Extraflame DUCHESSA IDRO User manual

Stufe a Pellet
Read the instructions carefully before installation, use and maintenance.
The instruction book is an integral part of the product.
PELLET STOVES
User manual
DUCHESSA
IDRO
DUCHESSA
IDRO STEEL

2

3
Congratulations! You are now the owner of an Extraame stove
The Extraame pellet stove is a great heating solution developed from the most advanced technology
with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that
the heat of a ame gives, in complete safety.
This manual will help you to use your stove correctly. It must be read with great attention before use.
IMPORTANT
Make sure that your dealer lls the space in that is dedicated to your authorised specialist. He will help you
with pleasure if you should have problems using your new pellet stove.
AUTHORISED SPECIALIST
COMPANY _________________________________________________________________
Mr. ________________________________________________________________________
STREET NAME _________________________________________ NR. __________________
POST CODE ____________________TOWN/CITY __________ COUNTY _______________
TELEPHONE _________________________ FAX __________________________________
All Extraame products are built in compliance with the following Directives:
89/106 EEC (Construction Products)
89/366 EEC (EMC Directive)
2004/108 CE (EMC Directive)
2006/95 CE (Low Voltage Directive)
and the Standards:
EN 14785
EN 60335-1
EN 60335-2-102
EN 61000-3-2
EN 61000-3-3
EN 50366
EN 55014-1
EN 55014-2

4

5
Index
Chapter 1
WARNINGS AND SAFETY DEVICES.......................................................................................................... 7
Chapter 2
TECHNICAL FEATURES ............................................................................................................................. 8
DIMA DUCHESSA IDRO.........................................................................................................................................................9
DIMA DUCHESSA IDRO STEEL......................................................................................................................................... 10
Chapter 3
WHAT IS THE PELLET?.............................................................................................................................11
PELLET STORAGE.................................................................................................................................................................. 11
PELLET FEEDING ................................................................................................................................................................... 11
Chapter 4
SAFETY DEVICES.....................................................................................................................................12
FLUE EXHAUST BREAKAGE............................................................................................................................................... 12
PELLET FEED MOTOR STOP.............................................................................................................................................. 12
DOOR MICRO SWITCH........................................................................................................................................................ 12
NO IGNITION........................................................................................................................................................................... 12
TEMPORARY POWER CUT ................................................................................................................................................. 12
ELECTRIC SAFETY................................................................................................................................................................. 12
FLUE EXHAUST SAFETY DEVICE ..................................................................................................................................... 12
PELLET TANK TEMPERATURE SAFETY VIA 85°C BULB............................................................................................ 12
WATER OVERHEATING SAFETY VIA 100° C BULB...................................................................................................... 13
MINIMUM AND MAXIMUM PRESSURE PRESSURE SWITCH................................................................................. 13
DEVICES NOT ON THE LIST ............................................................................................................................................... 13
INSTALLATION AND SAFETY DEVICES ......................................................................................................................... 13
SAFETY DEVICES FOR CLOSED VESSEL PLANT......................................................................................................... 13
Chapter 5
ASSEMBLY AND INSTALLATION INSTRUCTIONS.................................................................................16
GLOSSARY ............................................................................................................................................................................... 16
INSTALLATION........................................................................................................................................................................ 17
ALLOWED INSTALLATIONS ........................................................................................................................................ 17
INSTALLATIONS NOT ALLOWED.............................................................................................................................. 17
CONNECTION TO THE SMOKE EVACUATION SYSTEM ........................................................................................... 18
SMOKE CHANNEL OR CONNECTIONS................................................................................................................... 18
CHIMNEY OR INDIVIDUAL FLUE............................................................................................................................... 19
APPLIANCE CONNECTION TO THE FLUE AND FUEL PRODUCTS EVACUATION.................................... 21
CHIMNEY CAP ................................................................................................................................................................. 21
CONNECTION TO EXTERNAL AIR INLETS.................................................................................................................... 22
INSULATION, FINISHINGS, COVERING AND SAFETY RECOMMENDATIONS ................................................. 22
NATIONAL, REGIONAL, PROVINCIAL AND TOWN COUNCIL REGULATIONS................................................. 22
Chapter 6
HYDRAULIC SYSTEM...............................................................................................................................23
TYPE OF SYSTEM................................................................................................................................................................... 23
CLOSED VESSEL SYSTEM FOR AUTOMATIC LOADING APPLIANCES......................................................... 23
GENERALITY..................................................................................................................................................................... 23
SAFETY VALVES............................................................................................................................................................... 24
CLOSED EXPANSION VESSEL..................................................................................................................................... 24

