prong
receptacle.
• Routecordawayfromappliance.
• DoNOTroutecordunderorinfrontofappliance.
CAUTION
Tools Needed:
Phillipsscrewdriver
Power Drill
1/4”or7/64”drillbit
Tape Measure
Detachtheremotethermostatfromitsdockingstationby
pulling them directly away from each other.
Usingthefastenersand(ifneeded)anchors–included
withtheremotetransmitterpackaging–fastenthedocking
station to the wall.
IMPORTANTNOTES:
Forbestapplianceperformance,positionthedocking
stationat60inchesheightfromtheoor,nofurtherthan20
feet from the appliance, out of direct sunlight, and out of the
directowofconvectionaircomingfromtheapplianceor
structure’sHVACdischargeair.
For instructions on thermostat function and interaction with
theappliancerefertotheowner’smanual.
G. Power Cord
1. Prior to installing the power cord, turn the dial control
“OFF”.
2. Makesurethewallreceptaclehas120vacoutput.
NOTE:Usingacircuitprotectorcanprotecttheappli-
ance circuits from power surges.
3. Theappliancerecepticalislocatedonitslower,back
right hand corner. Install the cord to wall and appliance
reception.
4. Refertoowner’smanualforapplianceoperation.