6
COMMISSIONING CHECKS......................................................................................................................................... 25
FEEDING WATER FEATURES ....................................................................................................................................... 25
FILLING THE PLANT....................................................................................................................................................... 25
Chapter 7
PRODUCT FUNCTIONALITY...................................................................................................................26
CONTROL BOARD................................................................................................................................................................. 26
CURRENT DATE AND TIME ADJUSTMENT................................................................................................................... 26
BASIC INSTRUCTIONS......................................................................................................................................................... 27
IGNITION .................................................................................................................................................................................. 27
WATER TEMPERATURE ADJUSTMENT........................................................................................................................... 28
WORK......................................................................................................................................................................................... 28
PUMP FUNCTIONING.......................................................................................................................................................... 29
SWITCHOFF ........................................................................................................................................................................... 29
Chapter 8
THE REMOTE CONTROL..........................................................................................................................30
Chapter 9
ADDITIONAL EXTERNAL ROOM THERMOSTAT ...................................................................................31
INSTALLATION ....................................................................................................................................31
INDICATOR...........................................................................................................................................31
Chapter 10
USER PARAMETERS ................................................................................................................................32
WEEKLY PROGRAMMER ..................................................................................................................................................... 32
PELLET FEED ADJUSTMENT ............................................................................................................................................. 35
Chapter 11
CLEANING................................................................................................................................................37
BRAZIER CLEANING............................................................................................................................................................. 37
DOOR, ASH DRAWER AND BRAZIER GASKETS ......................................................................................................... 38
CONNECTION TO THE FLUE.............................................................................................................................................. 38
Chapter 12
PRODUCT DISPLAY TABLES ................................................................................................................... 39
Chapter 13
WARRANTY..............................................................................................................................................43
Chapter 14
QUALITY CONTRO...................................................................................................................................45

WARNINGS AND SAFETY DEVICES 7
Chapter 1
The stoves produced by our establishment are built
withattentionto the individual componentsinaway
to protect both the user and the installer from any
accidents. It is therefore recommended that after
any intervention on the product, authorised sta
pays particular attention to the electric connections,
especially the stripped parts of the wires.These must
not escape from the terminal board in any situation,
thus preventing possible contact with the live parts
of the wire.
Installation must be carried out by authorised
sta, who must provide the buyer with a
declaration of conformity for the system and will
assume full responsibility for nal installation
and as a consequence the correct functioning of
the installed product. It is necessary to bear in
mind all laws and national, regional, provincial
and town council Standards present in the
country the appliance has been installed.
Extraame S.p.A. cannot be held responsible for
the failure to comply with such precautions.
The instruction manual is an integral part of the
product: make sure that it always accompanies
the appliance, even if transferred to other owners
or user or is transferred to another place. If it is
damaged or lost, request another copy from the
area technician.
This stove must be destined for the use for which
it has been expressly realised. The manufacturer is
exempt from any liability, contractual and extra-
contractual, for injury/damage caused to persons/
animals and objects, due to installation, adjustment
and maintenance errors and improper use.
After the packaging has been removed, check the
integrity and completeness of the contents. If this
does not comply, contact the dealer where the
appliance was purchased.
All electric components that make up the stove must
be replaced with original spare parts exclusively by
an authorised after-sales centre, thus guaranteeing
correct functioning.
The stove must be serviced at least once a year,
programming it in advance with the technical
after-sales service.
N.B.: In case of thermo product or boiler, the
product or system venting is not covered by the
warranty.
For safety reasons, remember that:
The stove must not be used by children or
unassisted disabled persons.
Do not touch the stove when you are barefoot
or when parts of the body are wet or humid.
The safety and adjustment devices must not be
modied without the authorisation or indications
of the manufacturer.
Do not pull, disconnect and twist electric cables
leaving the stove, even if disconnected from the
electric power supply mains.
Do not close or reduce the dimensions of the
airing vents in the place of installation.
The airing vents are indispensable for correct
combustion.
Do not leave the packaging elements within
reach of children or unassisted disabled persons.
The hearth door must always be closed during
normal functioning of the product.
Avoid direct contact with parts of the appliance
that tend to heat up during functioning.
Check for the presence of any obstructions
before switching the appliance on following a
prolonged standstill period.
The stove has been designed to function in
any climatic condition (also critical). In particularly
adverse conditions (strong wind, freezing) safety
systems may intervene that switch the stove o.
If this occurs, contact the technical after-sales
service and always disable the safety system.
If the ue should catch re, be equipped with
suitable systems for suocating the ames or
request help from the re service.
WARNINGS AND SAFETY DEVICES

TECHNICAL FEATURES
8
Chapter 2
TECHNICAL FEATURES
Features U.M. Duchesssa
Idro
Duchessa Idro
Steel
Weight kg 170 158
Height mm 1034 1034
Width mm 538 538
Depth mm 543 543
Flue exhaust pipe diameter mm 80 80
Air intake pipe diameter mm 50 50
Max. global heat output kW 13.1 13.1
Max. useful heat output kW 12.0 12.0
- useful output power to the air kW 1.2*1.2*
- useful output power to the water kW 10.8 10.8
Minimum global heat output kW 3.9 3.9
Min. useful heat output kW 3.6 3.6
- useful output power to the air kW 0.6*0.6*
- useful output power to the water kW 3.0 3.0
Max. hourly fuel consumption kg/h 2.8 2.8
Min. hourly fuel consumption kg/h 0.8 0.8
Feed-box capacity kg ~ 20 ~ 20
Recommended ue draught Pa ~ 10 ~ 10
Nominal electric output W 300 300
Nominal voltage Vac 230 230
Nominal frequency Hz 50 50
Water inlet/outlet pipe diameter “ 3/4 3/4
Automatic exhaust pipe diameter “ 1/2 1/2
Pump head m 5 5
Max. working water pressure accepted bar 2.5 2.5
Tests performed using wooden pellets as fuel, certied according to ONORM M7135 DIN PLUS.
*The product has no tangential blowing hot air into the environment therefore the relative data only refers to
natural convection.
The data given above is indicative and not binding. The manufacturer reserves the right to make any
modications in order to improve product performance.

168
545
1034
B
54
868
88
538
A
C
203
63
47
59
G
52
D
118
E
31
34
TECHNICAL FEATURES 9
Chapter 2
DIMA DUCHESSA IDRO
A = AIR INTAKE PIPE Ø 50 mm
B = FLUE GAS EXHAUST PIPE Ø 80 mm
C = BOILER 3/4“ FLOW/OUTLET
D = BOILER 3/4“ RETURN/INLET
E = 3 BAR 1/2“ SAFETY DRAIN
G = BOILER 3/4“ OUTLET AIR

E
88
31
54
1034
A
545
34
47
D
868
G
118
63
B
538
168
52
59
203
C
TECHNICAL FEATURES
10
Chapter 2
DIMA DUCHESSA IDRO STEEL
A = AIR INTAKE PIPE Ø 50 mm
B = FLUE GAS EXHAUST PIPE Ø 80 mm
C = BOILER 3/4“ FLOW/OUTLET
D = BOILER 3/4“ RETURN/INLET
E = 3 BAR 1/2“ SAFETY DRAIN
G = BOILER 3/4“ OUTLET AIR

WHAT IS THE PELLET? 11
Chapter 3
WHAT IS THE PELLET?
Pellets are realised by subjecting wood shavings i.e. the rejects of pure wood (without paint) sawmill,
carpenter products and products from other activities connected to working and transforming wood, to
very high pressures.
This type of fuel is absolutely ecological as no glues are used to hold it together. In fact, the compactness
of the pellets is guaranteed through time by a natural substance that is found in wood: lignin.
As well as being an ecological fuel, as wood residues are made the most of, the pellet also has technical
advantages.
Pellet density is about 650 kg/m3 and water content is equal to 8% of its weight. For this reason the pellet
does not have to be seasoned in order to obtain a suciently adequate heat yield.
The pellet used must comply with the features described by the Standard:
Ö-Norm M 7135
DIN plus 51731
UNI CEN/TS 14961
Extraame recommends the use of pellets with a diameter of 6 mm with its products.
ATTENTION!
THE USE OF EXPIRED PELLETS OR ANY OTHER MATERIAL DAMAGES THE FUNCTIONS OF
YOURSTOVEAND CANDETERMINETHEINVALIDITYOFTHEWARRANTYANDTHEANNEXED
RESPONSIBILITY OF THE MANUFACTURER.
PELLET STORAGE
To guarantee combustion without problems, the pellets must be kept in a dry place.
PELLET FEEDING
To feed the pellet, open the tank lid located on the upper part of the stove, and empty the bag of pellets
being careful they do not fall out.
gure 3.1

SAFETY DEVICES
12
Chapter 4
SAFETY DEVICES
FLUE EXHAUST BREAKAGE
If the suction device stops, the electronic board immediately blocks the pellet supply.
PELLET FEED MOTOR STOP
If the motor reducer stops for any reason, the stove goes into alarm mode and the fumes motor continues
to function in order to expel all combustion gas until the minimum cooling level is reached.
DOOR MICRO SWITCH
When the stove door is opened, a safety micro switch blocks fuel feeding.
NO IGNITION
If a ame is not developed during the ignition phase, the appliance will go into no ignition alarm mode,
displaying “NO ACC”.
TEMPORARY POWER CUT
If the power cut is less than 10 seconds, normal stove functioning will continue when the current returns.
If the power cut is longer than 10 seconds, the stove“black out”alarm will occur when the current returns,
taking the product to complete cooling. When cooling has ended it will re-start in automatic mode.
ELECTRIC SAFETY
The stove is protected against strong current changes by a master fuse that is found in the rear part of the
stove. (2.5A 250V Delayed).
FLUE EXHAUST SAFETY DEVICE
An electronic pressure switch blocks stove functioning and takes it to alarm conditions.
PELLET TANK TEMPERATURE SAFETY VIA 85°C BULB
If there is overheating inside the feed-box this device blocks pellet feed motor functioning; restoration is
manual and must be performed by an authorised technician.
The restoration of 85°C safety device is not under warranty unless the after-sales centre can show
the presence of a faulty component.

SAFETY DEVICES 13
Chapter 4
WATER OVERHEATING SAFETY VIA 100° C BULB
When the temperature of the water inside the product is in proximity of 100°C, pellet feeding is blocked. If the
bulb trips, restoration of the safety device is manual and must be performed by an authorised technician.
The restoration of 100°C safety device is not under warranty unless the after-sales centre can show
the presence of a faulty component.
MINIMUM AND MAXIMUM PRESSURE PRESSURE SWITCH
A minimum and maximum pressure pressure switch is installed in series with the pellet motor electric
energy power supply. If the pressure in the system is below 0.6 bar, the electric energy power supply is
blocked to the pellet feed motor. If the pressure in the system exceeds 2.5 bar, manual rearm of the pressure
switch is triggered: restoration of the safety device is manual and must be performed by an authorised
technician.
Attention:anypresenceof air inthe systemcouldcause the minimumormaximum pressurepressure
switch to also intervene. If the minimum pressure pressure switch intervenes blocking pellet feed into
the machine, alarms may occur connected to the lack of fuel.
Attention
For regular functioning of the product the ideal system pressure must be calibrated at approx.
1.1 bar with cold system. Moreover, there must be no air in the system.
Extraame recommends suitable air vent circuit in the system. Any air venting operations
from the system or the product is not covered by the warranty.
DEVICES NOT ON THE LIST
During installation of the stove it is MANDATORY to adjust the system with a manometer in order to display
the water pressure.
INSTALLATION AND SAFETY DEVICES
The installation, relative plant connections, commissioning and inspection of correct functioning must
be carried out perfectly, in total compliance with Standards in force, both national and regional, as well as
these instructions.
For Italy, installation must be carried out by professionally authorised sta (Ministerial Decree dated
22.01.2008 n°37).
Extraame S.p.A. declines all responsibility for damages to objects and/or persons caused by the plant.
SAFETY DEVICES FOR CLOSED VESSEL PLANT
According to the UNI 10412-2 (2006) Standard in force in Italy, the closed plants must have:
Safety valve
Pump control thermostat
Acoustic alarm activation thermostat
Temperature indicator
Pressure indicator
Acoustic alarm

SAFETY DEVICES
14
Chapter 4
Adjustment automatic circuit breaker switch
Automatic circuit breaker switch (block thermostat)
Circulation system
Expansion system*
Safety dissipation system incorporated with the generator with thermal safety valve (self-activated),
whenever the appliance does not have a temperature self-adjustment system.
The temperature safety sensors must be in place on the machine at a distance no greater than 30 cm from
the ow connection.
Whenever the generators lack a device, those missing can be installed on the thermo product ow pipe,
within a distance no greater than 1m from the machine.
The domestic heating appliances with automatic feeding must:
be equipped with a fuel block thermostat, or
be equipped with a cooling circuit prepared by the manufacturer of the appliance.
Thecoolingcircuitmust be activatedbya heat safety valvesuchtoguaranteethat the limit temperature
set by the Standard is not exceeded.
Connection between the power supply unit and the valve must be free from interceptions.
The pressure upstream from the cooling circuit must be at least 1.5 bar.
6 Litre expansion vessel
3 Bar safety valve Pressure switch
*The product expansion vessel is equal to 6 litres.The
closedsystemexpansionvesselmustbedimensioned
between 4% and 6% of the total volume of the plant
therefore, the standard closed vessel may not be
sucient in cases of greater water volumes.

SAFETY DEVICES 15
Chapter 4
Door micro switch
Rearm of the tank bulb 85°C Rearm water bulb 100°C

ASSEMBLY AND INSTALLATION INSTRUCTIONS
16
Chapter 5
ASSEMBLY AND INSTALLATION INSTRUCTIONS
The installation must be in compliance with:
UNI 10683 (2005) heat generators fed with wood and other solid fuels: installation.
The chimneys have to be in compliance with:
UNI 9731 (1990) chimneys: classication based on thermal resistance.
EN 13384-1 (2006) chimneys thermal and uid-dynamics calculation method.
UNI 7129 point 4.3.3 Fire Department dispositions, local rules and prescriptions.
UNI 1443 (2005) chimneys: general requisites.
UNI 1457 (2004) chimneys: terracotta and ceramic inside pipes.
GLOSSARY
CLOSED HEARTH APPLIANCE
Heat generator which opening is only allowed through the loading of the fuel during use.
BIOMASS
Biological material, excluding the material incorporated in geological formation and transformed in fossil.
BIOFUEL
Fuel produced directly or indirectly by biomass.
CHIMNEY
Vertical pipe with the aim to collect and expel, at a convenient height from the ground, the fuel products
coming from only one appliance.
SMOKE CHANNEL OR CONNECTION
Pipe or connecting element between heat generator appliance and chimney to evacuate fuel products.
INSULATION
Together of devices and materials used to prevent the transmission of heat through a wall which separates
rooms with dierent temperature.
CHIMNEY CAP
Device positioned at chimney peak to ease the dispersion of fuel products in the atmosphere.
CONDENSATION
Liquid products which form when the fuel gas temperature is lower or equal to the water dew point.
HEAT GENERATORS
Appliance which allows to produce thermal energy (heat) through the rapid transformation, through
combustion, of the chemical energy of the same fuel.
GATE VALVE
Mechanism to amend the fuel gas dynamic resistance.

ASSEMBLY AND INSTALLATION INSTRUCTIONS 17
Chapter 5
SMOKE EVACUATION SYSTEMS
Flue gas exhaust system independent from the appliance constituted by a tting or smoke channel,
chimney or individual ue and chimney cap.
FORCED DRAUGHT
Air circulation by means of the fan activated by electric motor.
NATURAL DRAUGHT
Draught which determinates in a chimney/ue for eect of the volume mass dierence existing between
smoke (hot) and surrounding atmosphere air, without any mechanical intake aid installed inside it or at its
peak.
RADIATION AREA
Area immediately near the furnace in which the heat caused by combustion is diused, where there must
be no fuelling materials.
REFLUX AREA
Area where leaking of the fuel products is veried, from the appliance towards the installation room.
INSTALLATION
The installation must be preceded by checking the chimneys, ues or unload terminals positioning of
appliances similarly to:
No installation
Legal distances
Limitations disposed by local administrative regulations or particular authority prescriptions.
Conventional limitations deriving from apartment building, constraints or contracts.
ALLOWED INSTALLATIONS
Only appliances working softly respect to the room or which do not place the room in depression respect to
the external environment, can exist or be installed in the room where the heat generator will be installed.
Only in rooms for kitchen use are appliances for cooking food and relative hoods without extractor.
INSTALLATIONS NOT ALLOWED
In the room where the heat generator will be installed the following must not pre-exist or be installed:
hoods with or without extractor
collective type ventilation pipes.
Shouldthese appliances be inroomsadjacent,communicatingwiththe installation room,the simultaneous
useof the heatgeneratoris forbidden,wherea risk existsof one of thetwo rooms being placed in depression
respect to the other.

45°
<45°
<
ASSEMBLY AND INSTALLATION INSTRUCTIONS
18
Chapter 5
CONNECTION TO THE SMOKE EVACUATION SYSTEM
SMOKE CHANNEL OR CONNECTIONS
To mount the smoke channels, non-ammable elements will have to be used, ideal for resisting fuel
products and their eventual condensing.
The use of exible metal and asbestos cement pipes to connect the appliances to the ue is forbidden,
even for pre-existing smoke channels.
There must be continuity between the smoke channel and the ue so that the ue does not lean on the
generator. The smoke channels must not cross rooms where the installation of the combustion appliances
is not allowed.
The mounting of the smoke channels must be carried out in order to guarantee smoke seal for the
appliance functioning conditions, limit the forming of condensate and avoid it being transported towards
the appliance.
The mounting of horizontal routes must be avoided.
For appliances where ceiling or wall non coaxial discharges respect to the appliance smoke outlet have to
be reached, the direction changes will have to realised using open elbows not higher than 45° (see gures
below).
Insulating
product
Flue
Inspection
For the heat generator appliances equipped with electric fan for expelling fumes, the instructions below
must be followed:
The horizontal routes will have to have a minimum upward slope of 3%
The length of the horizontal route must be minimal and, however, not higher than 3 meters
The number of direction changes including the one for eect of using the “T” element must not be
more than 4 (if 4 bends are used, use double wall piping with an internal diameter of 120 mm).
In any case, the smoke channels must seal the fuel and condensing products and be insulated if they pass
externally to the installation room.
The use of counterslope elements is forbidden.
The smoke channel must allow the recovery of soot or be brushed.
The smoke channel must be at constant section. Any section changes are only allowed at the ue
coupling.
gure 5.2 gure 5.3

BC
20 cm
A
ASSEMBLY AND INSTALLATION INSTRUCTIONS 19
Chapter 5
It is forbidden to have other air supply channels and pipes for plant engineering, especially if over-sized,
transit inside the smoke channels.The mounting of manual draught adjustment devices on forced draught
appliances is forbidden.
CHIMNEY OR INDIVIDUAL FLUE
The chimney or individual ue must respond to the following requisites:
seal the fuel products, waterproof and adequately insulated similarly to the use conditions;
be realised with materials which resist the normal mechanical stresses, heat, action of the fuel products
and any condensing;
have mainly vertical progress with deviations from the axis not higher than 45°;
be adequately distanced from fuel or ammable materials through air space or opportune
insulation;
Minimum
80 cm2
Floor-protection
REFERENCES InflammableAbbildung 5.1
objects
Non-inammable
objects
A 200 mm 100 mm
B 1500 mm 750 mm
C 200 mm 100 mm
have preferably circular internal section: the square or rectangular sections must have round corners
with a radius not lower than 20 mm;
have constant internal section, free and independent;
have rectangular section with max. ratio between the sides of 1.5.
It is recommended that the smoke pipe be equipped with a collection chamber for solid materials and any
condensing situated under the smoke channel inlet, so that it can be easily opened and inspected from
airtight door.
gure 5.4 gure 5.5

< 3 m
3 - 5 %
< 3 m
45°
45°
ASSEMBLY AND INSTALLATION INSTRUCTIONS
20
Chapter 5
Inspection
Chimney cap
wind-proof
Flue
Inspection
External
pipe
insulated
Inspection
Inspection
gure 5.6 gure 5.7
gure 5.8 gure 5.9
